Snapper 1696005 User manual

Not for
Reproduction
Parts Manual fo
r
26", 28" & 30" TWO STAG
E
2011
LARGE FRAME SNOWTHROWERS
Revision: - 6/14/2011
Briggs & Stratton Yard Power Products Group
Manual No. 7105286
535 Macon Road
McDonough, GA, 30253 U.S.A.
800-935-2967
Descri
p
tionModel No.
169600
4
L1226E
169600
5
L1528E
1696011 L1528EX
169600
6
L1730E
169601
2
L1730EX

Not for
Reproduction

Not for
Reproduction
Table Of Content
s
TP 400-5495---LF-N
26", 28" & 30" TWO STAGE
2011 3
Manual No. 7105286
PAGE GROUP
4Handles & Controls Group
8Auger Housing Group
10 Auger Drive Group
12 Gear Case Assembly - Heavy Duty
14 Chute & Rotation Group
16 Engine & Frame Group - 11.5TP
20 Engine Group - 14.5HP & 16.5HP
24 Traction Drive Group - Easy Turn
28 Decals Group
30 Wheels & Tires Group

Not for
Reproduction
Manual No. 7105286 26", 28" & 30" TWO STAGE
2011
4
Handles & Controls Group

Not for
Reproduction
Footnotes:
Manual No. 710528626", 28" & 30" TWO STAGE
2011 5
Handles & Controls Group
Part No Descri
p
tionItem Qty
0010 1737966 1 HEADLIGHT, Oval
0010-10 ----- 1 * BULB, 881-12V 27W Halogen Lamp (Included with Ref. No. 0010)
0020 1738247D 1 COVER, Panel
0030 1960715 3 SCREW, Truss Head Torx, 1/4-20 x 3/4
0040 1732471 1 CABLE & SPRING ASSEMBLY, Auger Drive, RH
0050 1737759A 1 HANDLE, Lower
0060 1734587A 1 HANDLE, Upper, RH
0070 1734586A 1 HANDLE, Upper, LH
0080 1921333 2 CAPSCREW, Hex Head, 5/16-18 x 1, G5
0090 1664847 2 SCREW, Hex Washer Head, Taptite, 5/16-18 x 3/4
0100 1935048 2 NUT, Hex Flange, Two Way Lock, 5/16-18
0110 7035744 4 KNOB, Wiing, 5/16-18
0120 1750299 2 BOLT, Carriage, Curved Head, 5/16-18 x 2-1/4
0130 7091189 2 BOLT, Carriage, Curved Head, 5/16-18 x 2
0135 7090391 4 WASHER, Internal Tooth, 5/16
0140 1920397 4 NUT, Hex Lock ESNA Light, 1/4-20
0150 1678392 2 SPACER, 1/4 ID x 3/8 OD x 5/16"
0160 1921962 4 CAPSCREW, Hex Head, 1/4-20 x 1-3/4, G5
0170 1739783A 1 LEVER, Clutch, RH
0180 1739782A 1 LEVER, Clutch, LH
0190 1733505BM 1 BRACKET, Pivot, Free Hand
0200 1736360 1 ROD, Hold Down
0210 1733095 1 SPACER, 1/4 ID x 3/8 OD x 1/8"
0220 1960353 1 WASHER, 1/4
0230 1736542 2 SPACER, Stepped
0240 1750554 2 BOLT, Shoulder, 10-24
0250 1933896 2 NUT, Hex Lock, Nylon Insert, 10-24
0260 1726317 2 GRIP
0270 2820263 2 NUT, Hex, 5/16-24
0280 1917356 1 LOCKWASHER, Spring, 5/16
0290 1739290 1 BALL JOINT
0300 1751543 1 ROD, Speed Control
0310 1923701 1 CAPSCREW, Hex Head, 3/8-16 x 2, G5
0320 1931277 3 NUT, Hex Flange, Whiz Lock, 5/16-18
0330 724361 1 SPRING, 3/4"
0340 1918266 1 WASHER, 3/8
0350 1919439 1 NUT, Hex Lock ESNA Light, 3/8-16
0390 1737684 1 BRACKET, Controls
0400 1960589 1 SCREW, Phillips Head, #10-24 x 3/4
0410 1733192 1 KNOB, Slot Speed
0420 1933896 1 NUT, Hex Lock, Nylon Insert, 10-24
0430 1736836 1 SPEED LEVER
0440 727331 1 CABLE, Forward Drive
0450 723154 1 BOOT, Spring End Cover
Note* See your local hardware store for replacement bulbs & fuses.

