Smithco Super Star FX User manual

Super Star Diesel
Model 43-500-B
Super Star FX
Model 43-250-A
October 2014
Product Support: Hwy SS & Poplar Ave; Cameron WI 54822
1-800-891-9435 [e-mail]
Operator’s

CONTENTS
Introduction.................................................... 1-16
Introduction ...................................................................................... 1
Symbols.........................................................................................2-3
Safety............................................................................................... 4
WarningDecalLocation ................................................................... 5
SafePractices.................................................................................. 6
SuperStarDieselSpecifications ........................................................ 7
SuperStarFX Specifications ............................................................ 8
Setup ............................................................................................... 9
Controls&InstrumentsSuperStarFX .............................................10
Controls& InstrumentsSuper StarDiesel........................................ 11
Operation ........................................................................................12
Daily Checklist ................................................................................13
Quick Hitch .....................................................................................13
ServiceChart ..............................................................................14-15
How To Rake A SandTrap .............................................................16
Service............................................................... 17
Battery ............................................................................................17
Other ............................................................. 18-20
DeclarationofConformitySuperStarDiesel ...............................18-19
DeclarationofConformitySuperStarFX .....................................19-20
LimitedWarranty................................................................................
Introduction Service Diagrams

1
Introduction
PARTSMANUALSAVAILABLEONLINEATwww.smithco.com
INTRODUCTION
Thank you for purchasing a SmithcoSmithco
SmithcoSmithco
Smithco product.
Read this manual and all other manuals pertaining to the Bunker Rake carefully as they contain safety, operat-
ing, assembly and maintenance instructions. Failure to do so could result in personal injury or equipment dam-
age.
Keepmanualsin a safe place after operatorandmaintenancepersonnel have read them. Rightandleftsides are
fromtheoperator’sseat,facingforward.
All SmithcoSmithco
SmithcoSmithco
Smithco machineshave a SerialNumber and Model Number. Bothnumbers are needed when ordering
parts. Refer to engine manual for placement of engineserialnumber.
For product and accessory information, help finding a dealer, or to register your procuct please contact us at
www.Smithco.com.
Informationneededwhen ordering replacementparts:
1. ModelNumberofmachine
2. SerialNumberofmachine
3. NameandPartNumberofpart
4. Quantityofparts
For easy access record your Serial and Model numbers here.
CALIFORNIA
Proposition 65 Warning
Engineexhaustand some of its constituents
are known to the State of California to
cause cancer, birth defects, and other
reproductive harm.
WARNING
lb/kg Empty lb/kg Full

2
Introduction
PARTSMANUALSAVAILABLE ONLINEATwww.smithco.com
SYMBOLS
Park Brake Park Brake
Release Hydraulic Oil
Level
Choke - OpenChoke - ClosedHand Throttle
Hour Meter Hour Meter Fuse
Glow PlugGlow Plug - OffGlow Plug - On
RPM Gasoline Diesel
Water
Temperature
Temperature
Light
Engine Oil
Engine - Stop Engine - Start Engine - Run
No Electrical
Power
Electrical
Power
Read
Operator’s
Manual

3
Introduction
PARTSMANUALSAVAILABLE ONLINEATwww.smithco.com
SYMBOLS
No Smoking Moving Parts Manual
Operation
Pinch Point Step Hot Surface
Hydraulic Fluid
Penetration Lift Arm Tractor
Engage Disengage PTO
Ground Speed Fast Slow
HHigh LLow FForward
RReverse NNeutral Warning
Danger
Caution
Up/RaiseDown/LowerUp/DownArrow

4
Introduction
PARTSMANUALSAVAILABLE ONLINEATwww.smithco.com
SAFETY
Read and understand this manual and all safety signs before operating and maintaining. Review
the safety instructions and precautions annually.
TAKE NOTE! THIS SAFETY ALERT SYMBOL FOUND THROUGHOUT THIS MANUAL IS
USED TO CALL YOUR ATTENTION TO INSTRUCTIONS INVOLVING YOUR PERSONAL
SAFETY AND THE SAFETY OF OTHERS. FAILURE TO FOLLOW THESE INSTRUCTIONS
CAN RESULT IN INJURY OR DEATH.
THIS SYMBOL MEANS
- ATTENTION!
- BECOME ALERT!
- YOUR SAFETY IS INVOLVED!
SAFETY SIGNAL WORDS
Note the use of the signal words DANGER, WARNING and CAUTION with the safety
messages. The appropriate signal word for each has been selected using the following
guidelines:
DANGER: Red. Indicates an imminently hazardous situation that, if not avoided, will result
in death or serious injury. This signal word is to be limited to the most extreme situations
typically for machine components which, for functional purposes, cannot be guarded.
WARNING: Orange. Indicates a potentially hazardous situation that, if not avoided, could
result in death or serious injury, and includes hazards that are exposed when guards are
removed. It may also be used to alert against unsafe practices.
CAUTION: Yellow. Indicates a potentially hazardous situation that, if not avoided, may
result in minor or moderate injury. It may also be used to alert against unsafe practices.
SPARKARRESTOR
Theengine in these machines arenotequipped with a spark arrestor muffler. It isinviolation of California Public
ResourseCode Section 4442 which states:
No person shall sell, offer for sale, lease, or rent to any person any internal combustion engine subject to Sec-
tion 4442 or 4443, and not subject to Section 13005 of the Health and Safety Code, unless the person provides
a written notice to the purchaser or bailee, at the time of sale or at the time of entering into the lease or rental
contract, stating that it is a violation of Section 4442 or 4443 to use or operate the engine on any forest-covered,
brush-covered,or grass-covered land unless theengine is equipped with asparkarrester, as defined in Section
4442,maintained in effective working orderorthe engine is constructed, equipped,andmaintained for the pre-
vention of fire pursuant to Section 4443.
Other states or jurisdictions may have similar laws.

