Snapper ESS50220E (7800083), SS50220E User manual

Parts Manual fo
r
Revision IR,
522 SINGLE STAGE SNOW THROWER
SERIES 0
TP 400-5245-IR-SX-N
11/22/2006 Manual No. 7006053
McDonough, GA, 30253 U.S.A.
Copyright © 2006
Briggs & Startton Yard Power Products Group
Milwaukee, WI USA. All Rights Reserved
Briggs & Startton Corporation
MODEL
ESS50220
E
SS50220
E

Table Of Content
s
TP 400-5245-IR-SX-N
Manual No. 7006053522 SINGLE STAGE SNOW THROWER
SERIES 0 3
PAGE GROUP
4Handle Assembly Group
6Body Covering Group
8Auger and Housing Group
10 Chute System Group
12 Frame and Fuel Tank Group
14 Engine Drive System Group
18 Wheel Assembly Group
20 Electric Starter Group
22 Decals Group

Handle Assembly Group
TP 400-5245-IR-SX-N
Manual No. 7006053 522 SINGLE STAGE SNOW THROWER
SERIES 0
4

Handle Assembly Group
Footnotes:
TP 400-5245-IR-SX-N
Manual No. 7006053522 SINGLE STAGE SNOW THROWER
SERIES 0 5
Part No Descri
p
tionItem Qt
y
Note
1 722348 HANDLE & GRIP ASSEMBLY
2 722313 CONTROL, Bail
3 723154 BOOT, Clutch Spring
4 722366 CABLE, Upper Control
5 723259 BRACKET, Control Adjust
6 723261 CABLE, Lower Control
7 723263 SPRING, Extension 3/4 O.D. x .069
8 722326 U-BOLT
9 723239 WASHER, Form 11/32 ID 1.0
10 727445 T-KNOB, 3.00 Plastic Black
11 722312 HANDLE, Lower
12 725429 NUT 1/4-20 Regular Hex Control Lock
13 725330 WASHER FLAT 9/32 x 5/8 x .065
14 723280 SCREW, 1/4-20 x 1.25
15 1733377 BRACKET, Chute Handle Assembly
16 1740344 BOLT, 1/4-20 x 1.50 Hex Head
17 1740345E70 NUT, 1/4-20 Hex Head Nylock

Body Covering Group
TP 400-5245-IR-SX-N
Manual No. 7006053 522 SINGLE STAGE SNOW THROWER
SERIES 0
6

Body Covering Group
Footnotes:
TP 400-5245-IR-SX-N
Manual No. 7006053522 SINGLE STAGE SNOW THROWER
SERIES 0 7
Part No Descri
p
tionItem Qt
y
Note
1 1740006 PANEL, Control 22” SS DLR
2 723280 SCREW 1/4-20 x 1.25
3 725330 WASHER, Flat 9/32 x 5/8 x .065
4 725429 NUT, 1/4-20
6 722906 NUT, 5/8-32
7 728074 KEYS & RING, Starter
8 722259 BULB, Fuel Primer
9 722327 PANEL, Access 22” SS DLR
10 727479 NUT, Keps 1/4-20
11 723672 HOSE, Primer 9.5”
12 724504 SWITCH, Ignition
13 722312 HANDLE, Lower
14 723283 SCREW 1/4-14 x 3/4
15 724571 J-NUT 1/4-10
16 1740004 COVER, Bottom 22” SS DLR
17 1740005 COVER, Belt 22” SS DLR
18 721923 SCREW 10-24 x 1/2
19 723243 LOCKNUT, Hex 10-24 Regular Center Lock
20 722398 LOCKNUT, Hex 1/4-20
21 1740383 SCREW 1/4-20 x 5/8
22 1740351 COVER, Top 22” SS DLR
23 1740007 COVER, Auger Top 22” SS DLR
24 727970 WASHER, Interlock 41/64 x 1.1
25 1740002 COVER, Access Oil
26 1740020 GASKET, Chute Ring
27 720384 NUT, PUSH
28 729475 CLIP, Cable
29 1740381 SCREW 10-32 x .75
30 1740382 NUT 10-32 Nylock
31 1740397 SHOE, Skid L.H
32 1740398 SHOE Skid, R.H
33 729580 ROPE GROMMET
34 729667 ROPE GROMMET, Washer
35 1740071 COVER, Auger R.H

