Solaire Vitra VIT10 User manual

1
Vitra Vitra (s2)
Instruction Manual

2
Safety Instructions
Page 3
Installation Instructions
Page 4-5
Control Panel
Page 6
Manual Operation
Page 7
Connecting to WiFi
Page 8-9
Controlling the heater
Page 10-11
ERP Label
Page 12-13
Warranty and Disposal
Page 14
Contents

3
Read the manual before using the heater. Keep the manual for future reference.
Before use, check that the heater and its accessories are complete and intact.
The heater must be installed as per installation instructions. The heater must be plugged into a socket
that meets the following requirements: AC 230V, frequency 50/60Hz.
The heater is only suitable for indoor use.
Do not use the heater near ammable or explosive materials.
Inserting items into the protective grill of the heater is strictly prohibited.
Do not touch the metal housing as it will get hot when the heater is in use. Set aside some time to let
the heater cool before you turn it o and store it.
Unplug the heater if its out of use for a long time.
Prior to each use, make sure the heater is in good condition and intact. Do not plug in or use if the
casing, wire or plug are damaged.
The heating element may be damaged if the heater is dropped or hit. Do not use the heater if the
element is broken.
Unplug from the socket when moving or cleaning the heater. When disconnecting, ick the switch to the
o position, then unplug. Do not pull the cable.
The heater must not be located immediately below an electrical socket-outlet.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or a similarly
qualied person to avoid a hazard.
Avoid the use of an extension cord as this may overheat and cause a re risk.
Never place the heater where it may fall into water.
CAUTION: some parts of this product can become very hot and cause burns. Particular attention must
be given where children and vulnerable people are present.
CAUTION: never cover the heater. Covering the heater risks overheating and re.
Safety Instuctions
Type Voltage Frequency Power Category
VIT10 230V 50/60HZ 1000W I
VIT20 230V 50/60HZ 2000W I
Technical Data

4
Installation Instructions
Before installing, check that all parts are complete, and the product is intact.
The below clearances are required:
Bottom = 50mm
Top = 200mm
Sides = 50mm
If you want to use the heater freestanding, please t the Caldo / Vitra Feet, following the instructions
below. Make sure the heater is mounted on a level, stable and clean surface.
Freestanding Installation
1. Make sure the heater is Off.
2. Put the heater upside down on a soft
cotton cloth or carpet.
3. Fix the feet to the heater’s base using the
screws provided. Line up the holes in the
base with the holes in feet. Put the screws
through the holes and then tighten with a
screwdriver.
Wall Mounted Installation
Wall bracket
Both the Caldo and the Vitra are supplied with an installer friendly “H” style wall bracket assembly.
Simply put the bracket to the wall, make sure it is straight and level and mark the holes. Drill and
plug the wall and securely fasten the “H” bracket. The heater simply hooks onto the bracket and
the small top lug moves across to secure the heater.
4
Installation Instructions
Before installing, check that all parts are complete, and the product is intact.
If you want to use the electric heater freestanding, please t the feet provided with the
heater, following the instructions below. Make sure the heater is mounted on a level,
stable and clean surface.
Freestanding Installation
1. Make sure the heater is O
2. Put the heater upside down on a soft
cotton cloth or carpet.
3. Fix the feet to the heater’s base using
the screws provided. Line up the holes
in the base with the holes in feet. Put
the screws through the holes and then
tighten with a screwdriver
Wall Mounted Installation
1. Take out the wall brackets and expansion screw out from the box and x the screws onto the
wall according to the distances between holes of the wall brackets, as depicted in the picture
below.
Hook
Hook
Expansion Screw
Expansion Screw

5
2. Aim the 4 holes in the back of the heater to the 4 hooks on the wall bracket and push it on.
Then slide into the slot to click on, as shown below.
3. Fix the wall bracket lock piece onto the bracket with screws, slide the lock piece into the locking
slot on the back of the heater, then tighten the screw, as shown in the picture below.
Wall Bracket
Lock Piece
5