5
Introduction
PARTSMANUALSAVAILABLE ONLINEATwww.smithco.com
SAFETYSIGNLOCATIONSUPERSTAR
REMEMBER: If Safety Signs have been damaged, removed, become illegible or parts
replaced without decals, new decals must be applied. New decals are available from your
authorized distributor or factory.
25-352-P
By-pass Valve
This valve should be completely closed when running the unit. The valve is closed by turning clockwise. This valve can be opened to push the unit when the engine is not running.
Towing the Machine
The machine can be moved for a short distance with the engine off, but we do not recommend this as a standard procedure. When towing do not tow the machine faster than -3 MPH (3-5 km/h) because the drive system may be damaged. The tires may lock up if the machine is towed too fast. If this occurs, stop towing the machine. If the machine must be moved a considerable distance, transport it on a truck or trailer.
Speed Boss by
Speed Boss allows the machine to
operate at a proper speed while
ra ing bun ers on golf courses.
This speed has been factory set at an
average speed of 3-4 MPH (5-6.5 ph).
It may be re-set to any desired
operating speed. See Manual for
instructions.
CAUTION : When the rear ra e
attachment is lowered while the
machine is in forward motion, the
forward speed of the machine will
slow drastically. Operator should be
prepared for rapid change in speed.
U.S. Patent # 5,725,068 25-337-P

6
Introduction
PARTSMANUALSAVAILABLE ONLINEATwww.smithco.com
SAFEPRACTICES
1. It is your responsibility to read this manual and all publications associated with this machine (engine,
accessories and attachments).
2. Never allow anyone to operate or service the machine or its attachments without proper training and
instructions. Never allow minors to operate any equipment.
3. Learn the proper use of the machine, the location and purpose of all the controls and gauges before
you operate the equipment. Working with unfamiliar equipment can lead to accidents.
4. Wear all Personal Protective Equipment (PPE) on your head, eyes, ears, hands and feet. Operate the
machine only in daylight or in good artificial light.
5. Inspect the area where the equipment will be used. Pick up all debris you can find before operating.
Beware of overhead obstructions and underground obstacles. Stay alert for hidden hazards.
6. Never operate equipment that is not in perfect working order or without decals, guards, shields, or other
protective devices in place.
7. Never disconnect or bypass any switch.
8. Carbon monoxide in the exhaust fumes can be fatal when inhaled, never operate a machine without
proper ventilation.
9. Fuel is highly flammable, handle with care.
10. Keep engine clean. Allow the engine to cool before storing and always remove the ignition key.
11. After engine has started machine must not move. If movement is evident, the neutral mechanism is
not adjusted correctly. Shut engine off and readjust so the machine does not move when in neutral
position.
13. Never use your hands to search for oil leaks. Hydraulic fluid under pressure can penetrate the skin and
cause serious injury.
14. This machine demands your attention. To prevent loss of control or tipping of the vehicle:
A. Use extra caution in backing up the vehicle. Ensure area is clear.
B. Do not stop or start suddenly on any slope.
C. Reduce speed on slopes and in sharp turns. Use caution when changing directions on slopes.
D. Stay alert for holes in the terrain and other hidden hazards.
15. Before leaving operator’s position for any reason:
A. Disengage all drives.
B. Lower all attachments to the ground.
C. Set park brake.
D. Shut engine off and remove the ignition key.
16. Keep hands, feet and clothing away from moving parts. Wait for all movement to stop before you
clean, adjust or service the machine.
17. Keep the area of operation clear of all bystanders.
18. Never carry passengers.
19. Stop engine before making repairs/adjustments or checking/adding oil to the crankcase.
20. Use parts and materials supplied by SmithcoSmithco
SmithcoSmithco
Smithco only. Do not modify any function or part.
These machines are intended for professional maintenance on golf courses, sports turf, and any
other area maintained turf and related trails, paths and lots. No guaranty as to the suitability for any
task is expressed or implied.

7
Introduction
PARTSMANUALSAVAILABLE ONLINEATwww.smithco.com
SPECIFICATIONSSUPERSTARDIESEL
WEIGHTSANDDIMENSIONS
Length 57"(145 cm)
Height 47"(119 cm)
Wheel Base 41" (104 cm)
Weight 1100 lbs. ( 500 kg)
SOUNDLEVEL
At EarLevel 96 dB
ENGINE
Make Kubota
Model# D722
Type / Spec# E3B-KEA-2
Horsepower 20hp(14.9kW)
Fuel Diesel No. 2
No. 2-D, S500: Low Sulfur Diesel (LSD) less than 500 ppm or 0.05 wt.%
No.2-D, S15: Ultra Low Sulfur Diesel (ULSD) less than 15 ppm or 0.0015 wt.%
CoolingSystem LiquidCooled
LubricationSystem FullPressure
Alternator 16 amp
WHEELS&TIRE 3: 22 x 11 x10.0 knobby
5 psi (.34 bar)
Front tire fluid filled to 80 lbs. total. 45.5 pints of windshield washer fluid or
equivalent.
Speed
Forward Speed 0 to 11 m.p.h. (0-18 kph)
Reverse Speed 0 to 5 m.p.h. (0-8 kph)
BATTERY Automotive Type 45-12 Volt
BCI Group Size 45
Cold Cranking Amps 480
Ground Terminal Polarity Negative (-)
Maximum Length 9" (23 cm)
Maximum Width 5.38" (14 cm)
Maximum Height 9" (23 cm)
FLUIDCAPACITY
Crankcase Oil See Engine Manual
Fuel 20 quarts (18.93 liters)
Hydraulic Fluid 20 quarts (18.93 liters)
Grade of Hydraulic Fluid SAE 10W-40 API Service SJ or higher Motor Oil

