Parts Manual fo
r
26 & 27 HP HYDRO DRIV
E
500
Z
MID-MOUNT ZTR
Revision: K 3/11/2011
Briggs & Stratton Yard Power Products Group
Manual No. 5101455
535 Macon Road
McDonough, GA, 30253 U.S.A.
800-935-2967
Descri
p
tionModel No.
5900731 500ZB2648
5900982 500ZB2748

Not for
Reproduction

Not for
Reproduction
Table Of Content
s
TP 400-5348-K-MZ-N
26 & 27 HP HYDRO DRIVE
500Z 3
Manual No. 5101455
PAGE GROUP
4Wheel & Tire Group
6Main Frame & Front Casters Group
8Seat Mount & Floor Group
10 Fuel Tank & Mount Group
12 Evap Canister Group
14 Engine & PTO Group
16 Motion Control Group
18 Parking Brake Group
20 Pump Drive Group
22 Hydraulic Group
24 Rear Bumper Group
26 Decals - Brand & Model
28 Decals - Safety & Operational
30 Deck Lift Group
32 48" Mower Deck Group - Pulleys, Belts & Idler Arm
34 48" Mower Deck Group - Housing, Covers, Spindles & Blades
36 48" Mower Deck Group - Hanger Chains
38 48" Mower Deck Group - Rollers
40 Instrument & Control Panel Group
42 Wiring Schematic - 26HP & 27HP Briggs & Stratton

Not for
Reproduction
Manual No. 5101455 26 & 27 HP HYDRO DRIVE
500Z
4
Wheel & Tire Group

Not for
Reproduction
Footnotes:
Manual No. 510145526 & 27 HP HYDRO DRIVE
500Z 5
Wheel & Tire Group
Part No Descri
p
tionItem Qty
1 5101418 2 WHEEL, CASTER, 11 X 4.0-5 SILVER BEAD LO
2 2172353 2 VALVE STEM & CAP ASSEMBLY (SV)
3 5101418X1 4 BEARING, CASTER WHEEL, 11 X 4.0 - 5 BEAD LOCK (SV) (Two per wheel)(Service Part for #
5101418)
4 5021043 4 BEARING, RETAINER (SV) (Two per wheel)
5 5045996 2 CASTER AXLE DDSH
6 5025158 2 WASHER, 1/2 SAE
7 5025017X52 2 BOLT, 1/2-13 X 6-1/2 GD8 YZ
8 5025396 2 NUT, 1/2-13 HEX NYLOCK FLANGE
9 5101375 2 TIRE ASSEMBLY, REAR, 20 X 10.0 X 10
10 5020601 8 NUT, 1/2-20, FOR WHEEL BOLT SILVER
11 5101418X2 2 WHEEL FOR 11X4.0-5 TIRE ASSM (SV) (Service Part for # 5101418)
12 5101345X1 2 TIRE, 20 X 10 - 10 TURFMASTER (SV) (Service Part for # 5101375)
13 5023095X2 2 WHEEL ASSEMBLY 20 X 8.0 X 10 (SV) (Service Part for # 5101375)

Not for
Reproduction
Manual No. 5101455 26 & 27 HP HYDRO DRIVE
500Z
6
Main Frame & Front Casters Group

Not for
Reproduction
Footnotes:
Manual No. 510145526 & 27 HP HYDRO DRIVE
500Z 7
Main Frame & Front Casters Group
Part No Descri
p
tionItem Qty
1 5025457 2 BOLT, 1/4-28 X 1/2, GD5 YZ
2 5402539D 2 WELD, CASTER YOKE, IS500Z
3 5020884 4 BEARING, TAPERED ROLLER, 1"
4 5021072 2 SEAL, GREASE
5 5025449 4 WASHER, BELLEVILLE - 1.500 X .755
6 5025448 2 NUT, 3/4-16, HEX JAM NYLON LOCK
7 5100882 2 CAP, CASTER SPINDLE, LOW PROFILE
8 5402841D 1 WELD, MAINFRAME, SNAPPER PRO 38-44 - RED
9 5100716 1 GROMMET, 2" ID
10 5021379 1 GROMMET, 7/8
11 5020883 1 CUP, BEARING (SV)
12 5020095 2 GREASE FITTING, 1/4-28 STRAIGHT

Not for
Reproduction
Manual No. 5101455 26 & 27 HP HYDRO DRIVE
500Z
8
Seat Mount & Floor Group

