Solid State Logic XLogic Delta-Link MADI HD User manual

XLogic Delta-Link MADI HD
MADI Interface for Digidesign Pro Tools HD® Systems
User Guide
Version 1.1 rev. D
English

XLogic Delta-Link MADI-HD
Page 2 of 24
Table of Contents
XLogic Delta-Link MADI HD ...................................................................................................................1
Table of Contents................................................................................................................................ 2
Welcome !............................................................................................................................................3
1. Introduction .................................................................................................................................... 4
XLogicDelta‐LinkMADI‐HD ................................................................................................................................... 4
Readingconventions .................................................................................................................................................. 4
Disclaimer .................................................................................................................................................................... 5
Trademarks.................................................................................................................................................................. 5
Website ......................................................................................................................................................................... 5
2. Safety considerations.......................................................................................................................5
Definitions.................................................................................................................................................................... 5
Installation ................................................................................................................................................................... 6
ElectricalSafetyWarning........................................................................................................................................... 6
GraphicalSymbols...................................................................................................................................................... 8
3. Overview......................................................................................................................................... 9
Frontpanel................................................................................................................................................................... 9
Rearpanel .................................................................................................................................................................. 10
4. Installation .................................................................................................................................... 11
5. Synchronization .............................................................................................................................12
ProToolsHDcard .................................................................................................................................................... 12
Delta‐LinkMADIHD............................................................................................................................................... 12
WordClock/FrameClock......................................................................................................................................... 12
6. Sample Rates and I/O Mapping ......................................................................................................13
HighSpeedmodeandSMUXmode ...................................................................................................................... 13
I/OmappingandSampleRaterange ..................................................................................................................... 14
7. Pro Tools Software .........................................................................................................................17
Generalinformation ................................................................................................................................................. 17
RemotecontrolofDelta‐LinkMADIHDsettings ............................................................................................... 18
Knownissues............................................................................................................................................................. 19
Systemresources....................................................................................................................................................... 21
8. Software Updates...........................................................................................................................21
9. Technical Specifications.................................................................................................................22
Digital ......................................................................................................................................................................... 22
Input/Output ............................................................................................................................................................. 22
FrontPanelControls................................................................................................................................................. 22
Electrical ..................................................................................................................................................................... 22
Mechanical ................................................................................................................................................................. 22
10. Troubleshooting...........................................................................................................................23
Problemsolving ........................................................................................................................................................ 23
Technicalsupport...................................................................................................................................................... 23

XLogic Delta-Link MADI-HD
Page 3 of 24
Welcome !

CongratulationsonyourpurchaseoftheXLogicDelta‐LinkMADIHD!

Pleasebeassuredthatitwillprovideyouwithmanyyearsofreliableservicewhiledeliveringthe
pristineaudioqualityyouexpectfromanySolidStateLogicproduct.

TheDelta‐LinkMADIHDcanbeconnectedtooneortwoDigidesign®ProToolsHD®Coreor
ProToolsHD®Accelcard(s),providingabullet‐proof,yetcost‐effectivewaytoconnectyour
DigidesignProToolsHDsystemtoawiderangeofMADIcompatibleaudioequipment,including
mixingconsolesbySolidStateLogic®,Studer®,AMSNEVE®,Euphonix®,Otari®,Yamaha®and
more.

Formaximumformatflexibility,youcanevencombineyourDelta‐LinkMADIHDwithoneorour
twoMADIcompatibleALPHALINKmodels.Forinstance,aDelta‐LinkMADIHDcombinedwith
anALPHALINKMADI‐AXwillprovideADATandAnalogueconnectivitytoyourProToolsHD
systemataverycompetitiveprice.

IMPORTANT:PleaseregisteryourXLogicDelta‐LinkMADIHDonourwebsite.Thiswillensure
thatyoureceivenotificationsoffutureupdatesandotherimportantinformation,andthatyour
guaranteeisregistered.Registrationwillalsomakeyoueligiblefortechnicalsupport.

TheSolidStateLogichomepageisat:http://www.solid‐state‐logic.com/

FromthereyoucangototheSupportpage,whichincludeslinkstotheProductRegistrationand
Downloadpages.YoucanalsovisittheFrequentlyAskedQuestions(FAQ)areaforanyquestions
youmighthaveortocontacttechsupport.

