Snapper 924I User manual

Parts Manual fo
r
Revision IR,
TWO STAGE INTERMEDIATE FRAM
E
2008 MODELS
McDonough, GA, 30253 U.S.A.
TP 400-5297-IR-IS-N
9/20/2007 Manual No. 7006187
24" SNOW THROWERS
Copyright © 2007
Briggs & Startton Yard Power Products Group
Milwaukee, WI USA. All Rights Reserved
Briggs & Startton Corporation
MODEL
924I (1695313)
924IE (1695314)
924IR (1695411)

Table Of Content
s
TP 400-5297-IR-IS-N
Manual No. 7006187TWO STAGE INTERMEDIATE FRAME
2008 MODELS 3
PAGE GROUP
4Handles & Controls Group
6Auger Housing & Chute Group
10 Auger Drive Group
12 Engine & Frame Group
16 Traction Drive Group
18 Wheels & Tires Group
20 Decals Group

TP 400-5297-IR-IS-N
Manual No. 7006187 TWO STAGE INTERMEDIATE FRAME
2008 MODELS
4

Handles & Controls Group
Footnotes:
TP 400-5297-IR-IS-N
Manual No. 7006187TWO STAGE INTERMEDIATE FRAME
2008 MODELS 5
Part No Descri
p
tionItem Qt
y
Note
1 725684 1 CABLE, Auger
2 723154 2 BOOT, Spring End Cover
3 722520 1 SPRING, Auger Control
4 1920397 1 NUT, Hex Lock Esna Light 1/4-20
5 1734250D 1 PANEL, Dash Upper
6 1919326 4 WASHER, 5/16
7 1921978 4 CAPSCREW, Hex Head 5/16-18 x 2 G5
9 1740573A 1 HANDLE, Upper
10 1960126 2 NUT, Push Pal 1/4 Diameter Stud Capped
11 723725A 1 LEVER ASSEMBLY, Clutch R.H.
12 723705 2 GRIP, Control Lever
13 723707 2 GRIP, Handle
14 1734522 1 ROD, 1/4 Diamter 21.81 Large
15 1734396 2 SPACER
16 1960694 4 NUT, Hex Flange 1/4-20 Esna
18 1960686 4 NUT, Hex Flange 5/16-18 Esna
20 1740701A 1 HANDLE, Lower
22 1927429 2 SCREW, Hex Washer Head Taptite 1/4-20 x 5/8
23 1740698A 1 BRACKET, Gear Select
24 725568 1 LEVER, Spring Shift
25 1923341 2 CAPSCREW, Hex Head 1/4-20 x 3/4 G5
26 1960633 4 CARRIAGE BOLT, 1/4-20 x 1-1/2 G5
27 1935048 2 NUT, Hex Flange 5/16-18 Two-Way Lock
28 1664847 2 SCREW, Hex Washer Head Taptite 5/16-18 x 3/4
29 1921333 2 CAPSCREW, Hex Head 5/16-18 x 1 G5
30 1923358 2 NUT, Hex Centerlock 1/4-20
31 723688A 1 ROD, Shift No Thread
32 723604 1 GRIP, Ball End
34 723723A 1 LEVER ASSEMBLY, Clutch L.H.
35 1740587A 1 HANDLE, Upper L.H.
36 722096 1 CABLE, Front Drive
37 723259 1 BRACKET, Cable Adjusting
38 723949 2 BUMPER
40 1667588 1 BUSHING

Auger Housing & Chute Group
TP 400-5297-IR-IS-N
Manual No. 7006187 TWO STAGE INTERMEDIATE FRAME
2008 MODELS
6