Not for
Reproduction
Footnotes:
Manual No. 510145526 & 27 HP HYDRO DRIVE
500Z 9
Seat Mount & Floor Group
Part No Descri
p
tionItem Qty
1 5025155 3 WASHER, 5/16 SAE
2 5025011X8 4 BOLT, 5/16-18 X 1 GD5 YZ
3 5025392 10 NUT, 5/16-18 HEX NYLOCK FLANGE
4 5025127 1 NUT, 5/16-18 HEX SERRATED FLANGE (SMALL)
5 5025011X10 1 BOLT, 5/16-18 X 1-1/4 GD5 YZ
6 5021878 1 SPACER, .25 X .37 X .25
7 5025144X6 1 BOLT, 1/4-20 X 3/4", CARRIAGE
8 5025391 1 NUT, 1/4-20 HEX NYLOCK FLANGE
9 5044617 2 WASHER, .34 X 1.25 X 10 GA
10 5025394 10 NUT, 3/8-16 HEX NYLOCK FLANGE
11 5403706D 1 PLATE, SIO FLOOR MOUNT - RED
12 5100909 1 SEAT, NO ARM REST
13 5403015D 1 SEAT PLATE, STOP - RED
14 7078299 2 SPRING, SEAT SUPPORT
15 5402859D 1 MOUNT, SEAT STOP - RED
16 5403555D 1 PLATE, FOOT REST - RED
17 5403574D 1 WELD, PLATE, SEAT MOUNT - RED
18 5023263 1 VINYL CLAMP
19 5101374 1 SAFETY WALK, FLOOR REST, 16.00 X 6.00
20 5101333 1 SAFETY WALK, FLOOR PLATE, S50X, 10X17.13
21 5101004 1 SAFETY WALK, 4.00 X 7.50
22 5025013X8 6 BOLT, 3/8-16 X 1 GD5 YZ
23 5025156 6 WASHER, 3/8 SAE
24 1686907 1 ARM REST, (SET OF TWO) (SV)
25 5100636 1 SPRING, SEAT ADJUSTMENT (SV)
26 5061599X1 1 KIT, SEAT RAILS (COMPLETE)(SV)
27 35097 4 MOUNT, VIBRATION, RUBBER
28 197546 2 BUMPER, ROPS
29 5025481 4 BOLT, 3/8-16 X 5/8, SERRATED UNDER HEAD
30 5025480 4 WASHER, 3/8" ID, INTERNAL TOOTH
31 5025011X6 1 BOLT, 5/16-18 X 3/4 GD5
32 5041930 2 SPACER, .38 X .50 X .27

Not for
Reproduction
Manual No. 5101455 26 & 27 HP HYDRO DRIVE
500Z
10
Fuel Tank & Mount Group

Not for
Reproduction
Footnotes:
Manual No. 510145526 & 27 HP HYDRO DRIVE
500Z 11
Fuel Tank & Mount Group
Part No Descri
p
tionItem Qty
1 5101272 2 FUEL CAP, 3.5", VENTED (S/N: 2014923025 & BELOW)
1 5103005 1 FUEL CAP, 3-1/2", MANAGED VENT OUT, 12" (S/N: 2014923026 & ABOVE)
2 5101368 1 TANK, FUEL, RH, SNAPPER (S/N: 2014923025 & BELOW)
2 5102979 1 TANK, FUEL, SNAP & SNP PRO - RH (S/N: 2014923026 & ABOVE)
3 5101367 1 TANK, FUEL, LH, SNAPPER (S/N: 2014923025 & BELOW)
3 5102978 1 TANK, FUEL, SNAP & SNP PRO - LH (S/N: 2014923026 & ABOVE)
4 5025170 8 WASHER, 5/16 LOCK YZ
5 5025155 8 WASHER, 5/16 SAE
6 5023173 1 CLAMP, HOSE, 1.000 DIA. (NOT SHOWN - FOR RH FUEL HOSE)
7 5050831X6 1 HOSE, FUEL, 1/4 IN, LW PRMTN, 6" LONG
8 5050831X24 1 HOSE, FUEL, 1/4 IN, LW PRMTN, 24" LONG
9 5023358 1 VALVE, FUEL, STR. OUTLET
10 5401108D 1 BRACKET, FUEL VALVE, IS3000 - RED
11 5025011X8 8 BOLT, 5/16-18 X 1 GD5 YZ
12 5101378 1 FUEL GAUGE, 10" (SV)
13 5022917X1 1 GROMMET, FUEL GAUGE (SV)
14 5025013X10 1 BOLT, 3/8-16 X 1-1/4 GD5
15 5025156 1 WASHER, 3/8 SAE
16 5025394 1 NUT, 3/8-16 HEX NYLOCK FLANGE
17 5020835 6 CLAMP, HOSE, EXTERNAL, 1/2 - RED
18 5600050 2 KIT, BUSHING FUEL (SV)
19 5101144 2 PICKUP TUBE ASSEMBLY, FUEL LINE (SV)
20 5050831X26 1 HOSE, FUEL, 1/4 IN, LW PRMTN, 26" LONG

