ENGLISH
User Manual ISoClean 2 Automated PAP Disinfecting System

Thank you for purchasing the
SoClean 2 PAP disinfecting system.*
This manual contains a product overview and key
set-up instructions. Once connected, you’ll find that daily
disinfecting of your PAP equipment has never been easier.
The SoClean patented process destroys 99.9% of PAP
germs, bacteria and other pathogens without the need
for water or harsh chemicals.†The SoClean 2 allows you
to use disinfected PAP equipment daily, without the need
to disconnect.
While the SoClean is designed to fit many PAP models,
some models require additional parts or set-up steps.
If you do not currently have these parts, they can be
purchased from SoClean or an authorised reseller.
See SoClean.com for PAP model details.
SoClean is committed to developing innovative and safe
ways to improve the health and well-being of PAP users.
Please feel free to contact us with any questions you
may have at SoClean.com/contact.
Thank You!
*See Indication of use, Cautions and Specifications.
†Data on file.

TABLE OF CONTENTS
INDICATIONS FOR USE, CONTRAINDICATIONS,
SPECIFICATIONS, WARNINGS AND CAUTIONS 2
YOUR HEALTH AND OZONE SAFETY 4
CLASSIFICATION, MANUFACTURER SYMBOLS AND FCC NOTICE 5
INCLUDED WITH YOUR SOCLEAN 2 6
SOCLEAN 2 CONTROL PANEL 10
KEY PAP PARTS 12
CONNECTION STEPS 14
SUPPORTED PAP MACHINES AND ADAPTERS 17
SET LANGUAGE, CLOCK AND DISINFECTING SCHEDULE 18
USING YOUR SOCLEAN 2 22
CARE AND MAINTENANCE OF YOUR SOCLEAN 2 24
FAQS24
00800 5558 8811SoClean.com

2 | INDICATIONS FOR USE, CONTRAINDICATIONS, SPECIFICATIONS, WARNINGS AND CAUTIONS
*DISCLAIMER: SoClean does not represent through the use of the terms disinfect, disinfectant or disinfection
herein, or in other documentation, a kill rate of more than 99.9% of germs and bacteria in PAP equipment.
†Data on file.
People with acute or chronic respiratory conditions such
as asthma, bronchitis and sensitive or irritated breathing
passages (mouth, nose, throat) should consult their
medical doctor before using this product.
Specifications:
2 |
INDICATIONS FOR USE, CONTRAINDICATIONS,
SPECIFICATIONS, WARNINGS AND CAUTIONS
Read this User Manual before operating
the equipment.
Use this product only in the manner described in this User
Manual. If the equipment is used in a manner not specified
by the manufacturer, the safety protection provided by the
equipment may be impaired.
Environmental characteristics:
Operating: 10°C to 38°C (50°F to 100°F),
15% to 70% humidity
Ozone concentration:
10 ppm @ 5 min when measured 1 cm from the
ozone generator output tubing interface on the
SoClean device, assuming the starting ozone
concentration is < 0.3 ppm prior to turning the
SoClean device on.†
Electrical characteristics:
AC adapter input: AC 100~240V, 50/60HZ, 0.5A
AC adapter output: DC 12V, 1.5A max.
Power consumption: 18W max.
Physical characteristics:
Dimensions: 200 x 184 x 225 mm
Weight: 2.5 kg
Cord length: 142 cm
Storage and transport conditions:
-20°C to +55°C (-4°F to 131°F),
15% to 70% humidity
Indications for use: The SoClean 2 is a general Positive
Airway Pressure (PAP) disinfecting device and is intended
to be used in the home. An individual who uses Positive
Airway Pressure (PAP) equipment can use the SoClean 2 to
destroy 99.9% of germs and bacteria and other pathogens
on PAP equipment, or when the user wants the added
benefit of thorough PAP system disinfection.*†
The SoClean 2 attaches to a PAP machine and runs daily
while the mask is inside the Disinfecting chamber. The
SoClean 2 does not need to be disconnected before using
your PAP machine.
Contraindications for use: Do not use the SoClean
device if a fragrant essence is used in the PAP water
reservoir or if highly fragrant detergents are used to
disinfect the PAP equipment. Discontinue use if acne or a
rash develops along the mask contact line.

