Solas SEVENTY2 LGS-72 User manual

solasfires.com 1
SEVENTY2
DIRECT-VENT LOG SET KIT
PART: LGS-72
INSTALLATION MANUAL
ONLY FOR USE ON SÓLAS MODELS: 72N-SSL, 72P-SSR, 72N-ST, 72P-SSL, 72P-SSR, 72P-ST
WARNING
This log set kit shall be installed by a qualified service agency in
accordance with the manufacturer’s instructions and all applicable
codes and requirements of the Authority Having Jurisdiction. If
the information in these instructions is not followed exactly, a fire,
explosion or production of carbon monoxide may result causing
property damage, personal injury or loss of life. The qualified
service agency is responsible for the proper installation of this kit.
The installation is not proper and complete until the operation of the
converted appliance is checked as specified in the manufacturer’s
instructions supplied with the kit.
NOT FOR USE WITH VENT-FREE OR OUTDOOR FIREPLACES
SÓLAS BIRCH LOG SET KIT
INSTALLER: Leave this manual with appliance | CONSUMER: Retain this manual for future reference

SÓLAS CONTEMPORARY FIRE
2
KIT CONTENTS:
• (5) CERAMIC LOGS • 2lb. 0oz. LAVA ROCK
• (6) CERAMIC ROCKS • METAL LOG SET BURNERS
LOG SET INSTALLATION
SÓLAS BIRCH LOG SET
BURNER SUPPORT LOCATIONS
Unless the SEVENTY2 Slim-Line Built-In Gas Fireplace was originally ordered with the Birch Log Set,
your fireplace will have shipped from the factory with Glass Media burners in place. Before installing
the log set burners, you will need to remove the glass burners. See following steps 1-4 to remove the
Glass Media burners. If the fireplace has been ordered with the Log Set Burner, you can skip to
Step 10 (Page 6 of this manual).
1. The burners are retained by [12] #10 sheet metal screws.
Using a ⁄" nut driver, remove screws located below
the burner (in front of and behind burner).
2. The SEVENTY2 has a center burner link that aligns the
burners, remove the [2] #10 sheet metal screws using
a ⁄" nut driver.
REMOVAL OF GLASS MEDIA BURNER

solasfires.com 3
LOG SET INSTALLATION
5. Once the glass media burner has been removed,
locate the Log Set Burner included in the kit
LGS-72 and install in the fireplace reusing the
hardware removed during disassembly.
6. When converting to propane, remove collar on burner
inlet tube. When converting to natural gas install collar
over burner inlet tube and secure with #8 sheet metal
screw provided using a ⁄” nut driver.
3. Remove pilot hood.
4. Lift the end of each burner up and move towards the
end of the firebox until the burner inlet tube is o of the
burner orifice. Lift the burner out of the fireplace.
Collar OFF for LP Collar ON for NG

SÓLAS CONTEMPORARY FIRE
4
LOG SET INSTALLATION
7. Install the left logset burner within the firebox by lowering the burner into the firebox. (while keeping the burner
pressed toward the left side of the firebox) then sliding the burner right towards the center of the firebox to
engage the burner orifice. Confirm that the burner inlet tube has engaged the burner orifice. Secure the burner
using the [4] #10 sheet metal screws using a ⁄” nut driver set aside from steps 1-4.
Step 7-A
Step 7-B
Step 7-C

solasfires.com 5
LOG SET INSTALLATION
8. Install the right logset burner within the firebox by lowering the burner into the firebox. (while keeping the burner
pressed toward the right side of the firebox) then sliding the burner left towards the center of the firebox to engage
the burner orifice. Confirm that the burner inlet tube has engaged the burner orifice. Secure the burner using the [4]
#10 sheet metal screws using a ⁄” nut driver set aside from steps 1-4.
Step 8-A
Step 8-B
Step 8-C

SÓLAS CONTEMPORARY FIRE
6
LOG SET INSTALLATION
9. Secure the central burner link using the [2] #10 sheet metal screws using a ⁄” nut driver set aside from Step 2.
Figure 9-A shows the burners before the burner link is installed; Figure 9-B shows the burners after the burner link
has been installed.
10. Install the 3-rock cluster on the 2 pins located at the far left of the firebox as shown in Figure 10.
11. Install these two rocks shown in figure 11 on the pins slightly to the right of the 3-rock cluster installed in step 10.
Figure 9-A
Figure 10
Figure 9-B
Figure 11
> Start HERE if the SEVENTY2 Slim-Line Built-In was originally ordered with a Log Set Burner
INTALLATION OF BIRCH LOG SET

solasfires.com 7
LOG SET INSTALLATION
12. Install the 3-rock cluster as shown in Figure 12 on the pins to the right of the pilot assembly, towards the back of
the burner.
13. Install the 3-rock cluster shown in Figure 13 to the right of the cluster installed in step 12.
14. Install the middle birch log set by placing the right side of the log on the 3-rock cluster you installed in step #12.
The left side of the log engages with the pin located to the left of the pilot assembly.
Figure 12
Figure 14
Figure 13

SÓLAS CONTEMPORARY FIRE
8
LOG SET INSTALLATION
15. Install the log shown in Figure 15 with the left side resting on the 3-rock cluster you installed in step 10. The right
side of the log rests on the burner as shown located by a pin.
16. Install the log shown in Figure 16 with the right side resting on the 2 rocks installed in step 11. The left side of the
log rests on the burner as shown located by 2 pins.
17. Install the log shown in Figure 17 with the left side resting on the 3-rock cluster installed in step 13. The rock is
located by a single pin and aligned parallel to the front edge of the burner. The log rests on the rock as shown,
the right side is located by 2 pins on the burner.
Figure 15
Figure 16
Figure 17
could use new pic
could use new pic

solasfires.com 9
LOG SET INSTALLATION
18. Install the single rock and log shown in Figure 18, the rock is located by a single pin and aligned parallel to the
front edge of the burner with the left side of the log resting on top. The right side of the log rests on the burner,
a groove in the underside of the log interfaces with the front edge of the burner, slide the log to the right until the
tip of the log is about to make contact with the enamel side panel.
19. Evenly distribute the included 2lb and 0oz of lava rock on the exposed burner top. Cover the burner top
completely but do not compress or “pack” the lava rock tightly. Pay special attention to tight and hard to
reach areas when placing the media on the burner. It is ok if small amounts of lava rock are lost over the
edge of the burner.
Installation of the Birch Log Set is now complete, refer to the SEVENTY2 Installation and
Operation Manual for instructions on final assembly and lighting of the appliance.
Figure 18
could use new pic
could use new pic
