SolaX Power EPS Box User manual

描述
材料
料号
单位 页次
设计
审核
核准
技术要求：
1.材质80g铜版纸，彩色打印，正反打印
2.未注尺寸公差按 +- 1.5mm
3.图面、字体印刷清晰、无毛边、不起边、油墨不脱落
4.字体颜色为PANTONE Black C，无边框，底色为白色
5.符合RoHS要求
浙江艾罗电源有限公司
罗 西 2016/6/3
朱娴红 2016/6/29
朱娴红 2016/6/29
铜版纸
EPS BOX(UK)说明书
REV.REV.
Description Description
0.0
首次发行
罗 西 2016/5/25
描述
料号
单位
614.00123.00
页次
浙江艾罗电源有限公司
SolaX Power Co.,Ltd.
EPS BOX(UK)说明书
614.00123.00
285 mm
210 mm
EPS Box(UK)
Quick Installation Guide
Tools and Packing List check ing
EPS Box is a
manual
Open the box
Connect wires
02
Box
EPS Load
II
Introduction
I
III
V
Mounting
IV
0.0
V1.0 修改开关零线的连接方式
罗 西 2016/6/3
0.0
V1.1 修改页码和参数格式
罗 西 2016/6/20
Q-OP-SC-01-02 V1.0
0.0
V1.2 修改L/N线颜色,修改盒子外形
罗 西 2016/6/29

8
6
EPS Box(UK)
Quick Installation Guide
Tools
Before you start, get the following tolls ready.
EPS Box is a manual changeover switch which is
compatible with SolaX hybrid inverter. Configured
with EPS Box, customers just need to connect
several wires between inverter and EPS Box.
Please read this guide carefully before use.
5.1 Wires making
Wires below are needed
before installation.
Use the diagonal plier to trip
15mm of insulation from one
side of the wire as below.
Insert this end of wire into
cold pressed terminal and
tighten it.
GND wire*1
12AWG wires*2pcs 12AWG
Open the box by the screwdriver, and take the breaker down.
Open the tap hole, and then insert SUPPLY-L wire and SUPPLY-N wire into the ports of the
contactor(2&6) through the hole.
5.2 SUPPLY-wires connection
SUPPLY-L wire
SUPPLY-N wire
Open the box
Connect wires
01 02
GND
4
2
Screwdriver
II
Introduction
I
III
V
12mm
15mm
12mm
Mounting
IV
Diagonals plier
Box shell-GND
The wires marked 1,2,3 and 4 are
already prepared in the EPS BOX.
2AWG wires*4pcs
EPS Box
EPS Load
2AWG
1
34
SUPPLY-L wire —— 2
SUPPLY-Nwire —— 6
SUPPLY-L/Nwire~2AWG
2
6
6
2

Open the tap hole, then install the breaker, insert the wires already on the contactor into
the port of the breaker and earth bar as below, then insert EPS-N wire into the earth bar ,
insert EPS-L wire into the port of the breaker.
Insert LOAD-L wire and LOAD-N wire into ports of contactor(3&7) through the hole.
5.3 Load-wires connection
5.4 EPS-Wires connection
LOAD-L wire —— 3
LOAD-Nwire —— 7
LOAD-L/Nwire~2AWG
EPS-L/Nwire~12AWG
5.5 GND-Wires Connection
Insert the GND wire which is in the box into the shell of the box, then insert local GND
wire into the earth bar of the box.
5.6 Checking
to EPS port of inverter
to GRID
to the ground
Grid
Max.AC input current (A)
Rated AC voltage ( V )
Rated AC frequency (Hz)
EPS
Max.EPS input current (A)
Rated EPS voltage ( V )
Rated EPS frequency (Hz)
100
230
50
9
230
50
Load
Genaral Data
Operating Temperature range (℃ )
Dimension (mm)
Weight (kg)
Rated output current(A),on grid mode
Rated output current(A),EPS mode
Rated Grid Voltage( V )
100
9
230
204*204*142
3
-10~+50
Rated Grid Frequency(Hz) 50
Technical Parameters
EPS-L wire
EPS-N wire
03 04
to EPS load
614.00123.00
Please make sure all wires are tightened.
Overview of Box
VI
VII
GND wire
3
7
Load-L wire
Load-N wire
Box shell-GND
8
4
