Snapper RT1330 (2690172 User manual

Parts Manual fo
r
Revision IR,
REAR ENGINE RIDER
SERIES 0
McDonough, GA, 30253 U.S.A.
TP 400-5276-IR-RE-N
5/29/2007 Manual No. 7006468
HYDRO DRIVE RT RMO ACS
Copyright © 2007
Briggs & Startton Yard Power Products Group
Milwaukee, WI USA. All Rights Reserved
Briggs & Startton Corporation
MODEL
RT1330
(
1694615
)
RT1330
(
2690649
)
RT1330E
(
1694616
)
RT1330E
(
2690249
)
RT1330E
(
2690250
)

Table Of Content
s
TP 400-5276-IR-RE-N
Manual No. 7006468REAR ENGINE RIDER
SERIES 0 3
PAGE GROUP
4Wheels & Tires Group
6Front Column & Dash Group
10 Steering & Lift Group
12 Frame & Fuel System Group
16 Transmission Group - Hydro-Gear 340-0510
20 Engine & Electric Clutch Group - 13HP Briggs & Stratton Models
24 30" Mower Deck - Housing & Height Adjustment
28 30" Mower Deck - Drive & Arbor
30 Decals Group
32 Electrical Group

Wheels & Tires Group
TP 400-5276-IR-RE-N
Manual No. 7006468 REAR ENGINE RIDER
SERIES 0
4

Wheels & Tires Group
Footnotes:
TP 400-5276-IR-RE-N
Manual No. 7006468REAR ENGINE RIDER
SERIES 0 5
Part No Descri
p
tionItem Qt
y
Note
1 1729279 2 KEY, Square, 3/16 x 3/16 x 1-1/2 long
2 1723171 2 REAR WHEEL & TIRE ASSEMBLY, Hoosier, (Includes Ref. Nos.
3,
3 1717451 2 SPACER
4 2860202 2 WASHER, 3/4
5 2172353 4 VALVE STEM & CAP
6 1723400 2 REAR WHEEL ASSEMBLY, Metallic Gray
7 1723399 2 TIRE, Rear Wheel, 16 X 6.50-8
8 2164247 2 TUBE, Rear Wheel
9 1960160 4 WASHER, 3/4
10 2827794 2 E RING
11 1722675 4 HUB CAP, Silver
12 1723170 2 FRONT WHEEL & TIRE ASSEMBLY, Hoosier, 13 x 5.00-6,
Metallic
13 1723402 2 FRONT WHEEL ASSEMBLY 13 x 5.00-6, Metallic Gray
(Includes Re
14 1723401 2 TIRE, Front Wheel, 13 x 5.00-6
15 1664090 2 TUBE, Front Wheel, 4.10/3.50 x 6
16 1611710 2 KLIP RING

Front Column & Dash Group
TP 400-5276-IR-RE-N
Manual No. 7006468 REAR ENGINE RIDER
SERIES 0
6

Front Column & Dash Group
Footnotes:
TP 400-5276-IR-RE-N
Manual No. 7006468REAR ENGINE RIDER
SERIES 0 7
Part No Descri
p
tionItem Qt
y
Note
1 1713841 1 STEERING WHEEL ASSY (Incl. Ref. No. 49)
2 1960540 1 ROLL PIN, .188 x 1
3 1678381 1 TUBE, Steering
4 2916001 1 PIN
5 1960160 3 WASHER, 49/64
6 2176440 2 BUSHING, Nylon
7 1709229 1 TUBE ASSEMBLY, Shift
8 7090705 1 WASHER Was 1960170
9 1704428 2 BUSHING
10 7091587 1 WASHER, Plain, 17/32 x 1-1/4 x 7/64 Was 1924361
11 1707424 1 SPRING, Torsion
12 1918447 2 COTTER PIN, .094 x 3/4
13 1707375 1 ROD, Shift
14 1713843 1 KNOB, Rod, Shift
15 1960114 1 WASHER, Plain, 11/32 x 1 x 1/8
16 1706014 1 SHAFT & GEAR ASSY, Steering
17 173668 1 WASHER, Plain
18 1931350 2 CARRIAGE BOLT, 3/8-16 x 1 GR5
19 1703508A 1 PLATE, Steering Mounting
20 1928352 2 NUT, Hex, 3/8-16
21 7091540 1 CAPSCREW, Hex Head, 5/16-18 x 1-1/2 GR5 Was 1921221
22 3031355 1 NUT, Hex Flange Lock, 3/8-16 Was 1960339
23 1924356 3 WASHER, 13/32 x 1-1/2 x 1/8
24 1708426 1 GEAR, Steering
25 1666332 1 SPACER
26 1923701 1 CAPSCREW, Hex Head, 3/8-16 x 2 GR5
27 1714081 1 DASH, Hydro
28 1714082 1 DASH, Gear (Not Applicable)
29 1925592 3 CAPSCREW, Hex, Flange, Taptite, 1/4-20 x 3/4
30 1713855 1 KNOB, Rod, Parking Brake
31 1707057 1 ROD, Parking Brake
32 1933988 2 PUSH NUT, 5/16
33 1931277 2 NUT, Hex Flange, Whizlock, 5/16-18
34 1708965 1 QUADRANT, Lift
35 1925003 3 CAPSCREW, Hex Head, Taptite, 1/4-20 x 1/2
36 1709075 2 CLAMP, Dashboard
37 1921319 2 WASHER, Plain, 1/4