Not for
Reproduction
Manual No. 5101455 26 & 27 HP HYDRO DRIVE
500Z
12
Evap Canister Group

Not for
Reproduction
Footnotes:
Manual No. 510145526 & 27 HP HYDRO DRIVE
500Z 13
Evap Canister Group
Part No Descri
p
tionItem Qty
1 313036 4 CNSTR, CARB, 6 GAL (Single Tank Models)
1 313037 1 CNSTR, CARB, 9 GAL (Double Tank Models)
2 5408222A 1 BRACKET, CARB CANISTER, S50X - BLK
3 -- 1 DECAL, EPA CERT, ZTRS (Located on frame near Serial Tag)
4 5103055 2 CLAMP, 3" ID, CUSHIONED, STAINLESS
5 5025299X6 2 SCREW, 1/4-20 X 3/4 ALLEN BH
6 5025391 2 NUT, 1/4-20 HEX NYLOCK FLANGE
7 5103062 1 FITTING, 3/16" TEE, BARB TYPE, HDPE (Double Tank Models)
8 7700552X43 1 HOSE, VAPOR, 5MM ID, 43.00 LG (Double Tank Models)
9 7700552X22P5 1 HOSE, VAPOR, 5MM ID, 22.5.00 LG (Kawasaki Models)
9 7700552X36 1 HOSE, VAPOR, 5MM ID, 36.00 LG (Briggs & Stratton Models)
10 7700552X5P5 1 HOSE, VAPOR, 5MM ID, 5.50 LG (Double Tank Models)
11 7700552X11 1 HOSE, VAPOR, 5MM ID, 11.00 LG (Double Tank Models)
12 5025392 4 NUT, 5/16-18 HEX NYLOCK FLANGE
13 5025155 4 WASHER, 5/16 SAE
14 5025011X8 4 BOLT, 5/16-18 X 1 GD5 YZ
15 7700552X19 1 HOSE, VAPOR, 5MM ID, 19.00 LG (Single Tank Models)

Not for
Reproduction
Manual No. 5101455 26 & 27 HP HYDRO DRIVE
500Z
14
Engine & PTO Group

Not for
Reproduction
Footnotes:
Manual No. 510145526 & 27 HP HYDRO DRIVE
500Z 15
Engine & PTO Group
Part No Descri
p
tionItem Qty
1 5100907 1 MUFFLER, B&S-ELS 22-26HP
2 5050407X8 1 KEY, 1/4 SQ. X 1.00
3 5101337 1 PULLEY, PUMP DRIVE, 4.857 OB X 1" BORE
4 5102865 1 BOLT, CRANKSHAFT, 7/16 X 2-3/4
5 5048681 1 HOSE, OIL DRAIN
6 5100915 1 CLUTCH, # 5219-34A, ELECTRIC, IS500Z
7 5403009D 1 ANCHOR, CLUTCH - RED
8 44P777-0124-G1 1 * ENGINE, 26HP B&S, ELS (44P777-0124-G1) (26HP MODELS ONLY)
8 44Q777-0146-G1 1 * ENGINE, 27HP B&S, ELS (44Q777-0146-G1) (27HP MODELS ONLY)
9 690970 2 GASKET, EXHAUST
10 690341 4 * SCREW, SEM HEX HEAD
11 5025011X14 3 BOLT, 5/16-18 X 1-3/4 GD5 YZ
12 5025188 2 WASHER, 5/16" INT. TOOTH LOCK
13 5025155 3 WASHER, 5/16 SAE
14 5025057 3 NUT, 5/16-18 HEX NYLON LOCK
15 792303 1 * PRE CLEANER (SV)
16 792105 1 * AIR CLEANER W/ PRE CLEANER (SV) (INCLUDES REF NO 15)
17 - 1 SEE PUMP DRIVE GROUP
18 - 1 SEE PUMP DRIVE GROUP
19 - 1 SEE PUMP DRIVE GROUP
20 - 1 SEE PUMP DRIVE GROUP
21 696854 1 * OIL FILTER (SV) (NOT ILLUSTRATED)
22 5050833X11 1 WIRE LOOM, 1/2 ID X 11 IN (NOT ILLUSTRATED)
NOTE* Purchase engine parts from engine manufacturer dealer.

