Snapper 300T User manual

Parts Manual fo
r
Revision 6,
FRONT TINE TILLERS
SERIES 0 & 1
COPYRIGHT
©
2006
McDonough, GA, 30253 U.S.A.
TP 400-5174-6-RT-N
3/7/2006 Manual No. 7006003
SNAPPER PRODUCTS, INC.
ALL RIGHTS RESERVED.
MODEL
300
T
301
T
401TCR
500
T
500T
C
500TR
C
501
T
501T
C

Table Of Content
s
TP 400-5174-6-RT-N
Manual No. 7006003FRONT TINE TILLERS
SERIES 0 & 1 3
PAGE GROUP
4Handles, Controls
6Frame Skid Arm
8Transport Wheels & Arms
10 Chain Case
12 Drive - Belt Guard
14 High Torque Drive Kit #60264
16 Tines

Handles, Controls
TP 400-5174-6-RT-N
Manual No. 7006003 FRONT TINE TILLERS
SERIES 0 & 1
4

Handles, Controls
Footnotes:
TP 400-5174-6-RT-N
Manual No. 7006003FRONT TINE TILLERS
SERIES 0 & 1 5
Part No Descri
p
tionItem Qt
y
Note
1 7011870 2 GRIP, Handle
2 7029560 HANDLE BAR, Left Hand Was 36216
3 7018073 CONTROL, Throttle (B&S Shown)
7018092 CONTROL, Throttle (Tec.)
4 7037321 BRACE, Cross
5 7019295 DECAL, SNAPPER Was 18593
6 7031192 2 TIE-BAR
7 7057481 ASSM'Y., Handle (Includes items 8 thru 10 & 14)
8 7036217 HANDLE BAR, Right Hand
9 7040604 LEVER, Clutch Was 40366
10 7023792 PIN Was 11886
11 7091294 WASHER, 1/4 Flat (Discontinued) Was 90055
12 7011187 SPRING (Discontinued)
13 7011715 PIN (Discontinued)
14 7091020 NUT, Push Was 90489
15 7090111 7 SCREW, 1/4-28x1-3/4" Hex Hd. Cap
16 7090053 7 WASHER, 1/4 Internal Tooth
17 7090095 7 NUT, 1/4-28
18 7011709 2 CLIP, Throttle Control
19 7090222 4 NUT, 5/16-24 Hex Lock
20 7090238 2 SCREW, 5/16-24x1" Hex Hd. Cap
21 7090572 2 SCREW, 5/16-24x4" Hex Hd. Cap
22 7011708 GUIDE, Cable
23 7050344 CABLE, Clutch Assm'y. (Includes chain)
24 7011706 SPRING, Clutch Cable

Frame Skid Arm
TP 400-5174-6-RT-N
Manual No. 7006003 FRONT TINE TILLERS
SERIES 0 & 1
6

Frame Skid Arm
Footnotes:
TP 400-5174-6-RT-N
Manual No. 7006003FRONT TINE TILLERS
SERIES 0 & 1 7
Part No Descri
p
tionItem Qt
y
Note
1 7011192 2 HITCH
2 7047339 SKID-ARM
3 7021186 * ARM, Idler
4 7031167 * BRACKET, Idler
5 7031168 * LINK, Idler
6 7037323 RAIL, Left Hand
7 7037324 RAIL, Right Hand
8 7090222 6 NUT, 5/16-24 Hex Center Lock
9 7090289 2 * NUT, 3/8-24 Hex Center Lock
10 7011193 SPRING, Pin Release
11 7090245 SCREW, 5/16-24 x 2" Hex Head Cap, Gr. 2
12 7012591 PIN, Skid Arm Release
13 7010948 * PULLEY, Idler
14 7090233 2 SCREW, 5/16-24 x 3/4" Hex Head Cap, Gr. 5
15 7090122 * WASHER, 3/8 SAE
16 7091630 2 * NUT, 3/8-24 Hex Gr. 2 Was 90155
17 7091297 NUT, 5/16-24 Hex Was 90223
18 7090187 4 WASHER, 5/16 Split Lock
19 7090188 8 WASHER, 5/16 SAE
20 7090244 4 SCREW, 5/16-24 x 1-3/4" Hex Head Cap, Grade 2
21 7090358 3 SCREW, 5/16-24 x 2-1/2" Hex Head Cap, Grade 5
7050340 ASY, Idler Arm (Incl. items 3, 4, 5, 9, 13, 15 and
16)
NOTE: * Included in Idler Arm Assembly