Front Column & Dash Group
TP 400-5276-IR-RE-N
Manual No. 7006468 REAR ENGINE RIDER
SERIES 0
8

Front Column & Dash Group
Footnotes:
TP 400-5276-IR-RE-N
Manual No. 7006468REAR ENGINE RIDER
SERIES 0 9
Part No Descri
p
tionItem Qt
y
Note
38 1924009 2 CAPSCREW, Hex Head, 1/4-20 x 7/8 GR5
39 1960608 1 NUT, Hex, Flange, 1/4-20
40 1678392 3 SPACER, 17/64 x 3/8 x 21/64
41 1930591 6 CAPSCREW, Hex Head, Whizlock, 5/16-18 x 3/4
42 1708990A 1 SUPPORT, Steering
43 1708267D 1 SHROUD, Front (Red)
44 1935255 4 PAL NUT, 5/16-18
45 1708971 1 ROD, Lift Height
46 1917421 2 NUT, Hex, Jam 1/4-20
47 1713857 1 KNOB, Rod, Lift Height
48 1930641 2 NUT, Hex, Flange, Whizlock, 1/4-20
49 1714097 1 CAP, Steering Wheel

Steering & Lift Group
TP 400-5276-IR-RE-N
Manual No. 7006468 REAR ENGINE RIDER
SERIES 0
10

Steering & Lift Group
Footnotes:
TP 400-5276-IR-RE-N
Manual No. 7006468REAR ENGINE RIDER
SERIES 0 11
Part No Descri
p
tionItem Qt
y
Note
1 1930651 1 NUT, Hex 3/8-16
2 2108512 1 PIVOT
3 1708955A 1 ARM ASSEMBLY, Lift
4 1708966 1 GRIP, Lever
5 1708557A 1 LEVER, Lift
6 1708884 1 SPRING, Compression
7 7090122 3 WASHER, Plain, 13/32 x 7/8 x 5/64 Was 1924940
8 1918447 3 COTTER PIN, 3/32 x 3/4
9 1708556 1 CABLE ASSEMBLY, Lift
10 1919439 1 NUT, Hex, Esna Lock, 3/8-16
11 1708559 1 PULLEY, Lift
12 1708973 1 SPACER
13 1924356 1 WASHER, Plain, 13/32 x 1-1/2 x 1/8
14 1921969 1 CAPSCREW, Hex Head, 3/8-16 x 1-1/2 GR5
15 1930645 1 NUT, Hex, Flange Lock, 3/8-16
16 1708514 1 ECCENTRIC
17 1922755 1 WASHER, 13/32 x 7/8 x 1/8
18 1921971 1 CAPSCREW, Hex Head, 3/8-16 x 1-3/4 GR5
19 1706011 1 SPINDLE ASSEMBLY, LH
20 1935048 3 NUT, Hex, Flange Lock, 5/16-18
21 1960236 2 SPACER
22 1704420 2 KLIP RING
23 1931335 2 CARRIAGE BOLT, 5/16-18 x 1 GR5
24 1708501A 1 TIE ROD, LH
25 1919381 1 WASHER
26 1710703 1 SPACER, 21/64 x 1/2 x 5/8
27 7090705 2 WASHER Was 1960170
28 1708516A 1 LEVER
29 1708521 1 ROD, Hitch
30 1920328 2 CAPSCREW, Hex Head, 1/2-13 x 1-1/2 GR5
31 1709237A 1 HITCH, Hook
32 1709235 2 SPACER
33 1930644 2 NUT, Hex, Flange, 1/2-13
34 1706019 1 SPINDLE ASSEMBLY, RH
35 1708500A 1 TIE ROD, RH

Frame & Fuel System Group
TP 400-5276-IR-RE-N
Manual No. 7006468 REAR ENGINE RIDER
SERIES 0
12

