Solaris Garden carousel User manual



Assembly



Assembly

Guide





Assembly


TableofContents
Introduction  1
ChoosingYourGardenCarouselLocation  1
PoweringtheGardenCarousel  2
VideoGuides  2
ContentsofShippingBox1  3
ContentsofShippingBox2  3
Step-By-StepAssemblyInstructions  6
SeedlingGrowLightAssembly  6
LEDStandAssembly  7
PlanterCarouselAssembly  9
OptimumLightSchedule  11
TestingtheWaterFlow  12
WarrantyandReturns  13
ContactUs  13
Appendix  14
Aboutthesubmersiblewaterpump  14
AbouttheGardenCarouselBarrinalights 14
TimerManufacturer’sDocumentation  15






Assembly



Introduction

SolarisSystemsIncisahydroponic/aeroponicsystemscompanywhosegoalistomakeit

easyforanyonetogrowlettuce,herbsandothercrops.ThecombinationoftheBioDome

seedstarterwiththeGardenCarouselenablesyoutoalwayshavesomethingreadywhen

harvestingfullplants.



Withthissystemyouwillhaveyourownpersonal“Farm-to-Table”

foodsource.Sinceyouaregrowingindoorsyouwillnothaveto

contendwithinsects,pests,pesticides,sprays,dirt,weather,

fungus,rain,coldweatherandalltheotherthingsthatcanaﬄict

yourplantsinanoutsidegarden.Youcanpickyourlettuceor

herbsforsupperjustafewminutesbeforeyouarereadytoeat.

Thatisthedeﬁnitionoffreshandyouwillmostcertainlynoticethe

tastedifferencecomparedtosimilaritemspurchasedfroma

grocerystore.



ChoosingYourGardenCarouselLocation

Yourplantswillbelikebabieswhoneedfeedingandcare,soitisbesttoplaceyour

GardenCarouselinalocationwhereyouwillnormallypassbyitseveraltimesaday.This

willmakeiteasiertocheckonyourplants,rotatethemsothattheygetevenamountsof

light,andcheckthatthedrippersarenotcloggedbyalgaeorotherorganicdebris.



Asthereisrunningwaterinyoursystem,placingthe

systemonatileorconcreteﬂoorisideal.Ifplacedon

acarpetﬂoor,youmaywanttousea24”x36”boot

1 tray underneaththeunittopreventanywaterdrips

orspillsfromwettingyourcarpet.



1 For this, and other product links and recommendaons, visit our Oponal Items and Supply Reﬁlls secon in our

Grow Guide, or the boom of the web page hps://gardencarousel.com/order

1



Assembly



Forleafyvegetablesandherbs,theLEDgrowlightsprovideallthelightyourplantswill

need.However,asunnylocationisrecommendedifyouwantyourplantstoﬂower.



TheGardenCarouselhasafootprintof21”x21”,whichisonly3squarefeet.The36plant

systemis61"high,theLEDstandis71"high.



YourGardenCarouselcanbeplacedinacornerbecausetheplantholderrestsona

turntable.Thismeansthatyouonlyneedaccesstothefrontofthesystemforplantingand

harvesting.Itisgoodpracticetorotatetheplantholderacoupleofinchesatleastoncea

daytoevenouttheamountoflighteachplantreceives,makingsuretherotationstillputs

alltheplantsunderthedrippers.



PoweringtheGardenCarousel

Yoursystemrequiresonlyoneplugofastandardwalloutletbecausea“Y”powercable

anda6footextensioncordareincluded.OneplugoftheYcordisusedforthetimerthat

controlstheLEDlightsandtheotherplugforthewaterpump.Thepumpruns

continuously,24/7,whichisessentialtokeepyourplantsaliveandhealthy.



⚠DoNOTuseapowerstripifyourclosestoutletistoofartoreachwiththeYpower

cable.Powerstrips,withtheiropensockets,areanelectricalhazardnearawatersource.

Rather,usetheprovided6footextensioncord,ifyourGardenCarouselismorethanafew

feetfromanoutlet.



