Board Type Serial-Ethernet Converter
CSE-M73A User Manual
Version 1.0

CSE-M73A User Manual Ver. 1.0
- 1 - https://www.ezTCP.com
This symbol, found on your product or on its packaging, indicates that this
product should not be treated as household waste when you wish to dispose
of it. Instead, it should be handed over to an applicable collection point for the
recycling of electrical and electronic equipment. By ensuring this product is
disposed of correctly, you will help prevent potential negative consequences to the
environment and human health, which could otherwise be caused by inappropriate disposal
of this product. The recycling of materials will help to conserve natural resources. For more
detailed information about the recycling of this product, please contact your local city
office, household waste disposal service or the retail store where you purchased this
product.

CSE-M73A User Manual Ver. 1.0
- 2 - https://www.ezTCP.com
Contents
1Overview ..................................................................................................................................- 5 -
1.1 Overview ................................................................................................................................................................- 5 -
1.2 Application Examples.......................................................................................................................................- 5 -
1.3 Specification .........................................................................................................................................................- 7 -
1.3.1 Hardware ......................................................................................................................................................- 7 -
1.3.2 Software ........................................................................................................................................................- 7 -
1.4 Dimension .............................................................................................................................................................- 8 -
1.5 Interfaces ...............................................................................................................................................................- 9 -
1.5.1 RS232 Port (JP1 and JP2)......................................................................................................................- 9 -
1.5.2 RS422 and RS485 port (JP4 and JP5) .......................................................................................... - 10 -
1.5.3 UART port (JP3) ...................................................................................................................................... - 10 -
1.5.4 Ethernet Interface.................................................................................................................................. - 11 -
1.5.5 ISP Jumper................................................................................................................................................ - 11 -
1.5.6 Power........................................................................................................................................................... - 11 -
1.5.7 System LED............................................................................................................................................... - 12 -
2Installation and Test............................................................................................................ - 13 -
2.1 Installation.......................................................................................................................................................... - 13 -
2.1.1 Setting Network Aera .......................................................................................................................... - 13 -
2.2 Simple Test......................................................................................................................................................... - 15 -
3Configuration ....................................................................................................................... - 18 -
3.1 Configuration with ezManager................................................................................................................. - 18 -
3.1.1 Configuration via LAN......................................................................................................................... - 18 -
3.1.2 Configuration via Serial ...................................................................................................................... - 19 -
3.2 AT command..................................................................................................................................................... - 20 -
4Operation Modes ................................................................................................................ - 21 -
4.1 What is the Operation Mode?.................................................................................................................. - 21 -
4.2 How to enter each mode............................................................................................................................ - 21 -
4.3 Comparison of each mode......................................................................................................................... - 22 -
4.4 Normal Mode ................................................................................................................................................... - 22 -
4.5 Serial Configuration Mode ......................................................................................................................... - 23 -
4.6 ISP Mode ............................................................................................................................................................ - 23 -
4.6.1 Upgrading Firmware............................................................................................................................. - 23 -

