Solar Pv logic stp005 User manual

TECHNICAL HELPLINE 01684 774000

User Manual

IMPORTANT: PLEASE READ BEFORE FIRST USE

5wp/10wp/20wp/30wp/45wp/60wp/80wp/100wp/120wp/150wp

SOLAR PANEL KITS

Models:

STP005/STP010/STP020/STP020MA/STPMH020/STPMH020PB/STPMH020AE/STP030/STP030MA/STPMH030/

STPMH030PB/STPMH030AE/STBBK45/STP045/STP045MA/STPMH045/STPMH045PB/STPMH045AE/STBBK60/

STP060/STP060MA/STPMH060/STPMH060PB/STPMH060AE/STBBK80/STP080/STP080MA/STPMH080/STPMH080PB/

STPMH080AE/STBBK100/STP100/STP100MA/STPMH100/STPMH100PB/STPMH100AE/STBBK120/STP120/STP120MA/

STPMH120/STPMH120PB/STPMH120AE/STBBK150/STP150/STP150MA/STPMH150/STPMH150PB/STPMH150AE/

STBBL200/STBBK240/STBBK300/STBBK450

TECHNICAL HELPLINE 01684 774000 TECHNICAL HELPLINE 01684 774000

SOLAR PANEL KIT CONTENTS

(Letters after item descriptions refer to the picture opposite)

STP005

1 x 5wp Solar Panel (a)

1 x 4m Cable (h)

1 x In line fuse / holder (i)

2 x Crocodile clips (k)

6 x Ring terminals (l)

1 x Instruction sheet (m)

STP010

1 x 10wp Solar Panel (a)

1 x 4m Cable (h)

1 x In line fuse / holder (i)

2 x Crocodile clips (k)

6 x Ring terminals (l)

1 x Instruction sheet (m)

STP020

1 x 20wp Solar Panel (a)

1 x 4m Cable (h)

1 x In line fuse / holder (i)

2 x Crocodile clips (k)

6 x Ring terminals (l)

1 x Instruction sheet (m)

STP020MA

1 x 20wp Solar Panel (a)

1 x 10Ah charge controller (b)

1 x 4m Cable (h)

1 x In line fuse / holder (i)

2 x Crocodile clips (k)

6 x Ring terminals (l)

1 x Instruction sheet (m)

STPMH020/PB/AE

1 x 20wp Solar Panel (a)

1 x 10Ah charge controller (b)

4 x Aluminium ﬁtting brackets (c)

(or 1 x 4pack of premium corner

proﬁles if PB kit has been selected; or 1 x 2pack

of aero proﬁles if AE kit has been selected)

16 x Stainless steel screws (d)

1 x Water resistant cable feed gland (e)

1 x 300cc Tube of bonding agent (g)

1 x 4m Cable (h)

1 x In line fuse / holder (i)

6 x Ring terminals (l)

1 x Instruction sheet (m)

STP030

1 x 30wp Solar Panel (a)

1 x 4m Cable (h)

1 x In line fuse / holder (i)

2 x Crocodile clips (k)

6 x Ring terminals (l)

1 x Instruction sheet (m)

STP030MA

1 x 30wp Solar Panel (a)

1 x 10Ah charge controller (b)

1 x 4m Cable (h)

1 x In line fuse / holder (i)

2 x Crocodile clips (k)

6 x Ring terminals (l)

1 x Instruction sheet (m)

STPMH030/PB/AE

1 x 30wp Solar Panel (a)

1 x 10Ah charge controller (b)

4 x Aluminium ﬁtting brackets (c)

(or 1 x 4pack of premium corner proﬁles if PB

kit has been selected; or 1 x 2pack of aero

proﬁles if AE kit has been selected)

16 x Stainless steel screws (d)

1 x Water resistant cable feed gland (e)

1 x 300cc Tube of bonding agent (g)

1 x 4m Cable (h)

1 x In line fuse / holder (i)

6 x Ring terminals (l)