8
Introduction
PARTSMANUALSAVAILABLE ONLINEATwww.smithco.com
SPECIFICATIONSSUPERSTARFX
WEIGHTSANDDIMENSIONS
Length 64"(1.63 m)
Width 57" (1.45 m)
Height 47" (1.19 m)
Wheel Base 41" (1.04 m)
Weight 950 lbs. ( 451 kg)
SOUNDLEVEL
AtEarLevel 87 dB
ENGINE
Make Briggs and Stratton Vanguard
Model# 356447
Type / Spec# 0263 G1
Horsepower 18 hp (13kW)
Fuel Unleaded 87 Octane Gasoline Minimum
Cooling System Air Cooled
Lubrication System Full Pressure
Alternator 16 amp
TIRES &WHEELS Three: 22 X 11 - 10.0 Knobby Tires 5 psi (.34 bar)
Front tire fluid filled to 80 lbs. total 45.5 pints of windshield washer fluid or
equivalent.
Speed
Forward Speed 0 to 11 m.p.h. (0-18 kph)
Reverse Speed 0 to 5 m.p.h. (0-8 kph)
BATTERY Automotive Type 45-12 Volt
BCI Group Size 45
Cold Cranking Amps 480
Ground Terminal Polarity Negative (-)
Maximum Length 9" (23 cm)
Maximum Width 5.38" (14 cm)
Maximum Height 9" (23 cm)
FLUIDCAPACITY
Crankcase Oil See Engine Manual
Fuel 20 quarts (18.93 liters)
Hydraulic Fluid 20 quarts (18.93 liters)
Gradeof HydraulicFluid SAE 10W-40API Service SJ or higher Motor Oil

9
Introduction
PARTSMANUALSAVAILABLE ONLINEATwww.smithco.com
SETUP
The Bunker Rakes arrive from SmithcoSmithco
SmithcoSmithco
Smithco withsome assembly requiredbefore service.
1. Set park brake. Pull the brake lever up past center and the park brake is engaged.
2. Rearwheelmounting. Block front tire. Jackuprear of machine being
carefulnotto damage underside of machine.Placewheel on hub lining
up bolt holes. Use the ten lug nuts provided. Then torque to 64 - 74 ft/lb
(87-100Nm) using a cross pattern.Retorqueafter the first 10 hoursand
every200hoursthereafter.Lowermachinetogroundandremoveblocks
and jack.
3. Install steering wheel (Ref 3) on machine. Install key (Ref 4) into tilt
steeringshaft. Put steering wheel (Ref3) onto Tilt steering unit(Ref 5).
Use nit (Ref 2) to secure steering wheel to tilt steering unit. Place cap
(Ref1)ontocenterofsteeringwheel.
4. Check the tire pressure. The Knobby tire pressure should be 5 psi (0.34
bar).TurfTracTire pressure should be 5 psi (.34bar).
5. Batterynotfurnished. Install an automotive type45 -12 volt; 480 cold
cranking amps (minimum) battery in the battery box of the Super Stars
Thisis a negative groundingsystem.Attach the battery hold-downs.
Thenattachred positive (+) cable (A)topositive
terminal.Sliderubberboot over the positive terminal to
preventshorts.Attachblacknegative(-) cable (B) to
thenegativeterminal.
Connecting battery cables to the wrong post
could result in personal injury and/or damage
to the electrical system. Make sure battery and
cables do not interfere or rub on any moving
part. Connect the red positive (+) cable (A) to
the battery first. When disconnecting remove
the black negative (-) cable (B) first.
6. Check engine oil and add as necessary. See engine
manualforrecommendedmotoroil.DO NOT OVERFILL.
7. FillGasTanks with Unleaded 87Octanegasoline (minimum).
Fill Diesel Tanks with Diesel No. 2. No. 2-D, S500: Low Sulfur Diesel (LSD) less than 500 ppm or 0.05
wt.%. No.2-D, S15: Ultra Low Sulfur Diesel (ULSD) less than 15 ppm or 0.0015 wt.%
Fuel is flammable. Caution must be used when storing or handling it. Do not fill fuel tank
while engine is operating or in an enclosed area. Fumes are explosive and dangerous to
inhale. DO NOT SMOKE while filling the fuel tank. DO NOT OVERFILL.
8. Check hydraulic oil level on the tank. The level should be 2 -21/2"(5 - 6.35 cm) from top of tank. If level is
low, add SAE 10W-40API Service SJ or higher motor oil.
9. Machineshouldbegreasedbeforestarting.
10. Readoperatinginstructionsbeforestarting machine.

10
Introduction
PARTSMANUALSAVAILABLE ONLINEATwww.smithco.com
CONTROLS&INSTRUMENTSSUPERSTARFX
INSTRUMENTSLOCATEDONTHECONTROLPANEL
A. Hand Throttle - The hand throttle is used to regulate engine speed.
B. Oil Light - The oil light should come on when ignition
is on without engine operating. The oil light will light
when the oil pressure is low. If oil light should come
on, shut off engine immediately and find the cause.
C. Ignition Switch - The ignition switch has three
positions: Off-Run-Start.
D. Choke - Pull choke control knob up to close choke
plate when starting a cold engine. A warm engine may
not require "choking" to start.
E. On/Off valve - Rocker Switch to turn on/off 3
wheeldrive.
F. Light - his is a Rocker switch to turn on and off lights.
STEERING
Acquaint yourself with the steering before operating the machine. This machine is
equipped with a tilt steering mechanism. The lever to tilt the steering wheel is located at
bottom of rubber boot on steering column. Hold the lever down and adjust the steering
wheel to a comfortable position.
RAKELIFTLEVER
This lever (H) raises and lowers all rear attachments. To lower push forward, to raise pull
back. Release the lever when attachment is in proper position and lever will return to
neutral.
LIFT ASSEMBLY LEVER
This lever (J) raises and lowers all attachments under the center of the machine. To lower
push forward, to raise pull back. Release the lever when attachment is in proper position
and lever will return to neutral.
HOUR METER
Located on the right front fiberglass cowling (I). The hour meter indicates hours of ma-
chine operation. The hour meter operates when ignition switch is on.
SEAT ADJUSTMENT
Seat adjustment lever is located under front of seat on left side. It allows seat ad-
justment forward or backward for operator's comfort. The seat also has the start
safety switch in it. To start the Super Star the operator must be sitting on the seat.
RIGHT FLOORBOARD
FootPedalcontrolsforwardand reverse motion. Pushing down on the frontof
pedal(K)willgive you a forward motion andpushingdownonrear pedal (L) will
giveyou a reverse motion. Whenpedal is released the hydrostatictransmis-
sioncenters and stopsthe vehicle. Ground speedis proportional to how far the
footpedalis depressed.

