Soldron SL-878D User manual

SL-878D Multi-function ESD
Protected Hot Air and Iron
Digital Rework Station
A Br and y ou can tr ust

SL-878D Multi-function ESD protected
Hot air and digital Rework station
Thank you for choosing Soldron® as your preferred brand. This product shall deliver a perfect
soldering experience with long life and reliability. We also offer service and assistance in
order to help maintain your product, in perfect working condition.
PACKAGE CONTENTS:
Station x 1
Iron (with MCH element) x 1
3 Pin Electric cord x 1
HotAir Blower gun x 1
HotAir Nozzles x 3 (5mm, 7mm & 11mm)
Iron Stand with Cleaning Sponge x 1
Instruction Leaet x 1
Warning and Caution are defined as follows:
WARNING!:
Misuse may potentially cause death of, or serious injury to,
the user. The manufacturer will not be held liable for any loss
life or property.
CAUTION!:
Misuse may potentially cause death or serious injury to the
user. Proper diligence has to be used by the user in order to
avoid injury or physical damage to objects and or re hazard.
NOTE: Please use proper safety gear such as goggles and
breathing mask in a safe work environment, prior to
operation of this product.
When the power is on, tip temperature is between
200°C/392°F and 480°C/896°F
These temperatures are potentially high enough to cause the
following:
Serious burn injuries by touching the metallic parts/hot
air to oneself or others.
Can cause res if product comes into contact with
inammable objects.
People in the vicinity of the product should be warned
about its potential dangers.
Power should be off when not being used and when
unattended.
Before replacing parts on the respective unit, be sure to
switch off the unit and allow ample time for cooling to
ambient.
The following conditions must be strictly be adhered to while
using this product.
Use for soldering applications only
Banging the soldering iron against hard surfaces to
remove extra solder may damage the product beyond
warranty, and cause short circuit or shock hazard.
Do not attempt to modify the unit as warranty will be void.
Use only genuine Soldron Replacement parts.
Product should not come in contact with water or
moisture.
Do not block air vents or front nozzle on hot air blower as
this may cause overheating and become a re hazard.
Have proper ventilation while soldering as fumes may be
harmful if inhaled.
Do not let heated iron come in contact with the electrical
cord or plastic casing of the station.
Be sure to lightly dampen the sponge to clean the tip
when necessary for extended tip maintenance.
Be sure to keep the vents of the hot air blower clean and
unobstructed for proper airow.
Do not t or unplug the iron and/or hot air blower from the
base station before switching off the electricity.
The hot air blower and the iron have different types of plugs
and should not be interchanged.
Setting up and operation:
a) First things first-
1. Be sure to lightly wet the sponge and place carefully in the
receptacle provided
2. You can add very little water to the space under the sponge
section to avoid it from drying up during use.
b) Connecting the iron and hot air blower to the station:
1. Put the iron and blower in the respective provided stands.
2. Connect the soldering iron and hot air blower plugs into their
respective sockets on the station.
3. Gently tighten the nuts, securing the plugs to the sockets.
4. Set the knobs on the station at zero position.
5. Connect the supplied power cord into the station and the
other end into the mains.
6. Turn on the switch at the rear of the station.
7. Set the temperature and air knobs as per requirement.
8. Hot air blower's inbuilt sensors will activate when placed
within it's holder and cool down by leaving it's fan on and
switching off it's heating. When completely cool, the blower fan
will switch off until picked up again, which will then re-activate
into working mode.
9. When the LED light on the panel starts blinking, it indicates
that the preset temperature has been reached.
10. The iron and hot air blower are now ready for use.
Note: The hot air blower may be used without nozzle
attachments for large area heating and larger components.
Smaller nozzles may be used to heat smaller
areas/components.
c) Important Points for tip care
1. Higher soldering temperatures can reduce the life of the tip
(Try to use lower temperatures where possible)
2. Clean the tip with the provided cleaning sponge to remove
all oxides and ux deposits. This improves the effectiveness of
the bit over long term usage.
3. After soldering job is complete, clean the tip and coat it with
solder to enhance its life.
4. CAUTION!: Using les and abrasive materials to clean the
tip, will wear away the protective iron coating to expose the
copper which will render the tip useless.
5. When the tip develops a hole due to wear of protective iron
A Br and y ou can tr ust