Transport Wheels & Arms
TP 400-5174-6-RT-N
Manual No. 7006003 FRONT TINE TILLERS
SERIES 0 & 1
8

Transport Wheels & Arms
Footnotes:
TP 400-5174-6-RT-N
Manual No. 7006003FRONT TINE TILLERS
SERIES 0 & 1 9
Part No Descri
p
tionItem Qt
y
Note
1 TRANSPORT ASSM'Y. (NA)
2 7040367 FRAME, Arm-Wheel Structure
3 7021184 PIN, Wheel Arm Lock
4 7011190 SPRING, Lock Pin
5 7091809 PIN, 1/8x1-1/4" Cotter Was 90042
6 7090250 WASHER, 1/2 SAE
7 7090289 3 NUT, 3/8-24 Hex Lock
8 7090171 SCREW, 3/8-24x2-3/4" Hex Hd. Cap
9 7018228 2 WHEEL, 10"x1-3/4"
10 7091526 2 BOLT, 3/8-24x2-5/16" Shoulder Was 11720

Chain Case
TP 400-5174-6-RT-N
Manual No. 7006003 FRONT TINE TILLERS
SERIES 0 & 1
10

Chain Case
Footnotes:
TP 400-5174-6-RT-N
Manual No. 7006003FRONT TINE TILLERS
SERIES 0 & 1 11
Part No Descri
p
tionItem Qt
y
Note
1 7050812 CHAIN CASE ASY. (Incl. Items 2 thru 28)
2 7050726 CASE ASY., R.H. (Incl. Items 3 thru 6)
7073261 CASE, R.H. Was 47722 (Without Bearings,
Seals, Plug)
3 7010932 BEARING, Drive Shaft
4 7011177 PLUG, Wrench
5 7011176 BEARING, Needle
6 7013681 * SEAL, Tine Rotor Shaft
7 7050725 CASE ASY., L.H. (Incl. Items 3, 5, 6, 8)
7047721 CASE, L.H. (Without Bearings, Seals)
8 7011179 SEAL, Drive Shaft
9 7021751 SPACER, Drive Shaft
10 7010211 KEY, 3/16 x 3/4" Woodruff
11 7040413 SHAFT, Drive
12 7020938 WASHER, Shim
13 7050724 SPROCKET, Intermediate Asy. (Includes Item 14)
7040437 SPROCKET, Intermediate (Without Bearings)
14 7011178 2 BEARING, Roller (Press Fitted Flush)
15 7021752 RACE, Sprocket Bearing
16 7011183 CHAIN, Primary Drive
17 7018071 GASKET, Case Housing
18 7092062 NUT, 5/16-24 Hex Lock Was 11201
19 7090554 HWST, 5/16C X3/8 ZP
20 7014980 WASHER, Seal
21 7090222 2 NUT, 5/16-24 Hex Center Lock
22 7012232 SPACER, Case Housings
23 7011181 SPACER, Rotor Shaft
24 7011182 CHAIN, Final Drive
25 7040364 SHAFT, Tine Rotor
26 7090227 2 SCREW, 5/16-24 x 5/8" Hex Head Cap, Grade 2
27 7090358 SCREW, 5/16-24 x 2-1/2" Hex Head Cap, Grade 5
28 7090361 23 SCREW, 5/16-18 x 5/8" Hex Washer Self-Tap
29 7011024 PLUG
30 7011191 2 SPACER, Case Housing to Rail
NOTE: * 60328 TOOL, Seal Replacement

Drive - Belt Guard
TP 400-5174-6-RT-N
Manual No. 7006003 FRONT TINE TILLERS
SERIES 0 & 1
12