XLogic Delta-Link MADI-HD
Page 4 of 24
1. Introduction
XLogic Delta-Link MADI-HD
TheDelta‐LinkMADIHDisanelegantlystyled,1Uhigh,rackmountableunit.Thefrontpanel
designisreminiscentoftherestoftheXLogicAlpha‐Linkrange…ratherunderstatedinthiscase:
sincetheunitiscontrolledfromthecomputer,theonlyfrontpanelcontrolsarethepowerswitch,
thePowerLEDandaclocksynclockindicatorLED.

WithDelta‐LinkMADIHD,SolidStateLogic,bringsMADIcompatibilitytoProToolsHD®
systemusers.ThismeansthatyoucannowconnectyourProToolsHD®systemquicklyand
easilytoaMADIcompatiblemixingdesk,viatheDelta‐LinkMADIHD.

Italsomeansthatyoucanhook‐upanystandalone,MADIcompatiblemultichannelI/Oand
formatconversionunittoyourProToolssystem.SolidStateLogichasanumberofsuchunits:

•XLogicAlpha‐LinkMADI‐SX(64MADII/O,12stereo/24monoAES/EBUI/O,24balanced
analogI/O).
•XLogicAlpha‐LinkMADI‐AX(64MADII/O,24ADATI/O,24balancedanalogI/O).

TheDelta‐LinkMADIHDisalsosuitableforapplicationswhereProToolsaudiohardwareisused
withthirdpartysoftwarepackages(e.g.LogicAudio).

Reading conventions
Softwaremenus
Whereappropriate,toindicatea“path”underaSolidStateLogicorProToolssoftwaremenu,the
followingformatwillbeused:

menu:Header|Submenu1|Submenu2|Submenu3|Item.

Screenshots
TheappearanceofSSLorProToolssoftwareonyourcomputerscreenmaybedifferentfromthe
screenshotsinthismanual.Thiscouldbebecauseyouareusingadifferentoperatingsystemor
operatingsystemversionorbecauseyouareusingdifferentdisplaysettings,etc.

XLogic Delta-Link MADI-HD
Page 5 of 24
Disclaimer
Thismanualhasbeenwrittenwithgreatcareandattentiontodetail,andwehaveattemptedto
covereveryoperationalaspectoftheDelta‐LinkMADIHD.However,itisnotacontractual
document.SolidStateLogicand/orthewriter(s)ofthismanualcannotbeheldresponsibleforany
lossordamagearisingdirectlyorindirectlyfromanyerrororomissioninthismanual.
Trademarks
Alltrademarksarethepropertyoftheirrespectiveownersandareherebyacknowledged.
Website
TheURLfortheSolidStateLogicwebsiteis:http://www.solid‐state‐logic.com/
2. Safety considerations
Thissectioncontainsdefinitionsandwarnings,andpracticalinformationtoensureasafeworking
environment.Pleasetaketimetoreadthissectionbeforeundertakinganyinstallationwork.
Definitions
‘Maintenance’
Allmaintenancemustbecarriedoutbyfullytrainedpersonnel.Note:itisadvisabletoobserve
suitableESDprecautionswhenmaintenancetoanypartisundertaken.

‘Non‐UserAdjustments’
Adjustmentsoralterationstotheequipmentmayaffecttheperformancesuchthatsafetyand/or
internationalcompliancestandardsmaynolongerbemet.Anysuchadjustmentsmusttherefore
onlybecarriedoutbyfullytrainedpersonnel.

‘Users’
Thisequipmentisdesignedforusesolelybyengineersandcompetentoperatorsskilledintheuse
ofprofessionalaudioequipment.

‘Environment’
ThisproductisaClassAproductintendedtoformanintegratedcomponentpartofaprofessional
audiorecording,mixing,dubbing,film,TV,radiobroadcastorsimilarstudiowhereinitwill
performtospecificationprovidingthatitisinstalledaccordingtoprofessionalpractice.

