Parts Manual fo
r
22" VARIABLE SPEED
WALK BEHIND MOWERS
Revision D, TP 400-5323-D-WB-N4/11/2008
Briggs & Stratton Yard Power Products Group
Manual No. 7102345
535 Macon Road
McDonough, GA, 30253 U.S.A.
800-935-2967
MODEL
NSPV22675HW (7800230)
SPV22675HW (7800190)

Table Of Content
s
TP 400-5323-D-WB-N
22" VARIABLE SPEED
3
Manual No. 7102345
PAGE GROUP
4Handles and Controls (SPV22)
6Deck Assembly (SPV22)
10 Engine and Blade Assembly (SPV22)
12 Height-of-Cut Assemblies
14 Transmission (22")
16 Decals (22")

TP 400-5323-D-WB-N
Manual No. 7102345 22" VARIABLE SPEED
4

Handles and Controls (SPV22)
Footnotes:
TP 400-5323-D-WB-N
Manual No. 710234522" VARIABLE SPEED
5
Part No Descri
p
tionItem Qt
y
Note
1 7101312 1 HANDLE, Plastic Upper, WBM
2 7101415 1 ASSY, Control Head, 22” WBM, VS, HW (incl. cable & handle)
3 7101321BH 1 BAIL, Plastic Handle, WBM
4 7090015 2 BOLT, 1/4-20 x 1-3/4” Round Head Square Neck, GR 2
5 2860694 2 NUT, 1/4-20 Hex Flange Nyloc,YZ
6 7300670A 1 PLATE, Control Panel- Plastic Handle
7 7100225 4 SCREW, #8-16 Torxplus Recessed Pan Head, Twin Helix
8 7300649BH 2 HANDLE, Connecting 21”/22” WBM
9 7101410 1 ROPE GUIDE (1/4-20 thread)
10 7035744 2 KNOB, 5/16-18 Wing (Black)
11 7091189 2 BOLT, 5/16-18 x 2” Curved Head Square Neck, GR 2
12 7024649 3 WIRE TIE,11 Inch Standard Black Nylon
13 7300667BH 1 HANDLE, Lower, 22” WBM, Hi-Wheel
14 7101395 1 CABLE, Bail, 22” WBM
15 7101202 2 KNOB, Quick Release
16 7101199 2 BUSHING, Handle Pin
17 7101200 2 SPRING, Compression
18 7101198 2 PIN, Handle Adjust
19 7090958 2 BOLT, 5/16-18X x 1-1/2” Round Head Short Square Neck, GR 5
20 7090951 2 NUT, 5/16-18 Large Head Center Lock, Black
21 7101246 1 GRASSBAG, 22” RD
22 7101230A 1 BAG FRAME, 22” WBM
23 7026421 1 GRIP, Rectangular (Black)
24 7090391 2 WASHER, 5/16” Internal Tooth Lock