ENG | 3
WARNING: Ensure the correct clock time and cycle
start time are set on your SoClean 2 before using
your PAP machine. Pay particular attention to the
AM/PM setting if using the 12-hr mode. Failure to do
so may result in the SoClean 2 device operating at an
unexpected time.
WARNING: In the event of loss of power to your
home or the SoClean 2 device, ensure the correct
clock time and cycle start time are set on your
SoClean 2 before using your PAP machine. Failure to
do so may result in the SoClean 2 device operating at
an unexpected time.
WARNING: Do not physically alter the Hose detect
switches on your SoClean 2 device. Inspect the
Hose detect switches regularly for damage or
inability to move up/down. Failure of the Hose
detect switches on your SoClean 2 may result in the
SoClean operating at an unexpected time.
WARNING: Keep away from water sources including
rain, bathtubs, sinks and pools. To clean, wipe with a
damp cloth. Do not submerge the SoClean device in
liquid or use chemical cleaners.
WARNING: Keep away from children. Do not place
any living thing inside the Disinfecting chamber
during use.
WARNING: Do not inhale from the Injection hose or
the Injection hose outlet on the back of the device.
WARNING: Do not breathe through your PAP mask if
the SoClean is operating a disinfecting cycle.
WARNING: Do not use in explosive air environments,
near gas vapours or other flammables, etc. Do not
place any flammable or ignitable items on top of the
SoClean 2.
WARNING: Keep the SoClean lid closed until the
green status light illuminates (approximately two hours
after completion of the disinfecting cycle).
WARNING: Do not remove gasket from the Hose
detect switch slot.
CAUTION: The lid gasket is removable. Ensure that
the lid gasket is installed properly before operating a
disinfecting cycle.
WARNING: Do not dismantle the SoClean 2.
CAUTION: Do not place Neutralising pre-wash
in the PAP reservoir. Neutralising pre-wash is for
cleaning your PAP equipment only.
CAUTION: Please ensure that the black Injection
hose from the back of the SoClean is connected to
your PAP before operating your SoClean device.
WARNING: If a strong ozone odour is detected
when the SoClean is operating, turn the SoClean
2 off by disconnecting the AC power adapter and
inspect the SoClean 2 for visible damage, such as
cracks in the enclosure or tubing along with tubing
connections.
WARNING: Do not route your PAP hose through
both Hose detect slots while or after using your
PAP. This may result in the SoClean device running
at an unexpected time.

4 |4 |
YOUR HEALTH AND OZONE SAFETY
• Ozone, the triatomic form of oxygen (O3), is known
as activated oxygen.
• Ozone is an effective, invisible disinfectant.
• The SoClean 2 uses ozone to disinfect Positive Airway
Pressure (PAP) equipment; ozone contacts the PAP
equipment only, not the user.
• The SoClean 2 is designed to produce only enough
ozone for effective disinfection of your PAP equipment.
• While breathing large amounts of ozone can irritate
breathing passages of humans, following the
instructions for use ensures that SoClean 2 users
will not breathe in large amounts of ozone.
• Ozone quickly dissipates in the atmosphere. If you
accidentally interrupt the disinfecting cycle and release
ozone by opening the Disinfecting chamber before the
end of the disinfecting cycle, simply step away from
the SoClean 2 to avoid unintended exposure.
• The smell of ozone is detectable at low concentrations
by some people. The scent of ozone is similar to a
sweet chlorine-like smell.
• If you smell ozone and believe the SoClean device is
not operating correctly, disconnect the power to the
device and contact SoClean.
Precautions for beneficial use of the SoClean 2
WARNING: If a strong ozone odour is detected
when the SoClean is operating, turn the SoClean 2 off
by disconnecting the AC power adapter and inspect
the SoClean 2 for visible damage, such as cracks in
the enclosure or tubing along with tubing connections.
WARNING: People with acute or chronic respiratory
conditions such as asthma, bronchitis, colds, flu, and
sensitive or irritated breathing passages (mouth, nose,
throat) should consult their medical doctor before
using this product.
YOUR HEALTH AND OZONE SAFETY/CLASSIFICATION, MANUFACTURER, SYMBOLS AND FCC NOTICE

