Smeg LBS86F User manual

Washing Machine
Lavatrice
LBS86F

2 - EN
1 Warnings
General Safety
• Neverplaceyourmachineonacarpet
coveredfloor.Otherwise,lackofairflowfrom
belowofyourmachinemaycauseelectrical
partstooverheat.Thismaycauseproblems
withyourwashingmachine.
• Ifthepowercableormainsplugisdamaged
youmustcallAuthorizedServiceforrepair.
• Fitthedrainhoseintothedischargehousing
securelytopreventanywaterleakageand
toallowmachinetotakeinanddischarge
waterasrequired.Itisveryimportantthatthe
waterintakeanddrainhosesarenotfolded,
squeezed,orbrokenwhentheappliance
ispushedintoplaceafteritisinstalledor
cleaned.
• Yourwashingmachineisdesignedto
continueoperatingwhenthepowerrestores
afterapowerinterruption.Themachinewill
resumeitsprogramwhenthepowerrestores.
Pressthe“Start/Pause/Cancel”buttonfor
3secondstocanceltheprogram(See,
CancelingaProgram)
• Theremaybesomewaterinyourmachine
whenyoureceiveit.Thisisfromthequality
controlprocessandisnormal.Itisnot
harmfultoyourmachine.
• Someproblemsyoumayencountermaybe
causedbytheinfrastructure.Press“Start/
Pause/Cancel”buttonfor3secondsto
canceltheprogramsetinyourmachine
beforecallingtheauthorizedservice.
First Use
• Carryoutyourfirstwashingprocesswithout
loadingyourmachineandwithdetergent
under“Cottons90°C”program.
• Ensurethatthecoldandhotwater
connectionsaremadecorrectlywhen
installingyourmachine.
• Ifthecurrentfuseorcircuitbreakerisless
than16Amperes,pleasehaveaqualified
electricianinstalla16Amperefuseorcircuit
breaker.
• Whileusingwithorwithoutatransformer,do
notneglecttohavethegroundinginstallation
laidbyaqualifiedelectrician.Ourcompany
shallnotbeliableforanydamagesthatmay
arisewhenthemachineisusedonaline
withoutgrounding.
• Keepthepackagingmaterialsoutofreach
ofchildrenordisposethembyclassifying
accordingtowastedirectives.
Intended use
• Thisproducthasbeendesignedforhome
use.
• Theappliancemayonlybeusedforwashing
andrinsingoftextilesthataremarked
accordingly.
Safety instructions
• Thisappliancemustbeconnectedtoan
earthedoutletprotectedbyafuseofsuitable
capacity.
• Thesupplyanddraininghosesmustalways
besecurelyfastenedandremaininan
undamagedstate.
• Fitthedraininghosetoawashbasinor
bathtubsecurelybeforestartingupyour
machine.Theremaybeariskofbeing
scaldedduetohighwashingtemperatures!
• Neveropentheloadingdoororremovethe
filterwhilethereisstillwaterinthedrum.
• Unplugthemachinewhenitisnotinuse.
• Neverwashdowntheappliancewithawater
hose!Thereistheriskofelectricshock!
• Nevertouchtheplugwithwethands.Do
notoperatethemachineifthepowercordor
plugisdamaged.
• Formalfunctionsthatcannotbesolvedby
informationintheoperatingmanual:
• Turnoffthemachine,unplugit,turnoff
thewatertapandcontactanauthorized
serviceagent.Youmayrefertoyourlocal
agentorsolidwastecollectioncenterinyour
municipalitytolearnhowtodisposeofyour
machine.
If there are children in your house...
• Keepchildrenawayfromthemachinewhenit
isoperating.Donotletthemtamperwiththe
machine.
• Closetheloadingdoorwhenyouleavethe
areawherethemachineislocated.

3 - EN
2 Installation
Removing packaging reinforcement
Tiltthemachinetoremovethepackaging
reinforcement.Removethepackaging
reinforcementbypullingtheribbon.
Opening the transportation locks
A
Transportationsafetyboltsmustberemoved
beforeoperatingthewashingmachine!
