Smith Corona BT200 User manual

Bluetooth Headset
User’s Manual
BT200
The unit is a wireless comfort Bluetooth® headset for mobile phones and
offices. When mobile phones replace the ordinary phones at the office, you
need a comfortable and ergonomic solution for those who spend long hours
on the phone. The unit such a solution, a truly comfortable headset with
good sound quality, built for comfortable all day wearing. As an accessory,
there is an USB Bluetooth dongle for the PC. With the dongle, you can
connect your headset to a computer and use it as an audio device for VoIP
applications, for example SkypeTM .
Features
 Bluetooth Version 4.2, with improved data transfer, security and connectivity.
 Up to 20 hours talk time.
 At least 96 hours stand by time
 Up to 30 meters working range (class 2)
 Voice guidance
 Volume control buttons
 Answer button
 Dedicated microphone mute button
 Last number re-dial
 Low battery indication
 Adjustable headband and soft ear cushion for all day wearing comfort
 LED status indication
 Charging cradle(Option)
Introduction
Available in Monaural or Binaural

What’s inside
Direct Charging from USB port of PC
If the headset has been out of use for some item, it may take up to 2 hours to
charge it fully. Normal charging time is 2-3 hours. Low battery is indicated by the
flashing red LED on the headset.
Headset Hanger USB charging cable
Overview
Headset Hanger : For your convenience, fix the
headset hanger on any place available.
Optional Accessories
Charging stand
BT-200 Bluetooth dongle
Both the charging-stand and micro USB cable can be plugged into either a computer
or wall charger.
Attaching the headband
To attach the microphone boom arm to the headband, align the triangle shape on
the microphone boom arm with the triangle shape on the headband and push to
click into place. The microphone boom arm will then rotate to your required
position.

Detaching the headset
To detach the microphone boom arm from the headband, gently push the
microphone speaker from inside the ear cushion. This will pop the microphone
boom away from the headband
IMPORTANT: Do not pull on the microphone boom to remove it from the headband.
Positioning the Microphone
The microphone boom arm is flexible, so you can gently
bend the boom and position it to suit the curve of your face.
Holding the headset, rotate the headband to bring the boom
close to your cheek.
The ideal placement for the microphone is usually
at the corner of your mouth, not in front of it,
and about an inch from your face.
Be sure that the side of the microphone is pointed
toward your mouth.

Turn on the headset
Press and hold the ‘answer’ button for 2 seconds. Release the button when the LED
flashes 3 times and ‘Power on’ is heard in the speaker.
Turn off the headset
Press and hold the ‘answer’ button for 3 seconds. Release the button when the LED
flashes red 3 times and ‘Power off’ is heard in the speaker.
Prior to using the headset, it must be paired and connected to another Bluetooth
device, such as a mobile phone. For specific instructions, check the users guide of
your phone.
General procedure
 Turn on Bluetooth on your phone
 Put the headset in pairing mode (make sure the headset is switched off, press
and hold the answer button for 1 sec until the LED flashes red rapidly)
 Perform a search for Bluetooth devices on your phone.
 Connect to >>device logo<< when found.
 Blue LED is On and ‘Pairing done, Connected’ is heard in the speaker when
pairing is completed
Different phones have different ways to handle Bluetooth devices. Read the users
manual of your phone for more info. Some phone for more info. Some phones will
connect to the headset automatically when it is within range, for example when you
return to your office. For other phones, it may be necessary to reconnect manually
when the connection has been broken.
Turning the headset on and off
Pairing
The pairing mode is active for 3 minutes. After that, the headset will enter standby
mode.
..
There are two different firmware versions for different languages. Each version
supports 3 different languages for user. The first version has English, Spanish, and
French voice prompts. The second version offers German, Italian, and Dutch voices.
To select languages, the headset should not connect to Bluetooth host. When the
headset is out of synchronization, press ‘answer’ button twice and selected
languages will be heard. To change it, press ‘answer’ button twice again and then
next available languages will be informed. If announced languages wants to be used,
just stay and use it.
Answer a call
 Press the ‘answer’ button briefly.
Reject a call
 Press the ‘answer’ button for 1 sec while incoming call, and ‘Call rejected’ is
heard in speaker.
Make a call
 Dial the number on the mobile phone and press the answer button briefly.
End a call
 Press the answer button briefly or end the call on the mobile phone.
Set Voice Prompt Language
Using the headset
NOTE: If your phone requires a pairing code please use 0000.