Not for
Reproduction
Manual No. 7105286 26", 28" & 30" TWO STAGE
2011
6
Handles & Controls Group

Not for
Reproduction
Footnotes:
Manual No. 710528626", 28" & 30" TWO STAGE
2011 7
Handles & Controls Group
Part No Descri
p
tionItem Qty
0460 723259 1 BRACKET, Cable Adjusting
0470 1733509 1 ROD & SPRING ASSEMBLY
0480 2108360 2 SPRING, Compression, 2-1/4
0490 1927429 2 SCREW, Hex Washer Head, Taptite, 1/4-20 x 5/8
0500 723873 3 BOLT, Carriage, 5/16-18 x 3/4
0510 1732064BM 1 SUPPORT, Dash
0520 2825094 5 TIE, Self Lock
0570 1750773 1 HARNESS, Deflector
0570-10 ----- 1 * FUSE, 10 Amp (Included with Ref. No 0570)
0600 725331 2 WASHER, Flat, 11/32
0620 5025391 3 NUT, Hex Flange, Nylock, 1/4-20
Note* See your local hardware store for replacement bulbs & fuses.

Not for
Reproduction
Manual No. 7105286 26", 28" & 30" TWO STAGE
2011
8
Auger Housing Group

Not for
Reproduction
Footnotes:
Manual No. 710528626", 28" & 30" TWO STAGE
2011 9
Auger Housing Group
Part No Descri
p
tionItem Qty
0010 1687614 1 AUGER HOUSING ASSEMBLY, 26"
0010 1687613 1 AUGER HOUSING ASSEMBLY, 28"
0010 1687606 1 AUGER HOUSING ASSEMBLY, 30"
0020 1733102BM 2 DRIFT CUTTER
0030 725347 2 NUT, Wing, Serrated, 5/16-18
0040 723873 2 BOLT, Carriage, 5/16-18 x 3/4
0050 1739305 3 NUT, Hex Flange, ESNA, 5/16-18
0060 1732384BM 1 BLADE, Scraper, 26"
0060 1709947BM 1 BLADE, Scraper, 28"
0060 1732385BM 1 BLADE, Scraper, 30"
0070 1960699 7 BOLT, Carriage, Short Neck, 5/16-18 x 5/8, G5 (Qty 5 used on 26" & 28")
0080 1935048 7 NUT, Hex Flange, Two Way Lock, 5/16-18 (Qty 5 used on 26" & 28")
0090 1960711 4 BOLT, Carriage, Short Neck, 3/8-16 x 3/4, G5
0100 1727854BM 2 SKID SHOE
0110 1960687 4 NUT, Hex Flange, ESNA, 3/8-16
0120 1733103 2 BEARING, Flange, 1.383 ID x 3.75OD
0130 1931202 6 SCREW, Hex Washer Head, Taptite, 5/16-18 x 1-1/4
0140 722401 2 NUT, Nylock 10 x 24
0150 1736620 2 CLAMP
0160 1960569 2 SCREW, Truss Head Torx, #10-24 x 3/8
0170 1736094 1 BRUSH, Cleanout
0180 2108202 1 BEARING, Ball, 3/4 ID x 1-3/4 OD
0190 1665982 1 RETAINER, Bearing
0200 1931333 3 BOLT, Carriage, Short Neck, 5/16-18 x 3/4, G5
0210 1734932BM 2 COVER, Bushing

Not for
Reproduction
Manual No. 7105286 26", 28" & 30" TWO STAGE
2011
10
Auger Drive Group