Otherwise,themachinewillbedamaged!
1. Loosenalltheboltswithaspanneruntilthey
rotatefreely(“C”)
2. Removetransportationsafetyboltsbyturning
themgently.
3. Fitthecovers(suppliedinthebagwiththe
OperationManual)intotheholesontherear
panel.(“P”)
 
C
Keepthetransportationsafetyboltsinasafe
placetoreusewhenthewashingmachine
needstobemovedagaininthefuture.
C
Nevermovetheappliancewithoutthe
transportationsafetyboltsproperlyfixedin
place!
Adjusting the feet
A
Donotuseanytoolstoloosenthelocknuts.
Otherwise,theycanbedamaged.
1. Manually(byhand)loosenthelocknutson
thefeet.
2. Adjustthemuntilthemachinestandslevel
andfirmly.
3. Important:Tightenalllocknutsupagain.
Connecting to the water supply.
Important:
• Thewatersupplypressurerequiredtorunthe
machinemustbe1-10bar(0,1–1MPa).
• Connectthespecialhosessuppliedwiththe
machinetothewaterintakevalvesonthe
machine.
• Ifyouaregoingtouseyourdoublewater-inlet
machineasasingle(cold)water-inletunit,
youmustinstallthestopper*,suppliedwith
yourmachinetothehotwatervalve.
• Ifyouwanttousebothwaterinletsofthe
product,youcanconnectthehotwaterhose
afterremovingthestopperandgasketgroup
fromthehotwatervalve.
*Appliesfortheproductssuppliedwithablind
stoppergroup.
• Modelswithasinglewaterinletshouldnotbe
connectedtothehotwatertap.
Whenreturningtheappliancetoitsplaceafter
maintenanceorcleaning,careshouldbetaken
nottofold,squeezeorblockthehoses.
Connecting to the drain
Thewaterdischargehosecanbeattachedtothe
edgeofawashbasinorbathtub.Thedrainhose
shouldbefirmlyfittedintothedrainastonotget
outofitshousing.
Important:
• Theendofthedrainhosemustbedirectly
connectedtothewastewaterdrainortothe
washbasin.
• Thehoseshouldbeattachedtoaheightofat
least40cm,and100cmatmost.
• Incasethehoseiselevatedafterlayingit
onthefloorlevelorclosetotheground
(lessthan40cmabovetheground),water
dischargebecomesmoredifficultandthe
laundrymaycomeoutwet.
• Thehoseshouldbepushedintothedrainage
formorethan15cm.Ifitistoolongyoumay
haveitshortened.
• Themaximumlengthofthecombinedhoses
mustnotbelongerthan3.2m.
Electrical connection
Connectthemachinetoanearthedoutlet
protectedbyafuseofsuitablecapacity.
Important:
• Connectionshouldcomplywithnational
regulations.
• Thevoltageandtheallowedfuseprotection
arespecifiedinthesection“Technical
Specifications”.
• Thespecifiedvoltagemustbeequaltoyour
mainsvoltage.
• Connectionviaextensioncordsormulti-plugs
shouldnotbemade.

4 - EN
B
Adamagedpowercablemustbereplaced
byaqualifiedelectrician.
B
Theappliancemustnotbeoperatedunlessit
isrepaired!Thereistheriskofelectricshock!
3 Initial preparations for
washing
Preparing clothes for washing
Laundryitemswithmetalattachmentssuchas,
bras,beltbucklesandmetalbuttonswilldamage
themachine.Removemetalattachmentsor
placetheitemsinaclothingbag,pillowcase,or
somethingsimilar.
• Sortthelaundryaccordingtotypeoffabric,
color,anddegreeofsoilingandpermissible
watertemperature.Alwaysfollowtheadvice
onthegarmentlabels.
• Placesmallitemslikeinfants’socksand
nylonstockings,etc.inalaundrybag,pillow
caseorsomethingsimilar.Thiswillalsosave
yourlaundryfromgettinglost.
• Wash“machinewashable”or“hand
washable”labeledproductsonlywithan
appropriateprogram.