11
Introduction
PARTSMANUALSAVAILABLE ONLINEATwww.smithco.com
CONTROLS&INSTRUMENTS SUPERSTARDIESEL
INSTRUMENTSLOCATEDONTHECONTROLPANEL
A. Oil Light - The oil light should come on
whenignitionison without engine operating.
The oil light will light when the oil pressure is
low. If oil light should come on, shut off
engineimmediatelyand find the cause.
B . Ignition Switch - The ignition switch has
threepositions:Off-Run-Start.
C . Temperture Light: Thetemperature light
will come on if machine starts to over heat.
D . Hand Throttle - The hand throttle is used to regulate engine speed.
E. Glow Plug: When ignition is turned to preheat, glow plug lights when ready to start.
F. Light - his is a Rocker switch to turn on and off lights.
G. On/Off valve - Rocker Switch to turn on/off 3 wheel drive.
STEERING
Acquaintyourselfwith the steering before operating themachine.This
machine is equipped with a tilt steering mechanism. The lever to tilt the
steering wheel is located at bottom of rubber boot on steering column.
Holdthelever down and adjust thesteeringwheelto a comfortable posi-
tion.
RAKELIFTLEVER
This lever (H) raises andlowers all rearattachments.To lowerpush
forward,to raise pullback. Release thelever when attachmentis in
properpositionandleverwillreturnto neutral.
LIFTASSEMBLYLEVER
Thislever (J) raises and lowersall attachments under the centerofthe machine.
To lowerpush forward, toraise pull back.Release the lever when attachmentis in
properpositionandleverwillreturnto neutral.
SEATADJUSTMENT
Seat adjustment lever is located under front of seat on left side. It allows seat
adjustmentforwardorbackward for operator's comfort. The seat alsohasthe
start safety switch in it. To start the Super Star the operator must be sitting on
the seat.
RIGHTFLOORBOARD
FootPedalcontrolsforward and reverse motion. Pushing down onthefrontofpedal(K) will give you a forward
motionandpushing down on rear pedal(L)will give you a reverse motion.Whenpedal is released the hydro-
static transmission centers and stops the vehicle. Ground speed is proportional to how far the foot pedal is de-
pressed.
HOURMETER
Locatedon the right front fiberglasscowling.Thehour meter indicates hours of machineoperation.The hour
meter operates when ignition switch is on.

12
Introduction
PARTSMANUALSAVAILABLE ONLINEATwww.smithco.com
OPERATION
STARTINGENGINE
Before operating this machine, become familiar with all controls and functions of these units. Also complete
all maintenance requirements and read all safety warnings. By knowing the machine thoroughly, how it oper-
ates and by doing the prescribed maintenance steps, you can expect relatively trouble-free operation for
years to come.
1. Make sure the fuel flow valve, located on the fuel tank, is “ON.”
2. Set park brake. Start safety switch is on the park brake.
3. The ignition switch is a three position on gas and four position on diesel.
For Gas engines: Insert key (A) and turn clockwise until engine starts
(C). Release key and it will return to run position (B). Use choke and hand
throttle as necessary. For Diesel Engines: Insert key (A) and turn clock-
wise to (B). When glow light goes out, turn key clockwise until engine
starts (C). Release key and it will return to run position (B).
4. Allow engine to idle and warm up a few minutes before selecting a direc-
tion of travel.
5. To shut off engine on all gas machines turn key to the stop position.
COLDWEATHERSTARTING -GASONLY
When attempting to start the engine in cold weather, the oil in the hydrostatic pump
may provide too much resistance to start a cold machine.
Before attempting to start the engine in cold weather, disengage the drive belt to
the hydrostatic by pushing down the idler lever until it catches in the notch on the
latching lever. Start engine and allow it to warm up with no load. When the engine is
warm, shut off engine. Push down on the latching lever until the idler is released.
Engine must be stopped when the drive belt is engaged. If the engine is running when the belt is en-
gaged,thevehiclemay move suddenly, injuring you and/or bystanders.
Alwaysstoptheengine before reengaging the drive belt. The suddenapplicationofpowertothe hydro-
static may cause serious damage the pump, the engine or both.
FUELEMISSIONS
Withthe emissions control now ineffect,the CF-4 and CG-4 lubricatingoils have been developed foruseof a
low-sulfurfuelonon-roadvehicleengines.Whenandoff-roadvehicleenginerunsonahigh-sulfurfuel,itisadvis-
able to employ the CF, CD, or CE lubricating oils with a high total base number. If the CF-4 or CG-4 lubrication
oilis used withhigh-sulfur fuel, change the lubricating oil more often.
Lubricatingoilrecommendedwhenalow-sulfurorhigh-sulfur fuel is used.
O= Recommended X= Not Recommende
d
Low-sulfur High-sulfu
r
CF O O
CF-4 O X
CG-4 O X
Lubricating Oil Class Fuel