Deck Assembly (SPV22)
TP 400-5323-D-WB-N
Manual No. 7102345 22" VARIABLE SPEED
6

Deck Assembly (SPV22)
Footnotes:
TP 400-5323-D-WB-N
Manual No. 710234522" VARIABLE SPEED
7
Part No Descri
p
tionItem Qt
y
Note
1 7300400D 1 DECK, 22” Walk, 3-N-1
2 722848 3 SCREW, 1/4-20 x 11/16” Pan Head Torx, Self-Tap
3 7091020 4 PUSHNUT, 1/4”
4 7300855D 1 BRACKET, Chute
5 7300856D 1 PLATE, Mulch, 22” RB Scotts
6 722507 1 SPRING, Torsion, Chute
7 7101067 1 ROD, Pivot
8 721682 1 COVER, Mulch, Plastic, Black
9 721681 1 SIDE CHUTE, Plastic, Black
10 7102422 1 GUARD, Rear
11 7091286 4 SCREW, #10-24 x 1/2” Hex Washer Self-Tap, SEMS
12 7091619 6 NUT, 3/8-16 Hex Flange Lock, YZ
13 7501056 1 * ASSY, HOC, Right Rear, 22” WBM
14 7501055 1 * ASSY, HOC, Left Rear, 22” WBM
15 7501058 1 * ASSY, HOC, Left Front, 22” WBM, Propelled
16 7501057 1 * ASSY, HOC, Right Front, 22” WBM, Propelled
17 7100633 4 GRIP, Height Latch
18 7500546 2 ASSY, Wheel, 12 x 2 Idle, BB, Snapper Cool Gray incl. two 1-1/8” O.D. Flanged
Ball Bearings (p/n 7101380)
19 7500542 2 ASSY, Drive Wheel, 8 x 2, BB, Snapper Charcoal Gray incl. two 1-1/8” O.D. Flanged
Ball Bearings (p/n 7101380)
20 722604 4 WASHER, 1” OD x .387 ID, FLAT
21 7091585 4 NUT, 3/8-16 Hex Center Lock, YZ
22 7101393 2 HUBCAP, 12” Wheel, Snapper Cool Gray
23 7101350 2 HUBCAP, 8” & 9” Wheel Spoked- Snapper Cool Gray
24 7101243 1 DOOR, 22” Rear
25 7101070 1 ROD, Pivot, Rear Door
26 7101461 1 SPRING, Torsion, Rear Door, 22” WBM
27 7300583BH 1 BRACKET, Lower Handle, LH, 22” WBM, HW
28 7300582BH 1 BRACKET, Lower Handle, RH, 22” WBM, HW
29 7091811 2 BOLT, 5/16-18 x 5/8” Hex Flange Lock- YZ
30 7091601 2 NUT, 5/16-18 Hex Flange Lock, GR 5, YZ
31 7014341 4 RETAINING RING Waldes #5133-50 or equiv.
32 7101207 2 GEAR, Pinion, 22” WBM, FWD
33 7101402 2 DUST SHIELD, 22” WBM, FWD
34 7900054 4 SCREW, 3/8-16 x 3/4” Hex Head Cap, GR 5, YZ
35 7100857 1 TRANSMISSION, Rocker, 22” WBM HW, VS
36 7101270 2 PIN, Drive, 22” WBM, FWD
37 7300854D 1 BAFFLE, Rear, 22” Deck
Note: * See Height-of-Cut Assemblies page

Deck Assembly (SPV22)
TP 400-5323-D-WB-N
Manual No. 7102345 22" VARIABLE SPEED
8

Deck Assembly (SPV22)
Footnotes:
TP 400-5323-D-WB-N
Manual No. 710234522" VARIABLE SPEED
9
Part No Descri
p
tionItem Qt
y
Note
38 7300440D 1 BAFFLE, Front, 22” WBM
Note: * See Height-of-Cut Assemblies page

Engine and Blade Assembly (SPV22)
TP 400-5323-D-WB-N
Manual No. 7102345 22" VARIABLE SPEED
10

Engine and Blade Assembly (SPV22)
Footnotes:
TP 400-5323-D-WB-N
Manual No. 710234522" VARIABLE SPEED
11
Part No Descri
p
tionItem Qt
y
Note
1 1 * ENGINE, B&S, 675 Ser, B3, X-Spec (Mod. 126T02-0675-B3) used on SPV22675HW
1 1 * ENGINE, B&S, 675 Ser, X-Spec, F3 (Mod. 126L02-0675-F3) used on NSPV22675HW
1 1 * ENGINE, B&S, 675 Ser, X-Spec B1, FC (Mod. 126T02-0177-
B1)
used on SPV22675HWFC
2 7101449 1 ASSY, Engine Spacer, 22” WBM, Propelled (includes 3 bushings, p/n
7101448)
3 7300400D 1 DECK, 22” Walk, 3-N-1
4 7101195 1 COVER, Front Deck, 22” FWD
5 7900018 2 SCREW, 4.8 x 1.59 x 13mm Hi-Lo, Round Washer Head Torx
6 7101302 2 SPACER, Belt Guide, 22” VS
7 7101024 2 BELT GUIDE, Engine, 22” VS
8 7101451 2 SCREW, 3/8-16 x 3” Hex Washer Self-Tap
9 7091214 1 KEY, #HP-506 Hi-Pro
10 7100437 1 PULLEY, Engine
11 7092086 1 SET SCREW, 5/16-18 x 1/2” Hex Recess
12 7100740 1 BLADE HUB, 22” Deck
14 721890 1 WASHER, .38” ID x 1.183 OD Bellville
15 720351 1 BOLT, 3/8-16 NS x 2-1/2” Hex Head
16 094696 2 SCREW, #8-18 x 1-1/4” Pan Head Thread Forming
17 794552 1 SHROUD, Engine, Snapper Waterfall
NOTE: * Purchase engine parts from engine manufacturer dealer.