1 x Instruction sheet (m)

STBBK45

1 x 45wp solar panel (a)

1 x 10Ah charge controller (b)

1 x Pair Narrow boat bracket and fixings

12 x Stainless steel screws (d)

1 x Water resistant cable feed gland (e)

1 x 300cc Tube of bonding agent (g)

1 x 4m cable (h)

1 x In line fuse / holder (i)

6 x Ring terminals (l)

1 x Instruction sheet (m)

STP045

1 x 45wp Solar Panel (a)

1 x 4m Cable (h)

1 x In line fuse / holder (i)

2 x Crocodile clips (k)

6 x Ring terminals (l)

1 x Instruction sheet (m)

STP045MA

1 x 45wp Solar Panel (a)

1 x 10Ah charge controller (b)

1 x 4m Cable (h)

1 x In line fuse / holder (i)

2 x Crocodile clips (k)

6 x Ring terminals (l)

1 x Instruction sheet (m)

STPMH045/PB/AE

1 x 45wp Solar Panel (a)

1 x 10Ah charge controller (b)

4 x Aluminium ﬁtting brackets (c)

(or 1 x 4pack of premium corner proﬁles if PB

kit has been selected; or 1 x 2pack of aero

proﬁles if AE kit has been selected)

16 x Stainless steel screws (d)

1 x Water resistant cable feed gland (e)

1 x 300cc Tube of bonding agent (g)

1 x 4m Cable (h)

1 x In line fuse / holder (i)

6 x Ring terminals (l)

1 x Instruction sheet (m)

STBBK60

1 x 60wp solar panel (a)

1 x 10Ah charge controller (b)

1 x Pair Narrow boat bracket and fixings

12 x Stainless steel screws (d)

1 x Water resistant cable feed gland (e)

1 x 300cc Tube of bonding agent (g)

1 x 4m cable (h)

1 x In line fuse / holder (i)

6 x Ring terminals (l)

1 x Instruction sheet (m)

STP060

1 x 60wp Solar Panel (a)

1 x 4m Cable (h)

1 x In line fuse / holder (i)

2 x Crocodile clips (k)

6 x Ring terminals (l)

1 x Instruction sheet (m)

STP060MA

1 x 60wp Solar Panel (a)

1 x 10Ah charge controller (b)

1 x 4m Cable (h)

1 x In line fuse / holder (i)

2 x Crocodile clips (k)

6 x Ring terminals (l)

1 x Instruction sheet (m)

STPMH060/PB/AE

1 x 60wp Solar Panel (a)

1 x 10Ah charge controller (b)

4 x Aluminium ﬁtting brackets (c)

(or 1 x 4pack of premium corner proﬁles if PB

kit has been selected; or 1 x 2pack of aero

proﬁles if AE kit has been selected)

16 x Stainless steel screws (d)

1 x Water resistant cable feed gland (e)

1 x 300cc Tube of bonding agent (g)

1 x 4m Cable (h)

1 x In line fuse / holder (i)

6 x Ring terminals (l)

1 x Instruction sheet (m)

STBBK080

1 x 80wp solar panel (a)

1 x 10Ah charge controller (b)

1 x Pair Narrow boat bracket and fixings

12 x Stainless steel screws (d)

1 x Water resistant cable feed gland (e)

1 x 300cc Tube of bonding agent (g)

1 x 4m cable (h)

1 x In line fuse / holder (i)

6 x Ring terminals (l)

1 x Instruction sheet (m)

STP080

1 x 80wp Solar Panel (a)

1 x 4m Cable (h))

1 x In line fuse / holder (i)

2 x Crocodile clips (k)

6 x Ring terminals (l)

1 x Instruction sheet (m)

STP080MA

1 x 80wp Solar Panel (a)

1 x 10Ah charge controller (b)

1 x 4m Cable (h)

1 x In line fuse / holder (i)

2 x Crocodile clips (k)

6 x Ring terminals (l)

1 x Instruction sheet (m)