Auger Housing & Chute Group
Footnotes:
TP 400-5297-IR-IS-N
Manual No. 7006187TWO STAGE INTERMEDIATE FRAME
2008 MODELS 7
Part No Descri
p
tionItem Qt
y
Note
1 1935048 1 NUT, Hex Flange 5/16-18 Two Way Lock
2 1734442 1 COVER, Gears
3 1732412 1 BOLT, Shoulder 5/16-18 G5
4 1734774 1 GEAR & SUPPORT ASSEMBLY, Chute
5 1733026 1 WASHER, Powdered Metal
7 1922127 2 CAPSCREW, Hex Head 5/16-18 x 1-3/4 G5
8 1960684 6 NUT, Hex KEPS 5/16-18 Conical Washer
9 1734440 1 SUPPORT, Worm "U" 10GA
10 1734423A 1 SUPPORT, Gear & Chute 10GA
11 722139 1 PIN, Hair Chute Gear
12 1734404 1 ROD, Chute Control E-Coat
13 1714084 1 KNOB, Spinner
14 1960093 1 NUT, Push Pal 3/8 Diameter Stud Capped
15 1734439 1 WORM, Chute L.H.
16 1667588 1 BUSHING
17 1931335 2 CARRIAGE BOLT, 5/16-18 x 1 G5
19 1734201A 1 SUPPORT, Tube 10GA
21 1931337 2 CARRIAGE BOLT, 5/16-18 x 1-1/2 G5
23 1931648 3 SCREW, Hex Whiz Lock Flange 5/16-18 x 1/2
24 2108202 1 BEARING, Ball
25 1960687 8 NUT, Hex Flange 3/8-16 ESNA
26 1734055D 2 BRACKET, Housing 12GA
27 1734063D 2 ANGLE, Fill Strip
28 1931315 17 CARRIAGE BOLT, 1/4-20 x 1/2 G5
29 1726458D 1 PLATE, End L.H.
30 1726457 2 HOUSING, Auger Bearing
31 1668639A 2 CAP, Bearing
32 1960373 6 SCREW, Hex Washer Head Taptite 5/16-18 x 1
33 1727854A 2 SKID, Shoe Reversible
35 1960711 4 CARRIAGE BOLT, 3/8-16 x 3/4 G5
37 1930641 17 NUT, Hex Flange 1/4-20 Whiz Lock Large
38 7300098A 1 BLADE, Scraper 24"
41 1930659 3 RETAINER, Nut, 5/16-18
42 1933896 2 NUT, Hex Lock 10-24 w/Nylon Insert
43 724565 2 BLOCK, Universal Pivot
44 722242 2 CLIP, Retainer

Auger Housing & Chute Group
TP 400-5297-IR-IS-N
Manual No. 7006187 TWO STAGE INTERMEDIATE FRAME
2008 MODELS
8

Auger Housing & Chute Group
Footnotes:
TP 400-5297-IR-IS-N
Manual No. 7006187TWO STAGE INTERMEDIATE FRAME
2008 MODELS 9
Part No Descri
p
tionItem Qt
y
Note
45 2860604 2 SCREW, Hex Washer Head Slot #10C x 1-1/4 G2
46 1726459D 1 PLATE, End R.H. 14GA
47 1734475D 1 WRAPPER ASSEMBLY, 24" Auger
48 1733209 1 STICK, Cleanout w/Brush
49 7091542 3 SCREW, Phillips Head Taptite, Torx 5/16C x 1/2
52 720727 1 WINGNUT, 5/16-18
55 1734227 1 CHUTE & DEFLECTOR ASSEMBLY
57 1665982 1 RETAINER, Bearing
58 1960762 1 NUT, Hex Lock Jam ESNA Lite 3/8-24
59 1734542 1 WASHER, Cup
60 1925003 5/7 SCREW, Hex Washer Head Taptite 1/4-20 x 1/2 (Quantity 7 CE/Export)
62 1960756 1 SCREW, Truss Head Torx 5/16-18 x 3/4
63 1960686 1 NUT, Hex Flange 5/16-18 ESNA
64 1734215A 1 RING, Chute Base
71 1733475 1 GUARD, Chute (CE/Export)
72 1960140 2 NUT, Push (CE/Export)
73 1733476A 1 BRACKET, Chute Guard 12GA (CE/Export)

Auger Drive Group
TP 400-5297-IR-IS-N
Manual No. 7006187 TWO STAGE INTERMEDIATE FRAME
2008 MODELS
10