• Donotwashcolorsandwhitestogether.
New,darkcoloredcottonsmayreleasealot
ofdye.Washthemseparately.
• Useonlydyes/colorchangersandlime
removerssuitableformachinewash.Always
followtheinstructionsonthepackaging.
• Washtrousersanddelicateclothesturned
insideout.
Correct load capacity
C
Pleasefollowtheinformationinthe"Program
SelectionTable".Washingresultswilldegrade
whenthemachineisoverloaded.
Loading door
Thedoorlocksduringprogramoperationandthe
DoorLockedSymbollightsup.Thedoorcanbe
openedwhenthesymbolfadesout.
Detergents and softeners
Detergent Drawer
Thedetergentdraweriscomposedofthree
compartments:
Thedetergentdispensermaybeintwodifferent
typesaccordingtothemodelofyourmachine.
–(I)forprewash
–(II)formainwash
-(III)siphon
–( )forsoftener
Detergent, softener and other cleaning agents
Adddetergentandsoftenerbeforestartingthe
washingprogram.
Neveropenthedetergentdispenserdrawerwhile
thewashingprogramisrunning!
Whenusingaprogramwithoutpre-wash,no
detergentshouldbeputintothepre-wash
compartment(Compartmentno.I).
Detergent quantity
Theamountofwashingdetergenttobeused
dependsontheamountoflaundry,thedegreeof
soilingandwaterhardness.
• Donotuseamountsexceedingthequantities
recommendedonthepackagetoavoid
problemsofexcessivefoam,poorrinsing,
financialsavingsandfinally,environmental
protection.
• Neverexceedthe(>max<)levelmarking;
otherwise,thesoftenerwillbewastedwithout
beingused.
• Donotuseliquiddetergentifyouwantto
washusingthetimedelayfeature.

5 - EN
Turning the machine on
Youcanpreparethemachineforprogram
selectionbypressingthe“On/Off”button.When
the“On/Off”buttonispressed,the“Ready”light
illuminatesindicatingthatthedoorisulocked.
Pressthe“On/Off”buttonagaintoshutdownthe
machine.
Program selection
Selecttheappropriateprogramfromtheprogram
tableandthefollowingwashingtemperature
tableaccordingtotype,amountanddegreeof
soilingofthelaundry.Selectthedesiredprogram
withtheprogramselectionbutton.
C
Eachoftheseprogramsconsistofa
completewashingprocess,includingwash,
rinseand,ifrequired,spincycles.
90˚C Normallysoiled,whitecottonsand
linens.
60˚C
Normallysoiled,fadeproof
coloredlinens,cottonsor
syntheticclothesandlightlysoiled
whitelinens
40˚C
30°C
Cold
Blendedclothesincluding
syntheticsandwoolensaswellas
delicates.
C
Programsarelimitedwiththehighestspin
speedappropriateforthatparticulartypeof
cloth.
Main programs
Dependingonthetypeoftextile,thefollowing
mainprogramsareavailable:
• Cotone (Cottons)
Youcanwashyourdurableclotheswiththis
program.Yourlaundrywillbewashedwith
vigorouswashingmovementsduringalonger
washingcycle.
• Sintetici (Synthetics)
Youcanwashyourlessdurableclothesonthis
4 Selecting a program and operating your machine
1- SpinSpeedAdjustmentKnob*
2- TimeDelayButton*
3- TemperatureAdjustmentKnob*
4- Start/Pause/CancelButton
5- AuxiliaryFunctionKeys
6- ProgramSelectionKnob
7- On/OffButton
8- ProgramFollow-upIndicators*
9- Child-proofLockIndicator*
*Accordingtoyourmachine’smodel
Control panel
26 71 5
48
36257
84

6 - EN
program.Gentlerwashingmovementsanda
shorterwashingcycleisusedcomparedto
the“Cottons”program.Itisrecommendedfor
yoursyntheticclothes(suchasshirts,blouses,
synthetic/cottonblendedgarments,etc.).For
curtainsandlace,the“Synthetic40”program
withpre-washandanti-creasingfunctions
selectedisrecommended.