13
Introduction
PARTSMANUALSAVAILABLE ONLINEATwww.smithco.com
DAILYCHECKLIST
Use all procedures and parts prescribed by the manufacturer's. Read the engine manual
before operation.
The suggested maintenance checklist is not offered as a replacement for the manufacturer’s but as a supple-
ment. You must adhere to guidelines established by manufacturer for warranty coverage. In adverse condi-
tions such as dirt, mud or extreme temperatures, maintenance should be more frequent.
DAILY CHECKLIST
1. Check park brake adjustment. Adjust as required.
2. Check engine oil level. Add as needed. DO NOT OVERFILL.
3. Tire pressure should be 5 psi (0.34 bar) maximum for knobby tires and 5 psi (.34 bar) for turf trac.
4. Inspect electrical system for loose connections or frayed wiring, including battery cables. Replace any
faulty equipment or tighten if loose.
5. Check hardware for loose or missing nuts, bolts, screws, etc., and tighten or replace as needed.
6. Inspect hydraulic lines for damage or leaks. Never use hands to inspect leaks.
7. Check hydraulic oil level on the tank. The level should be 2 -21/2"(5 - 6.35 cm) from top of tank. If level
is low, add SAE 10W-40 API Service SJ or higher motor oil.
8. Inspect steering, throttle and shift linkages for good hookups and clear travel.
9. Check anti-vibration mounts on engine frame.
10. Check controls for smooth, proper working operation. Lubricate as needed.
11. Remove debris from engine compartment
QUICK HITCH
Bunker Rakes are fitted with a Quick HitchAccessory Mount System. On each mount is a spring loaded
locking mechanism and a lock pin. Remove the lock pin and push down on the spring loaded locking
mechanism and your rear attachment will pull off, so you can easily switch out attachments. The lock pin
acts as a safety device to keep lock pin from opening up when crossing rough terrain.
Thereare also adjustment screws onthe
Quick Hitch Accessory Mount System that
mayneed to be adjustedforcertain rear
attachments.Theseallow the rear attach-
ment to move from side to side without
touchingthe rear wheels. Pleasesee
instructionsoneachindividual attachment
that you purchase.
Runmachineand test for operation ofthe
rearattachmentby raising and lowering the
assembly and with the attachment down
turn sharp corners in both directions to
ensure rake is not contacting the tires.
Adjustment Screws
SpringLoaded
LockingMecha-
nism

14
Introduction
PARTSMANUALSAVAILABLE ONLINEATwww.smithco.com
SERVICECHARTSUPERSTARFX
Before servicing or making adjustments to the machine, stop engine, set park break, block
wheels and remove key from ignition.
Follow all procedures and ONLY use parts prescribed by the manufacturer. Read the engine
manual before maintenance.
Thesuggestedmaintenance checklist is not offeredasareplacement for the manufacturer’s enginemanualbut
asa supplement.Youmustadhere to the guidelines establishedby the manufacturer forwarrantycoverage. In
adverseconditionssuch as dirt, mud orextremetemperatures,maintenance should be more frequent.
Maintenance Service Interval Maintenance Procedure
Torque the wheel lug nuts. (64-74 ft/lb (87-100 Nm))
Change the engine oil filter.
Check the engine oil level.
Clean area around muffler and controls.
Check the hydraulic fluid level.
Check the tire pressure.
Check condition of hydraulic hoses and fittings.
Inspect and clean the machine.
After the first 50 hours Change Hydraulic Oil Filter.
Clean or change air filter.1
Clean pre-cleaner.1
Change engine oil and filter.
Replace spark plug .
Lubricate machine.
Clean or change remote air cleaner.
Check the battery fluid level and cable connections..
Check muffler and spark arrestor.
Check belt tension .
Check engine valve clearance and adjust if necessary.
Check idle speed.
Clean battery terminals.
Change hydrauilic oil filter.
Torque the wheel lug nuts. (64-74 ft/lb (87-100 Nm))
Change fuel filter.
Change hydrauilic oil and filter.
Clean oil cooler fins.1
Clean air cooling system.1
Check safety filter in remote air cleaner.
After the first8 operating hours
Before each use daily
Every100 hours
Every250 hours
Every500 hours or yearly
1
In dusty conditions or when airborne debris is present, clean more often.

15
Introduction
PARTSMANUALSAVAILABLE ONLINEATwww.smithco.com
SERVICECHARTFORSUPERSTARDIESEL
Maintenance Service Interval Maintenance Procedure
Torque the wheel lug nuts. (64-74 ft/lb (87-100 Nm))
Change the engine oil filter.
Check the engine oil level.
Clean area around muffler and controls.
Check the hydraulic fluid level.
Check the tire pressure.
Check condition of hydraulic hoses and fittings.
Check for oil or water leaks.
Proper function of glow lamp timer.
Color of exhaust fumes.
Inspect and clean the machine.
After the first 50 hours Change Hydraulic Oil Filter.
Change Engine oil and filter.
Clean or change air filter.1
Clean pre-cleaner.1
Change engine oil and filter.
Replace spark plug .
Lubricate machine.
Clean or change remote air cleaner.
Check the battery fluid level and cable connections..
Check belt tension .
Check radiator hoses and clamp bands.
Check idle speed.
Repalce oil filter cartridge.
Change hydrauilic oil filter.
Check air intake line
Torque the wheel lug nuts. (64-74 ft/lb (87-100 Nm))
Change fuel filter.
Change hydrauilic oil and filter.
Clean oil cooler fins.1
Clean air cooling system.1
Change radiator coolant.
Check safety filter in remote air cleaner.
After the first 8 operating hours
Before eachuse daily
Every100 hours
Every200 hours
Every500 hours or yearly
1
In dusty conditions or when airborne debris is present, clean more often.

