The off-the-vehicle wheel balancer is designed for dynamic and static balancing of
motorcycle wheels and secondarily for the wheels of cars and light trucks, that fall within
the limits stated in the technical speci•cations. This is a high accuracy measuring device.
Handle with care.
M O T O R C Y C L E W H E E L B A L A N C E R
EEWB333B

UPDATING GUIDE :
November 2019
Release B
- Optional Accessories updating - This document replaces previous ZEEWB333B06 - PCN:19G0222

3
EEWB333B
IMPORTANT SAFETY INSTRUCTIONS
•Basic safety precau•ons should always be followed.
Wear safety goggles.
Read and follow all Instruc!ons and safety messages.
Wear appropriate clothing; keep hair and loose "#ng clothing, your hands
and all parts of your body away from moving parts.
Eye injury or other bodily injury can result from flying par•cles or entanglement with
moving parts.
•Electric powered wheel balancer can cause shocks, fire or explosion.
Do not operate the wheel balancer with a damaged power cord or plug.
Do not use on wet surfaces, outdoors or expose the balancer to rain.
Unplug the power cord when the balancer is not in use.
If an extension cord is used, make sure that it is in good condi!on and that the cur-
rent ra!ng is 8 Amps or higher.
Use only in well ven!lated areas.
Do not operate the balancer in the vicinity of $ammable liquids (gasoline) or below
grade or in an explosive atmosphere.
Electric shock, fire or explosion can cause serious injury or death.
•Misuse of this wheel balancer can result in accidents.
Do not allow untrained or unauthorized personnel to operate the balancer.
Do not disable or bypass the hood safety interlock system.
Always securely !ghten the quick nut that holds the wheel in place during the
moun!ng procedure.
Improperly balanced wheels can cause damage to the vehicle or automo•ve acci-
dents. Personal injury can result from altera•on to the balancer or improper use.

4EEWB333B
Table of Contents
Safety Instructions ..........................................................................................................................3
1.0 Introduction.....................................................................................................................................5
1.1 Safety Notice ..................................................................................................................................5
1.2 Balancer Application .......................................................................................................................5
1.3 EEWB333B Speci!cations.............................................................................................................6
1.4 Features..........................................................................................................................................6
1.5 Standard Accessories.....................................................................................................................7
1.6 Optional Accessories ......................................................................................................................7
1.7 Dimensions of the Machine ............................................................................................................8
1.8 Required Installation Area...............................................................................................................8
1.9 Installation Instructions ...................................................................................................................8
2.0 Balancer Installation .......................................................................................................................8
2.1 Electric Installation..........................................................................................................................9
3.0 Terminology ..................................................................................................................................10
3.1 The Input Panel ............................................................................................................................10
3.2 The Cabinet ..................................................................................................................................11
4.0 Operation of The Balancer............................................................................................................12
4.1 Check List - Inspection .................................................................................................................12
4.2 Wheel Mounting............................................................................................................................12
4.3 Mode Selection.............................................................................................................................14
4.3.1 Weight Placement Modes.............................................................................................................14
4.3.2 Motorcycle Mode ..........................................................................................................................14
4.3.3 SAPE arm positions for Alu weights placement............................................................................15
4.4 Selecting Operator Preferences ...................................................................................................16
4.4.1 Fine Balancing Mode....................................................................................................................16
4.4.2 Ounce/Grams Conversion ............................................................................................................16
4.4.3 Rim Diameter In Millimeters..........................................................................................................16
4.5 Enter Rim Parameters .................................................................................................................16
4.5.1 Rim Distance (offset) ....................................................................................................................16
4.5.2. Measure/Enter rim width...............................................................................................................16
4.5.3 Manual Parameter Entry...............................................................................................................17
4.5.3.0 Manual Rim Diameter Entry..........................................................................................................17
4.5.3.1 Manual Distance Entry .................................................................................................................17
4.6 Easy Alu Function.........................................................................................................................17
4.6.1 Automatic rim Dimension reading and Alu P Mode Selection.......................................................17
4.7 Spinning the Wheel.......................................................................................................................18
5.0 Correction of The Imbalance ........................................................................................................19
5.1 Alu P Weights Application with the SAPE arm..............................................................................20
6.0 Spoke Balancing Mode.................................................................................................................21
6.1 Split Weight Mode (SWM) ............................................................................................................21
7.0 User Calibration............................................................................................................................22
8.0 User Functions..............................................................................................................................23
8.1 Data Recall ...................................................................................................................................23
8.2 Weight Unit Toggle Mode..............................................................................................................24
8.3 Dimension Unit Toggle Mode........................................................................................................24
9.0 Optimization/Weight Minimization.................................................................................................25
10.0 Trouble Shooting ..........................................................................................................................33
10.1 System Messages ........................................................................................................................34
10.1.1 C Codes........................................................................................................................................34
10.1.2 E Codes........................................................................................................................................36
10.1.3 H Codes - Warning .......................................................................................................................38
11.0 Maintenance .................................................................................................................................38
Warranty/Service and Repair