Drive - Belt Guard
Footnotes:
TP 400-5174-6-RT-N
Manual No. 7006003FRONT TINE TILLERS
SERIES 0 & 1 13
Part No Descri
p
tionItem Qt
y
Note
1 7037747 GUARD, Belt
2 7011969 V-BELT (B&S Engine) L-451
7015483 V-BELT (Robin Engines)('87 Models &
Earlier)
7015740 V-BELT (Robin Engines)('88 Models &
Later)
3 7011809 PULLEY, Engine
4 7031964 GUIDE, Belt (B&S Engine)
5 7037748 MOUNT, Engine (B&S Engine)
6 7011194 PULLEY, 8" (B&S)('87 & Earlier Robin)
7015741 PULLEY, ('88 & Later Robin)
7 7031963 CLIP, Rear
8 7012447 HANGER, Guard
9 7038250 GUIDE, Belt (Wisconsin/Robin Engine)
10 7071916 DECAL-SNAPPER Was 18586
11 7015490 DECAL (FT4X), (Wisconsin/Robin Engine)
12 7090534 2 SCREW, 5/16-18x1/2" Hex Hd. Cap Was 90203
13 7090391 3 WASHER, 5/16 Internal Tooth Lock
14 7090815 SCREW, 3/8-16x1/2" Hex Hd. Cap, Self Tapping Was 90506
15 7090122 WASHER, 3/8 SAE
16 7091502 SCREW, 1/2-20x3/4" Hex Hd. Cap Was 90367
17 7090509 WASHER, 1/2 Internal Tooth Lock
18 7091511 2 NUT, 5/16-18 Hex Was 90196
19 7011791 RETAINER, Bolt
20 7010211 KEY, #9 Woodruff
21 7090201 2 SCREW, 5/16-18 Set, Hex Socket
22 7090222 NUT, 5/16-24 Hex Lock
23 7090316 BOLT, 5/16-18x3/4" Carriage
24 7090187 WASHER, 5/16 Split Lock
25 7090948 2 BOLT, M8x19
26 7029840 WASHER, 5/16 Faceted Was 11784
27 7010061 KEY, 3/16x3/16x1"

High Torque Drive Kit #60264
TP 400-5174-6-RT-N
Manual No. 7006003 FRONT TINE TILLERS
SERIES 0 & 1
14

High Torque Drive Kit #60264
Footnotes:
TP 400-5174-6-RT-N
Manual No. 7006003FRONT TINE TILLERS
SERIES 0 & 1 15
Part No Descri
p
tionItem Qt
y
Note
1 7012249 V-BELT (Reducer to Chain Drive 37")
2 7012248 V-BELT (Engine to Reducer 26.75")
3 7059526 SPEED REDUCER ASSM'Y. (no longer available)
4 7091630 2 NUT, 3/8-24 Hex Was 90155
5 7031168 LINK, Idler
6 7090122 2 WASHER, 3/8" Flat
7 39585 MOUNT, Speed Reduction (no longer available)
8 7090570 BOLT, 1/2-13x2-3/4" Carriage
9 7031909 GUIDE, Belt
10 7091587 2 WASHER, 1/2 Flat Was 90250
11 7012254 RACE, Bearing
12 7091316 NUT, 1/2-13 Hex Was 90258
13 7057094 SHEAVE ASSM'Y. (Includes item 14)
14 7012252 2 BEARING
15 7012124 PULLEY, Idler
16 7090289 NUT, 3/8-24 Hex Lock
17 7018182 ARM, Pulley
18 7060274 HARDWARE BAG (no longer available) (Includes items 19 thru 23)
19 7090209 2 SCREW, 5/16-18x1" Hex Head Cap
20 7090188 4 WASHER, 5/16 Flat
21 7090500 2 WASHER, 7/16 Flat
22 7090187 2 WASHER, 5/16 Split Lock
23 7091511 3 NUT, 5/16-18 Hex Was 90196

Tines
TP 400-5174-6-RT-N
Manual No. 7006003 FRONT TINE TILLERS
SERIES 0 & 1
16

Tines
Footnotes:
TP 400-5174-6-RT-N
Manual No. 7006003FRONT TINE TILLERS
SERIES 0 & 1 17
Part No Descri
p
tionItem Qt
y
Note
1 7050721 TINE ASSM'Y. (Includes items 2 thru 7)
2 7049572 TINE ASSM'Y., Right Hand, Inside
3 7049569 TINE ASSM'Y., Right Hand, Outside
4 7049570 TINE ASSM'Y., Left Hand, Outside
5 7049571 TINE ASSM'Y., Left Hand, Inside
6 7011713 4 PIN, 3/8x2-1/4" Clevis
7 7011714 4 PIN, Hair

Parts Manual fo
r
FRONT TINE TILLERS
SERIES 0 & 1
IT IS THE POLICY OF SNAPPER TO IMPROVE ITS PRODUCTS
WHENEVER IT IS POSSIBLE AND PRACTICAL TO DO SO. WE
RESERVE THE RIGHT TO MAKE CHANGES OR ADD IMPROVEMENTS
AT ANY TIME WITHOUT INCURRING ANY OBLIGATION TO MAKE
SUCH CHANGES ON PRODUCTS MANUFACTURED PREVIOUSLY.
Revision 6,
COPYRIGHT
©
2006
TP 400-5174-6-RT-N
3/7/2006 Manual No. 7006003
SNAPPER PRODUCTS, INC.
ALL RIGHTS RESERVED.
McDonough, GA, 30253 U.S.A.
