SO-LOW MV85 Series User manual

To reduce the risk of fire, electric shock or injury to persons using this freezer, read all
instructions and follow basic safety precautions before using the unit, including the following:
Do not modify the plug provided with the freezer. If it will not fit the outlet,
have a proper outlet installed by a qualified electrician.
Do not position equipment so it is difficult to disconnect from the power supply.
freezer must be at least 6” away from any wall or object on any side.
While under warranty, do not attempt to repair or replace any part of the
freezer for servicing without first contacting the So-Low Service Department.
SAVE THESE INSTRUCTIONS

♦
● MEANING OF ILLUSTRATED SYMBOLS…………………………………...
● STARTING INSTRUCTIONS…………………………………………………..
♦
●PRE-INSTALLATION INFORMATION………………………………………...
♦
● TEMPERATURE SPECIFICATIONS………………………………………….
● ELECTRICAL SPECIFICATIONS……………………………………………..
♦
♦
♦
♦
♦
● ALARM SYSTEM………………………………………………………………..
8
♦
● CUSTOM SETTINGS………….………………………………………………...
9
● ADVANCED SETTINGS………………………………………………………...
10
● SERVICE SETTINGS…………………………………………………..............
11
● ADVANCD SERVICE SETTINGS……………………………………………...
11
♦
● DOWNLOAD…………………………………………………............................
12
● UPLOAD…………………………………………………..................................
12
♦
♦
● MV85-1 DIAGRAM………………………………………….............................
● MV85-1 PARTS LIST……………………………………….............................
● MV85-2 DIAGRAM………………………………………….............................
● MV85-2 PARTS LIST……………………………………….............................
● MV85-3 DIAGRAM………………………………………….............................
● MV85-3 PARTS LIST……………………………………….............................

Various symbols are used in this safety manual in order to use the unit without
danger of injury and damage of the unit. A list of problems caused by ignoring
the warnings and improper handling is divided as shown below. Be sure that you
understand the warnings and cautions in this manual before operating the unit.
CAUTION
BLACK WITH YELLOW BACKGROUND
LIGHTNING BOLT
CAUTION, RISK OF ELECTRICAL SHOCK
WARNING
BLACK WITH YELLOW BACKGROUND
EXCLAMATION POINT
CAUTION, REFER TO ACCOMPANYING DOCUMENTS

WARNING
THIS FREEZER IS PROVIDED WITH AN INPUT CIRCUIT
PROTECTIVE DEVICE WHICH SHALL BE MAINTAINED
AND SERVICED BY QUALIFIED PERSONNEL ONLY.
CAUTION
UNDER NO CIRCUMSTANCES USE EXTENSION LEADS
OR ADAPTORS. CONNECT THE APPLIANCE DIRECTLY
TO A FIXED INSTALLATION. IF THE APPLIANCE IS
CONNECTED TO A LONG EXTENSION CABLE THERE
IS A RISK THAT THE CABLE WILL BECOME HOT.
CAUTION
UNPLUG FREEZER BEFORE ANY TECHNICAL SERVICE IS
PERFORMED ON THE UNIT.
WARNING
DO NOT POSITION EQUIPMENT SO IT IS DIFFICULT TO
DISCONNECT FROM THE POWER SUPPLY.

-40°C TO -85°C
•
•
MV85-1
MV85-2
MV85-3
115 VOLTS
60 HERTZ
1 PHASE
15 AMP
DEDICATED LINE
NEMA 5-15
WARNING
ONLY PLUG THIS UNIT INTO THE PROPER OUTLET. DO
NOT ATTEMPT TO MODIFY PLUG IN ANY WAY. IMPROPER
USE OF THE ELECTRICAL PLUG WILL VOID WARRANTY
CAUTION
FAILURE TO GROUND THE EQUIPMENT MAY CAUSE
PERSONAL INJURY OR DAMAGE TO THE EQUIPMENT.
ALWAYS CONFORM TO THE ELECTRICAL CODES.

MODEL
CU.
FT.
REFRIGERATION SYSTEM
REFRIGERANT
MV85-1
0.25
3/8 HP REFRIGERATION SYSTEM
EP88 –6.10 OZ.
MV85-2
2
3/8 HP REFRIGERATION SYSTEM
EP88 –6.88 OZ.
MV85-3
3
3/8 HP REFRIGERATION SYSTEM
EP88 –6.90 OZ.

CAUTION
DISCONNECT THIS UNIT FROM THE POWER SUPPLY
BEFORE PERFORMING MAINTENANCE ON THE UNIT.
•
•
•
WARNING
IT IS RECOMMENDED TO SLOWLY RE-ADD YOUR
PRODUCT INTO THE FREEZER TO PREVENT AN
EXTREME LOAD ON THE COMPRESSORS, WHICH
COULD SHORTEN FREEZER LIFE EXPECTANCY.

•
•
•
WARNING
WHEN FILLING THE UNIT WITH RACKS/BOXES, MAKE
SURE TO PRE-COOL THEM IN ORDER NOT TO EFFECT
THE INSIDE TEMPERATURE OF THE UNIT.
WARNING
THE INNER DOORS SHOULD BE USED AT ALL TIMES.
MAKE SURE TO CLOSE THEM TIGHTLY.
THE MANUFACTURER IS NOT RESPONSIBLE FOR DAMAGE
TO THE FREEZER CAUSED BY FAILURE TO DO SO.
WARNING
CLEAN THE FREEZER BOTH INSIDE AND OUT USING A
DAMP, WRUNG OUT CLOTH. DRY WITH A DRY CLOTH.
THE SMELL FROM THE PLASTIC PARTS IN THE FREEZER
WILL DISAPPEAR ONCE THE FREEZER HAS BEEN COOLED
DOWN.

CONTROL DISPLAY