XLogic Delta-Link MADI-HD
Page 6 of 24
Installation
VoltageSelectionandFusing
TheXLogicDelta‐LinkMADIHDunithasanauto‐sensingpowersupplythatcanoperateon100–
230Vwithoutadjustment.TheMADI‐HDpowersupplymoduleisinternallyfused.Ifthefuse
shouldfailforanyreasontheunitshouldbereturnedtoSolidStateLogicforrepair/replacement
asappropriate.

SafetyEarthConnection
AnymainspowereditemofSolidStateLogicequipmentthatissuppliedwitha3‐coremainslead
(whetherconnectorisedornot)shouldalwayshavetheearthwireconnectedtothemainssupply
ground.Thisisthesafetyearthandgroundstheexposedmetalpartsoftheracksandcasesand
shouldnotberemovedforanyreason.
Electrical Safety Warning
WheninstallingorservicinganyitemofSolidStateLogicequipmentwithpowerappliedand
coverisremoved,HAZARDOUSCONDITIONSCANEXIST.

Thesehazardsinclude:
Highvoltages
Highenergystoredincapacitors
Hotcomponentsurfaces
Anymetaljewellery(watches,bracelets,neck‐chainsandrings)thatcouldinadvertentlycomeinto
contactwithuninsulatedpartsshouldalwaysberemovedbeforereachinginsidepowered
equipment.

MainsSupplyandPhases
Toensuresafeoperationofthisequipment,connectonlytoanac.
powersourcethatcontainsaprotectiveearthing(PE)conductor.
Also,thisequipmentisdesignedforconnectiontosinglephasesupplieswiththeneutral
conductoratearthpotential–categoryTNorTT–andisfittedwithaprotectivefuseinthelive
conductoronly.Itisnotdesignedforusewithliveandneutralconnectionsreversedorwherethe
neutralconductorisnotatearthpotential(ITsupplies).


Mainscableswillbecodedwiththefollowingcolourscheme:
LIVE:  Brown
NEUTRAL: Blue
EARTH: Yellow/Green


XLogic Delta-Link MADI-HD
Page 7 of 24
MainsIsolationandOver‐CurrentProtection
Anexternaldisconnectdeviceisrequiredforthisequipment;adetachablepowercord,asfittedto
thisequipment,isasuitabledisconnectdevice.Notethatthesocketoutletusedforthedetachable
powercordshouldbeinstalledneartheequipmentandshouldbeeasilyaccessible.

Anexternalover‐currentprotectiondeviceisrequiredtoprotectthewiringtothisequipment
whichmustbeinstalledaccordingtocurrentwiringregulations.Thefusingorbreaking‐currentis
definedintheenvironmentalspecificationinSection5.0ofthismanual.Incertaincountriesthis
functionissuppliedbyuseofafusedplug.
CECertification
NotethatthemajorityofcablessuppliedwithSolidStateLogicequipmentarefitted
withferriteringsateachend.ThisistocomplywithcurrentEuropeanCEregulations
andtheseferritesshouldnotberemoved.Ifanyoftheequipmentmetalworkis
modifiedinanywaytheCEcertificationstatusoftheproductmaybeadverselyaffected.
Notethataframeorchassisterminalstud(functionalearth)hasbeenfittedtothisequipmentto
provideaconvenientlowimpedancebondingpointforinterconnectedequipment,shoulditbe
required.

FCCCertification
TheXLogicDelta‐LinkMADIHDunithasbeentestedandfoundtocomplywiththelimitsfora
ClassAdigitaldevice,pursuanttopart15oftheFCCRules.Theselimitsaredesignedtoprovide
reasonableprotectionagainstharmfulinterferencewhentheequipmentisoperatedina
commercialenvironment.Thisequipmentgenerates,uses,andcanradiateradiofrequencyenergy
and,ifnotinstalledandusedinaccordancewiththeinstructionmanual,maycauseharmful
interferencetoradiocommunications.Operationofthisequipmentinaresidentialareaislikelyto
causeharmfulinterferenceinwhichcasetheuserwillberequiredtocorrecttheinterferenceathis
ownexpense.