6
Control Panel
Displays Temperature or Timer Settings
Current Temperature
Keyboard Lock
Up Button
ON/OFF Button
Boost Button
Down Button
Press = Change Display
Brightness Button
Hold = Toggle WiFi Mode
Boost Function
From the control panel on the front of the Caldo and Vitra heaters, the user can boost the heating.
They have the option of 1 or 2 hours of Comfort temperature, which can be adjusted up/down
using the <> icons. Once the boost period has expired, the heaters will return to Eco temperature.
No other access can be obtained.
Eco Temperature = Resting set temperature when the heater is not in use. Factory default 15 c.
Comfort Temperature = Boosted temperature when in timed schedule. Factory default 21 c.
Comfort
Mode
ECO
Mode
WiFi
Active
Anti Frost
Mode

7
Manual Operation - Without WiFi
The Vitra is primarily a WiFi controlled heater. However, for cases where WiFi connectivity is not
available , the Vitra can be programmed manually using the control panel on the front of the heater.
• After switching on, the heater will beep once and enter standby mode. The light will be
illuminated.
• To initiate heating, press the button. The heater will then enter ECO mode. (Indicated by the 
icon. )
• Eco mode is set to a default temperature of 15 degrees. Ideal for maintaining background heat.
The Eco temperature can only be adjusted using the SolAire WiFi APP.
When you need more heat “Comfort” mode can be set. This allows the temperature to be “boosted”
for either 1 or 2 hour(s). In this mode, the temperature can be set between 5 and 30 degrees.
• To enter “Comfort” mode press. The Display will blink and read 01 (1 hour boost). Press again
and the display will read 02 (2 hour boost). Select the duration of the boost by leaving the desired
time blinking
• After selecting 01 or 02, the display will stop blinking, then read 21. This is the heater’s target
temperature. The icon will illuminate, indicating the comfort mode has been activated.
• Adjust the target temperature by pressing the < and > buttons.
Once the Comfort mode has concluded, the heater will automatically resume Eco mode.
To adjust the display’s brightness, press the  button.
There are 3 levels of brightness: Full, Dimmed and O.
7

8
Connecting to WiFi
1. Download the APP onto your smart phone or tablet. You can nd the app by scanning the QR
code below or searching “SolAire WiFi IQ” in the Google Play or Apple app store.
2. You will need to create an account, unless you already have an account. Create an account by
tapping Register.
The device will automatically determine your country, although you can change this if necessary. Enter
your phone number or email address. If you enter a phone number, a verication number will be sent
to your phone: enter this number to verify, then create a password. If you enter your email address,
you’ll just need to create a password.
3. Put the heater in WiFi connection mode. This is indicated by the ashing WiFi icon. If the WiFi
icon is not ashing, go to standby mode and hold down the display button for 10 seconds untill the
heater beeps.
4. Once the WiFi Icon is ashing, go to the app and press Add a Device. Select the device type
(heater) and conrm that the indicator is ashing. You will then be prompted to enter your WiFi
password. This allows the app to nd your heater using your WiFi.
8

9
5. The app will then display its connecting screen.
If the heater fails to connect, press and hold the  button
for 3 seconds.
It will switch to its secondary connection (AP) mode.
Then follow the steps on the App for the AP mode.
6. The heater will beep and display a solid WiFi icon once
the device is connected.
The app will conrm the heater has been added.
You can now name the device, share it with family members,
or proceed to scheduling your heating.
Using the WiFi App
You can use the app to control multiple devices. The status of your devices is shown on the device list:
• Oine (device is turned o at wall)
• Turned O (device is in standby mode)
• Turned On (device is in heating mode)
When the heater is online, tap the device name to go to the control interface. Note: when the heater is oine,
you will not be able to control it with the app.
9

10
Controlling the Heater
When the heater is online, tap the device name to go to the control interface. Note: when the heater is oine,
you will not be able to control it with the app.
Temperature calibration
If the heater reports a temperaturethatdiers fromtheactualroomtemperature the thermostat can be re
calibrated.
Adjustthe actualtemperatureuntilitmatches yourroom’s temperature, Click the thermometer icon to
adjust the temperature detected by the heater.
10