• Lana (Woollens)
Youcanwashyourmachine-washablewoolen
garmentsonthisprogram.Washbyselecting
thepropertemperatureaccordingtothelabels
ofyourclothes.Itisrecommendedtouse
appropriatedetergentsforwoolens.
Additional programs
Forspecialcases,therearealsoextraprograms
available:
C
Additionalprogramsmaydifferaccordingto
themodelofyourmachine.
• Anti-Allergico 65
Increasedhygieneisprovidedbyalonger
heatingperiodandanadditionalrinsecycle.Itis
recommendedforbabyclothesandclothesworn
byallergicpeople.
• Delicati (Delicate)
Youcanwashyourdelicateclothesonthis
program.Ithasmoresensitivewashing
movementsanddoesnotmakeintermediate
spinningcomparedto“Synthetic”program.
• Lavaggio a Mano (Hand wash)
Youcanwashyourwoolen/delicateclothesthat
bear“notmachine-washable”labelsforwhich
handwashisrecommendedonthisprogram.
Itwashesthelaundrywithverytenderwashing
movementswithoutdamagingyourclothes.
• Refresh 30
Thisprogramisusedtoquicklywash(30
minutes)asmallamountoflightlysoiledcotton
garments.
• Sport 40
Youcanusethisprogramtowashcottonsand
syntheticstogetherwithoutneedingtosortthem.
• Intensivo
Youcanwashyourdurableandheavilysoiled
clothesonthisprogram.Thisprogramwashes
foralongertimeandanextrarinsecyclewillbe
madecomparedtothe“Cottons”program.You
canuseitforyourheavilysoiledclothesthatyou
wishtoberinsedgently.
Special programs
Forspecificapplications,youcanselectanyof
thefollowingprograms:
• Risciacquo (Rinse)
Thisprogramisusedwhenyouwanttorinseor
starchseparately.
• Centrifuga (Pump)
Thisprogramspinswithmaximumpossiblerpm
inthedefaultsetting.
C
Youshouldusealowerspinspeedfor
delicatelaundries.
• Scarico (Spin)
Thisprogramisusedtodischargethewaterof
theclothessoakedintowaterinthemachine.
Spin Speed selection
Youcanhaveyourclothesspunatthemaximum
rpmselectiononyourmachinebyusingthe
selectionknobinmodelsequippedwithanrpm
selectionknob.Inordertoprotectyourclothes,
yourmachinewillnotspinabove800rpmon
syntheticprogramsand600rpmonwoolens
program.Furthermore,ifyouwanttoskipthe
spincycleandtakeyourclothesout,turnthe
rpmselectionknobto“nospin”position.
Inmachinesnotequippedwithaspinspeed
selectionknob,themachinewillspininthe
maximumpossiblerpminthedefaultsettingof
theselectedprogram.

7 - EN
Program selection and consumption table
•:Selectable
*:Automaticallyselected,notcancellable.
**:EnergyLabelprogramme(EN60456)
Waterandpowerconsumptionandprogrammedurationmaydifferfromthetableshown,subjectto
changesinwaterpressure,waterhardnessandtemperature,ambienttemperature,typeandamount
oflaundry,selectionofauxiliaryfunctions,andfluctuationsinthesupplyvoltage.
C
Theauxiliaryfunctionsinthetablemaydifferaccordingtothemodelofyourmachine.
EN 2
Programme
Max.Load(kg) ProgrammeDuration(~min) WaterConsumption(l) EnergyConsumption(kWh) Prelavaggio QuickWash RisciacquoAggiuntivo Anti-Creasing RinseHold Spinspeedreduction EsclusioneCentrifuga
Cotone 90 6 130 54 1.7 • • • • • • •
Cotone 60** 6 140 49 1.02 • • • • • • •
Cotone 40 6 125 49 0.65 • • • • • • •
Intensivo 60 6 160 85 1.35 • • • •
Anti-Allergico65 65 6 170 65 1.18 * • • •
Sintetici 60 3110 55 0.85 • • • • • • •
Sintetici 40 390 55 0.5 • • • • • • •
Sport40 40 3.5 95 50 0.44 • • • • • • •
Delicati 40 270 57 0.39 • • • • •
Lana 40 1.5 55 50 0.26 • • • •
LavaggioaMano 30 1 40 35 0.15 • •
Refresh30 30 2.5 30 49 0.16 • •

8 - EN
Auxiliary functions
Auxiliary function selection keys
Selecttherequiredauxiliaryfunctionsbefore
startingtheprogram.