Auger and Housing Group
TP 400-5245-IR-SX-N
Manual No. 7006053 522 SINGLE STAGE SNOW THROWER
SERIES 0
8

Auger and Housing Group
Footnotes:
TP 400-5245-IR-SX-N
Manual No. 7006053522 SINGLE STAGE SNOW THROWER
SERIES 0 9
Part No Descri
p
tionItem Qt
y
Note
1 725304 SCREW, 1/4-20 x 1.00
2 725429 NUT, Hex 1/4-20
3 723010 SCREW, 1/4-20 x 3/4
4 725330 WASHER, Flat
5 1740348 HOUSING ASSEMBLY, Auger
6 728095 SCREW, 1/4-20 x 5/8
7 1740380 AUGER, Assembly, 22”
8 724638 RETAINER, Bearing
9 724001 BEARING, Ball
10 724570 SLEEVE, Spacer
11 723659 PLATE, Bearing Retainer
12 723622 PULLEY, Auger Drive V6
13 724547 BEARING, Flange

Chute System Group
TP 400-5245-IR-SX-N
Manual No. 7006053 522 SINGLE STAGE SNOW THROWER
SERIES 0
10

Chute System Group
Footnotes:
TP 400-5245-IR-SX-N
Manual No. 7006053522 SINGLE STAGE SNOW THROWER
SERIES 0 11
Part No Descri
p
tionItem Qt
y
Note
1 723283 SCREW 1/4-14
2 727525 RETAINER, Chute Ring
3 1740060 RING, Chute
4 723873 BOLT, Carriage 5/16-18 x 3/4
5 725320 NUT 5/16-18 Reghex
6 722303 NECK, Chute
7 1716631 CHUTE, 22” Upper
8 727445 T-KNOB, 3.00 Plastic
9 1920283 WASHER, Flat 1 - 1/2 O.D
10 1716642 LOCKWASHER, Shakeproof
11 725408 LOCKNUT, Hex 5/16-18
12 1716624 WASHER Rubber 1-1/2 O.D
13 1740384 BOLT, Upper Chute
14 725332 WASHER, Flat 13/32 x 13/16
15 725321 NUT, 5/16-18 Hex, Nylock
16 1716612 CHUTE, Lower
18 722073 GEAR, 9-Tooth
19 723283 SCREW, 1/4-14 x .75
20 725354 NUT, Push
21 1714084 KNOB, Crank
23 1733369 CRANK, Chute Rotation
24 1720576 HANDLE, Chute Rotator Lower
25 722139 PIN, Hair
26 722076 YOKE ASSEMBLY, Adapter
27 724605 PIN, Cotter
28 724564 PIN, Universal Joint
29 724579 PIN, Clevis
30 724565 HOUSING, Universal
31 722322 ROD, Lower Crank
32 723010 SCREW 1/4-20 x 3/4
33 722315 BLADE, Scraper
34 722398 LOCKNUT, Hex 1/4-20
35 1740347 PIN, Spring 5/32 x 1.00
36 1740346 CLIP, Hairpin 3/32 x 1.625 Black
37 1720577 CHUTE HANDLES, Spliced

Frame and Fuel Tank Group
TP 400-5245-IR-SX-N
Manual No. 7006053 522 SINGLE STAGE SNOW THROWER
SERIES 0
12

Frame and Fuel Tank Group
Footnotes:
TP 400-5245-IR-SX-N
Manual No. 7006053522 SINGLE STAGE SNOW THROWER
SERIES 0 13
Part No Descri
p
tionItem Qt
y
Note
1 723010 SCREW, 1/4-20 x 3/4
2 725330 WASHER, Flat 9/32 x 5/8 x .065
3 1740031E70 BRACKET, Fuel Tank
4 1715917 CAP, Fuel Tank
5 1716634 TANK, Fuel
6 725429 NUT, Hex 1/4-20
7 725408 NUT, Hex 5/16-18
8 722361 TUBING, Fuel Line
9 723462 CLAMP, Fuel Line
10 722264 FILTER, Fuel Line
12 722304 CRADLE ASSEMBLY, Engine
13 727410 FRAME, L.H.
14 727291 SCREW, 5/16-18 x .63
15 727940 SCREW, 1/4-20 x 2.00
16 727517 PLATE, Mounting Support
17 722305 SUPPORT, Frame
18 722320 FRAME, R.H.
19 722633 SCREW, 5/16-18 x 3/4
20 1740032 RING, Foam
21 724068 CLAMP, Fuel Line, Screw Type
22 723210 SCREW, 1/4-20 x 5/8