5
EEWB333B
1.0 INTRODUCTION
Congratulations on purchasing the EEWB333B computer wheel balancer. This wheel balancer is designed for
ease of operation, accuracy, reliability and speed. With a minimum of maintenance and care your wheel balancer
will provide many years of trouble-free operation.
Instructions on use, maintenance and operational requirements of the machine are covered in this manual.
STORE THIS MANUAL IN A SAFE PLACE FOR FUTURE REFERENCE.
READ THIS MANUAL THOROUGHLY BEFORE USING THE MACHINE.
1.1 SAFETY NOTICE
This manual is a part of the balancer product.
Read carefully all warnings and instructions of this manual since they provide important information concern-
ing safety and maintenance.
1.2 BALANCER APPLICATION
The Snap-on wheel balancer model EEWB333B is intended to be used as equipment to balance motorcycle,
car and light truck wheels within the following range:
Maximum wheel diameter : 42” (1067mm)
Maximum wheel width : 20” (508mm)
Maximum wheel weight : 120 lbs / 54,4 kg
This equipment is to be only used in the application for which it is specifically designed.
Any other use shall be considered as improper and abusive.
The manufacturer shall not be considered liable for possible damages caused by improper, wrong, or abusive
use of this equipment.

6EEWB333B
1.3 EEWB333B SPECIFICATIONS
Digital wheel balancer for motorcycles wheels.
Weight Imbalance Accuracy 0.10 oz. / 2.8 grams
Weight Placement Resolution ± 0.7 degrees
Weight Imbalance Resolution:
Roundoff Mode 0.25 oz. / 5 grams
Non-Roundoff Mode 0.05 oz. / 1 gram
Max. Shaft Weight Capacity 154 lbs / 70 kg
Max.Tire Diameter 42” / 1067 mm
Rim Width Capacity 3”-20” / 76 mm - 508 mm
Rim Diameter Capacity 8”-30” / 203 mm-762 mm
Balancing Cycle Time. 15 seconds
Shaft Speed at calculation 100 RPM
Electrical 115vac, 1ph, 60Hz, 4A
Required Work Area 52” x 48” (1321 x1219 mm)
Shipping Weight, complete 325 lbs/147 kg
Shipping Dimensions 52.75”h 41.5”w 37”d
Machine Dimensions 54”h 51”w 48.5”d
Actual Weight with Accessories 309 lbs / 140 kg
Operating Temperature Range 32-122F / 0-50C
1.4 FEATURES
ACCURACY
• Weight placement accuracy is ± 0.7°
• Weight imbalance accuracy to 2.8 grams.
• Self test check with every power up cycle.
• Fast operator calibration.
• Pre-programmed Error Codes indicate procedural
errors or safety concerns.
SPEED and DURABILITY
• Automatic distance and diameter entry. Simply
touch the SAPE arm to the wheel, the distance and
diameter parameters are automatically entered.
• Specialized adaptor provides an accurate balance
and minimizes errors due to mounting.
• Adaptor comes complete with 14mm shaft, 3/4 inch
adaptors, cones and spacers.
• Clamps tire to keep it true to balancer shaft center
without movement.
• Quick cycle time of 15 seconds.
• Automatic recalculation if weight positions are
changed. No need for re-spinning the wheel.
• Weight pocket storage tray.
• Easy-to-Read Data display.
• Easy weight tray access.
SOFTWARE VERSATILITY
• Both dual weight Dynamic and single weight Static
capability.
• Match Balance program for reducing weight re-
quired.
• Built-in spin counter for monitoring balancer pro-
ductivity.
• Service code access to all Balancer electronic
functions for fast, easy diagnosis.
• Operator selectable round-off mode.
• Easy Alu enter the rim dimensions and automati-
cally select a balancing mode.
• 5 Aluminum Modes
• 2 Alu-S modes
• Hidden Weight (Spoke) mode
• Ounce / Gram toggle from front panel
• Multiple operator feature allows several
operators to recall wheel parameters.
NOTE: Machine starts in Motorcycle Mode.