InstructionsforDisposalofWEEEbyUsersintheEuropeanUnion
Thesymbolshownhereisontheproductoronitspackaging,whichindicatesthat
thisproductmustnotbedisposedofwithotherwaste.Instead,itistheuser’s
responsibilitytodisposeoftheirwasteequipmentbyhandingitovertoadesignated
collectionpointforrecyclingofwasteelectricalandelectronicequipment.The
separatecollectionandrecyclingofyourwasteequipmentatthetimeofdisposalwill
helptoconservenaturalresourcesandensurethatitisrecycledinamannerthatprotectshuman
healthandtheenvironment.Formoreinformationaboutwhereyoucandropoffyourwaste
equipmentforrecycling,pleasecontactyourlocalcityoffice,yourhouseholdwastedisposal
serviceorwhereyoupurchasedtheproduct.

XLogic Delta-Link MADI-HD
Page 8 of 24
Graphical Symbols
Thefollowingsymbolsmaybeusedeitherontheproductorinthismanual:


Generalhazard–refertouserorservicemanualfordetails.


Electricalhazard.


ProtectiveEarth(ground).


FrameorChassisterminal.(FunctionalEarth)


XLogic Delta-Link MADI-HD
Page 9 of 24
3. Overview
Front panel

Powerswitch
Thisswitchisusedtopowertheunitupordown.

PowerOnLED
ThisLEDislitwhentheDelta‐LinkMADIHDisswitchedon.

LockLED
ThisLEDindicatesthataWordClocksignalisreceived.

•ItislitwhentheDelta‐LinkMADIHDisreceivingastablesignalattherequiredSample
Rate.

•ItflashesslowlywhentheDelta‐LinkMADIHDisreceivingastablesignalatanincorrect
SampleRate.

•ItflashesquicklywhentheDelta‐LinkMADIHDisreceivingnosignal,anunstablesignal,
orasignalataSampleRatethatfallsoutsidetheboundaries.

PowerswitchLockLED PowerLED

XLogic Delta-Link MADI-HD
Page 10 of 24
Rear panel

ProToolsHDinterface
EachProToolsHDportprovides32inputandoutputchannels,regardlessofSampleRate.

MADIinterface
EachMADIportprovidesupto64inputandoutputchannels,dependingonSampleRate.

TheMADIinterfaceusesoptical,Fibre‐SCtypeconnectors.WeofferaseparateMADIcoaxialto
opticalconvertersolution

USBinterface
TheUSBinterfacecanbeusedtocontrolvarioussettingsoftheDelta‐LinkMADIHDhardware
andtoupdatethesoftware.

ThisinterfaceisUSB1.0compliantandusesaStyle‐AUSBconnector.

WordClockinput
TheBNCWordClockinputmustbeusedtosupplyaclockreferencesignaltotheDelta‐Link
MADIHD.

MainsConnector
Theunitispoweredbyaninternal,self‐switchingpowersupply.TheconnectorisoftheIECtype.
PrimaryPortA PrimaryPortBUSBPort
M
ainsconnector
M
ADIPortAoutput(left)and
input(right)connectors
M
ADIPortBoutput(left)
andin
p
ut(ri
g
ht)connectors
WordClockinput
connector

XLogic Delta-Link MADI-HD
Page 11 of 24
4. Installation

TheDelta‐LinkMADIHDpackageincludes:

•TheDelta‐LinkMADIHDunit.
•Themainsconnectioncable.

NOTE:ThecablesrequiredtoconnecttheDigidesigncardstotheDelta‐LinkMADIHD(DigiLink
cables)arenotsuppliedwiththeiBox.Themaximumallowablelengthvariesasfollowsaccording
totheSampleratebeingused:

•192kHzoperation:90cm(3ʹ)
•96kHzoperation:180cm(6ʹ)
•48kHzoperation:360cm(12ʹ)

Ifrequired,Delta‐LinkMADIHDcanberackmounted.Itoccupies1Uofrackspaceinastandard
19‐inchrack.

ItisassumedthatyourProToolsHDsystemisalreadyinstalledinthehostcomputer(Windows
PCorMACOSX).