VideoGuides

Toviewvideoguidesofthefollowingassemblysteps,visit

https://gardencarousel.com/guides

2



Assembly



ContentsofShippingBox1



4' LED Grow Lights x 4

Dip Sck x 1

Water Feed Pipe x 1



ContentsofShippingBox2



Plant Holders x 8, with turntable

Mechanical Light Timer x 1

Eco 264 Water Pump x 1



Plant Holders x 32

Plant Holders - boom x 4

Water Reservoir x 1



3



Assembly



Reservoir Cover x 1

Water Distribuon Head x 1

6' Extension Cord x 1



LED Stand base x 1

LED Stand cover x 1

Y Power Cord x 1



Seed Packets x 4

BioDome Grow Lights x 1

BioDome Grow Light Legs x 2



4



Assembly



pH Down (8 oz) x 1

FloraMicro & FloraGro (8 oz) x 1

pH Test Kit x 1



Tall plant brace x 2



ContentsofShippingBox3



BioDome Seed Starter Kit x 1

BioSponges x 120



5



Assembly



Step-By-StepAssemblyInstructions

SeedlingGrowLightAssembly

1.Removethewhitebackingfromthe

double-sidedtapeonthelightholders.

2.Placethelightsontopofthelegs.Make

surethesidewiththewiresgoonthelegs

withthecut-out.



The lights assembled on their legs.

The lights placed over the BioDome



6



Assembly



LEDStandAssembly

1.AttachthefourLEDlegstotheLEDstand

base,andpositionitsothatthelegwiththe

powerisnearesttheoutletyouwillbeusing.

2.Connectthepowercordfromtheelectrical

legwiththetimertotheendofanLEDbulb.



3.Pushthelight'sringinsertstraightdown

intotheleg,aboutoneinch.

4.PushtheotherLEDbulbsintothethree

remaininglegssotheyfaceinward.



7



Assembly



5.PositiontheLEDstandcoversothepower

cordshangdown,andconnecteachcorner's

cordtothetopofanLEDbulb.

6.PushthecoverdownovertheLEDsabout

oneinch.



7.PlacetheGardenCarouselinsidetheLED

StandandplugthepumpintotheopenY-

connectorsocket.



8



Assembly



PlanterCarouselAssembly

1.Removeeverythingfromthereservoirexcept

forthepump.

2.Putthewaterfeedpipeintothepump.The

threadedendshouldbefacingup.



3.Putthereservoircoverontopofthe

reservoirwiththesmallholeinthefront.

4.Slidethebottomplanterwiththeattached

turntableoverthewaterfeedpipe,downtothe

reservoircover.



9



Assembly



5.Slidetheremaining7plantersdownthe

waterfeedpipe,offsettingthem45°fromeach

othersotheystack.

6.Pushthewaterdistributionheaddown

securelyontothewaterfeedpipe.Arrange

dripperssoeachoneisfacingdownand

centered.



7.Addtheplantholders.



10



Assembly



OptimumLightSchedule

Mostpeoplesettheirlighttimertoleavethelightsonfor14hoursadayforfasterplant

growthcycles,typicallyfrom6amuntil8pm.



Onethingthatisimportanttoknowisthatallplantsneeddarkhoursforrespiration. Itis

notusefultoleavetheLEDlightsonformorethan14hoursadaybecausethelackofdark

timewillslowtheplants’growth.



Setthetimertoyourdesiredlightcycleifitisdifferentfromthedefaultsettings.The

mechanicaltimercomespresettoONat6amandOFFat8pm,butbesuretosetthe

timertothecurrenttimewhenyouplugitinsincetheclockonlyrunswhenthetimerhasa

powersource.Thetimerhasnoback-upbatterysoitwillneedtoberesetifyoulose

powerorunplugit.



Plugthetimerintooneoutletofthe“Y“powercord.PlugtheLEDlightsintothetimer,not

totheotherendoftheYpowercord.ThisenablesyoutocontrolwhentheLEDlightsturn

onandoff.