PORTABLE HOT AIR BLOWER
8858
STATION
This state of the art micro hot air station has all the features and specifications
to match and beat larger and more space consuming hot air blower units. Save
space and look good soldering!
WARNING:
Always use in a safe and stable environment, while wearing appropriate safety gear. The blower
gets very hot and direct contact with any surface skin and otherwise should be avoided. Always
switch off the unit when not in use. Always keep away from children
This product is only intended for use with electronic and electrical purposes, by professional and
trained personnel.
ASSEMBLY INSTRUCTIONS:
1. Place the blower handle into the provided cradle
2. Plug in the blower wire into the control unit
3. Plug in the provided mains wire and switch the mains on
4. The 7 segment display will light up with 3 horizontal lines
5. You are now ready to operate the unit

8858
OPERATIONAL INSTRUCTIONS:
1. Press the setup button to toggle the mode
2. There are 2 modes:
a. Fan Mode - Signified by FXX (Where XX range is 01-10) This is what changes
the fan speed by pressing the up and down buttons
i. F05-F10 for temperature set above 300 Degrees C.
ii. F01-F05 speeds may be used for temperatures ranging from100 Degrees to 299 Degrees.
b Temperature mode - Signified by 3 digit number (Range 100-480 Degrees C.)
i. This can be changed using the up and down buttons
3. Once the required above settings have been set, you may initiate use of the blower by
taking it carefully off the cradle.
4. The blower temperature and fan settings may be changed while the blower is running,
for better fine tuning.
SLEEP MODE (2 METHODS)
● Placing blower into cradle Method:
1. Place the blower securely into the cradle
2. The fan will speed up till the internal element has cooled completely
3. Once the fan stops, the blower will be at a safe temperature to set aside
4. Please leave the unit in a safe space to cool completely before packing it away.
● Button Method:
1. Long pressing the “SETUP”/ “ON/OFF” button
2. A long beep will be heard
3. The fan will speed up till the internal element has cooled completely
4. Once the fan stops, the blower will be at a safe temperature to set aside
5. It is highly recommended to always use the provided cradle when possible
STORAGE:
1. Please make sure the unit is cooled and switched off before storing.
2. Store in a cool, dry place to avoid oxidation and extend the life of the product.
WARRANTY:
SOLDRON provides a Limited manufacturer warranty for 6 months from the date of purchase.
Please see SOLDRON.COM/warranty for more information.
Manufactured in india By
Vimla Engineering
A2/157,Shah & Nahar lndustrial Estate, S. J. Marg,
Lower PareI ( W), Mumbai - 400 013.
Tel No. : 022-48973383
www.soldron.com