1. Inatypicalsetup,pleaseconnectPrimaryPortAoftheDelta‐LinkMADIHDtothe
PrimaryPortofyourHDCorecardandPrimaryPortBoftheDelta‐LinkMADIHDtothe
PrimaryPortofyourfirstHDAccelcardviaDigiLinkcables.Technically,anyPrimaryPort
oftheDelta‐LinkMADIHDiscompatiblewithanyPrimaryPortofaProToolsHD
system.However,connectingPrimaryPortsAandBoftheDelta‐LinkMADIHDto
consecutivelynumberedPrimaryPortsoftheProToolsHDsystemispreferableinorderto
maintainclaritywhenworkingintheI/OSetuppageoftheProToolssoftware.

WARNING!:DonotconnectordisconnecttheDelta‐LinkMADIHDto/fromtheProTools
cardswhiletheProToolssoftwareisrunning.

2. ConnectthemainscabletotheMainsconnectoroftheDelta‐LinkMADIHD.

3. ExternaldevicesmaynowbeconnectedtotheMADIinputsandoutputs.

4. PowerupthecomputerthathostsyourProToolssystem,andpoweruptheDelta‐Link
MADIHD(usingthePowerswitchonthefrontpanel).

XLogic Delta-Link MADI-HD
Page 12 of 24
5. Synchronization
Pro Tools HD card
TheProToolsHDcardisdesignedtooperateasaClockSlave,lockingtoaclockreferencesignal
providedbytheaudiounitconnectedtoitsprimaryport.TheinterfaceunitcandefinetheSample
Rateinternally,orcanitselfbesynchronizedtoanexternalreferencesignal(e.g.,WordClock).

WhenevertheuserselectsaSampleRatesettinginthePCorMacsoftware,thecorresponding
commandissenttotheinterfaceunit.
Delta-Link MADI HD
TheDelta‐LinkMADIHD,liketheProToolsHDcard,isdesignedtooperateasaClockSlave.
OncethecardandDelta‐LinkMADIHDareconnectedtogether,theycanbeseenasaunit
requiringanexternalclockreferencesignal.However,thisunitnowhasMADIports,insteadof
theʺDigitalandAnalogʺconnectionstootherdevicesprovidedbyProToolsinterfaces.

AlthoughareferencesignalisembeddedinthePrimaryport,theMADIconnectionrequiresa
separateWordClocksignal.Therefore,theDelta‐LinkMADIHDisequippedwithaWordClock
inputconnector.

DependingonthetypeofunitthatisconnectedtotheMADIport,theSampleRatewillnolonger
changeautomaticallywhenasettingisselectedinthePCorMacsoftware(becausethereisno
commandchannel).Therefore,theSampleRateneedstobesetmanualyatbothends(inthePro
ToolssoftwareandonthehardwareconnectedtotheMADIport).
WordClock / FrameClock
TheWordClockinputcantranslateWordClockorFrameClocktotherequiredSampleRate.

TheʺLOCKʺLEDonthefrontpanelindicatesreceptionofastablesignal.

NOTE:Whenaʺmultiplexingʺmodeisusedfordigitalaudiotransfers,theframerateoftheaudio
clockisequaltotheaudiosamplerateatupto48kHz,halfoftheaudiosamplerateatupto96kHz
oraquarteroftheaudiosamplerateatupto192kHz..Forinstance,at44.1kHz,88.2kHzor
176.4kHz,theframerateis44.1kHz.At48kHz,96kHzor192kHz,theframerateis48kHz.The
termʺFrameClockʺdenotessuchanaudioclocksignalthatisproportionalbutnotalwaysequalto
thesamplerate.


XLogic Delta-Link MADI-HD
Page 13 of 24
6. Sample Rates and I/O Mapping
High Speed mode and SMUX mode
Samplingfrequenciesupto48kHzaredesignatedasbeingintheʺNFSrangeʺ(fromNFs,Normal
Frequency_sample).Samplingfrequenciesabove48kHzandupto96kHzareintheʺDFSrangeʺ
(fromDFs,DoubleFrequence_sample).Samplingfrequenciesabove96kHzandupto192kHzare
intheʺQFSrangeʺ(fromQFs,QuadrupleFrequency_sample).

AthighSampleRates(i.e.,SampleRatesintheDFSandQFSranges),theMADIinterfacecan
operateineitheroftwomodes,HighSpeedorSMUX.