7
EEWB333B
1.5 STANDARD ACCESSORIES
Standard accessories included with the EEWB333B
are:
•8430-02
Caliper M/C
•WWPR13A
Weight Pliers
•EAA0260D80A
Motorcycle Adaptor
with 14mm shaft
long
- EAM0005D62A
SAPE Extension
- 8-01550A
Hooked Wrench
•EAA0277D22A
Harley Davidson 3/4” Shaft
1.6 OPTIONAL ACCESSORIES
•EAA0255J33A
40 mm Shaft Upgrade Kit
- EAM0003J08A Cone 3.3–5.2”
- EAM0003J07A Cone 2.8–3.9”
- EAM0003J06A Cone 2.2–3.3”
- EAM0003J05A Cone 1.7–2.5”
- EAC0058D07A Pressure Cup
- EAC0058D15A Soft Protector Ring
- EAC0058D08A Pressure Disk
- EAA0263G66A Quick Nut
- EAM0021D90A 40mm Stub Shaft
•EAK0341G68A
Plastic Protection
for Motorcycle Adaptor Arm

8EEWB333B
PRE-INSTALLATION CONSIDERATIONS
1.7 DIMENSIONS OF THE MACHINE
Figure 4
Dimensions for the installation.
1.8 REQUIRED INSTALLATION AREA
Make sure that from the operating position the user
can see all of the machine and the surrounding area.
The operator should prevent non authorized persons
and/or objects from entering the area which may create
potential hazards.
The machine should be installed on a stable level floor.
Do not install the machine on a uneven floor.
If the balancer is to be installed on a raised floor, the
floor must have a capacity of at least 110lbs per sq ft.
(5000 N/m² - 500 kg/m²).
It is not required to secure the machine to the floor.
Install the machine in a dry, covered area.
The installation of the machine requires a working area
of at least 60” x 48” (1524mm x 1219 mm) (Figure 5).
NOTE: Do not install the balancer below grade level
or in a pit.
Figure 5 - Recommended Work Area
1.9 INSTALLATION INSTRUCTIONS
CAUTION! CAREFULLY REMOVE THE BALANCER
FROM THE PALLET.
Remove the hardware that secures the machine
to the pallet and slide the balancer onto the floor
where it is to be installed.
THE UNIT IS HEAVY AND THE WEIGHT IS NOT
EVENLY DISTRIBUTED.
DO NOT LIFT THE BALANCER BY THE SHAFT.
DROPPING THE UNIT MAY CAUSE PERSONAL
INJURY OR EQUIPMENT DAMAGE.
!!IMPORTANT!!!
Machines are shipped calibrated from the
factory. Do not attempt field calibration
unless balance results deem calibration
as necessary.
2.0 BALANCER INSTALLATION
Mounting the Shaft Adapter
IMPORTANT!
CHECK THAT THE SURFACES ARE PERFECTLY
CLEANAND NOT DAMAGED.AN INCORRECT MOUNT-
ING MAY RESULT IN SIGNIFICANT IMBALANCE.
A. (Figure 6)
Fit the Flange (A) and lock it with the bolts (B). Mount
the threaded shaft (C) onto the arbor of the balancer.
Tighten firmly, but do not exceed 70 inch-lbs.
60”
48”