SL-878D Multi-function ESD protected
Hot air and digital Rework station
Thank you for choosing Soldron® as your preferred brand. This product shall deliver a perfect
soldering experience with long life and reliability. We also offer service and assistance in
order to help maintain your product, in perfect working condition.
PACKAGE CONTENTS:
 Station x 1
 Iron (with MCH element) x 1
 3 Pin Electric cord x 1
 Hot Air Blower gun x 1
 Hot Air Nozzles x 3 (5mm, 7mm & 11mm)
 Iron Stand with Cleaning Sponge x 1
 Instruction Leaet x 1
Warning and Caution are defined as follows:
WARNING!:
Misuse may potentially cause death of, or serious injury to,
the user. The manufacturer will not be held liable for any loss
life or property.
CAUTION!:
Misuse may potentially cause death or serious injury to the
user. Proper diligence has to be used by the user in order to
avoid injury or physical damage to objects and or re hazard.
NOTE: Please use proper safety gear such as goggles and
breathing mask in a safe work environment, prior to
operation of this product.
When the power is on, tip temperature is between
200°C/392°F and 480°C/896°F
These temperatures are potentially high enough to cause the
following:
 Serious burn injuries by touching the metallic parts/hot
air to oneself or others.
 Can cause res if product comes into contact with
inammable objects.
 People in the vicinity of the product should be warned
about its potential dangers.
 Power should be off when not being used and when
unattended.
 Before replacing parts on the respective unit, be sure to
switch off the unit and allow ample time for cooling to
ambient.
The following conditions must be strictly be adhered to while
using this product.
 Use for soldering applications only
 Banging the soldering iron against hard surfaces to
remove extra solder may damage the product beyond
warranty, and cause short circuit or shock hazard.
 Do not attempt to modify the unit as warranty will be void.
 Use only genuine Soldron Replacement parts.
 Product should not come in contact with water or
moisture.
 Do not block air vents or front nozzle on hot air blower as
this may cause overheating and become a re hazard.
 Have proper ventilation while soldering as fumes may be
harmful if inhaled.
 Do not let heated iron come in contact with the electrical
cord or plastic casing of the station.
 Be sure to lightly dampen the sponge to clean the tip
when necessary for extended tip maintenance.
 Be sure to keep the vents of the hot air blower clean and
unobstructed for proper airow.
 Do not t or unplug the iron and/or hot air blower from the
base station before switching off the electricity.
 The hot air blower and the iron have different types of plugs
and should not be interchanged.
Setting up and operation:
a) First things first-
1. Be sure to lightly wet the sponge and place carefully in the
receptacle provided
2. You can add very little water to the space under the sponge
section to avoid it from drying up during use.
b) Connecting the iron and hot air blower to the station:
1. Put the iron and blower in the respective provided stands.
2. Connect the soldering iron and hot air blower plugs into their
respective sockets on the station.
3. Gently tighten the nuts, securing the plugs to the sockets.
4. Set the knobs on the station at zero position.
5. Connect the supplied power cord into the station and the
other end into the mains.
6. Turn on the switch at the rear of the station.
7. Set the temperature and air knobs as per requirement.
8. Hot air blower's inbuilt sensors will activate when placed
within it's holder and cool down by leaving it's fan on and
switching off it's heating. When completely cool, the blower fan
will switch off until picked up again, which will then re-activate
into working mode.
9. When the LED light on the panel starts blinking, it indicates
that the preset temperature has been reached.
10. The iron and hot air blower are now ready for use.
Note: The hot air blower may be used without nozzle
attachments for large area heating and larger components.
S m a l l e r n o z z l e s m a y b e u s e d t o h e a t s m a l l e r
areas/components.
c) Important Points for tip care
1. Higher soldering temperatures can reduce the life of the tip
(Try to use lower temperatures where possible)
2. Clean the tip with the provided cleaning sponge to remove
all oxides and ux deposits. This improves the effectiveness of
the bit over long term usage.
3. After soldering job is complete, clean the tip and coat it with
solder to enhance its life.
4. CAUTION!: Using les and abrasive materials to clean the
tip, will wear away the protective iron coating to expose the
copper which will render the tip useless.
5. When the tip develops a hole due to wear of protective iron
A Brand you can trust

SL-878D Multi-function ESD
Protected Hot Air and Iron
Digital Rework Station
A Brand you can trust

Thank you for choosing Soldron®as your preferred
soldering brand. This product will give you the perfect
soldering experience with longevity, efficiency and
reliability.
We also offer after sales service and assistance in
order to help you maintain your product in perfect
working condition
SMPS STATION
SOLDRON PORTABLE VARIABLE
WATTAGE MICRO SOLDERING