Last number redialing
 Press the answer button briefly twice and you can hear ‘Re-Dialing’ from speaker.
Mute On/Off
 Press and release the mute button and ‘Mute On’ is heard in speaker.
 Press again to resume the call and ‘Mute Off’ is heard in speaker.
Volume adjustment
 Press volume up/volume down to adjust the
listening volume. There is a small notch on
each volume button that makes them easy to
find. The headset listening volume can also
be adjusted on the phone.
Note that high listening volume settings may
cause echo or other noise on the line, for one
or both parties on the line. Try to lower the
listening volume if this is the case.
Important! – High listening volume settings
may be harmful to your hearing.
Safe and efficient use
Do not expose your product to humidity, liquid or extreme temperature conditions.
Such conditions, or other rough treatment such as dropping or bending the product
may damage it. Do not use any accessories or chargers other than original intended
for use with this product. Neither headset nor charger contain any user serviceable
parts, and must not be opened.
A Bluetooth device use radio signals to communicate with other devices. The power
of this radio signal is low, maximum 0.001 Watts. Do not use the product where it is
forbidden, for example in airplanes, at hospitals, in blasting areas or in explosive
atmospheres. Radio signals may interfere with other electronic devices, especially if
these are not shielded.
Permanent hearing loss may occur if headsets are used at high
listening volumes for longer periods of time. Set the volume to a safe
level. You can adapt to high listening volume over time, especially in a noisy
environment where the level of sound may seem normal even if the volume is high.
Reduce the time you use a headset with high listening volume.
Battery information
The device is equipped with a rechargeable Lithium-polymer battery. A new battery
will need a few charging cycles before it can reach maximum capacity. A fully charged
battery will loose its charge over time even if the headset is not used.
Battery capacity and life span may be reduced if the device is exposed to extreme
high or low temperatures, for example if it is left in a car. A device with a cold or hot
Technical information

battery may stop working until it is back to normal (room) temperature. Battery
capacity at temperatures below -0oC is reduced.
Never dispose of batteries in open fire since they may explode. Always dispose of
use batteries and electronic devices according to local recycling regulations.
FCC Information
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that
may cause undesired operation.
FCC notification to users
This equipment has been tested and found to comply with the limits for a CLASS B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference, the user is encouraged to try to correct
the interference by consulting with a dealer or an experienced technician for technical
assistance.
Any changes or modifications to the equipment not expressly approved by the party
responsible for compliance could void user’s authority to operate the equipment.
WARNING & SAFETY INFORMATION
The antenna(s) used for this device must be installed to provide a separation distance
of at least 20cm from all persons and must not be co-located or operating in
conjunction with any other antenna or transmitter.
Troubleshooting
If you have problems connecting the headset to your phone, do as follows:
 Check that the headset is charged, turned on and within 10 meters of the phone.
 Check that Bluetooth is switched on your phone.
 Check that the headset is listed as a headset device in your phone and also
connected. You may need to re-connect to the headset
 Try removing the headset from the phone, then pair and connect again.
Some features are not possible to use with a certain phone:
 Check the user manual of your phone for missing settings or functions that needs
to be activated.
 Different mobile phone manufacturers may implement Bluetooth functions in
different ways. The unit should work with all phones that support the Headset
and Hands-free Bluetooth profiles, but functionality may vary depending on the
telephone model you use. You might also want to check for the latest firmware
for your phone.
Maintenance
Your headset is a technically advanced device containing circuit boards and fine
mechanics, made from top grade component. To increase reliability and life span,
Help and tips

always treat your headset with care.
 Do not expose the headset to moist, liquids, rain or dust.
 Store the product at a dry and dust-free location.
 For cleaning, use a dry cloth.
 Do not store a fully charged headset in the charging stand for longer periods of
time.
 Ear cushions are available as spare parts.
We will repair or replace, at our opinion, this product if found defective due to
materials or workmanship within the warranty period beginning from the original
date of purchase. This product is warranted by authorized representative for the
period specified.
The Original dated purchase receipt must be presented to the authorized service
center when service is rendered. On all carry-in models, transportation to and from
the service station is the responsibility of the purchaser.
This warranty does not cover damages due to accident, fire, flood, earthquake
and/or other acts of God; misuse, incorrect line voltage, improper installation,
improper or unauthorized repairs, commercial use or damages occurred in shipping.
Exterior and interior finish, lamps, glass, plastics parts and temperature probes are
not covered under this warranty. Customer adjustment according to the owner’s
manual are not covered under this warranty. This warranty is automatically void if
the serial number is missing or altered.
Warranty and service
Key Table