Auger Drive Group
Footnotes:
TP 400-5297-IR-IS-N
Manual No. 7006187TWO STAGE INTERMEDIATE FRAME
2008 MODELS 11
Part No Descri
p
tionItem Qt
y
Note
1 1668344 2 PIN, , Shear
2 1715091 1 PULLEY, Auger Input
3 1715120A 1 IMPELLER ASSEMBLY
4 1726535A 1 AUGER ASSEMBLY, L.H., 22" Housing
5 1726536A 1 AUGER ASSEMBLY, R.H., 22" Housing
6 2818312 2 KEY, Woodruff
7 1928721 2 SCREW, Set Square Head Cup Point 5/16-18 x 1/2 G8
8 1960474 1 SCREW, Set Square head Cup Point 3/8-16 x 1/2 G8
9 7023590 2 COTTER PIN, 1/4" Self Locking
10 1734573 1 GEAR BOX ASSEMBLY, Auger Drive
11 1734916 2 TUBE

Engine & Frame Group
TP 400-5297-IR-IS-N
Manual No. 7006187 TWO STAGE INTERMEDIATE FRAME
2008 MODELS
12

Engine & Frame Group
Footnotes:
TP 400-5297-IR-IS-N
Manual No. 7006187TWO STAGE INTERMEDIATE FRAME
2008 MODELS 13
Part No Descri
p
tionItem Qt
y
Note
1 1664847 6 SCREW, Hex Washer Head Taptite, 5/16-18 x 3/4
2 1732486 1 COVER, Belt w/Toolbox
3 1733014 1 STOP, Belt
4 1733324 1 V-BELT, 3L 33.13
5 1733583D 1 PLATE, Engine Mount
6 1734311 1 WELD, Auger Idler
7 1734313 1 V-BELT, 4L 37.00 Auger
8 1917356 3 LOCKWASHER, Spring 5/16
9 725367 1 PIN, Hair
10 1919381 3 WASHER, 5/16
11 1921515 1 CAPSCREW, Hex Head 5/16-24 x 3/4 G5
12 1924856 4 SCREW, Hex Washer Head Taptite 5/16-18 x 1/2
13 1927429 12 SCREW, Hex Washer Head Taptite 1/4-20 x 5/8
14 2831277 1 NUT, Hex Flange 5/16-18 Whiz Lock
15 1960027 2 WASHER, 1/2
16 1960251 2 NUT, Hex Centerlock Jaam 3/8-16
17 1921982 1 CAPSCREW, Hex Head 5/16-24 x 1-1/4 G5
18 1960686 3 NUT, Hex Flange 5/16-18 Esna
19 720064 4 CARRIAGE BOLT, 5/16-18 x 1-1/2
20 720376 4 NUT, Push for 1/4 Diameter Thread
21 1740572D 1 FRAME BOX
22 1740906A 1 PANEL, Bottom
23 722072 1 BUSHING, Idler Bracket
24 722085 1 PULLEY, Engine Snow 2Stage
25 722090 1 SPOT WELD, Idler Bracket
26 722365 1 SPACER,-0.53 ID 1.00 OD 1.61 LG AUG IDLER
27 722378 2 IDLER, Plastic Ball Bearing
28 722455 1 SPRING, Extension Auger Idler
29 722887 2 SCREW, 1/4-AB x 3/4 Hex w/Extension Tooth Washer
30 724418 1 SPRING, Extension Idler
31 1921969 1 CAPSCREW, Hex Head 3/8-16 x 1-1/2 G5
32 1733451 1 ARM, Control
33 1735135 1 PIN, Clevis
34 725996 1 BOLT, Hex 5/16-24 x 1
35 1734732 1 HEAT SHIELD, 16GA (Used only on Domestic Models)
36 -- 1 *ENGINE, 9.0TP B&S Mod. #12D1140118-E1
36 -- 1 *ENGINE, 9.0TP B&S Mod. #12D1140119-E1 (CE/Export)
Note: * See your local Briggs & Stratton distributor for parts & service.

