SoCo Swings CHARLESTON LOVESEAT WICKER User manual

Assembly Instructions for Low Country Wicker Lounger
ASSEMBLY INSTRUCTIONS FOR
CHARLESTON LOVESEAT
WICKER

1
Key
A
1
B
1
C
1
D
1

2
Assembly
1. Locate all your Charleston Loveseat parts, including:
A. Center cushion piece (1)
B. Footrests with rope attached (2)
C. Set of loveseat spreader bars (2) and footrest spreader bar (1; not pictured,
contains two mini eye bolts installed in the middle of the bar)
D. Set of bent arms (2)
E. Hardware pack wrapped inside the cup holder (contains 2
eye bolts, 2 S-hooks, 2 chains, hex bolts, nuts, washers,
hex bolt head covers, and wrench) Note: Items in pack
pictured, but not quantity.
2. Place the wicker bent arms on the ground making sure the arms are face up and ropes are
not twisted or turned (this impedes the next step).
3. Place the cushion in between the bent arms (which are still on the ground). The SoCo tag on
the cushion should be on the backside of the chair (not facing out) positioned at the top.
E

3
4. Thread the two loveseat spreader bars
through the sleeves on the underside of the
cushion.
5. Align the top spreader bar to the top Front
of each arm.
6. Insert a hex bolt (front to back) into each
hole and tighten nut and washer using the
wrench included in the kit. Tighten each bolt
until it is flush with the front side of the
wicker.
4
4
5
6

4
7. Repeat steps 5 and 6 for the bottom of the
arms BUT put the spreader bar on the back of
each arm.
8. Place plastic covers included in your
hardware kit over the hex bolts.
9. Attach your Happy Bag and Happy Hour Cup Holder to the loveseat, hang loveseat from the
eye bolts (see instructions below) or frame, and enjoy!
7

5
Installing the Eye Bolts
Hanging the Footrests
Locate the ceiling beam/joist by using a stud finder or tapping
and verifying with a small nail. Be sure to locate the exact
center of the ceiling joist for the most secure installation.
Using a 3/16” (3mm) wood drill bit, drill a starter hole
(approx. 4” or 10 cm deep) perpendicular to the ceiling.
Screw in the supplied eye bolts until all threads have
disappeared into the joist. Do not loosen or adjust once in
place.
Caution: We highly recommend using only a gentle to and fro
motion. Swinging or spinning could loosen the eye bolts from
the ceiling joist and compromise the sturdiness. We highly
recommend hanging the loveseat no more than 18” above the
ground and not exceeding a maximum weight
recommendation of 550 pounds.
When hanging the loveseat, be sure the ropes are not tangled
or caught behind the spreader bars. The ropes must be free
and clear when lifting the loveseat.
With a person on each side, lift the loveseat and connect the
S-hooks (provided in the hardware kit) to the eye bolts in the
ceiling beam (or frame if that’s what you’re using to hang the
loveseat). If the eye bolts are too high, use the chains
(provided in the hardware kit) to bridge the gap between the
eye bolts and the S-hooks.
Note: images used to illustrate this section are of the wooden loveseat; the instructions apply to
both models—wooden and wicker.
1. To hang the footrests, use the third
spreader bar containing two smaller eye bolts
in the middle of the bar (position them facing
down) and two larger eye bolts on the ends of
the bar (when the smaller eye bolts are
positioned facing down, the larger eye bolts
will face up).
1

6
Washing and Care Instructions
2. Using two S-hooks, attach the spreader bar
to the chains or eye bolts suspending the
loveseat by threading S hooks to the larger
eye bolts on each end of the spreader bar.
3. The smaller eye bolts in the middle of the
spreader bar are for the footrests. The ropes
on the footrests have S-hooks attached. Use
those hooks to attach the ropes to the
spreader bar.
NOTE: This spreader bar should not be used in any way to support the weight of the loveseat
(use chains and S-hooks). Individuals should also not sit on the bar once it’s installed. It should
only be used to support the footrests.
Your loveseat will last longer depending on its use, where it is installed, and the care it is given.
It will last longer if you keep it dry by either covering it (yes, we sell those!) or storing it indoors
when not in use. We recommend using a fabric protector such as Scotchgard on the pad and
ropes to resist stains. To wash, scrub gently with a soft brush and a mixture of water and a mild
laundry detergent. You can spot-treat stains using Resolve, Shout, or other laundry stain
removers on the fabric parts of the lounger. Warning: Not suitable for washing machines,
tumble dryers, or chemical bleaches.
3

7
Important Reminders
Warranty
Warranty Limitations
✓The loveseat is NOT a swing. We highly recommend using only a gentle to and fro
motion. Swinging or spinning could loosen the eye bolts from the ceiling joist and
compromise the sturdiness.
✓Check the eye bolts from time to time to make sure they’re holding fast.
✓Visually inspect the ropes, loveseat hardware, and attachment hardware
periodically.
✓We highly recommend hanging the loveseat no more than 18” above the ground.
✓Sit on the loveseat gently as it will stretch at first. You can always take up the slack
later.
✓We recommend not exceeding a maximum weight limit of 550 pounds.
✓Enhance your relaxation with optional springs.
Your loveseat is guaranteed for two (2) years from the date of purchase to be free from defects
in workmanship and materials, under normal residential use and conditions. SoCo Swings
agrees, at its option during the warranty period, to furnish a product of equal value in exchange
without charge (except for a fee for shipping, handling, packing, return postage, and insurance
which will be incurred by the customer). Such repair or replacement is subject to verification of
the defect or malfunction and proof of purchase as confirmed by showing the model number on
original dated sales receipt.
This warranty does not include:
•Any condition resulting from other than ordinary residential wear or any use for which the
product was not intended
•Any condition resulting from incorrect or inadequate maintenance or care
•Damage resulting from misuse, abuse, negligence, accidents, or improper installation
•Dissatisfaction due to buyer’s remorse
•Normal wear and tear
•Damages incurred during transportation
•Damages incurred during assembly or maintenance
•Any used, previously displayed items (such as a demo item)

8
Disclaimer
SoCo Swings and all agents and representatives thereof cannot assume responsibility for special,
indirect, or consequential damages or contingent liability for use of the loveseat in a manner not
expressly intended by the manufacturer. The loveseat is NOT a swing. We highly recommend
using only a gentle to and fro motion. Swinging or spinning could loosen the eye bolts from the
ceiling joist and compromise the sturdiness. The end consumer is ultimately responsible for
verifying proper installation of the loveseat and the eye bolts according to the guidelines
explained in this installation guide. We strongly recommend not exceeding our maximum weight
limit of 550 pounds.
If you have any questions regarding our products, please contact us via email
[e-mail] and/or our website: www.socoswings.com. If you’re not totally satisfied
with any part of your purchase or gifting experience, please let us know. Our customer service
reps are fully trained, happiness ninjas ready to solve your problems quickly, efficiently, and
with as little fuss as possible.