Not for
Reproduction
Footnotes:
Manual No. 710528626", 28" & 30" TWO STAGE
2011 11
Auger Drive Group
Part No Descri
p
tionItem Qty
0010 1737078BM 1 AUGER, RH, 28" / 30" (Includes Ref. No. 0010-20)
0010 1737082BM 1 AUGER, RH, 26" (Includes Ref. No. 0010-20)
0020 1737079BM 1 AUGER, LH, 28" / 30" (Includes Ref. No. 0010-20)
0020 1737083BM 1 AUGER, RH, 26" (Includes Ref. No. 0010-20)
0010-20 2821133 1 FITTING, Grease
0030 1931333 1 BOLT, Carriage, Short Neck, 5/16-18 x 3/4, G5
0040 1931277 1 NUT, Hex Flange, Whiz Lock, 5/16-18
0050 1732303 1 GEAR CASE ASSEMBLY
0060 2818312 2 KEY, Woodriff
0070 1612187BM 1 IMPELLER
0080 1960474 1 SET SCREW, Square Head, 3/8-16 x 1/2, G8
0090 1928721 2 SET SCREW, Square Head, 5/16-18 x 1/2, G8
0100 1732185 1 PULLEY
0110 1739295 2 PIN, Shear, 1-3/4" (Use on 28 & 30" Models)
0110 1668344 2 PIN, Shear, 1-3/4" (Use on 26" Models)
0120 1739292 2 PIN, Cotter, Bow Tie, 3/16 (Use on 28 & 30" Models)
0120 7023590 2 PIN, Cotter, Self Locking, 1/4 (Use on 26" Models)
0130 1733406 2 SPACER, 1" (Used on 30" Models only)
-- 1751347 1 KIT, Shear Pin (Use on 28 & 30" Models)
-- 1750790 1 KIT, Shear Pin (Use on 26" Models)

Not for
Reproduction
Manual No. 7105286 26", 28" & 30" TWO STAGE
2011
12
Gear Case Assembly - Heavy Duty

Not for
Reproduction
Footnotes:
Manual No. 710528626", 28" & 30" TWO STAGE
2011 13
Gear Case Assembly - Heavy Dut
y
Part No Descri
p
tionItem Qty
1 1926105 1 CAPSCREW, 1/4-20 x 2-3/4
2 1960346 5 CAPSCREW, 1/4-20 x 2-1/4
3 1734218 1 GEAR CASE, L.H.
4 1668971 1 TAPERED PIPE PLUG
5 1612124 1 GASKET
6 1732440 1 SHAFT, Auger Cutoff
7 1732182 1 SHAFT, Worm Cutoff
8 1612093 1 SEAL, Oil
9 1612149 2 FLANGE BUSHING
10 2836098 1 PIN, Drive Lock
11 1612127 1 THRUST COLLAR
12 1612142 1 ROLLED WORM CASE
13 2168111 1 THRUST WASHER
14 2118315 2 THRUST WASHER
15 1612141 1 GEAR, Worm
16 1734219 1 GEAR CASE, R.H.
17 1930642 6 NUT, Top Lock Flange, 1/4-20
18 2118118 1 SEAL
19 1732152 1 WIREFORM BRACKET
20 2818312 1 KEY, Woodruff, .18 x .62
21 1732991 2 BUSHING
22 1612111 1 TUBE
23 2830246 1 KEY, Woodruff, 1/4 x 3/4
24 1960294 1 NUT, Hex-Flange, 1/4-20

Not for
Reproduction
Manual No. 7105286 26", 28" & 30" TWO STAGE
2011
14
Chute & Rotation Group

Not for
Reproduction
Footnotes:
Manual No. 710528626", 28" & 30" TWO STAGE
2011 15
Chute & Rotation Group
Part No Descri
p
tionItem Qty
0010 1728967 1 PINION
0030 1739621 3 SCREW, Torx Button Head, M5 x .8 x 14
0035 7091552 3 WASHER, Flat, 1/4
0040 1925592 1 SCREW, Hex Washer Head, Taptite, 1/4-20 x 3/4
0050 1752877 1 COVER, Electric Chute Rotation
0060 7011938 3 RETAINER, Spout
0070 1960001 6 SCREW, Hex Washer Head, Plastite, 10-14 x 5/8
0090 1752240 1 SWITCH, Chute Rotation
0140 2825094 1 TIE, Self Locking
0150 1733601 2 DECAL, Hinge
0160 1738231H 1 DISCHARGE CHUTE
0200 1739309 1 MOTOR, Chute Rotation
0230 1737962BM 1 GEAR, Chute
0290 1738267BM 1 BRACKET, Weld Stud
0300 1737941 1 MOTOR, Chute Deflector
0310 1960715 2 SCREW, Truss Head Torx, 1/4-20 x 3/4
0320 1960694 2 NUT, Hex Flange, ESNA, 1/4-20
0330 1737379 1 SWITCH / COVER
0340 1738244 1 WASHER, Rubber
0350 1738245 1 NUT, Left Hand
0360 5025154 1 WASHER, 1/4
0530 1733475 1 GUARD, Chute (Export Models Only)
0540 1737683 1 BRACKET, Chute Guard (Export Models Only)
0550 1738174 2 GROMMET, Chute (Export Models Only)
0560 1960140 2 NUT, Push, 3/16 (Export Models Only)
0570 1925003 2 SCREW, Hex Washer Head, Taptite, 1/4-20 x 1/2 (Export Models Only)
1090 1931317 3 BOLT, Carriage, Short Neck, 1/4-20 x 3/4, G5
1100 1960685 3 NUT, Hex KEPS, 1/4-20