C
Auxiliaryfunctionbuttonsmaydiffer
accordingtothemodelofyourmachine.
Auxiliary function selection
Ifanauxiliaryfunctionthatshouldnotbeselected
togetherwithapreviouslyselectedfunction
ischosen,thefirstselectedfunctionwillbe
cancelledandthelastauxiliaryfunctionselection
willremainactive.
Auxiliaryfunctionthatisnotcompatiblewiththe
programcannotbeselected.(see“Program
SelectionTable”)
• Prelavaggio (Prewash)
Apre-washisonlyworthwhileforheavilysoiled
laundry.Withoutpre-washyousaveenergy,
water,detergentandtime.Pre-washwithout
detergentisrecommendedforlaceandcurtains.
• Quick Wash
Thisfunctioncanbeusedforcottonsand
syntheticsprograms.Itdecreasesthewashing
timesforlightlysoiledlaundriesandalsothe
numberofrinsingsteps.Shortenstheprogram
timeapproximately45minutes.
• Risciacquo Aggiuntivo (Rinse Plus)
Withthisfunction,youcanincreasethenumber
ofcurrentrinsingsteps.Thus,sensitiveskins’
riskofbeingaffectedbytheremainderdetergent
ontheclotheswillbedecreased.
• Anti-Creasing
Thisfunctionreducesdrummovementand
limitsthespinningspeedtopreventcreasing.In
addition,washingiscarriedoutatahigherwater
level.
C
Usethisfunctionfordelicatelaundriesthat
creaseeasily.
C
Wheneveryouselectthisauxiliaryfunction,
loadyourmachinewithhalfofthemaximum
laundryspecifiedintheprogramtable.
• Rinse Hold
Ifyoudonotwanttounloadyourclothes
immediatelyafterthecotton,synthetics,woolen
anddelicatefabricsprogram,youmayrelease
yourclothesinsidethemachineinthelastrinsing
waterbypressingtherinseholdbuttoninorder
topreventyourclothesbecomewrinkled.You
canspinbypressing“Start/Pause/Cancel”
buttonafterthisprocess.
• Esclusione Centrifuga (No Spin)
Youmayusethisprogramifyoudonotwant
tospinyourclothesattheendofcottons,
synthetics,woolenordelicateprograms.
• Spin speed reduction
Youmayusethespeedreductionbutton
wheneveryouwishtospinyourclothesbelow
themaximumspinspeed.Whenspeedreduction
buttonispressed,spinspeedwillbeatthe
minimumrpmgivenonthepanel.
Time delay
Ifyouwishtowashyourclothesatalatertime
inmachinesequippedwithatimedelaybutton,
thetimedelayfunctionallowsyoutodelaythe
programstarttimefor3,6or9hours.
Whenthetimedelayingbuttonispressedonce,
a3hoursdelayisselected.Whenthesame
buttonispressedagain,6hours;andifpressed
oncemore,a9hoursdelaywillbeselected.If
thetimedelayingbuttonispressedonemore
time,timedelayingfunctionwillbecancelled.
Timedelayfunctionstartscountdownafter
settingthedesiredtimedelayandpressingthe
“Start/Pause/Cancel”button.
C
Morelaundrymaybeloadedduringthetime
delayperiod.
Changing and canceling the time delay.
Pressthe“Start/Pause/Cancel”buttontoswitch
themachineto“Pause”mode.Press“Start/
Pause/Cancel”buttontostarttheprogramafter
makingthenewtimedelayselection.