16
Service
HOWTORAKE ASANDTRAP
HOWTORAKEASANDTRAP
View bunker to determine the most efficient pattern to follow so that rake pattern and configuration of bunker
will flow in same general direction and look attractive.
Enter bunker at its lowest point. Perhaps drain area or another point where “lip” of the trap is minimal.
Operate at 2-4 m.p.h. (3-6.5 kph) for best raking results. Control speed with hydraulic pedal.
Oncefullyinsidebunker, lower rear rake and proceed forward as described above.
First pass should be directly down center of trap. This helps avoid ex-
tremely sharp turns that will spoil sands’ appearance.
Onceat far end, turn machine and
drivedownone side
oftrapand come
back up other side.
Grassorother material
may build up on rake
tines as machine passes
“enter/exit”pointinFigure
1. Lift rake briefly while still
movingforward.
Do not rake closer than 6" (15
cm) to edge of trap.
Do not rake slopes in trap. The
weightof machine will pull sanddown.
Use cultivator or other center mounted accessories only as necessary for compacted sand. Frequent use will
leave sand too soft and objectionable to some golfers.
Use front mounted plow to push sand to desired locations within trap.
After exiting trap, secure machines in accordance with practices described in this manual. Rake trap edges,
slopes and “enter /exit” area with a hand rake.
After returning to maintenance area, thoroughly clean machine, check fluids, and lubricate as advised in this
manual.

17
Diagrams
PARTS MANUALS AVAILABLE ONLINE AT smithco.com
BATTERY
BATTERY
Batteries normally produce explosive gases which can cause personal injury. Do not allow flames, sparks or any ignited
object to come near the battery. When charging or working near battery, always shield your eyes and always provide
proper ventilation.
Battery cable should be disconnected before using "Fast Charge".
Charge battery at 15 amps for 10 minutes or 7 amps for 30 minutes. Do not exceed the recommended charging rate. If
electrolyte starts boiling over, decrease charging.
Always remove grounded (-) battery clamp first and replace it last. Avoid hazards by:
1. Filling batteries in well-ventilated areas.
2. Wear eye protection and rubber gloves.
3. Avoid breathing fumes when electrolyte is added.
4. Avoid spilling or dripping electrolyte.
Battery Electrolyte is an acidic solution and should be handled with care. If electrolyte is splashed on
any part of your body, flush all contact areas immediately with liberal amounts of water. Get medical
attention immediately.
JUMP STARTING
Use of booster battery and jumper cables. Particular care should be used when connecting a booster
battery. Use proper polarity in order to prevent sparks.
To jump start (negative grounded battery):
1. Shield eyes.
2. Connect ends of one cable to positive (+) terminals
of each battery, first (A) then (B).
3. Connect one end of other cable to negative (-)
terminal of "good" battery (C).
4. Connect other end of cable (D) to engine block on
unit being started (NOT to negative (-) terminal of
battery)
To prevent damage to other electrical components on unit
being started, make certain that engine is at idle speed
before disconnecting jumper cables.