11
Using the WiFi App
You can create a heating schedule to program the heater through the day.
The APP displays the schedule as a graph. Tap and Drag your nger on the screen to programme the heater.
The App will then let you pick from 3 heating modes: Comfort, Eco and Anti Frost. The temperature of these
heating modes can be set to any temperature the you desire
Other Features
Scenes
“Scenes” bring all your devices together to respond to
environmental conditions. Triggers of events include the
temperature, humidity levels, air quality, sunrise and sunset, and
device behavior. Only devices connected to the app can be used in
scenes.
Sharing
You can share control of your devices with family members. Go to
“device sharing”, toggle which devices you want to share, and tap
Share with New Member. You can then add their email address
or phone number. If they have the app, the device will appear on
their device list. If they don’t have the app, they will be sent a link
to download the app.
Note you can only share to numbers and email addresses that are
connected to app- compatible devices: smartphones or tablets.
Voice integration
Smart Life is compatible with both Amazon Echo and Google
Home.
11

12
12
1000W ERP LABEL
Model identi�ier(s): CALDO 1000W
Item Symbol Value Unit Item Unit
Heat output Type of heat input, for electric storage local space heat-
Nominal heat output Pnom 1.0 kW manual heat charge control, with integrat-
ed thermostat No
Minimum heat output
(indica�ve) Pmin 0.00 kW manual heat charge control with room and/
or outdoor temperature feedback No
Maximum con�nuous
heat output Pmax,c 1.0 kW electronic heat charge control with room
and/or outdoor temperature feedback No
Auxiliary electricity con-
sump�on fan assisted heat output No
At nominal heat output elmax N/A kW Type of heat output/room temperature control (select
At minimum heat output elmin N/A kW single stage heat output and no room tem- No
In standby mode elSB 0.00089 kW Two or more manual stages, no room tem-
perature control No
with mechanic thermostat room tempera-
ture control No
with electronic room temperature control No
electronic room temperature control plus No
electronic room temperature control plus Yes
Other control op�ons (mul�ple selec�ons possible)
room temperature control, with presence No
room temperature control, with open win- No
with distance control op�on Yes
with adap�ve start control No
with working �me limita�on No
with black bulb sensor No
Contact details Sol*Aire Hea�ng Products Limited
12

13
13
2000W ERP LABEL
Model idener(s): CALDO 2000W
Item Symbol Value Unit Item Unit
Heat output Type of heat input, for electric storage local space heat-
Nominal heat output Pnom 2.0 kW manual heat charge control, with integrat-
ed thermostat No
Minimum heat output
(indicave) Pmin 0.00 kW manual heat charge control with room and/
or outdoor temperature feedback No
Maximum connuous
heat output Pmax,c 2.0 kW electronic heat charge control with room
and/or outdoor temperature feedback No
Auxiliary electricity con-
sump�on fan assisted heat output No
At nominal heat output elmax N/A kW Type of heat output/room temperature control (select
At minimum heat output elmin N/A kW single stage heat output and no room tem- No
In standby mode elSB 0.00089 kW Two or more manual stages, no room tem-
perature control No
with mechanic thermostat room tempera-
ture control No
with electronic room temperature control No
electronic room temperature control plus No
electronic room temperature control plus Yes
Other control op�ons (mul�ple selec�ons possible)
room temperature control, with presence No
room temperature control, with open win- No
with distance control opon Yes
with adapve start control No
with working me limitaon No
with black bulb sensor No
Contact details Sol*Aire Heang Products Limited

14
Warranty Information
• The manufacturer provides warranty in accordance with the legislation of the customer’s own country of
residence, with a minimum of 1 year, starting from the date on which the appliance is sold to the end user.
• The product has a 2 year Guarantee in the UK
• The warranty only covers defects in material or workmanship.
• The repairs under warranty may only be carried out by an authorized source. When making a claim under the
warranty, the original bill of purchase (with purchase date) must be submitted.
The warranty will not apply in cases of:
• Normal wear and tear
• Incorrect use, e.g. overloading of the appliance, use of non-approved accessories
• Use of force, damage caused by external inuences
• Damage caused by non-observance of the user manual, e.g. connection to an unsuitable mains supply or non-
compliance with the installation instructions
• Partially or completely dismantled appliances
Correct Disposal of this product
This marking indicates that this product should not be disposed with other household
wastes throughout the EU. To prevent possible harm to the environment or human health
from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse
of material resources. To return your used device, please use the return and collection
systems or contact the retailer where the product was
purchased. They can take this product for environmental safe recycling.
The product is for household use only
Sol*Aire Heating Products
Big Shed
New Row
DL11 7AW
Email: [email protected]
Tel: [phone]
14