Height-of-Cut Assemblies
TP 400-5323-D-WB-N
Manual No. 7102345 22" VARIABLE SPEED
12

Height-of-Cut Assemblies
Footnotes:
TP 400-5323-D-WB-N
Manual No. 710234522" VARIABLE SPEED
13
Part No Descri
p
tionItem Qt
y
Note
1 7501056 1 ASSY, HOC, Right Rear, 22” WBM
2 7501055 1 ASSY, HOC, Left Rear, 22” WBM
3 7501057 1 ASSY, HOC, Right Front, 22” WBM, Propelled
4 7501058 1 ASSY, HOC, Left Front, 22” WBM, Propelled
5 7091497 2 SCREW, 3/8-16 x 1-1/2” Hex Head Cap, GR 5, YZ
6 7900047 2 WASHER, .391 x 1 x 14 Gage Flat
7 7900046 2 WASHER, .76 x 1.25 x .180 Flat
8 7101205 2 LEVER, HOC, 22” WBM
9 7500409 1 ASSY, Rear Axle, RH 22” WBM
10 7500408 1 ASSY, Rear Axle, LH 22” WBM
11 722611 4 WASHER, 1 ID x 1.64 OD Bellville
12 7300529 1 PLATE, Index, HOC, Rear
13 721899 2 SPACER, Height Adjust
14 7013847 2 RETAINER, 3/8” Bolt
15 720118 2 RETAINING RING, .906 ID x .078 Thick
16 7500404 2 ASSY, Front Axle 22”, Propelled
17 7101212 2 LEVER, HOC, 22” WBM
18 7300528 1 PLATE, HOC, Front Right, 22” WBM
19 7300527 1 PLATE, HOC, Front Left, 22” WBM
20 720685 2 RETAINER, Bearing
21 720761 2 BALL BEARING

Transmission (22")
TP 400-5323-D-WB-N
Manual No. 7102345 22" VARIABLE SPEED
14

Transmission (22")
Footnotes:
TP 400-5323-D-WB-N
Manual No. 710234522" VARIABLE SPEED
15
Part No Descri
p
tionItem Qt
y
Note
1 7100857 1 TRANSMISSION, Rocker, 22” WBM HW, VS
2 7900032 8 SCREW, 7mm x 1 x .550 AB Point
3 7100913 1 BELT, Traction Drive, 22” Pivot Handle 3L Section; 31.94 effective length
4 7101009 1 BELT GUIDE, Transmission, 22” WBM
5 7091195 2 SCREW, #10-16 x 3/4” Pan Head Self-Tap, Combo

Decals (22")
TP 400-5323-D-WB-N
Manual No. 7102345 22" VARIABLE SPEED
16

Decals (22")
Footnotes:
TP 400-5323-D-WB-N
Manual No. 710234522" VARIABLE SPEED
17
Part No Descri
p
tionItem Qt
y
Note
1 7101538 1 DECAL, Front Cover, 22” Snapper, FWD
2 7102153 1 DECAL, Briggs Engine, Snapper
3 7102151 1 DECAL, Briggs Engine, 675 Series
3 7102172 1 DECAL, Engine, TP, 675, Snapper, FC (not shown) similar in appearance to 7102151
4 7013010 1 DECAL, Danger, Cut Finger
5 7102286 1 DECAL, CPSC Blade
6 7101429 1 DECAL, Control Head, VS, Snapper, FC
7 7101536 1 DECAL, Control Head, VS, Snapper
8 7101394 1 DECAL, Warning, Rear Discharge Door
9 7102275 1 DECAL, Customer Service
10 7101671 1 DECAL, WB Safety, French/English

Parts Manual fo
r
22" VARIABLE SPEED
IT IS THE POLICY OF BRIGGS & STRATTON CORP TO IMPROVE ITS
PRODUCTS WHENEVER IT IS POSSIBLE AND PRACTICAL TO DO SO.
WE RESERVE THE RIGHT TO MAKE CHANGES OR ADD
IMPROVEMENTS AT ANY TIME WITHOUT INCURRING ANY
OBLIGATION TO MAKE SUCH CHANGES ON PRODUCTS
WALK BEHIND MOWERS
Revision D,
TP 400-5323-D-WB-N
4/11/2008
Manual No. 7102345
Copyright © 2008
Milwaukee, WI USA. All Rights Reserved
