HAMPTON BAY GSM00223A User manual

THANK YOU
y through the purchase of this swing. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Item # 121 881
Model # GSM00223A
USE AND CARE GUIDE
TROUTDALE STEEL/ALUMINUM SWING WITH CANOPY
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m.,EST, Monday - Friday, 9 a.m. - 6p.m., EST, Saturday
01-800-00-46633
HOMEDEPOT.COM.MX

2
Table of Contents
Warranty ........................................................................2
What is Covered ...................................................................... 2
What is Not Covered ................................................................ 2
Warranty
WHAT IS COVERED
We warrant theframes to be free of manufacturing defects tothe original purchaser for one year, and aone year limited warranty for the fabric.
WHAT IS NOT COVERED
Contact the Customer Service Tea
Safety Information
PRODUCT CAUTION
SAFETY WARNINGS
Safety Information .......................................................2
Product Caution .................................................................... 2
WARNING: Weightlimit for the chairs is250 lbs
(113.39 kg) for each seat.
WARNING: Thisswing isheavy, and may require
two adults for safe assembly.
CAUTION: When not in use, securetheproductin a
cool and covered location.
!
Safety Warnings ..................................................................... 2
Table ofContents ........................................................2
This swing was made for the explicit purpose of providing outdoor functions and is not to be used as a toy. This product is intended for
normal outdoor use; however, the manufacturer recommends storing and / or covering this swing when any formidable / severe weather is
approaching. Do not locate this product near open flames. Do not use this product as a support. Do not shake, lean or climb on the product.
Children under the age of 10, near the product, should be supervised by a competent adult at all times. This product is NOT intended for
commercial use and will void the warranty.
It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover
commercial use, hardware, acts of nature, fire, freezing and abusive use. In addition, purchased parts are not covered under this warranty.
We reserve the right to make substitutions with similar merchandise, if the model in question is no longer in production.
1 YEAR FRAME AND 1 YEAR FABRIC LIMITED WARRANTY
Pre-Assembly ................................................................3
Planning Assembly .................................................................. 3
Hardware Included .................................................................. 3
Care and Cleaning...................................................... 51.
Assembly ....................................................................... 5
Package Contents................................................................. .. 4
m at 1-800-00-46633 or visit www.homedepot.com.mx.

3
Pre-Assembly
PLANNING ASSEMBLY
Read all instructions before assembly.
To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard.
NOTE: More than one person may be required to
assemble this product.
HARDWARE INCLUDED
AA M8x50 bolt with washer
Description QuantityPart
BB M6x70 bolt with washer
CC M6x65 bolt with washer
2+1
16+1
4+1
4+1
8+1
6+1
26+1
4+1
8+1
DD M6x60 bolt with washer
DD
CC
BB
AA
NOTE: Hardware not shown to actual size.
EE M6x50 bolt with washer
FF M6x35 bolt with washer
GG M6x30 bolt with washer
HH M6x18 countersunkbolt
II M6x15 bolt with washer
JJ Hex wrench
1
HOMEDEPOT.COM.MX
Please contact 01-800-00-46633 for further assistance
EE
JJ
II
HH
GG
FF

Pre-Assembly (continued)
PACKAGE CONTENTS
H
T
S
N
M
L
P
FO
G
Q
L
F
G
V
U
BK
A
R
C
B
C
C
E
ED
AI
J
4
Part Description Quantity
Left connector bar
Right connector bar
Side top bar
Center lengthways bar
Lengthways bar
Post - 1
Post - 2
Post base plate
Short shade rod
Long shade rod
Fabric shade
Side panel
Support bar
Swing seat
Swing back
Right arm
Left arm
Magnet iron plate
Seat cushion
Bolster
Big lumbar pillow
Small lumbar pillow
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
V
2
2
2
1
4
2
2
4
2
3
1
2
1
1
1
1
1
1
1
2
3
3

5
Assembly
HOMEDEPOT.COM.MX
Please contact 01-800-00-46633 for further assistance
1
Attach the right connector bar (A) to the left connector bar (B) with the magnet iron plate (R) using M6x15 bolts and washers (II).
Attach the other right connector bar (A) to the left connector bar (B) using M6x15 bolts (II) without the magnet iron plate.
CONNECTING THE CONNECTOR BAR WITH THE MAGNET IRON PLATE
A
A
R
B
R
B
B
B
B
A
A
A
II
II
II
II
II