ENG | 5
FCC Notice
Please note that changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 18 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorientate or relocate the receiving aerial.
• Increase the separation between the equipment and the receiver.
• Connect equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CLASSIFICATION, MANUFACTURER, SYMBOLS AND FCC NOTICE
Classification
US FDA Class I according to 21 CFR § 880.6890 - General purpose disinfectants.
EC/EU MDD Class IIa according to 93/42/EEC Annex IX Rule 15 - Device is intended to disinfect medical devices.
Designed by and manufactured for: SoClean, Inc., 12 Vose Farm Road, Peterborough, New Hampshire 03458 USA
Complies with
Medical Device
Directive of the
European Union.
0120
Waste Electrical and Electronic Equipment (WEEE).
It is the responsibility of the end user to dispose
of this equipment at a designated collection point.
Not made with
natural rubber latex
Symbols
Serial number
Catalogue
number
Consult
manual
Date of
manufacture
Do not use
if package
is damaged.
Authorised
representative
in the European
Community
EC REP
Manufacturer
JDI Electronics Factory
Sima Industrial Zone, Sima Village, Changping Town,
Dongguan City, Guangdong Province, China 523570

6 | INCLUDED WITH YOUR SOCLEAN 2
Number Part name SKU Description
1Removable
hose slot plug PN1214
This allows you to set up the SoClean 2 device on either the right or
left side of your PAP machine. Place this plug in the hose slot that
you don’t use.
2Disinfecting
chamber N/A Place your mask in here when you wake up. Close the lid to ensure
that the daily automated disinfecting cycle runs.
3 Lid gasket PN1215 Ensures a tight seal around the Disinfecting chamber when the
SoClean 2 lid is closed. Do not close the lid without this part in place.
4 SoClean lid N/A Close the lid after you place your mask in the Disinfecting chamber
to ensure that the daily automated disinfecting cycle occurs.
5 Cartridge filter PN1207
This Cartridge filter converts ozone back into normal oxygen.
Remove outer plastic wrapper and blue tape prior to
installation. You can repurchase the filter along with the Check
valve as part of the Cartridge filter kit.
6Hose detect
switch N/A
The Hose detect switch detects when the SoClean 2 is configured
for operation by detecting the presence of the hose in the hose slot
when the lid is closed. If no hose is detected, the SoClean 2 will
not run a disinfecting cycle. Hose detect switch operation can be
inspected by gently pushing down and releasing the grey plastic
switch and hearing an audible click. The switch should move freely
down and up when pressed gently.
7Neutralising
pre-wash PN1101
The Neutralising pre-wash removes any material or odour that could
react with ozone. Wash your PAP equipment following the PAP
manufacturer’s instructions before connecting the SoClean 2 device,
or when you receive a new mask, hose or reservoir.
INCLUDED WITH YOUR SOCLEAN 2