Frame & Fuel System Group
Footnotes:
TP 400-5276-IR-RE-N
Manual No. 7006468REAR ENGINE RIDER
SERIES 0 13
Part No Descri
p
tionItem Qt
y
Note
1 1921333 2 CAPSCREW, Hex Head, 5/16-18 x 1
2 1925003 8 CAPSCREW, Hex Head, Taptite, 1/4-20 x 1/2
3 1715962A 1 SHROUD, Rear
4 1931277 5 NUT, Hex, Flange, Whizlock, 5/16-18
5 1726558A 1 SUPPORT, Fuel Tank
6 1931333 1 CARRIAGE BOLT, 5/16-18 x 3/4
7 1708362A 1 STRAP, Fuel Tank, Brace
8 1714020 1 CAP, Fuel Tank, Vented
9 1726635 1 TANK, Fuel
10 1710437 1 SPACER, 21/64 x 1/2 x 21/64
11 7090122 1 WASHER, Plain, 13/32 x 7/8 x 5/64 Was 1924940
12 1960373 1 CAPSCREW, Hex, Taptite, 5/16-18 x 1 Black (13 HP Models)
13 1726400 1 BUSHING, Rubber
14 1674792 1 ELBOW, Fitting with Screen
15 2860112 2 CLAMP, Hose
16 1718678 1 HOSE, Fuel Line
17 1960044 2 WASHER, Plain
18 1933988 2 PUSH NUT, 5/16
19 1930591 10 CAPSCREW, Hex Head, Whizlock, 5/16-18 x 3/4
20 1708525 1 PAD, Foot Rest, LH
21 1727222A 1 FRAME ASSEMBLY
22 1708524 1 PAD, Foot Rest, RH
23 1704351 14 FASTENER
24 1727685A 1 PANEL, Front
25 1935255 4 PAL NUT, 5/16-18
26 1726563A 1 SUPPORT, U , Seat (13 HP Models)
27 1715970 2 BUMPER, Rubber
28 1924856 1 CAPSCREW, Hex Head, Taptite, 5/16 x 1/2
29 1708725A 1 DUCT, Air Inlet (13 HP Models)
30 1704626 2 SPACER, Plastic
31 1705249 2 SPACER
32 1704628 2 PIN, Quick
33 1705248 2 PIVOT, Hood
35 1917356 4 WASHER

Frame & Fuel System Group
TP 400-5276-IR-RE-N
Manual No. 7006468 REAR ENGINE RIDER
SERIES 0
14

Frame & Fuel System Group
Footnotes:
TP 400-5276-IR-RE-N
Manual No. 7006468REAR ENGINE RIDER
SERIES 0 15
Part No Descri
p
tionItem Qt
y
Note
36 7091540 1 CAPSCREW, Hex Head, 5/16-18 x 1-1/2 Was 1921221
37 1917372 1 NUT, Hex, 5/16-18
38 1921977 1 CAPSCREW, 5/16-18 x 1-1/4
39 1703900 1 SPACER
40 2860208 2 WASHER, 1
41 1708881 1 CAP, Black, Vinyl
42 1725532A 1 ADJUSTER, Seat
43 1667286 1 SPRING, Extension
44 1725531A 1 SUPPORT, Seat
45 1708511 4 SPACER
46 1725486 1 SEAT ASSEMBLY
47 1726649 1 DECK, Seat, Red
48 1673320 3 RIVET
49 1708504 1 SCREEN, Seat Deck Top
50 1960295 7 CAPSCREW, Hex Head, Whizlock, 1/4-20 x 5/8
51 1930642 7 NUT, Hex, Flange Lock, 1/4-20
52 1919381 1 WASHER, 5/16
53 1960715 4 SCREW, Truss Head, 1/4-20 x 3/4
55 1726836A 1 PLATE, Control
56 1724598 1 SCREEN
57 1919381 4 WASHER, 11/32 x 1 x 1/8
58 1920397 1 NUT, ESNA 1/4-20

Transmission Group - Hydro-Gear 340-0510
TP 400-5276-IR-RE-N
Manual No. 7006468 REAR ENGINE RIDER
SERIES 0
16