AllfourLEDlightsshouldcomeonwhenyouplugtheirpowercordintothetimer.Ifoneor

allofthemdonotturnon,checktoseeifthetimerissetfor“on”atthetimeyouare

testing.AlsochecktheplugconnectionstotheLEDlightstomakesuretheyareﬁrmlyin

thesockets.



Remember,thepumpshouldNOTbeattachedtoanon/offswitchofanykindbecausethe

pumpneedstooperatecontinuouslytokeeptheplants’rootsfromdryingout.The

BioSpongesholdenoughmoisturetokeeptherootsmoistforabout30minutes,butno

longerthanthatbeforetheplantswillstarttowilt.

11



Assembly



TestingtheWaterFlow

Onceyou'veaddedwatertothereservoir(seethePreparingtheWaterchapterintheGrow

Guide),pluginthepumptotheotherYcablesocketandwatchtoseethatwateriscoming

outofall8drippersasteadyrate.Ifsomeofthedrippershaveasteadystreambutsome

otherdrippershavelittletonowatercomingout,ﬁrstclosethevalve(s)onthedrippers

withthefastestrateuntiltheyhavesloweddown.Thiswillallowamoreevenpressure

distribution.Next,openthevalvesontheslowdrippersuntiltheyareallsomewhatequal.

Yourplantswilldoﬁnewithawiderangeofwaterﬂowratessodonotbeconcernedif

somedrippersaredrippingfasterthanothers.



Onceyou'veveriﬁedthatalleightdrippersarefunctioning,makesurethatalleight

endpointsofthebottomplantersaregettingwaterﬂowaswell. Thisensuresthatthe

plantersandplantholdersareintheproperpositionandthateveryplantwillgetthewater

itneeds.



12



Assembly



WarrantyandReturns

SolarisSystems,IncbacksallGardenCarouselproductswithaoneyearpartswarranty

againstmanufacturingdefectsorfailure,notduetomisuseorerrorinoperation.Should

anypartfailwithinoneyearofpurchasebecauseofamanufacturingdefectorfailurenot

duetomisuseorerrorinoperation,SolarisSystemswillreplacethatpartfreeofcharge.

AnymodiﬁcationstotheGardenCarouselorallowingwatertofallbelowthetopofthe

pumpwillvoidthewarranty.



SolarisSystems,Incoffersa14-dayreturnpolicyonallGardenCarousels.Returnsmustbe

initiatedwithin14calendardaysfromthedatetheproductwasreceived.Tobeeligiblefor

areturn,yourGardenCarouselmustbeunusedandinthesameconditionthatyou

receivedit.Youritemmustbeintheoriginalpackaging.Areceiptorproofofpurchaseis

alsorequired.



Youwillberesponsibleforpayingshippingcostsforreturningyouritem.Shippingcosts

arenon-refundable.



ContactUs

IfyouhaveanyquestionsaboutthebestwaytogrowyourplantsusingtheGarden

Carousel,visitourwebsiteathttps://gardencarousel.comforadditionaltipsandtricks,or

sendanemailto[email protected].



If anything is missing from your shipment, contact us immediately and we will send the

missing component.



13



Assembly



Appendix

Aboutthesubmersiblewaterpump

TheEcoPlusEco264SubmersiblePumpisaﬁxedﬂowrate,290gallonperhour

multipurposepump.EcoPluspumpsareforindoororoutdooruseandshouldneverbelet

rundry.



AbouttheGardenCarouselBarrinalights

BarrinaLEDgrowlights4ftprovideindoorplantswithfull-spectrumsunlightreplacement.

Itprovidesthemostreasonablegrowlightwavebasedontheratiooftheabsorptionofthe

plants.Over95%lightenergycanbeabsorbedbyplants.Thelighteﬃciencycanbe

increasedby17~20%withreﬂector.Theshellofourlightwasmadeof100%aluminum

whichprovideshigh-eﬃciencyheatdissipation,ensuringthelongerservicelifeoftheLED

chips.Thesegrowlightsaresuitableforplantsinanyindoorapplication.Sunlightwhite

colormakesyoureyesfeelcomfortable.



14



Assembly



TimerManufacturer’sDocumentation



15