Engine Drive System Group
TP 400-5245-IR-SX-N
Manual No. 7006053 522 SINGLE STAGE SNOW THROWER
SERIES 0
14

Engine Drive System Group
Footnotes:
TP 400-5245-IR-SX-N
Manual No. 7006053522 SINGLE STAGE SNOW THROWER
SERIES 0 15
Part No Descri
p
tionItem Qt
y
Note
1 * ENGINE, 5HP 4CY B&S Model 09A413-0202-E1
1 * ENGINE, 5HP 4CY B&S Model 09A413-0203-E1
2 722304 CRADLE ASSEMBLY, Engine
3 727410 FRAME, L.H.
4 722360 ANTIVIBRATION MOUNT, Engine
5 727947 BOLT, Hex 5/16-18 x 0865
6 725244 BOLT, Hex 5/16-24 x 1.125
7 725331 WASHER, Flat
8 725408 LOCKNUT, Hex Center 5/16-18
9 723651 GUIDE, Belt
10 723625 BOLT, Hex Head Shank 5/16-1/2 x 11/64
11 723648 PAD, Brake
12 728095 SCREW, 1/4-20 x 5/8
13 727078 IDLER, Arm Pivot
14 723264 SPRING, Extension 3/8 O.D. X .039W
15 725429 NUT, Hex 1/4-20
16 723625 BOLT
17 722046 WIRE, Brake
18 723263 SPRING
19 727500 PIN, Cotter
20 723409 ARM, Idler
21 723256 ROD, Clutch Linkage
22 724085 PULLEY, Idler
23 723012 SCREW, 3/8-16 x 1.50
24 722331 PULLEY, Model 9 Engine
25 722330 BOLT, Engine Pulley
26 725330 WASHER, Flat
27 727940 SCREW, 1/4-20 x 2.00
28 729335 PINCH ROLLER
29 722944 WASHER, Flat
30 724840 NUT, Hex
31 727984 BELT, Drive
32 720025 BOLT, Hex 5/16-18
33 724071 SCREW 3/8-16 x 1.00
34 723979 WASHER, Flat
35 725326 LOCKWASHER, Split
36 725320 NUT, 5/16-18
Note: * For information on Replacement Parts contact the engine manufacturer.

Engine Drive System Group
TP 400-5245-IR-SX-N
Manual No. 7006053 522 SINGLE STAGE SNOW THROWER
SERIES 0
16

Engine Drive System Group
Footnotes:
TP 400-5245-IR-SX-N
Manual No. 7006053522 SINGLE STAGE SNOW THROWER
SERIES 0 17
Part No Descri
p
tionItem Qt
y
Note
1740284 INSTRUCTION BOOK (Not shown)
Note: * For information on Replacement Parts contact the engine manufacturer.

Wheel Assembly Group
TP 400-5245-IR-SX-N
Manual No. 7006053 522 SINGLE STAGE SNOW THROWER
SERIES 0
18

Wheel Assembly Group
Footnotes:
TP 400-5245-IR-SX-N
Manual No. 7006053522 SINGLE STAGE SNOW THROWER
SERIES 0 19
Part No Descri
p
tionItem Qt
y
Note
1 724559 RETAINER, E-Ring
2 725332 WASHER, Flat 13/32 x 13/16
3 725603 WHEEL & TIRE 7” x 1.50”
4 723192 SPACER, Sleeve 13/32 x 5/8
5 722328 AXLE, Single Stage, 22”
6 724750 WASHER, Flat - 25/64 x 1.00 x 1/8

Electric Starter Group
TP 400-5245-IR-SX-N
Manual No. 7006053 522 SINGLE STAGE SNOW THROWER
SERIES 0
20