ENG | 7
1
2
34
5
7
6

8 | INCLUDED WITH YOUR SOCLEAN 2
Number Part name SKU Description
8 Control panel N/A Buttons, display and cycle light indicator for SoClean
functions. See page 10 for details.
9Injection hose
A and B PN1104.12 The Injection hose A and B carries ozone from the SoClean
device to the PAP machine. See page 16.
10 Check valve PN1207
This item comes pre-installed into the Injection hose. It is a
one-way Check valve that prevents water in your humidifier
reservoir from backing up and entering your SoClean device.
If you can see water in this clear tube, replace the check
valve assembly immediately. You can repurchase it along
with the Cartridge filter as part of the Cartridge filter kit.
11 Injection fitting
PN1106 (with
humidifier reservoir)
PN1116 (without
humidifier reservoir -
not included)
Connects the Injection hose A and B to your PAP machine.
See page 15.
12 AC adapter PN1209 Supplies power to your SoClean 2. See page 16.
INCLUDED WITH YOUR SOCLEAN 2
Replacement Parts
WARNING: Please purchase your Cartridge filter kits from SoClean®only. Authentic Cartridge filter kits can be purchased from SoClean via multiple online
marketplaces, such as Amazon®and eBay®in addition to SoClean.com. However, please confirm that the seller of your Cartridge filter kit is SoClean, and not
any other seller, to ensure the authenticity of your Cartridge filter kit. SoClean has discovered counterfeit Cartridge filter kits being sold, particularly on Amazon®
and eBay®, with check valves and filters that leak and can cause damage to your SoClean machine or to your property due to water leakage from the counterfeit
check valves. Please contact SoClean immediately if you have had any issues with your Cartridge filter kit. Amazon®is a registered trademark owned by Amazon
Technologies, Inc. eBay®is a registered trademark owned by eBay, Inc. SoClean®is a registered trademark owned by SoClean, Inc.
You will replace some SoClean parts regularly due to normal wear
and usage. A message appears on your SoClean after a certain
amount of use (typically around six months) as a reminder to
replace the Cartridge filter and Check valve. These two parts are
ordered as a set called the Cartridge filter kit (PN1207).
The Neutralising pre-wash is also available for purchase if you run
out. Follow your PAP manufacturer’s instructions for cleaning your
PAP equipment.
To reorder supplies, contact your authorised reseller or visit
SoClean.com and search for the desired part.

ENG | 9
8
10
9
12
11
A
B

10 |
1 2 3 4 5
6
7
8
SOCLEAN 2 CONTROL PANEL
Number Button(s)/Display Description
1 Sets the clock. See page 19.
2 Disinfecting cycle length The length, in minutes, of the disinfecting cycle. See page 20 to set
this. The default disinfecting cycle length is set to 7 minutes.
3 Current time The current time. See page 19 to set. The default time is set to12:00 am.
4 Daily disinfecting start time The time when the daily disinfecting cycle starts. See page 20 to set
the schedule. The default disinfecting cycle start time is set to 10:00 am.
5Starts a disinfecting cycle immediately. The scheduled disinfecting will
still occur. See page 21.
6Decreases (-) or increases (+) time.
WARNING: In the event of loss of power to your home or the SoClean 2, ensure that the correct clock time and cycle start time are
setonyourSoClean2beforeusingyourPAPmachine. Failuretodo somayresultintheSoClean2operatingat anunexpectedtime.
SOCLEAN 2 CONTROL PANEL

ENG | 11
Number Button(s)/Display Description
7 Status light
The light below the display indicates the disinfecting cycle status.
See pages 19, 20 and 21 for instructions on scheduling and
manual operation. A green light indicates that disinfecting is
complete, and you can remove your PAP mask from the SoClean
Disinfecting chamber and use your PAP machine.
RED – The SoClean is operating and generating ozone.
YELLOW – The two-hour disinfecting cycle is still active.
The ozone is working and dissipating.
GREEN – The disinfecting cycle is complete. You can use your
PAP machine any time. The light turns off when you open the lid.
8Sets daily disinfecting start time. See page 20.
Changes clock between the 24-hour or 12-hour format. See page 19.
and
Messages
The SoClean display panel shows messages that may require action. This list shows the messages and how to correct them:
Message What to Do
Hose not present. Cycle will not run.
Ensure that the PAP hose is seated securely in the hose slot. Check
that the Removable hose slot plug is seated correctly on the other
side. See page 22.
Order filter kit. Your Cartridge filter has reached the end of its life based on your
use. See page 25.
Disinfection in process. Do not open the lid!
Ozone present. The SoClean 2 is performing disinfection. This
takes approximately two hours. The green cycle indicator light
means that disinfection is complete. You can then open the lid, take
out your mask and use your PAP machine.

12 | KEY PAP PARTS
KEY PAP PARTS
The SoClean device is designed to connect permanently to
your PAP machine and enable operation of either product.
The SoClean device connects to most PAP machines
using the standard included parts. This section describes
key parts of your PAP machine in the connection
procedure. The figure on the next page shows a generic
representation of these key parts.
Some PAP machines have features that require additional
steps or parts. Adapters required for SoClean to function
with your PAP contain appropriate instructions. See page 17
for a list of available adapters for specific PAP machines.
See SoClean.com for additional instructions for specific
PAP machines.
These are the typical parts of a PAP machine that are
referenced in the SoClean connection procedures. These
are only representations: your actual PAP machine can look
different from these drawings. Review the documentation
that came with your PAP machine for a better idea of what
these parts look like.

