HawkLite
INSTALLATION INSTRUCTIONS
SAFETY INSTRUCTIONS
THIS FIXTURE USES 120-277VAC 50/60 Hz, and/or 347-480VAC 50/60 Hz
Failure to supply correct voltage may result in damage to the luminaire and will void the warranty.
• Observe and follow all label informaon and instrucons regarding dry, damp and wet locaon lisngs, proper type and
waage, warnings of installaon near combusble materials and/or insulaon.
• Be sure to connect ground wire to prevent electric shock or other potenal hazards.
• Product must be installed in a manner consistent with the intended use and in compliance with NEC and local codes.
• WARNING: RISK OF FIRE.
RECOMMENDED TOOLS
Wire
Cutter/Stripper #2 Flathead
⁹⁄₁₆"
Socket
IMPORTANT: Read ALL instrucons before starng installaon.
CAUTION: Ensure that the AC service is OFF before installaon or maintenance.
Do not switch AC service to ON unl the enre installaon is complete.
WARNING: The luminaire installaon and wiring connecons shall be performed by qualied personnel in
accordance of Naonal Electric Code (NEC) and/or any local codes.
Failure to do so may result in serious injury and/or damage to the luminaire.
•
LEVEL
LEVELING
STOPS
PEST
GUARD
MOUNTING
BOLTS
SURGE
SUPRESSOR
1
• INSPECT LUMINAIRE FOR SHIPPING DAMAGE
• DO NOT REMOVE OR LOOSEN OPTICS
• DISENGAGE COVER RETAINING CLIPS AND OPEN •
LEVEL
LEVELING
STOPS
PEST
GUARD
MOUNTING
BOLTS
SURGE
SUPRESSOR
2
• REMOVE COVER AND INSPECT LUMINAIRE
9/16”
#2

Solais + EnergyLite | 8655 Corporate Drive, Suite 100 | Frisco, TX 75033 | 469.294.1516
©Solais Lighting Group, Inc. | All rights reserved | www.solais.com | HawkLite Install - 11/2019
LIGHTING GROUP
SOLAIS
HawkLite
INSTALLATION INSTRUCTIONS
LN
G
Warning: Failure to
lead to serious injury!
BLACK
WHITE
GREEN
L
N
G
1/4”
2.5° STEPS
1.5"
(1.66" O.D.)
2.5"
(2.38" O.D.)
3
• SLIP FIXTURE OVER 1.5" (1.66" O.D.) - 2.5" (2.38 O.D.) TENON
• SEAT POLE TO DESIRED LEVELING STEP
• TORQUE BOLTS EVENLY TO 30 ft-lbs
LN
G
Warning: Failure to
lead to serious injury!
BLACK
WHITE
GREEN
L
N
G
1/4”
2.5° STEPS
1.5"
(1.66" O.D.)
2.5"
(2.38" O.D.)
• SECURE FIELD WIRING TO TERMINAL BLOCK
LN
G
Warning: Failure to
lead to serious injury!
BLACK
WHITE
GREEN
L
N
G
1/4”
2.5° STEPS
1.5"
(1.66" O.D.)
2.5"
(2.38" O.D.)
5
• LOOSEN FLATHEAD SCREWS ON RECEPTACLE
• ROTATE HOUSING TO INDICATE NORTH
• RETORQUE SCREWS ON RECEPTACLE
• INSTALL PHOTOCELL OR SHORTING PLUG
LN
G
Warning: Failure to
lead to serious injury!
BLACK
WHITE
GREEN
L
N
G
1/4”
2.5° STEPS
1.5"
(1.66" O.D.)
2.5"
(2.38" O.D.)
6
• RE-ATTACH COVER AND ENSURE WIRING IS FREE FROM
BEING PINCHED BY COVER
• SECURELY CLOSE UNTIL LATCHES MAKE AN AUDIBLE CLICK
• CLEAN WITH MILD SOAP AND WATER ONLY
9/16”
4
#2
OFF
#2