18
Business name and full address of the manufacturer ▪ Търговско име и пълен адрес на производителя ▪ Obchodní jméno a plná adresa
výrobce ▪ Producentens firmanavn og fulde adresse ▪ Bedrijfsnaam en volledig adres van de fabrikant ▪ Tootja ärinimi ja täielik aadress ▪
Valmistajan toiminimi ja täydellinen osoite ▪ Nom commercial et adresse complète du fabricant ▪ Firmenname und vollständige Adresse des
Herstellers ▪ Επωνυμία και ταχυδρομική διεύθυνση κατασκευαστή ▪ A gyártó üzleti neve és teljes címe ▪ Ragione sociale e indirizzo completo
del fabbricante ▪ Uzņēmuma nosaukums un pilna ražotāja adrese ▪ Verslo pavadinimas ir pilnas gamintojo adresas ▪ Isem kummerċjali u
indirizz sħiħ tal-fabbrikant ▪ Nazwa firmy i pełny adres producenta ▪ Nome da empresa e endereço completo do fabricante ▪ Denumirea
comercială şi adresa completă a producătorului ▪ Obchodný názov a úplná adresa výrobcu ▪ Naziv podjetja in polni naslov proizvajalca ▪
Nombre de la empresa y dirección completa del fabricante ▪ Tillverkarens företagsnamn och kompletta adress
Smithco Inc.
34 West Avenue
Wayne, PA USA
19087-3311
Product Code ▪ Код на продукта ▪ Kód výrobku ▪ Produktkode ▪ Productcode ▪ Toote kood ▪ Tuotekoodi ▪ Code produit ▪ Produktcode ▪
Κωδικός προϊόντος ▪ Termékkód ▪ Codice prodotto ▪ Produkta kods ▪ Produkto kodas ▪ Kodiċi tal-Prodott ▪ Kod produktu ▪ Código do Produto ▪
Cod
p
rodus ▪ Kód v
ý
robku ▪ Oznaka
p
roizvoda ▪ Códi
g
o de
p
roducto ▪ Produktkod
ϰϯͲϱϬϬ
Machine Name ▪ Наименование на машината ▪ Název stroje ▪ Maskinnavn ▪ Machinenaam ▪ Masina nimi ▪ Laitteen nimi ▪ Nom de la machine
▪ Maschinenbezeichnung ▪ Ονομασία μηχανήματος ▪ Gépnév ▪ Denominazione della macchina ▪ Iekārtas nosaukums ▪ Mašinos pavadinimas ▪
Isem tal-Magna ▪ Nazwa urządzenia ▪ Nome da Máquina ▪ Numele echipamentului ▪ Názov stroja ▪ Naziv stroja ▪ Nombre de la máquina ▪
Maskinens namn
Smithco Diesel Super Star
Designation ▪ Предназначение ▪ Označení ▪ Betegnelse ▪ Benaming ▪ Nimetus ▪ Tyyppimerkintä ▪ Pažymėjimas ▪ Bezeichnung ▪
Χαρακτηρισμός ▪ Megnevezés ▪ Funzione ▪ Apzīmējums ▪ Lithuanian ▪ Denominazzjoni ▪ Oznaczenie ▪ Designação ▪ Specificaţie ▪ Označenie ▪
Namen stro
j
a ▪ Descri
p
ción ▪ Betecknin
g
ƵŶŬĞƌZĂŬĞ
Serial Number ▪ Сериен номер ▪ Sériové číslo ▪ Serienummer ▪ Serienummer ▪ Seerianumber ▪ Valmistusnumero ▪ Numéro de série ▪
Seriennummer ▪ Σειριακός αριθμός ▪ Sorozatszám ▪ Numero di serie ▪ Sērijas numurs ▪ Serijos numeris ▪ Numru Serjali ▪ Numer seryjny ▪
Número de Série ▪ Număr de serie ▪ Sériové číslo ▪ Seri
j
ska številka ▪ Número de serie ▪ Serienummer
ϭϰϱϬϬ
Engine ▪ Двигател ▪ Motor ▪ Motor ▪ Motor ▪ Mootor ▪ Moottori ▪ Moteur ▪ Motor ▪ Μηχανή ▪ Modulnév ▪ Motore ▪ Dzinējs ▪ Variklis ▪ Saħħa Netta
Installata ▪ Silnik ▪ Motor ▪ Motor ▪ Motor ▪ Motor ▪ Motor ▪ Motor ͲϳϮϮŝĞƐĞů<ƵďŽƚĂŶŐŝŶĞ
Net Installed Power ▪ Нетна инсталирана мощност ▪ Čistý instalovaný výkon ▪ Installeret nettoeffekt ▪ Netto geïnstalleerd vermogen ▪
Installeeritud netovõimsus ▪ Asennettu nettoteho ▪ Puissance nominale nette ▪ Installierte Nettoleistung ▪ Καθαρή εγκατεστημένη ισχύς ▪ Nettó
beépített teljesítmény ▪ Potenza netta installata ▪ Paredzētā tīkla jauda ▪ Grynoji galia ▪ Wisa’ tal-Qtugħ ▪ Moc zainstalowana netto ▪ Potência
instalada ▪ Puterea instalată netă ▪ Čistý inštalovaný výkon ▪ Neto vgrajena moč ▪ Potencia instalada neta ▪ Nettoeffekt
ϭϴŬt
Conforms to Directives ▪ В съответствие с директивите ▪ Splňuje podmínky směrnic ▪ Er i overensstemmelse med direktiver ▪ Voldoet aan de
richtlijnen ▪ Vastab direktiividele ▪ Direktiivien mukainen ▪ Conforme aux directives ▪ Entspricht Richtlinien ▪ Ακολουθήστε πιστά τις Οδηγίες ▪
Megfelel az irányelveknek ▪ Conforme alle Direttive ▪ Atbilst direktīvām ▪ Atitinka direktyvų reikalavimus ▪ Valutazzjoni tal-Konformità ▪
Dyrektywy związane ▪ Cumpre as Directivas ▪ Respectă Directivele ▪ Je v súlade so smernicami ▪ Skladnost z direktivami ▪ Cumple con las
Directivas ▪ U
pp
f
y
ller direktiv
ϮϬϬϲ ϰϮ 
ϮϬϬϬ ϭϰ ŶŶĞdžs/WĂƌƚϭ
Conformity Assessment ▪ Оценка за съответствие ▪ Hodnocení plnění podmínek ▪ Overensstemmelsesvurdering ▪ Conformiteitsbeoordeling ▪
Vastavushindamine ▪ Vaatimustenmukaisuuden arviointi ▪ Evaluation de conformité ▪ Konformitätsbeurteilung ▪ ∆ιαπίστωση Συμμόρφωσης ▪
Megfelelőség-értékelés ▪ Valutazione della conformità ▪ Atbilstības novērtējums ▪ Atitikties įvertinimas ▪ Livell tal-Qawwa tal-Ħoss Imkejjel ▪
Ocena zgodności ▪ Avaliação de Conformidade ▪ Evaluarea conformităţii ▪ Vyhodnotenie zhodnosti ▪ Ocena skladnosti ▪ Evaluación de
conformidad ▪ Bedömnin
g
av överensstämmelse
ϮϬϬϲ ϰϮ ŶŶĞdžs///
>Zd/KEK&KE&KZD/dzඵʪʫʶʸʤˀʤˉʰ˔ʯʤˁˎʽ˃ʦʫ˃ˁ˃ʦʰʫඵ ZK,>aE1K^,K ඵKsZE^^dDD>^^Z<>Z/E'ඵ
KE&KZD/d/d^sZ<>Z/E'ඵs^dsh^<>Zd^/KKEඵsd/Dh^dEDh</^hh^s<hhdh^ඵ>Zd/KE