2
l
6
Assembly (continued)
Attach the side top bars (C) with the upturned holes to the connector bars (A & B) using M6x60 bolts and washers (DD).
Attach the center lengthways bar (D) with the upturned holes to the connector bars (A & B) using M6x65 bolts and washers (CC).
Attach the lengthways bars (E) with the upturned holes to the connector bars (A & B) using M6x60 bolts and washers (DD).
Fully tighten all of the bolts using the hex wrench (JJ).
ATTACHING THE CROSSBAR
DD
DD
A&B with
magnet plate
A&B
A&B
E
E
EE
C
C
D
D
CC
DD
Note: The first fabric hanger on the center lengthways
bar (D) is the rolling wheel, others are the plastic wheel.
Plastic wheel Rolling wheel
A&B with
magnet plate

l
7
Assembly (continued)
HOMEDEPOT.COM.MX
Please contact 01-800-00-46633 for further assistance
3
Attach the post base plates (H) to the posts - 1 (F) and posts - 2 (G) using M6x15 bolts and washers (II).
ATTACHING THE POST BASE PLATE TOTHE POSTS
posts - 1 (F) and posts - 2 (G)
posts - 1 (F) and posts - 2 (G) H
H
II

4
l
8
Assembly (continued)
Attach the posts - 1 (F) and posts - 2 (G) to the assembled structure using M6x60 bolts and washers(DD), M6x70 bolts and washers
(BB) and M6x15 bolts and washers (II).
Fully tighten all of the bolts using the hex wrench (JJ).
ATTACHING THE POSTS TO THE ASSEMBLED STRUCTURE
F
FG
G
II
Posts - 2 (G)
posts - 1 (F)
A&B with
magnet plate
A&B
DD
C
BB
BB

5
l
9
Assembly (continued)
ATTACHING THE SIDE PANELS AND SUPPORTBAR TO THE POSTS
Attach the side panels (L) to the posts - 1 (F) and posts - 2 (G) using M6x30 bolts and washers (GG).
Attach the support bar (M) to the side panels (L) using M6x15 bolts and washers (II).
Fully tighten the bolts using the hex wrench (JJ).
HOMEDEPOT.COM.MX
Please contact 01-800-00-46633 for further assistance
II
II
II
L
L
L
L
MM
MGG
GG
GG
FF GG
posts - 1 (F)
and posts - 2 (G)

6
l
10
Insert the short shade rods (I) into the fabric shade (K).
INSERTING THE SHORT SHADE RODS INTO THE FABRIC SHADE
Assembly (continued)
I
K
I

7
l
11
Assembly (continued)
Attach the short shade rods (I) to the connector bars (A & B) using M6x35 bolts and washers (FF).
ATTACHING THE SHORT SHADE RODS TO THE CONNECTOR BARS
HOMEDEPOT.COM.MX
Please contact 01-800-00-46633 for further assistance
C
A
A
I
I
I
FF
FF
FF
K
B
D

8
l
12
Insert the long shade rods (J) into the side fabric hanger on the side top bar (C), the slot at the end of the fabric shades (K),
through the center fabric hanger, into the remaining slots of the fabric shades (K) and attach to the side fabric hanger on the
other side top bar (C) using M6x18 countersunk bolts (HH).
Fully tighten M6x18 countersunk bolts using the hex wrench (JJ).
CONNECTING THE LONG SHADE RODS
Assembly (continued)
JJ
KK
K
K
DJJ
C
HH
K
HH
J
J
C
1

9
l
13
Attach the right arm (P) and the left arm (Q) to the swing seat (N) using M8x50 bolts and washers (AA).
Attach the right arm (P) and the left arm (Q) to the swing back (O) using M6x50 bolts and washers (EE).
Fully tighten all of the bolts using the hex wrench (JJ).
ASSEMBLING THE SWING FRAME
Assembly (continued)
HOMEDEPOT.COM.MX
Please contact 01-800-00-46633 for further assistance
OQ
N
AA
AA
N
AA
P
EE
EE
P
PO

10
l
14
Place the seat cushion (S), bolsters (T), the big lumber pillows (U) and small lumber pillows (V) on the swing seat (N).
PLACING THECUSHIONS ON THE SWING
Assembly (continued)
V
U
T
T
S

11
l
15
Assembly (continued)
Open the connector rings in the clockwise direction.
Hang the whole swing to the frame and close the connector rings in the counterclockwise direction.
HANGING THE SWING TO THE FRAME
Care and Cleaning
For best results, clean the frame and fabric with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt
particles that may accumulate.
Keep the swing away from fire, extreme heat, freezing conditions, and inclement weather such as rain, hail, sleet, snow, or wind.
Store the swing in a dry, sheltered place when not in use.
Do not clean with abrasive materials, bleach, or solvents.
HOMEDEPOT.COM.MX
Please contact 01-800-00-46633 for further assistance

Questions,problems,missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m.,EST, Monday - Friday, 9 a.m. - 6 p.m.,EST, Saturday
01-800-00-46633
HOMEDEPOT.COM.MX
Retain this manual for future use.
