Snapper 6016RT User manual

Parts Manual fo
r
Revision 2,
INTERMEDIATE REAR TINE TILLER
COPYRIGHT
©
2006
McDonough, GA, 30253 U.S.A.
TP 400-5131-2-RT-N
10/11/2006 Manual No. 7006257
SNAPPER PRODUCTS, INC.
ALL RIGHTS RESERVED.
6 & 7 HP 16" TWO SPEED
MODEL
6016RT
(
7800052
)
7016RT
(
7800053
)

Table Of Content
s
TP 400-5131-2-RT-N
Manual No. 7006257INTERMEDIATE REAR TINE TILLER
3
PAGE GROUP
4Handle Bar Group
6Engine, Belts & Wheels Group - 6 HP
10 Engine, Belts & Wheels Group - 7 HP
14 Transmission Group
16 Wheel & Tiller Shaft Group
18 Hood, Drag Stake & Tine Group - 6 HP
20 Hood, Drag Stake & Tine Group - 7 HP
22 Decal Group
24 Hiller/Furrower Attachment

Handle Bar Group
TP 400-5131-2-RT-N
Manual No. 7006257 INTERMEDIATE REAR TINE TILLER
4

Handle Bar Group
Footnotes:
TP 400-5131-2-RT-N
Manual No. 7006257INTERMEDIATE REAR TINE TILLER
5
Part No Descri
p
tionItem Qt
y
Note
1 1716699 2 HANDLE GRIP, Drive Control Lever
2 1722325 1 LEVER, Drive Control
3 1719038 2 HANDLE GRIP
4 1960392 4 SCREW, Pan Head Phillips #10-24 x 1/2
5 1716723 1 BRACKET, Drive Control Lever LH
6 1933896 6 NUT, Hex Nylock, 10-24
7 1716720 1 SPRING, Forward Cable Adjustment
8 2820438 4 NUT, Hex Jam, 5/16-24
9 1723692 1 HANDLE BAR ASSEMBLY
10 1719037 2 CABLE ASSEMBLY
11 1719063 2 C-CLAMP
12 1921332 3 CAPSCREW, Hex Head, 5/16-18 x 3/4
13 1723703 1 PIN, Detent
14 1723695 1 PIVOT ROD ASSEMBLY
15 1723696 1 PIVOT MOUNT ASSEMBLY
16 1921210 4 CAPSCREW, Hex Head, 3/8-16 x 1
17 1916950 5 NUT, Hex, 3/8-16
18 1924940 2 WASHER
19 1723694 1 PIVOT, Handle Bar Mount
20 1920415 1 CAPSCREW, Hex Head, 3/8-16 x 1-1/4
21 1716770 1 WASHER
22 1922648 1 CAPSCREW, Hex Head 3/8-16 x 4
23 1723697 1 PIVOT, Hnadle Bar Height Adjustment
24 1960044 2 WASHER
25 1716729 1 LINK, Reverse
26 1921977 1 CAPSCREW, Hex Head, 5/16-18 x 1-1/4
27 1716725 1 HANDLE, Reverse
28 1716704 1 BUSHING, Pivot, 5/16
29 1716722 1 BRACKET, Drive Control Lever RH
30 1935048 2 NUT, Hex Flange Tow Way Lock, 5/16-18
31 1921332 4 BOLT, Hex Flange Head, 5/16-18 x 3/4

Engine, Belts & Wheels Group - 6 HP
TP 400-5131-2-RT-N
Manual No. 7006257 INTERMEDIATE REAR TINE TILLER
6