KE&KZD/dඵ<KE&KZD/dd^Z<>ZhE'ඵȴȸȿёɇȸɇɉɀɀɃɆɌёɇȸɇඵD'&>>S^'/Ez/>d<Kdඵ/,/Z/KE/
KE&KZD/dඵd/>^d5^<>Z/:ඵd/d/<d/^<>Z/:ඵ/<:Z:KE/d>Ͳ<KE&KZD/dඵ<>Z:
'KEK_/ඵ>ZKKE&KZD/ඵ>ZԐ/KE&KZD/ddඵsz,>^E/K,Kඵ/:sK^<>EK^d/
ඵ>Z/MEKE&KZD/ඵ<>Zd/KEKDPsZE^^dDD>^
Measured Sound Power Level ▪ Измерено ниво на звукова мощност ▪ Naměřený akustický výkon ▪ Målte lydstyrkeniveau ▪ Gemeten
geluidsniveau ▪ Mõõdetud helivõimsuse tase ▪ Mitattu äänitehotaso ▪ Niveau de puissance sonore mesuré ▪ Gemessener Schalldruckpegel ▪
Σταθμισμένο επίπεδο ηχητικής ισχύος ▪ Mért hangteljesítményszint ▪ Livello di potenza sonora misurato ▪ Izmērītais skaņas jaudas līmenis ▪
Išmatuotas garso stiprumo lygis ▪ Livell tal-Qawwa tal-Ħoss Iggarantit ▪ Moc akustyczna mierzona ▪ Nível sonoro medido ▪ Nivelul măsurat al
puterii acustice ▪ Nameraná hladina akustického výkonu ▪ Izmerjena raven zvočne moči ▪ Nivel de potencia sonora medido ▪ Uppmätt
l
j
udeffektsnivå
ϵϲĚ;Ϳ>ǁĂ
Guaranteed Sound Power Level ▪ Гарантирано ниво на звукова мощност ▪ Garantovaný akustický výkon ▪ Garanteret lydstyrkeniveau ▪
Gegarandeerd geluidsniveau ▪ Garanteeritud helivõimsuse tase ▪ Taattu äänitehotaso ▪ Niveau de puissance sonore garanti ▪ Garantierter
Schalldruckpegel ▪ Εγγυημένο επίπεδο ηχητικής ισχύος ▪ Szavatolt hangteljesítményszint ▪ Livello di potenza sonora garantito ▪ Garantētais
skaņas jaudas līmenis ▪ Garantuotas garso stiprumo lygis ▪ Livell tal-Qawwa tal-Ħoss Iggarantit ▪ Moc akustyczna gwarantowana ▪ Nível sonoro
farantido ▪ Nivelul garantat al puterii acustice ▪ Garantovaná hladina akustického výkonu ▪ Zajamčena raven zvočne moči ▪ Nivel de potencia
sonora
g
arantizado ▪ Garanterad l
j
udeffektsnivå
ϵϳĚ;Ϳ>ǁĂ
Conformity Assessment Procedure (Noise) ▪ Оценка за съответствие на процедурата (Шум) ▪ Postup hodnocení plnění podmínek (hluk) ▪
Procedure for overensstemmelsesvurdering (Støj) ▪ Procedure van de conformiteitsbeoordeling (geluid) ▪ Vastavushindamismenetlus (müra) ▪
Vaatimustenmukaisuuden arviointimenettely (Melu) ▪ Procédure d’évaluation de conformité (bruit) ▪ Konformitätsbeurteilungsverfahren
(Geräusch) ▪ ∆ιαδικασία Αξιολόγησης Συμμόρφωσης (Θόρυβος) ▪ Megfelelőség-értékelési eljárás (Zaj) ▪ Procedura di valutazione della
conformità (rumore) ▪ Atbilstības novērtējuma procedūra (troksnis) ▪ Atitikties įvertinimo procedūra (garsas) ▪ Proċedura tal-Valutazzjoni tal-
Konformità (Ħoss) ▪ Procedura oceny zgodności (poziom hałasu) ▪ Processo de avaliação de conformidade (nível sonoro) Procedura de
evaluare a conformităţii (zgomot) ▪ Postup vyhodnocovania zhodnosti (hluk) ▪ Postopek za ugotavljanje skladnosti (hrup) ▪ Procedimiento de
evaluación de conformidad (ruido) ▪ Procedur för bedömning av överensstämmelse (buller)
ϮϬϬϬ ϭϰ ŶŶĞdžs/WĂƌƚϭ
UK Notified Body for 2000/14/EC ▪ Нотифициран орган в Обединеното кралство за 2000/14/ЕО ▪ Úřad certifikovaný podle směrnice č.
2000/14/EC ▪ Det britiske bemyndigede organ for 2001/14/EF ▪ Engels adviesorgaan voor 2000/14/EG ▪ Ühendkuningriigi teavitatud asutus
direktiivi 2000/14/EÜ mõistes ▪ Direktiivin 2000/14/EY mukainen ilmoitettu tarkastuslaitos Isossa-Britanniassa ▪ Organisme notifié concernant la
directive 2000/14/CE ▪ Britische benannte Stelle für 2000/14/EG ▪ Κοινοποιημένος Οργανισμός Ηνωμένου Βασιλείου για 2000/14/ΕΚ ▪
2000/14/EK – egyesült királyságbeli bejelentett szervezet ▪ Organismo Notificato in GB per 2000/14/CE ▪ 2000/14/EK AK reģistrētā organizācija
▪ JK notifikuotosios įstaigos 2000/14/EC ▪ Korp Notifikat tar-Renju Unit għal 2000/14/KE ▪ Dopuszczona jednostka badawcza w Wielkiej Brytanii
wg 2000/14/WE ▪ Entidade notificada no Reino Unido para 2000/14/CE ▪ Organism notificat în Marea Britanie pentru 2000/14/CE ▪ Notifikovaný
orgán Spojeného kráľovstva pre smernicu 2000/14/ES ▪ Britanski priglašeni organ za 2000/14/ES ▪ Cuerpo notificado en el Reino Unido para
2000/14/CE ▪ Anmält organ för 2000/14/EG i Storbritannien
^ŵŝƚŚĐŽtĞƐƚ/ŶĐ
ϮϬϬtĞƐƚWŽƉůĂƌǀĞŶĞ
ĂŵĞƌŽŶt/ϱϰϴϮϮh^
Operator Ear Noise Level ▪ Оператор на нивото на доловим от ухото шум ▪ Hladina hluku v oblasti uší operátora ▪ Støjniveau i førers
ørehøjde ▪ Geluidsniveau oor bestuurder ▪ Müratase operaatori kõrvas ▪ Melutaso käyttäjän korvan kohdalla ▪ Niveau de bruit à hauteur des
oreilles de l’opérateur ▪ Schallpegel am Bedienerohr ▪ Επίπεδο θορύβου σε λειτουργία ▪ A kezelő fülénél mért zajszint ▪ Livello di potenza
sonora all’orecchio dell’operatore ▪ Trokšņa līmenis pie operatora auss ▪ Dirbančiojo su mašina patiriamo triukšmo lygis ▪ Livell tal-Ħoss fil-
Widna tal-Operatur ▪ Dopuszczalny poziom hałasu dla operatora ▪ Nível sonoro nos ouvidos do operador ▪ Nivelul zgomotului la urechea
operatorului ▪ Hladina hluku pôsobiaca na sluch operátora ▪ Raven hrupa pri ušesu upravljavca ▪ Nivel sonoro en el oído del operador ▪
L
j
udnivå vid förarens öra
96dB(A)Lwa (2006/42/EC)