DFSrange(88.2kHzto96kHz)
TheMADIinterfacecanoperateinHighSpeedmodeorSMUX2mode.InHighSpeedmode,the
MADI‐embeddedreferencesignalhasafrequencyof88.2kHzto96kHz.InSMUX2,thefrequency
is44.1kHzto48kHz.

QFSrange(176.4kHzto192kHz)
TheMADIinterfacecanoperateinHighSpeedmodeorSMUX4mode.In
HighSpeedmode,theMADI‐embeddedreferencesignalhasafrequencyof176.4kHzto192kHz.
InSMUX4mode,thefrequencyis44.1kHz..48kHz.
NOTE: More information regarding this topic is available in the MADI interface document AES10-
2003.

XLogic Delta-Link MADI-HD
Page 14 of 24
I/O mapping and Sample Rate range
NFSrange(44.1kHzto48kHz):64‐48ʺnormalʺmode




TwoPrimaryPortsinteractwithoneMADIPort.

PrimaryPortA,channel01↔MADIPortA,channel01
…
PrimaryPortA,channel32↔MADIPortA,channel32

PrimaryPortB,channel33↔MADIPortA,channel33
…
PrimaryPortB,channel64↔MADIPortA,channel64
NOTE: The MADI Port B output signals duplicate the MADI Port A output signals, but the MADI
Port B inputs are not connected internally to the Primary Ports in this mode.
NFSrange(44.1kHzto48kHz):64‐48ʺspecialʺmode


XLogic Delta-Link MADI-HD
Page 15 of 24

TwoPrimaryPortsinteractwithtwoMADIPorts.

PrimaryPortA,channel01↔MADIPortA,channel01
…
PrimaryPortA,channel32↔MADIPortA,channel32

PrimaryPortB,channel33↔MADIPortB,channel33
…
PrimaryPortB,channel64↔MADIPortB,channel64

NOTE:The64‐48specialmodemustbeselectedremotelyviasoftware.

NOTE:TheSpecialmodeisespeciallysuitableforinterfacingwiththeSSLAlpha‐Linkrangeofaudio
interfaces:twoAlpha‐LinkMADIaudiointerfacescanbeconnectedtoanDelta‐LinkMADIHD,
providing48analoginput/outputchannelsand16digitalinput/outputchannels(,AES/EBUorADAT)at
96kHz.

DFSrange(88.2kHzto96kHz):64‐96mode

TwoPrimaryPortsinteractwithtwoMADIPorts.

PrimaryPortA,channel01↔MADIPortA,channel01
…
PrimaryPortA,channel32↔MADIPortA,channel32

PrimaryPortB,channel33↔MADIPortB,channel33
…
PrimaryPortB,channel64↔MADIPortB,channel64



XLogic Delta-Link MADI-HD
Page 16 of 24
QFSrange(176.4kHzto192kHz):32‐192mode

OnePrimaryPortinteractswithtwoMADIPorts.

PrimaryPortA,channel01↔MADIPortA,channel01
...
PrimaryPortA,channel16↔MADIPortA,channel16

PrimaryPortA,channel17↔MADIPortB,channel17
...
PrimaryPortA,channel32↔MADIPortB,channel32

XLogic Delta-Link MADI-HD
Page 17 of 24
7. Pro Tools Software
General information
TheDelta‐LinkMADIHDcanworkwithProToolsHDsystemsrunningonaWindowsPCor
MACOSXcomputer.

UsingtheDelta‐LinkMADIHDwiththeProToolssoftwareisgenerallystraightforward.
However,thereareafewpointstobeawareof:

•TheDelta‐LinkMADIHDappearsintheProToolssoftwareasfourDigidesign192I/O
units,exceptwhenoperatingat176.4or192kHz,inwhichcaseitappearsastwoDigidesign
192I/Ounits.

•TheMADIinputsandoutputsappearintheProToolssoftwareasAnalogueorDigital
(AES/EBUorADAT)inputsandoutputsbelongingtothesefourDigidesign192I/Ounits.
Therefore,youwillnotfindanyMADIinputsoroutputslistedintheHardwareSetup
pageoftheProToolssoftwareundermenu:Setup|Hardware.Pleaseusetheinputsand
outputsthatarelisted,regardlessoftheirdenomination‐theyarereallyyourMADIinputs
andoutputs‐anddonotselectʺNoneʺ.