Engine & Frame Group
TP 400-5297-IR-IS-N
Manual No. 7006187 TWO STAGE INTERMEDIATE FRAME
2008 MODELS
14

Engine & Frame Group
Footnotes:
TP 400-5297-IR-IS-N
Manual No. 7006187TWO STAGE INTERMEDIATE FRAME
2008 MODELS 15
Part No Descri
p
tionItem Qt
y
Note
36 -- 1 *ENGINE, 9.0TP B&S Mod. #12D1160120-E1 (CE/Export)
39 1929477 3 SCREW, Hex Washer Head Taptite (Used only on Domestic Models)
40 1724064 1 CORD, Electric Extension 10FT (Used only on Domestic Models)
41 2825094 1 TIE, Self Locking
42 1922755 1 WASHER, 3/8
43 1924940 1 WASHER, 3/8
Note: * See your local Briggs & Stratton distributor for parts & service.

Traction Drive Group
TP 400-5297-IR-IS-N
Manual No. 7006187 TWO STAGE INTERMEDIATE FRAME
2008 MODELS
16

Traction Drive Group
Footnotes:
TP 400-5297-IR-IS-N
Manual No. 7006187TWO STAGE INTERMEDIATE FRAME
2008 MODELS 17
Part No Descri
p
tionItem Qt
y
Note
1 1920397 2 NUT, Hex Lock Esna Light 1/4-20
2 1921959 3 CAPSCREW, Hex Head 1/4-20 x 5/8 G5
3 1922837 1 CAPSCREW, Hex Head 1/4-20 x 1-1/2 G5
4 1923341 2 CAPSCREW, Hex Head 1/4-20 x 3/4 G5
5 1923358 2 NUT, Hex Centerlock 1/4-20
6 1924856 8 SCREW, Hex Washer Head Taptite 5/16-18 x 1/2
7 1928372 3 NUT, Hex Keps 1/4-20
8 1960027 2 WASHER, 1/2
9 720220 1 BOLT, Hex 1/4-20 x 1-3/4 G8
10 721910 5 RETAINER, Ring 7/16
12 722069 1 PLATE, Swinging
13 722070 1 BRACKET, Cable Spool
14 722080 1 WELD, Axle Sprocket
15 722081 1 SPROCKET, Set
16 722082 1 AXLE, Swing Plate
17 722083 1 HEX SHAFT & SPROCKET ASSEMBLY
18 722091 2 BEARING, Axle D-Hole
19 722092 1 FRICTION PULLEY ASSEMBLY
20 722095 1 CABLE, Front Drive
21 722110 1 SPACER, Friction Pulley
22 722185 1 WHEEL, Friction
23 722209 1 AXLE
24 722377 1 WELD, Spring Link
25 722391 1 NUT, 38-24 FlangeLock
26 722423 3 SPRING, Extension
27 723655 4 RETAINER & BUSHING ASSEMBLY
28 723694 1 HUB, Friction Wheel & Bearing
29 724613 1 CHAIN, Roller
30 724619 5 WASHER, Flat
31 724621 1 SPOOL CABLE, Auger Control
32 724627 1 CHAIN, Roller
33 724636 1 BEARING, Flange 1/2 x 7/8
35 722078 1 WELD, Speed Select
36 1733326 1 RING, Retaining Extension

Wheels & Tires Group
TP 400-5297-IR-IS-N
Manual No. 7006187 TWO STAGE INTERMEDIATE FRAME
2008 MODELS
18

Wheels & Tires Group
Footnotes:
TP 400-5297-IR-IS-N
Manual No. 7006187TWO STAGE INTERMEDIATE FRAME
2008 MODELS 19
Part No Descri
p
tionItem Qt
y
Note
1 1679697 2 PIN, Klik
2 1734045 2 WHEEL& TIRE ASSEMBLY, 13 x 5
3 1657528 2 RETAINING RING, Extension, #75 3/4 Self Lock
4 725394 2 WASHER, Flat
5 1734997 2 WHEEL 3.25 Wide 6.00 Diameter
6 1734998 2 TIRE, 13 x 6.00 Snow Hog
7 2172353 2 VALVE STEM & CAP, Air

Decals Group
TP 400-5297-IR-IS-N
Manual No. 7006187 TWO STAGE INTERMEDIATE FRAME
2008 MODELS
20