Not for
Reproduction
Manual No. 7105286 26", 28" & 30" TWO STAGE
2011
16
Engine & Frame Group - 11.5TP

Not for
Reproduction
Footnotes:
Manual No. 710528626", 28" & 30" TWO STAGE
2011 17
Engine & Frame Group - 11.5TP
Part No Descri
p
tionItem Qty
0010 15C114-0153-F8 1 * ENGINE, 11.5TP Briggs & Stratton (Engine Model: 15C114-0153-F8)
0010-10 797003 1 * GUARD, Muffler, Plate
0010-20 699854 1 * SCREW, Muffler Guard
0010-30 795027 1 * CAP, Fuel
0020 724865 1 CORD, 10FT, 110V
0050 720064 4 BOLT, Carriage, 5/16-18 x 1-1/2
0060 720376 4 NUT, Push, For 1/4 Stud
0070 1739305 4 NUT, Hex Flange, ESNA, 5/16-18
0090 722085 1 PULLEY
0100 1919381 3 WASHER, 5/16
0110 1921982 1 CAPSCREW, Hex Head, 5/16-24 x 1-1/4, G5
0120 1733324 1 V-BELT, Traction Drive, 3L, 33.13
0130 1736421 1 V-BELT, 4L, 38.35, Auger
0140 1739070 1 BELT GUIDE
0150 1917356 4 LOCKWASHER, Spring, 5/16
0160 1921515 1 CAPSCREW, Hex Head, 5/16-24 x 3/4, G5
0170 722090 1 BRACKET, Idler
0180 722072 1 BUSHING, Idler Bracket
0190 722457 1 SPRING, Extension, Idler
0200 722378 2 IDLER, Plastic Ball Bearing
0210 1960251 2 NUT, Hex Center Lock Jam, 3/8-16
0220 724823 1 BOLT, Carriage, Short Neck, 3/8-16 x 1-1/4, G5
0230 722132 1 AUGER IDLER
0240 722118 1 SPACER, 1/2 ID x 1 OD x 1-3/4"
0250 1960027 1 WASHER, 1/2
0260 1733451 1 ARM, Control
0270 725367 1 PIN, Hair
0280 1736381 1 PIN, Clevis
0290 1740906BM 1 PANEL, Bottom
0300 1927429 12 CAPSCREW, Hex Washer Head, Taptite, 1/4-20 x 5/8
0310 722455 1 SPRING, Extension, Auger
0320 1739311D 1 FRAME
0330 1733583D 1 PLATE, Engine Mount
0340 722838 4 CAPSCREW, Hex Washer Head, 5/16-18 x 1/2
0350 1664847 6 CAPSCREW, Hex Washer Head, Taptite, 5/16-18 x 3/4
0360 1751525 1 BELT COVER ASSEMBLY
0370 722887 2 SCREW, Hex Washer Head, Tapping, SEMS, 1/4 x 3/4
0390 1750241 1 WATER SHIELD ASSEMBLY (Includes Ref. No. 0390-10)
0390-10 1733898 1 SEAL, Foam
0400 1750172 1 SEAL, Strip
0410 725996 2 CAPSCREW, Hex, 5/16-24 x 1
0420 7023590 1 PIN, Cotter, Self Lock, 1/4
0500 7091528 1 WASHER, Flat, 3/8
0510 1750135 1 SEAL, Engine Plate
NOTE: * Purchase engine parts from engine manufacturer dealer.

Not for
Reproduction
Manual No. 7105286 26", 28" & 30" TWO STAGE
2011
18
Engine & Frame Group - 11.5TP

Not for
Reproduction
Footnotes:
Manual No. 710528626", 28" & 30" TWO STAGE
2011 19
Engine & Frame Group - 11.5TP
Part No Descri
p
tionItem Qty
0520 798980 1 * OIL DRAIN ASSEMBLY (Optional Accessory)
NOTE: * Purchase engine parts from engine manufacturer dealer.

Not for
Reproduction
Manual No. 7105286 26", 28" & 30" TWO STAGE
2011
20
Engine Group - 14.5HP & 16.5HP