STPMH080/PB/AE

1 x 80wp Solar Panel (a)

1 x 10Ah charge controller (b)

4 x Aluminium ﬁtting brackets (c)

(or 1 x 2pack of 52.5cm proﬁles if PB kit has

been selected; or 1 x 2pack of aero proﬁles if

AE kit has been selected)

16 x Stainless steel screws (d)

1 x Water resistant cable feed gland (e)

1 x 300cc Tube of bonding agent (g)

1 x 4m Cable (h)

1 x In line fuse / holder (i)

6 x Ring terminals (l)

1 x Instruction sheet (m)

STBBK100

1 x 100wp solar panel (a)

1 x 10Ah charge controller (b)

1 x Pair Narrow boat bracket and fixings

12 x Stainless steel screws (d)

1 x Water resistant cable feed gland (e)

1 x 300cc Tube of bonding agent (g)

1 x 4m cable (h)

1 x In line fuse / holder (i)

6 x Ring terminals (l)

1 x Instruction sheet (m)

STP100

1 x 100wp Solar Panel (a)

1 x 4m Cable (h)

1 x In line fuse / holder (i)

2 x Crocodile clips (k)

6 x Ring terminals (l)

1 x Instruction sheet (m)

STP100MA

1 x 100wp Solar Panel (a)

1 x 10Ah charge controller (b)

1 x 4m Cable (h)

1 x In line fuse / holder (i)

2 x Crocodile clips (k)

6 x Ring terminals (l)

1 x Instruction sheet (m)

STPMH100/PB/AE

1 x 100wp Solar Panel (a)

1 x 10Ah charge controller (b)

4 x Aluminium ﬁtting brackets (c)

(or 1 x 2pack of 52.5cm proﬁles if PB kit has

been selected; or 1 x 2pack of aero proﬁles if

AE kit has been selected)

16 x Stainless steel screws (d)

1 x Water resistant cable feed gland (e)

1 x 300cc Tube of bonding agent (g)

1 x 4m Cable (h)

1 x In line fuse / holder (i)

6 x Ring terminals (l)

1 x Instruction sheet (m)

STBBK120

1 x 120wp solar panel (a)

1 x 10Ah charge controller (b)

1 x Pair Narrow boat bracket and fixings

12 x Stainless steel screws (d)

1 x Water resistant cable feed gland (e)

1 x 300cc Tube of bonding agent (g)

1 x 4m cable (h)

1 x In line fuse / holder (i)

6 x Ring terminals (l)

1 x Instruction sheet (m)

STP120

1 x 120wp Solar Panel (a)

1 x 4m Cable (h)

1 x In line fuse / holder (i)

2 x Crocodile clips (k)

6 x Ring terminals (l)

1 x Instruction sheet (m)

STP120MA

1 x 120wp Solar Panel (a)

1 x 10Ah charge controller (b)

1 x 4m Cable (h)

1 x In line fuse / holder (i)

2 x Crocodile clips (k)

6 x Ring terminals (l)

1 x Instruction sheet (m)

STPMH120/PB/AE

1 x 120wp Solar Panel (a)

1 x 10Ah charge controller (b)

4 x Aluminium ﬁtting brackets (c)

(or 1 x 4pack of premium corner proﬁles and

1 x 2pack of 18cm proﬁles if PB kit has been

selected; or 1 x 2pack of aero proﬁles if AE kit

has been selected)

24 x Stainless steel screws (d)

1 x Water resistant cable feed gland (e)

1 x 300cc Tube of bonding agent (g)

1 x 4m Cable (h)

1 x In line fuse / holder (i)

6 x Ring terminals (l)

1 x Instruction sheet (m)

STBBK150

1 x 150wp solar panel (a)

1 x 10Ah charge controller (b)

1 x Pair Narrow boat bracket and fixings

12 x Stainless steel screws (d)

1 x Water resistant cable feed gland (e)

1 x 300cc Tube of bonding agent (g)