SMPS
1) Clean the tip with the provided cleaning sponge to remove
all oxides and flux deposits on the tip. This improves the
effectives of the bit over long term usage.
2) After the soldering job is complete, clean the tip and coat
it with solder to enhance its life.
Important Points for tip care
1 x Soldering iron station
1 x Spring Soldering Iron holder
1 x High Quality cast iron base stand
1 x Sponge
Package Contents :
1) Be sure to lightly wet the sponge and place carefully on
the stand provided
2) you can add a little bit of water to the space under the
sponge section to avoid it from drying up during use.
3) Put the iron in the provided stand.
4) Connect the mains cord into the mains socket.
5) On power up the blue led on the station light ups.
6) Set the temperature using knob as per requirement.
7) Wait for few seconds to heat the micro iron.
8) The iron is now ready for use.
Set up and operation:
1) Using files and abrasive material to clean the tip, will loss
away the protective iron coating to expose the copper,
which will make the tip useless.
2) When the tip develops a hole due to loss of protective iron
coating, it's time to purchase and replace the bit with an
original Soldron®bit.
CAUTION!:

SMPS
Features:
1) Absolutely ESD safe and ideal for SMD/SMT work and rework
2) Micro MCH heater for long life
3) Easily replaceable as opposed to similar and cheaper
products
4) Premium grade long lasting fine needle bit included
5) Cutting Edge Design SMPS power supply
6) High-Grade Plastic Body Station and Iron
7) Pre-Printed Set and Run Modes on station
8) Easy Replaceable bits
Vimla Engineering
A2/157,Shah & Nahar lndustrial Estate, S. J. Marg,
Lower PareI ( W), Mumbai - 400 013.
Tel No. : 022-48973337
www.soldron.com
Specifications:
Name
Soldron
®
SMPS
Power Consumption
Input Voltage
Output Voltage
Temperature Range
Wire Length
4W to 18W variable
100VAC - 230 VAC
6VDC – 15VDC
250°C - 450°C
3 core mains cord 1.2mtrs
2 core iron wire

Instruction Manual for SOLDRON 8858 Micro Hot air
Soldering Station
This state of the art micro hot air station has all the features and specifications to match and
beat larger and more space consuming hot air blower units. Save space and look good
soldering!
WARNING:
Always use in a safe and stable environment, while wearing appropriate safety gear. The blower
gets very hot and direct contact with any surface skin and otherwise should be avoided.
Always switch off the unit when not in use.
Always keep away from children
This product is only intended for use with electronic and electrical purposes, by professional and
trained personnel.
Assembly instructions:
1. Place the blower handle into the provided cradle
2. Plug in the blower wire into the control unit
3. Plug in the provided mains wire and switch the mains on
4. The 7 segment display will light up with 3 horizontal lines
5. You are now ready to operate the unit
Operational Instructions:
1. Press the setup button to toggle the mode
2. There are 2 modes:
a. Fan Mode - Signified by FXX (Where XX range is 01-10) This is what changes
the fan speed by pressing the up and down buttons
i. F05-F10 for temperature set above 300 Degrees C.
ii. F01-F05 speeds may be used for temperatures ranging from100 Degrees
to 299 Degrees.
b. Temperature mode - Signified by 3 digit number (Range 100-480 Degrees C.)
i. This can be changed using the up and down buttons
3. Once the required above settings have been set, you may initiate use of the blower by
taking it carefully off the cradle.

4. The blower temperature and fan settings may be changed while the blower is running,
for better fine tuning.
Sleep Mode(2 methods)
● Placing blower into cradle Method:
1. Place the blower securely into the cradle
2. The fan will speed up till the internal element has cooled completely
3. Once the fan stops, the blower will be at a safe temperature to set aside
4. Please leave the unit in a safe space to cool completely before packing it away.
● Button Method:
1. Long pressing the “SETUP”/ “ON/OFF” button
2. A long beep will be heard
3. The fan will speed up till the internal element has cooled completely
4. Once the fan stops, the blower will be at a safe temperature to set aside
5. It is highly recommended to always use the provided cradle when possible
Storage:
1. Please make sure the unit is cooled and switched off before storing.
2. Store in a cool, dry place to avoid oxidation and extend the life of the product.
Warranty:
SOLDRON provides a Limited manufacturer warranty for 6 months from the date of purchase.
Please see SOLDRON.COM/warranty for more information.
