Snapper 63305 User manual

Parts Manual fo
r
Revision 1,
48" BAFFLE KIT (COMMERCIAL RIDER)
COPYRIGHT
©
2005
McDonough, GA, 30253 U.S.A.
TP 400-5033-1-AT-N
8/8/2005 Manual No. 7063305
SNAPPER PRODUCTS, INC.
ALL RIGHTS RESERVED.
MODEL
63305
7063305

Table Of Content
s
TP 400-5033-1-AT-N
Manual No. 706330548" BAFFLE KIT (COMMERCIAL RIDER)
3
PAGE GROUP
4ACCESSORY, 48" Baffle Kit

ACCESSORY, 48" Baffle Kit
TP 400-5033-1-AT-N
Manual No. 7063305 48" BAFFLE KIT (COMMERCIAL RIDER)
4

ACCESSORY, 48" Baffle Kit
Footnotes:
TP 400-5033-1-AT-N
Manual No. 706330548" BAFFLE KIT (COMMERCIAL RIDER)
5
Part No Descri
p
tionItem Qt
y
Note
-- 7063305 KIT, 48” Baffle
1 7075358 1 BAFFLE, Discharge, 48” Deck
2 7090361 3 SCREW, 5/16-18 x 5/8” Hex Washer Self-Tap
3 7058566 1 WELDMENT, Baffle, 48” Deck
4 7091575 2 NUT, 5/16-18 Hex Center Lock, GR5 or B
5 7091585 2 NUT, 3/8-16 Hex Center Lock, GR5 or B
6 7091790 2 BOLT, 3/8-16 x 1-1/4” Square Neck Carriage, GR5
7 7013847 2 RETAINER, 3/8” Bolt
8 7075362 1 PULLEY, Driven 48” Deck for use on NZM19480KWV
(Series 0) model only
9 7075771 3 BLADE, 16.5”
-- 7075762 1 SHEET, Instruction, 48”/52” Baffle Kit not shown

Parts Manual fo
r
48" BAFFLE KIT (COMMERCIAL RIDER)
IT IS THE POLICY OF SNAPPER TO IMPROVE ITS PRODUCTS
WHENEVER IT IS POSSIBLE AND PRACTICAL TO DO SO. WE
RESERVE THE RIGHT TO MAKE CHANGES OR ADD IMPROVEMENTS
AT ANY TIME WITHOUT INCURRING ANY OBLIGATION TO MAKE
SUCH CHANGES ON PRODUCTS MANUFACTURED PREVIOUSLY.
Revision 1,
COPYRIGHT
©
2005
TP 400-5033-1-AT-N
8/8/2005 Manual No. 7063305
SNAPPER PRODUCTS, INC.
ALL RIGHTS RESERVED.
McDonough, GA, 30253 U.S.A.