1 x 4m cable (h)

1 x In line fuse / holder (i)

6 x Ring terminals (l)

1 x Instruction sheet (m)

STP150

1 x 150wp Solar Panel (a)

1 x 4m Cable (h)

1 x In line fuse / holder (i)

2 x Crocodile clips (k)

6 x Ring terminals (l)

1 x Instruction sheet (m)

STP150MA

1 x 150wp Solar Panel (a)

1 x 10Ah charge controller (b)

1 x 4m Cable (h)

1 x In line fuse / holder (i)

2 x Crocodile clips (k)

6 x Ring terminals (l)

1 x Instruction sheet (m)

STPMH150/PB/AE

1 x 150wp Solar Panel (a)

1 x 10Ah charge controller (b)

4 x Aluminium ﬁtting brackets (c)

(or 1 x 4pack of premium corner proﬁles and

1 x 2pack of 18cm proﬁles if PB kit has been

selected; or 1 x 2pack of aero proﬁles if AE kit

has been selected)

24 x Stainless steel screws (d)

1 x Water resistant cable feed gland (e)

1 x 300cc Tube of bonding agent (g)

1 x 4m Cable (h)

1 x In line fuse / holder (i)

6 x Ring terminals (l)

1 x Instruction sheet (m)

STBBK200

2 x 100wp solar panel (a)

1 x 20Ah charge controller (b)

2 x Pair Narrow boat bracket and fixings

12 x Stainless steel screws (d)

1 x Water resistant cable feed gland (e)

1 x 300cc Tube of bonding agent (g)

2 x 4m cable (h)

1 x In line fuse / holder (i)

6 x Ring terminals (l)

1 x Instruction sheet (m)

STBBK240

2 x 120wp solar panel (a)

1 x 20Ah charge controller (b)

2 x Pair Narrow boat bracket and fixings

12 x Stainless steel screws (d)

1 x Water resistant cable feed gland (e)

1 x 300cc Tube of bonding agent (g)

2 x 4m cable (h)

1 x In line fuse / holder (i)

6 x Ring terminals (l)

1 x Instruction sheet (m)

STBBK300

2 x 150wp solar panel (a)

1 x 20Ah charge controller (b)

2 x Pair Narrow boat bracket and fixings

12 x Stainless steel screws (d)

1 x Water resistant cable feed gland (e)

1 x 300cc Tube of bonding agent (g)

2 x 4m cable (h)

1 x In line fuse / holder (i)

6 x Ring terminals (l)

1 x Instruction sheet (m)

STBBK450

3 x 150wp solar panel (a)

1 x 30Ah charge controller (b)

3 x Pair Narrow boat bracket and fixings

12 x Stainless steel screws (d)

2 x Water resistant cable feed gland (e)

1 x 300cc Tube of bonding agent (g)

3 x 4m cable (h)

1 x In line fuse / holder (i)

6 x Ring terminals (l)

1 x Instruction sheet (m)

TECHNICAL HELPLINE 01684 774000 TECHNICAL HELPLINE 01684 774000

Step 1: Fitting the cable to the solar panel (Cable pre ﬁtted to 60wp to 150wp panels)

1.1 Remove the cover (A) from the terminal box on the rear of the Solar Panel

1.2 Panel sizes up to 30wp generally have the junction box style shown in Fig 1A. Panels 45wp and over

have the syle shown in Fig 1B. Fitting the cable to both is similar but with the 3 terminal style shown in

Fig 1B you should ignore the centre terminal (L/H terminal is –ve and R/H is +ve).

1.3 Take one end of the cable and strip back the black outer insulation 4.5cm. Strip back the insulation

of the red and black inner cables 1.5cm to expose bare wire.

1.4 Feed the cable through the hole in the terminal box.

1.5 Twist the bare wire ends tightly and wrap clockwise around the loosened terminal screws B or C

(depending which junction box style you have). Alternatively, two ring terminals (supplied) can be

crimped onto the bare cable ends.