ThescreenshotbelowwasmadeusingaProToolsHD2systemwithasingleDelta‐LinkMADIHD
.Itshowsas192I/Operipherals(topleft).Alltheinputsandoutputsthatlistedbelongtothis
singleunit:


XLogic Delta-Link MADI-HD
Page 18 of 24
Remote control of Delta-Link MADI HD settings
SomeDelta‐LinkMADIHDsystemsettingscanbecontrolledviatheAnalogOuttabofthePro
ToolssoftwareʹsHardwareSetupwindow(menu:Setup|Hardware)



TheʺOutputTrimʺ settingsareirrelevanttotheDelta‐LinkMADIHDbecauseitsinputsand
outputsarealldigital.Therefore,wecanusethemtosetvariousAlpha‐Linkparametersas
follows:
Channel
NumberParameterIfʺAʺisselectedIfʺBʺisselected
1MADInumberofchannels*56/28/1464/32/16
2MADINFSmodeNormalSpecial
3MADIDFS/QFSmodeSMUXHighSpeed
4WordClockinputWordClock
FrameClock
(48kHz
/44.1kHz)
*The56/28/14‐channelMADImode,whichallowsSampleRatevariationsofupto+/‐12.5%,must
beusedForProToolssessionswithanadjustableSampleRate.The64/32/16‐channelMADImode
canbeusedforsessionswithafixedSampleRate.InthismodethetoleranceforSampleRate
variationsis+/‐1.5%.

XLogic Delta-Link MADI-HD
Page 19 of 24
Known issues
Startuperrors
WhentheProToolssoftwarestartsup,itusesthesettingsdefinedduringtheprevioussession,
e.g.,numberandtypeofAudioInterfaces,I/Osetup,etc.

IfyouhaveusedaLegacyAudioInterface(definedthroughmenu:Setup|Hardware),andthen
replaceditscurrentAudioInterfaceswiththeDelta‐LinkMADIHD,theProToolssoftwarewill
displaythefollowingerrormessage…:
ʺDAEerror‐1125wasencounteredʺ
ThisisbecausetheLegacyAudioInterfacecannotbedetectedanymore.AfterclickingʺOKʺ,the
ProToolssoftwarewillclosewithoutallowingyoutochangetheHardwaresetup!

AneasywaytogetaroundthisproblemistostartupProToolswiththeDelta‐LinkMADIHD
switchedOFF.Thefollowingmessagewilleventuallybedisplayed:ʺUnabletofindanAudio
Interfaceattachedto..ʺ.Atthispoint,poweruptheDelta‐LinkMADIHDandclickʺOKʺ.ProTools
willthencontinueitsstartupprocedure.

AnotherwaytosolvethisproblemistodeletethefileʺDigiSetup.OSXʺanddirectoryʺDAEprefsʺ
intheʺlibraryʺ‐>ʺPreferencesʺ directory(MAC).ThiswillforceProToolstostartupusingthe
defaultconfiguration(48kHz,limitedʺVoicesʺ,noHardwareknowledge...)

Onceready,gotomenu:Setup|HardwareandmakesureallLegacyInterfacesareremovedfrom
thePeripheralslist.

ThebestwaytodothisistoclickthenameofaLegacyAudioInterface(e.g.,882/20or888/24)and
toselectʺNoInterfacesʺfromtheʺInterfaceʺdropdownbox.AftertheLegacyInterfaceshavebeen
removed,selectthe192I/Odevice,clicktheʺMainʺ tabandselectʺExpansionI/Oʺ intheʺPort
Settingsʺsection.Asaresult,youwillseethesecond192I/OdeviceappearingintheʺPeripheralsʺ
list.









XLogic Delta-Link MADI-HD
Page 20 of 24
PlaybackEngine
TheDelta‐LinkMADIHDprovidesupto64inputandoutputchannels.Therefore,thenumberof
voicesforthePlaybackEnginemayneedtobeincreased.Forinstance,inordertoplaybackand
record64trackssimultaneouslyat96kHz,gotomenu:Setup|PlaybackEngineandselectʺ128
voicesʺ.