Engine, Belts & Wheels Group - 6 HP
Footnotes:
TP 400-5131-2-RT-N
Manual No. 7006257INTERMEDIATE REAR TINE TILLER
7
Part No Descri
p
tionItem Qt
y
Note
1 1722157 1 BRACKET, Engine
2 1723711 1 SPACER, Engine
3 1722158 1 PULLEY, Engine 2 Groove
4 1716770 1 WASHER
5 1917356 2 LOCKWASHER, Spring, 5/16
6 1921515 2 CAPSCREW, Hex Head, 5/16-24 x 3/4
7 2805850 2 KEY, PARALLEL PLN, 3/16 x 3/16 x 1-3/32
8 1960345 1 CAPSCREW, Hex Head, 3/8-24 x 2
9 1716728 2 YOKE, Cable
10 1722159 1 ARM, Pivot
11 1716702 2 PIN, Link Forward/Reverse
12 1722162 1 GUIDE, Belt Reverse
13 1924940 4 WASHER, 3/8
14 1716805 1 PULLEY, Idler Reverse
15 1916950 2 NUT, Hex Center Lock, 3/8-16
16 1716703 2 PIN, Cotter
17 1723710 1 BOLT, Flat Head, 5/16-24 x 1-1/2
18 1722160 1 PIVOT
19 1960044 3 WASHER, 5/16
20 1716766 1 V-BELT, Forward
21 1716802 2 SPRING, Idler Arm
22 1935048 3 NUT, Hex Flange Lock, 5/16-18
23 1921332 3 BOLT, Hex Flange Head, 5/16-18 x 3/4
24 1722161 1 GUIDE, Belt Forward
25 1722165 1 COVER, Belt
26 1722163 1 PULLEY, Transmission 2 Groove
27 1721525 1 WHEEL & TIRE ASSEMBLY TILLER, Left
28 1721524 1 WHEEL & TIRE ASSEMBLY TILLER, Right
29 1716776 2 PIN, Lock
30 1716803 1 PULLEY, Forward Idler
31 1722166 1 ARM, Idler Forward
32 1722168 1 SCREW, Hex Socket Shoulder, 5/16-18 x 3/8
33 1925690 1 CAPSCREW, Hex Head, 5/16-18 x 3-1/2
34 1722144 1 V-BELT, Reverse
35 1922127 4 CAPSCREW, Hex Head, 5/16-18 x 1-3/4
36 1 ^ ENGINE, 6HP B&S INTEK, Model #126412-0023-E2
37 1721528 1 ^^ BUMPER, Guard (Optional)
^See your local Briggs & Stratton dealer for Parts & Service.
^^Bumper is not standard with the 6HP tiller, but it is an available option, order the bumper guard (Ref# 37), 4 nuts (Ref#
22) and 4 capscrews (Ref# 35).

Engine, Belts & Wheels Group - 6 HP
TP 400-5131-2-RT-N
Manual No. 7006257 INTERMEDIATE REAR TINE TILLER
8

Engine, Belts & Wheels Group - 6 HP
Footnotes:
TP 400-5131-2-RT-N
Manual No. 7006257INTERMEDIATE REAR TINE TILLER
9
Part No Descri
p
tionItem Qt
y
Note
38 1919384 1 WASHER
39 2860164 1 WASHER
^See your local Briggs & Stratton dealer for Parts & Service.
^^Bumper is not standard with the 6HP tiller, but it is an available option, order the bumper guard (Ref# 37), 4 nuts (Ref#
22) and 4 capscrews (Ref# 35).

Engine, Belts & Wheels Group - 7 HP
TP 400-5131-2-RT-N
Manual No. 7006257 INTERMEDIATE REAR TINE TILLER
10