Starting the Program
Press“Start/Pause/Cancel”buttontostartthe
program.“Start/Pause/Cancel”buttonwilllight
uptoindicatethattheprogramhasstarted.The
doorislockedandthe“Ready”lightfades.
Progressing a program
Progressofarunningprogramisshownthrough
theprogramfollow-upindicator.Atthebeginning
ofeveryprogramstep,therelevantindicator
lampwilllightupandlightofthecompletedstep
willturnoff.
C
Ifthemachineisnotspinning,theprogram
maybeinrinseholdmodeortheautomatic
spincorrectionsystemmighthavebeen
activatedbecauseofexcessiveunbalanced
distributionoflaundryinthemachine.
Changing the program after the
program has started
Youcanusethisfeatureafteryourmachinehas
startedtowashdifferenttextilegroupsinthe
samebatchofclothesunderhigherorlower
temperatures.Youmustcanceltheongoing
programinordertochangethewashing
program.
Forexample,pressandholdthe“Start/Pause/
Cancel”buttonfor3secondsinordertoselect
“Cottons40”programinsteadof“Cottons60”
program.Selectthe“Cottons40”program.Start
theprogram.

9 - EN
Switching the machine to standby
mode
Press“Start/Pause/Cancel”buttonmomentarily
toswitchyourmachinetothestandbymode.
Auxiliaryfunctionscanbecancelledorselected
inaccordancewiththesteptheprogramisat.
Thedoorcanbeopenedifthewaterlevelis
suitable.Laundrymaybeadded/takenoutby
openingthedoor.
Child-proof lock
Thisfunctionprotectstheappliancefrombeing
tamperedbychildren.Inthiscase,allofthe
buttonsareinactiveexceptOn/Offbutton;by
On/Offbuttonyoucanwhetherstoporresume
(whilechild-lockon)theprogramofyour
machine.
Themachineisswitchedtochild-lockby
pressingthe1stand2ndauxiliaryfunctionsfrom
theleftfor3sec.Child-prooflocklamponthe
programfollow-upindicatorwilllightupwhen
thechild-prooflockisactivated.Todeactivate
thechild-prooflock,pressthesamebuttonsfor
3sec.
Ending the program through
canceling
Inordertocanceltheselectedprogram,press
the“Start/Pause/Cancel”buttonfor3seconds.
Youcanselectandstartanewprogramwhen
the“Ready”lightislit.
The“Spin”lightilluminatesifthecancellation
processisactivatedinthemiddleoftheprogram
andthemachinecaneitherdrainallthewateror
cantakeinwater3timesatmosttocooldown
theclothesandperformthedrainingprocess.
Theprogramwhichisselectedfirstwillkeep
ongoingevenifthepositionoftheprogram
selectionbuttonischanged.Anewprogram
canbeselectedorstartedafter“Programis
cancelled”inordertochangethewashing
program.
End of program
The“Ready”lampontheprogramfollow-up
indicatorwilllightupwhentheprogramcomes
toanend.Thedoorcanbeopenedandthe
machineisreadyforasecondcyclenow.Press
the“On/Off”buttontoshutdownthemachine.
5 Maintenance and cleaning
Detergent Drawer
Removeanypowderresiduebuildupinthe
drawer.Todothis;
1. Pressthedottedpointonthesiphoninthe
softenercompartmentandpulltowardsyou
untilthecompartmentisremovedfromthe
machine.
C
Ifmorethananormalamountofwater
andsoftenermixturestartstogatherinthe
softenercompartment,thesiphonmustbe
cleaned.
2. Washthedispenserdrawerandthe
siphonwithplentyoflukewarmwaterina
washbasin.
3. Replacethedrawerintoitshousingafter
cleaning.Checkifthesiphonisinitsoriginal
location.
Inlet water filters
Thereisafilterattheendofeachwaterintake
valveatthebacksideofthemachineandalso
attheendofeachwaterintakehosewherethey
areconnectedtothetap.Thesefiltersprevent
theforeignsubstancesanddirtinthewaterto
enterintothemachine.Filtersshouldbecleaned
astheygetdirty.
• Closethetaps.