Not for
Reproduction
Manual No. 5101455 26 & 27 HP HYDRO DRIVE
500Z
16
Motion Control Group

Not for
Reproduction
Footnotes:
Manual No. 510145526 & 27 HP HYDRO DRIVE
500Z 17
Motion Control Group
Part No Descri
p
tionItem Qty
1 5022068 2 GRIP, FOAM, 3/4 ID, 16 LONG
2 5402862D 2 NEUTRAL LOCK, SNAPPER PRO 36-44
3 5402984D 2 SWITCH PLATE, MOTION CONTROLS
4 5047004 2 MOUNT, CONTROL ARM
5 5025127 16 NUT, 5/16-18 HEX SERRATED FLANGE (SMALL)
6 5025011X8 4 BOLT, 5/16-18 X 1 GD5 YZ
7 5025154 12 WASHER, 1/4 SAE
8 5021146 2 BALL JOINT, 5/16-24, FEMALE
9 5025011X18 2 BOLT, 5/16-18 X 2-1/4" GD5 YZ
10 5046420 2 ROD, HYDRO LINKAGE
11 5402910D 2 PLATE, CONTROL TRANSAXLE - RED
12 5022628 2 BALL JOINT, 5/16-24, LH FEMALE
13 5100940 2 DAMPENER, CONTROL,#(P6709/P3610)
14 5100941 4 BALL STUD, 5/16 X .50,# PC-477-2)
15 5021098 2 BEARING, BRONZE FLANGE, 3/4
16 5101108 1 SHAFT, 3/4 X 19.52
17 5402913D 1 WELD, MOTION CONTROL, RH - RED
18 5402856D 1 WELD, MOTION CONTROL, LH - RED
19 5047055D 1 WELD, HANDLE MOTION CONTROL-LH
20 5047056D 1 WELD, HANDLE MOTION CONTROL-RH
21 5025015X6 2 BOLT, 7/16-14 X 3/4, GD 5 YZ
22 5025044 2 NUT, 7/16-14 HEX TOP LOCK
23 5025391 10 NUT, 1/4-20 HEX NYLOCK FLANGE
24 5025013X6 4 BOLT, 3/8-16 X 3/4 GD5 YZ
25 5010114 2 COLLAR, 3/4" SPLIT
26 5025013X14 4 BOLT, 3/8-16 X 1-3/4 GD5
27 5025057 4 NUT, 5/16-18 HEX NYLON LOCK
28 5025010X6 8 BOLT, 1/4-20 X 3/4 GD5 YZ
29 5025394 4 NUT, 3/8-16 HEX NYLOCK FLANGE
30 5025155 8 WASHER, 5/16 SAE
31 5025170 4 WASHER, 5/16 LOCK YZ
32 5025011X9 8 BOLT, 5/16-18 X 1-1/8 GD5
33 5023212 2 NUT, 5/16-24 HEX, LH
34 5025033 6 NUT, 5/16-24 HEX
35 5025010X5 6 BOLT, 1/4-20 X 5/8 GD5 YZ

Not for
Reproduction
Manual No. 5101455 26 & 27 HP HYDRO DRIVE
500Z
18
Parking Brake Group

Not for
Reproduction
Footnotes:
Manual No. 510145526 & 27 HP HYDRO DRIVE
500Z 19
Parking Brake Group
Part No Descri
p
tionItem Qty
1 5025010X5 4 BOLT, 1/4-20 X 5/8 GD5 YZ
2 5025391 4 NUT, 1/4-20 HEX NYLOCK FLANGE
3 5025013X18 2 BOLT, 3/8-16 X 2-1/4 GD5 YZ
4 5025394 2 NUT, 3/8-16 HEX NYLOCK FLANGE
5 5025213X8 1 PIN, CLEVIS, 5/16 X 1 YZ
6 5025211 1 PIN, HAIR, .0585 X 1-1/8, 1/4 EYE, YZ
7 5020047 5 COLLAR, 5/16" SET
8 5021102 2 SPRING, COMPRESSION
9 5010213 1 SPRING, CLUTCH HANDLE
10 5025337 2 WASHER, 5/16 USS
11 5025045 2 NUT, 5/16-24 HEX NYLON LOCK
12 5023216 1 NUT, 5/16-24 JAM
13 5101058 2 ROD, BRAKE CTRL, LOWER - CONZ
14 5101123 2 BEARING, 1/2" FLANGED
15 5044992 2 SPACER, .38 X .50 X 1.56
16 5402914D 1 WELD, BRAKE SHAFT - RED
17 5023323 1 CLEVIS, 5/16-24, STEEL
18 5101116 1 ROD, PULLER ROD
19 5402903D 1 WELD, BRAKE SHAFT, HANDLE - RED
20 5025510 1 GRIP, FOAM, 1/4" X 1

Not for
Reproduction
Manual No. 5101455 26 & 27 HP HYDRO DRIVE
500Z
20
Pump Drive Group