Engine, Belts & Wheels Group - 7 HP
Footnotes:
TP 400-5131-2-RT-N
Manual No. 7006257INTERMEDIATE REAR TINE TILLER
11
Part No Descri
p
tionItem Qt
y
Note
1 1722157 1 BRACKET, Engine
2 1723711 1 SPACER, Engine
3 1722158 1 PULLEY, Engine 2 Groove
4 1716770 2 WASHER
5 1917356 2 LOCKWASHER, Spring 5/16
6 1921515 2 CAPSCREW, Hex Head, 5/16-24 x 3/4
7 2805850 2 KEY, Parallel
8 1960345 1 CAPSCREW, Hex Head, 3/8-24 x 2
9 1716728 2 YOKE, Cable
10 1722159 1 ARM, Pivot
11 1716702 2 PIN, LINK Forward/Reverse
12 1722162 1 GUIDE, Belt Reverse
13 1924940 4 WASHER, 3/8
14 1716805 1 PULLEY, Idler Reverse
15 1930651 2 NUT, Hex Center Lock, 3/8-16
16 1716703 2 PIN, Cotter
17 1723710 1 BOLT, Flat Head, 5/16-24 x 1-1/2
18 1722160 1 PIVOT
19 1960044 3 WASHER, 5/16
20 1716766 1 V-BELT, Forward
21 1716802 2 SPRING, Idler Arm
22 1935048 7 NUT, Hex Flange 5/16-18
23 1921332 3 BOLT, Hex Flange Head, 5/16-18 x 3/4
24 1722161 1 GUIDE, Belt Forward
25 1722165 1 COVER, Belt
26 1722163 1 PULLEY, Transmission 2 Groove
27 1716773 1 WHEEL & TIRE ASSEMBLY, Tiller LH
28 1716775 1 WHEEL & TIRE ASSEMBLY, Tiller RH
29 1716782 2 CAPSCREW, Hex Socket Head, 1/4-20 x 2-3/32
30 1960151 2 WASHER, 1/4
31 1716781 2 SPRING
32 1716778 2 PIN, Lock
33 2828372 2 NUT, Hex KEPS 1/4-20
34 1716777 1 KNOB, Lock Out Set of Two
35 1722185 2 SETSCREW, Wheel Lockout
36 1722171 2 CLAMP, C Wheel Lockout
37 1721528 1 BUMPER, Guard
^See your local Briggs & Stratton dealer for Parts & Service.

Engine, Belts & Wheels Group - 7 HP
TP 400-5131-2-RT-N
Manual No. 7006257 INTERMEDIATE REAR TINE TILLER
12

Engine, Belts & Wheels Group - 7 HP
Footnotes:
TP 400-5131-2-RT-N
Manual No. 7006257INTERMEDIATE REAR TINE TILLER
13
Part No Descri
p
tionItem Qt
y
Note
38 1922127 8 CAPSCREW, Hex Head, 5/16-18 x 1-3/4
39 1722166 1 ARM, Idler Forward
40 1716803 1 PULLEY, Forward Idler
41 1722168 1 SCREW, Hex Socket Shoulder, 5/16-18 x 3/8
42 1925690 1 CAPSCREW, Hex Head, 5/16-18 x 3-1/2
43 1722144 1 V-BELT, Reverse
44 1 ^ ENGINE, 7HP B&S INTEK, Model #120412-0141-E1
45 1919384 1 WASHER, 3/8
46 2860164 1 WASHER
^See your local Briggs & Stratton dealer for Parts & Service.

Transmission Group
TP 400-5131-2-RT-N
Manual No. 7006257 INTERMEDIATE REAR TINE TILLER
14

Transmission Group
Footnotes:
TP 400-5131-2-RT-N
Manual No. 7006257INTERMEDIATE REAR TINE TILLER
15
Part No Descri
p
tionItem Qt
y
Note
1 1723700 1 DIPSTICK
2 1921332 12 CAPSCREW, Hex Head, 5/16-18 x 3/4
3 1722327 1 COVER PLATE & MOUNT
4 1716753 1 BRACKET, Engine Mount LH
5 1716752 1 BRACKET, Engine Mount RH
6 1935048 4 NUT, Hex Flange Lock, 5/16-18
7 1716789 2 GASKET, Housing & Transmission Cover
8 1716791 4 SEAL, Housing
9 1716792 2 GASKET, Bearing Cap Front/Rear
10 1716796 1 CAP, Rear Bearing
11 1716797 1 SEAL, Oil, Drive Shaft
12 1716798 3 BOLT, Hex Flange Head, 1/4-20 x 3/4
13 1716790 2 PLUG, Pipe, Socket Head, Oil Check, 1/4-18
14 1722330 1 TRANSMISSION, Housing, Tiller Casting
15 1716793 1 CAP, Rear Bearing
16 1716795 3 BOLT, Hex Flange Head, 1/4-20 x 7/8
17 1721511 1 BRACKET, Depth Regulator RT
18 1716799 1 GASKET KIT, Oil Seal ( Includes Ref. 7, 8, 9, and 11)
19 1723699 1 TRANSMISSION ASSEMBLY, Complete, w/Lockouts - 6 HP
19 1723701 TRANSMISSION ASSEMBLY, Complete - 7 HP