• Removethenutsofthewaterintakehosesto
cleanthesurfacesofthefiltersonthewater
intakevalveswithanappropriatebrush.
• Ifthefiltersareverydirty,youcanpullthem
outbymeansofpliersandcleanthem.
• Takeoutthefiltersontheflatendsofthe
waterintakehosestogetherwiththegaskets
andcleanthoroughlyunderstreamingwater.
• Replacethegasketsandfilterscarefullyto
theirplacesandtightenthehosenutsby
hand.

10 - EN
hose.Drainthewateroffintothecontainer
bypullingouttheplugattheendofthehose.
Iftheamountofwatertobedrainedoffis
greaterthanthevolumeofthecontainer,
replacetheplug,pourthewaterout,then
resumethedrainingprocess.
• Afterdrainingprocessiscompleted,replace
theplugintotheendofthehoseandfitthe
hosebackintoitsplace.
Ifyourproductisnotsuppliedwithanemergency
drainhose,dothefollowingasshowninthe
figurebelow:
• Placealargecontainerinfrontofthefilterto
receivewaterflowingfromthefilter.
• Loosenpumpfilter(anticlockwise)untilwater
startstoflowoutofit.Directtheflowing
waterintothecontaineryouhaveplacedin
frontofthefilter.Youcanuseapieceofcloth
toabsorbanyspilledwater.
• Whenthereisnowaterleft,turnthepump
filteruntilitiscompletelylooseandremoveit.
• Cleananyresiduesinsidethefilteraswellas
fibers,ifany,aroundthepropellerregion.
• Ifyourproducthasawaterjetfeature,be
suretofitthefilterintoitshousinginthe
pump.Neverforcethefilterwhilereplacing
itintoitshousing.Fitthefilterfullyintoits
housing;otherwise,watermayleakfromthe
filtercap.
4-Closethefiltercap.
Closethetwo-piecefiltercapofyourproductby
pushingthetabonit.
Closetheone-piecefiltercapofyourproductby
fittingthetabsonthebottomintotheirpositions
andpushingtheupperpartofit.
Draining any remaining water and
cleaning the pump filter
Yourproductisequippedwithafiltersystem
whichensuresacleanerwaterdischargethat
extendspumplifebypreventingsoliditemssuch
asbuttons,coinsandfabricfibersfromclogging
thepumppropellerduringdischargeofthe
washingwater.
• Ifyourmachinefailstodrainthewater,the
pumpfiltermaybeclogged.Youmayhave
tocleanitevery2yearsorwheneveritis
plugged.Watermustbedrainedofftoclean
thepumpfilter.
Inaddition,watermayhavetobedrainedoff
completelyinthefollowingcases:
• beforetransportingthemachine(e.g.when
movinghouse)
• whenthereisthedangeroffrost
Inordertocleanthedirtyfilteranddischargethe
water;
1-Unplugthemachinetocutoffthesupply
power.
A
Theremaybewaterat90°Cinthemachine.
Therefore,thefiltermustbecleanedonly
aftertheinsidewateriscooleddowntoavoid
hazardofscalding.
2-Openthefiltercap.Thefiltercapmaybe
composedofoneortwopiecesaccordingtothe
modelofyourmachine.
Ifitiscomposedoftwopieces,pressthetabon
thefiltercapdownwardsandpullthepieceout
towardsyourself.
Ifitiscomposedofonepiece,holditfromboth
sidesandopenitbypullingout.
3-Anemergencydrainhoseissuppliedwith
someofourmodels.Othersarenotsupplied
withthisitem.
Ifyourproductissuppliedwithanemergency
drainhose,dothefollowingasshowninthe
figurebelow:
• Pulloutthepumpoutlethosefromits
housing.
• Placealargecontainerattheendofthe

11 - EN
6 Solution suggestions for problems
Cause Explanation / Suggestion
Programcannotbestartedorselected.
• Machinemayhaveswitchedtoself
protectionmodeduetoaninfrastructure
problem(suchaslinevoltage,water
pressure,etc.).