ENG | 13
Humidifier Open humidifier
Reservoir*
PAP machine
*Reservoir contains water
and typically can be removed.
Mask
(Full, small,
nasal pillows)
PAP hose
Mask hose
Heat plate

14 | CONNECTION STEPS
CONNECTION STEPS
1. Pre-wash PAP equipment
Disconnect your PAP mask, hose and reservoir
from the PAP machine.
Use two capfuls of the included Neutralising pre-
wash with 4 litres (1 gallon) of water to wash your
PAP equipment (mask, hose and reservoir) according
to the manufacturer’s instructions (Figure 1).
Rinse thoroughly with clean water.
Reinsert the reservoir (if used) into the PAP machine.
Do not reattach the hose or mask yet.
After following these steps, your SoClean 2 will disinfect
your PAP machine daily without disconnecting. Before you
disconnect your PAP machine to wash the parts, look at
where the PAP hose is connected. You will reconnect the
SoClean Injection fitting to the same location.
Figure 1. Disassemble and Wash PAP Equipment
CAUTION: Do not place Neutralising pre-wash in the
SoClean 2 Disinfecting chamber or PAP reservoir. Neutralising
pre-wash is for cleaning your PAP equipment only.
Please note, SoClean devices do not replace proper
cleaning and maintenance of the PAP device according
to the manufacturer’s instructions

ENG | 15
2. Using an adapter
If your PAP machine requires an adapter, see adapter
instructions for set-up and proceed to Step 5.
3. Connect the Injection fitting
The Injection fitting connects the SoClean 2 to your PAP
machine. Once installed, you do not need to disconnect
the Injection fitting to use your PAP. The SoClean 2 is
intended to stay continuously connected to your PAP
machine.
Note: Your PAP reservoir model may require additional
configuration procedures or an adapter. If you have
difficulty with the steps in this guide, visit:
SoClean.com for information on various models.
With humidifier:
1. Position the Injection fitting onto the port of
your humidifier (where your PAP hose was
connected), allowing the smaller Injection hose B
to enter into the reservoir (Figure 2). The end of the
tubing should be positioned over the heat plate.
2. If necessary, carefully trim the Injection hose B in
increments until it is the correct length, and over
the heat plate.
Injection
fitting
Figure 2. Connect the Injection fitting
For additional help in connecting to your specific
machine, please visit our support pages at:
SoClean.com
Injection
hose B
Injection
hose A

16 | CONNECTION STEPS/SUPPORTED PAP MACHINES AND ADAPTERS
4. Connect the PAP hose
Regardless of your humidifier, you can now connect
your PAP hose to the end of the Injection fitting, which
is connected to your PAP machine (Figure 3).
5. Connect power
Plug the AC adapter into the connector marked DC 12V,
1.5A on the back of the SoClean 2. The AC adapter
should be plugged into a wall outlet that is easy to access
and observe (Figure 4).
Injection fitting
(hose goes to
SoClean)
PAP hose
(goes to mask)
Without humidifier:
1. Pull off the small Injection hose B from the inside of
the Injection fitting.
Note: If you are having difficulty disconnecting Injection
hose B, you may cut the tubing as close to the Injection
fitting as possible.
2. Attach the Injection fitting directly to your PAP machine.
3. Reconnect your PAP hose to the end of the
Injection fitting.
CAUTION: Please ensure that the black Injection hose
from the back of the SoClean 2 is connected to your PAP
before operating your SoClean 2.
Note: If you are having difficulty connecting to your PAP, an
additional part may be necessary. Contact SoClean.com.
Figure 3. Connect PAP hose to Injection fitting
Figure 4. Connect AC power
WARNING: In the event of loss of power to your home
or the SoClean 2, ensure that the correct clock time and
cycle start time are set on the SoClean 2 before using your
PAP machine. Failure to do so may result in the SoClean
device operating at an unexpected time.
6. Reconnect PAP equipment
You can now reattach the mask to the end of the PAP hose.