Wheel & Tiller Shaft Group
TP 400-5131-2-RT-N
Manual No. 7006257 INTERMEDIATE REAR TINE TILLER
16

Wheel & Tiller Shaft Group
Footnotes:
TP 400-5131-2-RT-N
Manual No. 7006257INTERMEDIATE REAR TINE TILLER
17
Part No Descri
p
tionItem Qt
y
Note
1 1716793 1 CAP, Rear Bearing
2 1716825 1 SHIM SET, Rear Bearing Cap
2 1716826 1 SHIM, 0.062 THK1-3/4” x OD1806 (As Required)
2 1716827 1 SHIM, 0.030 THK1-3/4” x OD1807 (As Required)
2 1716828 1 SHIM, 0.015 THK1-3/4” x OD1808 (As Required)
2 1716829 1 SHIM, 0.010 THK1-3/4” x OD1809 (As Required)
3 1716810 2 BEARING, Tapered (Cone & Race)
4 1716824 4 SPACER, 1” x 1-1/4”
5 1716816 4 BUSHING
6 1716815 4 SHIM SET, Axle Spacer
6 1716817 1 SHIM, 0.062 THK1-3/8” x OD1705 (As Required)
6 1716818 1 SHIM, 0.030 THK1-3/8” x OD1706 (As Required)
6 1716819 1 SHIM, 0.015 THK1-3/8” x OD1707 (As Required)
6 1716820 1 SHIM, 0.010 THK1-3/8” x OD1708 (As Required)
7 1716830 4 RING, Snap, Internal Retainer
8 1716791 4 SEAL, Housing
9 1716821 2 RING, Snap, External Retainer
10 1722333 1 DRIVE SHAFT, Main
11 1716813 2 KEY, Parallel Plane 1/4” x 1/4” x 1”
12 1716814 1 GEAR, Worm, Wheels Shaft
13 1716811 1 SHAFT ASSEMBLY, Wheels w/Lock Pin
13 1716812 1 SHAFT ASSEMBLY, Wheel w/Lock Pin
14 1716796 1 CAP, Rear Bearing
15 1716797 1 SEAL, Oil, Drive Shaft
16 2860164 1 WASHER, 5/8
17 1716811 1 SHAFT ASSEMBLY, Wheels w/Lock Pin
18 1716823 1 GEAR, Worm Shaft

Hood, Drag Stake & Tine Group - 6 HP
TP 400-5131-2-RT-N
Manual No. 7006257 INTERMEDIATE REAR TINE TILLER
18

Hood, Drag Stake & Tine Group - 6 HP
Footnotes:
TP 400-5131-2-RT-N
Manual No. 7006257INTERMEDIATE REAR TINE TILLER
19
Part No Descri
p
tionItem Qt
y
Note
1 1723703 1 PIN, Detent, 5/16
2 1723702 1 LEVER, Depth Regulator
3 1921958 2 CAPSCREW, Hex Head, 1/4 - 20 x 1/2
4 1722329 1 HOOD, Tiller, No Decal
5 1917356 2 LOCKWASHER, Spring, 5/16
6 1920787 2 CAPSCREW, Hex Head, 5/16-18 x 1/2
7 1921971 2 CAPSCREW, Hex Head, 3/8-16 x 1-3/4
8 1721513 1 TINE ASSEMBLY, LH
9 1916965 2 LOCKWASHER, Spring, 3/8
10 1930651 2 NUT, Hex Center Lock, 3/8-16
11 1935048 2 NUT, Hex Flange, 5/16-18
12 1721514 1 TINE ASSEMBLY, RH
13 1716701 2 BOLT, Hex Flange Head, 5/16-18 x 1/2

Hood, Drag Stake & Tine Group - 7 HP
TP 400-5131-2-RT-N
Manual No. 7006257 INTERMEDIATE REAR TINE TILLER
20