• Resetyourmachinebypressing“Start/Pause/
Cancel”buttonfor3seconds.(see,Cancelinga
Program)
Thereiswatercomingfromthebottomofthemachine.
• Theremightbeproblemswithhosesorthe
pumpfilter.
• Besurethesealsofthewaterinlethosesare
securelyfitted.
• Tightlyattachthedrainhosetothetap.
• Makesurethatthepumpfilteriscompletely
closed.
Machinestoppedshortlyaftertheprogramstarted.
• Machinecanstoptemporarilyduetolow
voltage. • Itwillresumeoperatingwhenthevoltageis backtothenormallevel.
Itcontinuouslyspins.Remainingtimedoesnotcountdown.(Formodelswithadisplay)
• Theremaybeanimbalanceoflaundryinthe
machine.
• Theautomaticspincorrectionsystemmight
havebeenactivatedduetotheunbalanced
distributionofthelaundryinthedrum.
• Thelaundryinthedrummaybeclustered
(bundledlaundryinabag).Laundryshouldbe
rearrangedandre-spun.
• Nospinningisperformedwhenthelaundryis
notevenlydistributedinthedrumtoprevent
anydamagetothemachineandtoits
environment.
Itcontinuouslywashes.Remainingtimedoesnotcountdown.(Formodelswithadisplay)
• Inthecaseofapausedcountdownwhiletakingin
water:
• Timerwillnotcountdownuntilthemachineisfilled
withthecorrectamountofwater.
• Themachinewillwaituntilthereisasufficientamount
ofwatertoavoidpoorwashingresultsduetolackof
water.Thenthetimerwillstarttocountdown.
• Inthecaseofapausedcountdownatthe
heatingstep:
• Timewillnotcountdownuntiltheselected
temperaturefortheprogramisreached
• Inthecaseofapausedcountdownatthe
spinningstep:
• Theremaybeanimbalanceoflaundryinthe
machine.
• Theautomaticspincorrectionsystemmighthave
beenactivatedduetotheunbalanceddistributionof
thelaundryinthedrum.
• Thelaundryinthedrummaybeclustered(bundled
laundryinabag).Laundryshouldberearrangedand
re-spun.
• Nospinningisperformedwhenthelaundryisnot
evenlydistributedinthedrumtopreventanydamage
tothemachineandtoitsenvironment.
Thereisfoamingoverthedetergentdrawer
• Toomuchdetergentwasused. • Mix1tablespoonfulsoftenerand½literwater
andpourintothemainwashcompartmentofthe
detergentdrawer.

12 - EN
LBS86F
6
84
60
50
63
230V/50Hz
10
2200
800
7 Specifications
Specificationsofthisappliancemaychangewithoutnoticetoimprovethequalityoftheproduct.
Figuresinthismanualareschematicandmaynotmatchyourproductexactly.
Valuesstatedonthemachinelabelsorinthedocumentationaccompanyingitareobtainedin
laboratoryinaccordancewiththerelevantstandards.Dependingonoperationalandenvironmental
conditionsoftheappliance,valuesmayvary.
Models
Maximumdrylaundrycapacity(kg)
Height(cm)
Width(cm)
Depth(cm)
NetWeight(±4kg)
Electricity(V/Hz.)
TotalCurrent(A)
TotalPower(W)
Spinningcycle(rpmmax.)
Thisappliance’spackagingmaterialisrecyclable.Helprecycleitandprotecttheenvironment
bydroppingitoffinthemunicipalreceptaclesprovidedforthispurpose.Yourappliancealso
containsagreatamountofrecyclablematerial.Itismarkedwiththislabeltoindicatetheused
appliancesthatshouldnotbemixedwithotherwaste.Thisway,theappliancerecyclingor-
ganisedbyyourmanufacturerwillbedoneunderthebestpossibleconditions,incompliance
withEuropeanDirective2002/96/EConWasteElectricalandElectronicEquipment.Contact
yourtownhalloryourretailerfortheusedappliancecollectionpointsclosesttoyourhome.
Wethankyoudoingyourparttoprotecttheenvironment.