Red (positive), black (negative) as marked on inside of terminal box

1.6 Tighten terminal screws and replace the terminal box cover.

Step 2: Connecting cables to solar charge controller (If required)

2.1 Position the solar charge controller as close as possible to the battery (must be a dry location)

2.2 Measure the distance between your battery terminals and the solar charge controller.

2.3 Cut the measured distance from the end of the cable, allowing some extra for slack.

2.4 Take the loose end of the cable ﬁtted to the solar panel and prepare as per 1.3 and attach to the

terminals (D) on the solar charge controller by using the same procedure as described in 1.5.

2.5 Prepare battery cable in the same way and insert into terminals (E)

Note: Red = positive (+), black = negative (–)

Step 3: Fitting the fuse

3.1 Strip back the black outer insulation of the cable 20cm.

3.2 Position the fuse as close to the battery as possible and if a charge controller is used between the

controller and the battery. Cut the red cable at the halfway point and strip 5mm of the red insulation

from both the cut ends. Twist the bare wire ends tightly. Fit into the screw terminals (F) on each of the

fuse holder pieces.

PLEASE READ ALL INSTRUCTIONS

CAREFULLY BEFORE WORK BEGINS

IMPORTANT: When connecting a solar panel to a battery, it is always recommended that

a voltage regulator is used to prevent both reverse current feed (at night) and overcharging

of the battery. The only exception to this is the STP005 and STP010 because they are ﬁtted

with a reverse feed diode and if connected to battery size at or greater than 35Ah and 70Ah

respectively will not overcharge because of each battery’s own impedance.

Kit shown: STPMH080

deg

lki

1A B

TECHNICAL HELPLINE 01684 774000 TECHNICAL HELPLINE 01684 774000TECHNICAL HELPLINE 01684 774000

Solar Technology International Ltd. Unit 6, Station Drive,

Bredon, Nr. Tewkesbury, Gloucestershire GL20 7HH, United Kingdom

Telephone: 01684 774000 Fax: 01684 773000

E-mail: support@solartechnology.co.uk Online: www.solartechnology.co.uk

Step 4: Connecting the cable to your battery

4.1 Strip the red and black insulation (3cm) from the inner cable ends. Attach the cable to crocodile clips by

following the same procedure as described in 1.5.

4.2 Alternatively, for a more permanent connection to the battery, strip red and black insulation (6cm) from

the inner cable ends, twist the bare wire and wrap around the battery terminals and ﬁx into position

using your battery clamps. Some clamps have connection screws ﬁtted, in which case, if the supplied

ring terminals have been crimped onto the wire ends, simply attach using your battery clamp screws.

4.3 When connecting to a battery always observe correct polarity.

Solar

TECHNOLOGY INTERNATIONAL

Options

Connecting an inverter into the system

7.1 Should you require your solar system to power 240v appliances, you will need

to connect an inverter. Select an inverter power (measured in watts) that is most

appropriate for the power of your appliances (also measured in watts). The inverter

will be ideally positioned reasonably close to the battery. Most inverters come with

pre-ﬁxed cable so ﬁx the loose end directly onto the battery terminals (positive to

positive / negative to negative) - contact 01684 774000 for more information.

Connecting two or more solar panels together

8.1 Should you wish to increase the power and make a solar array or increase the

voltage (to produce 24volt instead of 12 volt) this can easily be achieved. Please

contact Solar Technology on 01684 774000 and request a copy of our “Creating

a Solar Array” technical bulletin, which can also be found in the ‘ﬁle download’

section at www.solartechnology.co.uk.

Adding a second battery

9.1 If a second battery is used, it can be connected to the Charge Controller, using

terminals I (Fig. 3), by means of an additional piece of 2-core, 1mm cable (not

supplied). As in step 4.6 above, attach the other cable to the second battery, not

forgetting to add a fuse on the positive line as descibed in step 5 above. Power

from the Charge Controller will be diverted to the second battery only when the

primary battery is fully charged.