9
EEWB333B
2.1 ELECTRIC INSTALLATION
ANY ELECTRICAL WIRING MUST BE PER-
FORMED BY LICENSED PERSONNEL.
ALL SERVICE MUST BE PERFORMED BY AN
AUTHORIZED SERVICE TECHNICIAN.
Check on the plate of the machine that the electrical
speci!cations of the power source are the same as
the machine. The machine uses 115VAC, 60Hz, 1Ph,
4.0 Ampere.
NOTE:
Any electrical outlet installation must be verified
by a licensed electrician before connecting the
balancer.
NOTE:
This machine performs a self-test routine on start-
up. There will be a delay of several seconds before
the display is activated.
• Plug the power output plug (1,Figure 8a) of the adapter
into the power socket of the balancer (2).
• Plug the adapter into the mains power outlet.
Figure 6
B. Mount the SAPE Arm extension (1,Figure 7) to
the SAPE disc (2,Figure 7).
Figure 7
C. Install the accessory pins (Figure 8). Tighten !rmly.
Figure 8
D. Place cones and other accessories onto the acces-
sory pins.
Figure 8a
Rear side
A
B
C
2
1
2
1

10 EEWB333B
3.0 TERMINOLOGY
Before using the wheel balancer it is suggested that
you become familiar with the terminology and features
of the machine’s components. Refer to Figures from
9 to 10 for identi!cation and location.
Figure 9
Figure 9a
1
2
3
4
5
6
7
8
9
3.1 THE INPUT PANEL
INPUT PANEL - Figure 9a
1. Diameter key with indicator
Press to select “rim diameter” mode. The diameter
indicator will light up, the unit will beep. The current
value will be shown on the display and can be edited.
2. Width key with indicator
Press to select “rim width” mode. The width indicator
will light up, the unit will beep. The current value will
be shown on the display and can be edited.
3. Offset key with indicator
Press to select “offset” mode. The offset indicator
will light up, the unit will beep. The current value will
be shown on the display and can be edited.
Pressing the offset key in HWM enables the operator
to enter the plane reference points again.
4. + key
To increase an input value (e.g. rim diameter, offset,
rim width).
Hold down to change the value shown automatically.
5. Enter key
Press to con!rm input (dimension, mode) or save
“user” settings. The unit will beep.
6. - key
To decrease an input value (e.g. rim width, offset,
rim diameter).
Hold down to change the value shown automatically.
7. MODE key with indicator
Press to scroll along the special modes. The MODE
key indicator will light up, the unit will beep.
8. Fine key
Press to toggle the read-out accuracy between
roundoff mode (0.25 oz) and non-roundoff mode
(0.05 oz). The unit will beep. Combined with the
“MODE” key, it starts the calibration function.
9. ALU Weight Selection
Press to select the required weight application mode
(weight mode), the unit will beep. Combined with the
“MODE” key, it starts the “user” function.
10.Stop key
Press to stop a spinning wheel.
10
USER INTERFACE - Figure 9
1. Position Indicator LEDs - Displays the location for
wheel weight placement.
2. Inside Weight Amount and Function Display Win-
dow Shows inside or left weight amount and vari-
ous operation messages.
3. Outside Weight Amount and Function Display
Window Shows outside or right weight amount and
various operation messages.
4. Function Indicator LEDs - indicating active functions
and weights placement positions. They allow to set
the proper work"ow.
5. Input panel - it allow the main user selections.
1
2 3
4
5
