Panther H0767 User manual
INTRODUCTION
The Model H0767 Tapered Wood-Sided Wagon
features 8 1/4" high wooden interlocking side
panels that are easily removed for access to the
14 3/4" x 33" bed.
REMOVAL & INVENTORY
1. Remove your new wagon from the carton.
2. Compare all the contents with the inventory
list below Figure 1.
FRONT SUPPORT ASSEMBLY
1. Slide the front axle assembly onto the pivot
post of the bed.
2. Fasten using the lock pin and collar.
WHEELS
1. Inflate each wheel to 30 psi.
2. Slide a wheel onto each axle with the valve
stem to the outside.
3. Push a hub cap onto the end of each axle
until flush with the wheel.
BED & SIDE PANELS
1. Place the bed on top of the frame.
2. Insert one of the side panels into the frame,
making sure the slotted panel housing is fac-
ing inside.
3. Place the front and rear panels inside the
slotted panel housing on the side panel
installed in step 2.
4. Insert the other side panel into the frame,
making sure the front and rear panels each
slide into the slotted panel housing.
PULL HANDLE
1. Align the holes on the end of the pull handle
with the opening of the front axle assembly.
2. Insert the M8-1.25 x 95 slotted screw into the
holes and fasten using the 8mm flat washer,
lock washer and acorn nut.
If you need additional help with this procedure,
call our service department at: (570) 546-9663.
Panther™ products are manufactured by Grizzly
Industrial Inc.
Figure 1. Fully assembled wagon.
Tapered Wood-Sided
Wagon
Model H0767
INVENTORY LIST
A. Front Panel ................................................. 1
B. Back Panel ................................................. 1
C. Side Panels ................................................ 2
D. Wheels ....................................................... 4
E. Pull Handle ................................................. 1
F. Bed ............................................................. 1
G. Front Axle Assembly .................................. 1
H. Bolt Bag ...................................................... 1
— Slotted Screw M8-1.25 x 95 .................. 1
— Flat Washer 8mm .................................. 1
— Lock Washer 8mm ................................ 1
— Acorn Nut M8 x 1.25 ............................. 1
— Lock Pin ................................................. 1
— Collar ..................................................... 1
— Hub Caps .............................................. 4
Adult supervision is always required while
this wagon is being used by children.
1 PH0767001 HUB CAP
2 PH0767002 WHEEL 2.60 x 85
3 PH0767003 FRONT/REAR PANEL
4 PH0767004 PULL HANDLE
5 PH0767005 SLOTTED SCREW M8-1.25 x 95
6 PH0767006 FRONT AXLE ASSEMBLY
7 PH0767007 FRAME
REF PART# DESCRIPTION
H0767 Parts Breakdown and List
7
6
10
11
11
3
3
4
8
1
2
13
12
15
59
14
8 PH0767008 LOCK PIN
9 PH0767009 COLLAR
10 PH0767010 BED
11 PH0767011 SIDE PANEL
12 PW01M FLAT WASHER 8MM
13 PN18M ACORN NUT M8-1.25
14 PH0767014 PLASTIC HANDLE GRIP
15 PLW04M LOCK WASHER 8MM
REF PART# DESCRIPTION