Step 5: Additional information for ﬁtting a MH kit

5.1 Attach the aluminium ﬁtting brackets, premium or aero proﬁles (if PB or AE kit has been selected), to the side of the panel using the

supplied stainless steel screws, ensuring the brackets are ﬂush with the top of the panel frame (thereby leaving a gap between the bottom

of the panel frame and the roof).

5.2 Place the panel on the roof position where it is to be ﬁxed and draw a pencil line around the footprint of the brackets or proﬁles (if PB or

AE kit has been selected). Ideally the panel should be ﬁxed above the cable entry hole.

5.3 Clean the area on your motorhome, caravan or boat where each bracket or proﬁle (if PB or AE kit has been selected) and the cable feed

gland is to be ﬁxed with spirit, and make sure the area is clean, oil free and dry.

5.4 Insert the cable trailing from the solar panel junction box into the cable feed gland, ensuring the locking nut is loose, and then into the

entry hole on the roof. Using the provided bonding agent, now bond the cable feed gland into position.

5.5 Apply the bonding agent (around a 6mm thickness of bonding agent is ideal) to the edge of each bracket or proﬁle (if PB or AE kit has

been selected) and then, possibly with assistance, turn the panel so that the solar cells are facing upwards and bond the panel to the roof,

positioning the brackets in the pencil lines previously marked.

5.6 Once the cable has been pulled through the cable feed gland, the gland nut should be tightened to affect a water tight seal.

5.7 Now the cable can be channelled into the roof lining or into trunking/capping or similar and down to the battery. Finally, go to Steps 2, 3

and 4 to complete the installation.

NOTE – bonding agent requires 24 hours to properly cure. We would therefore recommend that the motorhome, caravan or boat is not

moved during this period.

Step 6: Additional information for ﬁtting a Narrow Boat Ktt

6.1 The brackets are supplied with stainless self-taping screws to fix the bracket to the roof of the narrow boat. Use the bracket itself as a

template and mark the hole centres. Be sure to measure the gap between brackets to suit the solar panel.

6.2 Once the drill hole points have been marked drill piolet holes and then apply a 6mm bead of bonding agent approx. 5mm inset

from around the edges of the bracket and a zig zag line in the middle. Squirt a blob in the piolet holes.

6.3 Place the brackets onto the surface and push down so the bonding agent just squeezes out beneath the edge of the bracket base.

Quickly insert the screws through the bracket holes and tighten up but not too tight so it compresses the bracket against the sealant.

6.4 Leave the brackets to cure for 24 hours and then fully tighten the screws.

6.5 The panel can then be fitted to the bracket and the cable gland installed as per 5.4 and 5.6 above

6.6 The charge controller should then be fitted as per Step 2, 3 and 4.

All Solar Technology International solar modules are

supplied with a 20 year limited peak power warranty.

The warranty claim will deemed to be valid if within

20 years any solar module exhibits power output at

less than 80% of minimum ‘Peak Power Standard

Test Conditions’ as noted on the data plate of each

module and/or any fault is determined to be the cause

of defects in materials and workmanship but not where

interference with the module/s by an unauthorised

person (of Solar Technology International) has caused

the fault or defect. The warranty includes any call

outs, labour and other expenses associated with the

repair or replacement of the defective part module.

Solar Technology International may, at its discretion

offer one of the following remedies in the event of

a successful claim against the module performance

warranty: 1) to replace the defective module/s 2)

refund the percentage of the cost of the module

to the customer representing the percentage of the

power output less than 80% of the minimum. Solar

Technology International endeavours to but is not

bound by its commitment to rectify any fault within

7 days of notification.

WARRANTY

This manual suits for next models

Other Solar Solar Panel manuals

Solar

Solar FLEXI SFP010 User manual

Solar

Solar Flexi PV SFP010 User manual

Solar

Solar SH1500 Version 1.7 User manual

Solar

Solar SH1500 Version 1.7 User manual