Transmission Group - Hydro-Gear 340-0510
Footnotes:
TP 400-5276-IR-RE-N
Manual No. 7006468REAR ENGINE RIDER
SERIES 0 17
Part No Descri
p
tionItem Qt
y
Note
1 1704849 1 PAD, Brake
2 1723348A 1 LEVER, Clutch
3 1708409 1 PIVOT, Brake
4 1708554 1 RING, Klipring Extension
5 2171241 1 KEY, Hi-Pro
6 1704419 2 STOP, Belt
7 1723497 1 PULLEY & HUB ASSEMBLY, Engine
8 1707346 1 V - BELT (4L 42.0 ET KEV)
9 1715025 2 BUSHING
10 1924361 2 WASHER, 1/2
11 1703805 1 RING, Klipring Extension
12 1931342 1 CARRIAGE BOLT, 5/16 - 18 x 2-1/4 G5
13 1708367 2 BRACKET, Torsion Bar
14 1924856 4 SCREW, Hex, Washer Head, Taptite, 5/16 - 18 x 1/2
15 2159106 1 SPRING, Extension
16 1709345 1 SPACER
17 1930641 1 NUT, Hex, Flange, 1/4 - 20, Whiz Lock LG
18 1725839A 1 PLATE, Idler 10GA
19 1709221 2 CLEVIS HALF
20 1924366 1 WASHER, 5/8
21 1919326 5 WASHER, 5/16
22 1917356 1 LOCKWASHER, Spring 5/16
23 1917372 1 NUT, Hex 5/16 - 18
24 1923341 1 CAPSCREW, Hex Head, 1/4 - 20 x 3/4 G5
25 1927429 1 SCREW, Hex, Washer Head, Taptite, 1/4 - 20 x 5/8
26 1928352 2 NUT, Hex Flange,, 3/8 - 16 Whiz Lock LG
27 1928731 1 NUT, Hex, Toplock, Jam, 3/8 - 16
28 1725250 1 SPRING, Extension
29 1922918 1 CAPSCREW, Hex Head, 3/8 - 16 x 3-1/4 G5
30 1668827 1 PULLEY
31 1708352A 1 GUARD, Spring
32 1725838 1 SPACER
33 1930644 1 NUT, Hex Flange, 1/2 - 13, Two-Way Lock
34 1924361 1 WASHER, 1/2
35 1719683 1 SPACER
36 1921176 1 CAPSCREW, Hex Head, 1/2 - 20 x 1-1/4 G5
37 1923114 1 CAPSCREW, Hex Head, 1/2 - 13 x 1 G5

Transmission Group - Hydro-Gear 340-0510
TP 400-5276-IR-RE-N
Manual No. 7006468 REAR ENGINE RIDER
SERIES 0
18

Transmission Group - Hydro-Gear 340-0510
Footnotes:
TP 400-5276-IR-RE-N
Manual No. 7006468REAR ENGINE RIDER
SERIES 0 19
Part No Descri
p
tionItem Qt
y
Note
38 1719725 1 SPACER
39 1931332 1 CARRIAGE BOLT, 5/16 - 18 x 5/8 G5
40 1726591A 1 CARRIER ASSEMBLY
41 1726554A 1 BRACKET, Switch Mounting (No-Mow Models Only)
42 1960252 2 CARRIAGE BOLT, 1/4 - 20 x 5/8 G5 (No-Mow Models Only)
43 1931277 3 NUT, Hex Flange, 5/16 - 18, Whiz Lock Small
44 1726555A 1 STRAP, Torque (No-Mow Models Only)
44 1726555A 1 STRAP, Torque
45 1960694 2 NUT, Hex Flange, 1/4 - 20 ESNA (No-Mow Models Only)
46 1725183 1 ROD
47 1921719 4 CAPSCREW, Hex Head, 5/16 - 18 x 2-1/2 G5
48 1725706A 2 BRACKET, Mounting
49 1664847 4 SCREW, Hex, Washer Head, Taptite, 5/16 - 18 x 3/4
50 1916621 2 NUT, Hex Machine Screw
51 1726327 1 SPRING, Extension
52 1935048 5 NUT, Hex Flange, 5/16 - 18, Two-Way Lock
53 1708360 1 SPRING
54 1725166 1 ROD, Brake
55 1921210 1 CAPSCREW, Hex Head, 3/8 - 16 x 1 G5
56 1726559 1 ROD, End
57 1725736A 1 LEVER, Control
58 1930645 1 NUT, Hex Flange, 3/8 - 16, Two-Way Lock
59 1925205 1 CAPSCREW, Hex Head, 5/16 - 18 x 5/8 G5
60 1725167 1 ROD, Control
61 1722460 2 PIN, Quick
62 1918447 6 PIN, Cotter
63 2860709 1 SCREW, Hex, Whiz Lock, Flange, 3/8 - 16 x 1-3/4
64 1666804 1 SPACER
65 2821133 1 FITTING, Lube, 1/4 Drive
66 1725768A 1 SHAFT & ARMS ASSEMBLY, Pivot
67 1709220 1 CLUTCH, Rear
68 1708366 1 BAR, Torsion
69 1709850 1 TUBE
70 1725767 1 ROD, Shift, Front
71 1924359 2 WASHER, 1/2
72 1706260 1 ROD, Clutch, Front
73 1725620 1 TRANSMISSION ASSEMBLY, Hydro Gear

Engine & Electric Clutch Group - 13HP Briggs & Stratton Models
TP 400-5276-IR-RE-N
Manual No. 7006468 REAR ENGINE RIDER
SERIES 0
20