CSE-M73A User Manual Ver. 1.0
- 3 - https://www.ezTCP.com
4.6.2 Revoking Serurity Options................................................................................................................. - 23 -
5Communication Modes ...................................................................................................... - 24 -
5.1 TCP Server .......................................................................................................................................................... - 24 -
5.1.1 Key parameters....................................................................................................................................... - 24 -
5.1.2 Examples.................................................................................................................................................... - 25 -
5.2 TCP Client ........................................................................................................................................................... - 28 -
5.2.1 Key parameters....................................................................................................................................... - 28 -
5.2.2 Examples.................................................................................................................................................... - 29 -
5.3 AT Command .................................................................................................................................................... - 32 -
5.3.1 Key parameters....................................................................................................................................... - 32 -
5.3.2 Examples.................................................................................................................................................... - 33 -
5.4 UDP ....................................................................................................................................................................... - 36 -
5.4.1 Key parameters....................................................................................................................................... - 36 -
5.4.2 Examples.................................................................................................................................................... - 37 -
6System Management .......................................................................................................... - 39 -
6.1 Upgrading Firmware...................................................................................................................................... - 39 -
6.1.1 Firmware .................................................................................................................................................... - 39 -
6.1.2 Processes ................................................................................................................................................... - 39 -
6.2 Status Monitoring........................................................................................................................................... - 41 -
6.2.1 Using TELNET .......................................................................................................................................... - 41 -
6.2.2 Using ezManager................................................................................................................................... - 43 -
6.2.3 Debugging Message............................................................................................................................ - 45 -
7Additional Functions........................................................................................................... - 47 -
7.1 Access Restriction ........................................................................................................................................... - 47 -
7.1.1 Restriction of Access (ezTCP Firewall) .......................................................................................... - 47 -
7.1.2 Setting Password.................................................................................................................................... - 47 -
7.2 Notify IP Change............................................................................................................................................. - 48 -
7.3 Sending MAC Address.................................................................................................................................. - 49 -
7.4 TELNET COM port Control Option (RFC 2217)................................................................................. - 49 -
7.5 Separator............................................................................................................................................................. - 50 -
7.6 SSL (Secure Socket Layer)........................................................................................................................... - 51 -
7.6.1 How to use as a TCP client............................................................................................................... - 51 -
7.6.2 How to use as a TCP server ............................................................................................................. - 51 -
7.7 SSH (Secure Shell) .......................................................................................................................................... - 52 -
7.7.1 How to use ............................................................................................................................................... - 52 -

CSE-M73A User Manual Ver. 1.0
- 4 - https://www.ezTCP.com
7.8 Multiple Connection...................................................................................................................................... - 53 -
7.8.1 How to use ............................................................................................................................................... - 53 -
7.8.2 Diagram...................................................................................................................................................... - 53 -
7.9 RS422, 485 and 3.3V Communication .................................................................................................. - 54 -
8Self-Test in Trouble ............................................................................................................. - 55 -
8.1 Searching problem with ezManager...................................................................................................... - 55 -
8.2 Connection Problem over TCP/IP............................................................................................................ - 55 -
8.3 Data Communication Problem on the Serial..................................................................................... - 57 -
9Related material................................................................................................................... - 58 -
9.1 Technical Documents .................................................................................................................................... - 58 -
9.2 Smart phone application............................................................................................................................. - 58 -
10 Technical Support and Warranty...................................................................................... - 59 -
10.1Technical Support ........................................................................................................................................... - 59 -
10.2Warranty.............................................................................................................................................................. - 59 -
10.2.1 Refund......................................................................................................................................................... - 59 -
10.2.2 Free Repair Services ............................................................................................................................. - 59 -
10.2.3 Charged Repair Services..................................................................................................................... - 59 -
11 Precaution and Exemption from Liability ....................................................................... - 60 -
11.1Precaution........................................................................................................................................................... - 60 -
11.2Exemption from Liability.............................................................................................................................. - 61 -
11.2.1 English version........................................................................................................................................ - 61 -
11.2.2 French version......................................................................................................................................... - 62 -
12 History................................................................................................................................... - 64 -

CSE-M73A User Manual Ver. 1.0
- 5 - https://www.ezTCP.com
1 Overview
1.1 Overview
Almost all communication devices including PC are using serial transmission. In this type,
devices send and receive data in the order of each byte. The serial communication is quite
simple to implement but has weaknesses like short distance and hard maintenance.
CSE-M73A lets the serial devices connect to the Internet. To communicate on the Internet,
devices should use TCP/IP protocol, so CSE-M73A processes the converting serial data to
TCP/IP.
CSE-M73A supports RS422, RS485 and 3.3V as well as RS232. The interfaces including the
RJ45 connecter let users apply this module to their system easily.
1.2 Application Examples
⚫1:1 Connection with a PC
Figure 1-1 1:1 connection with a PC
⚫Applied to LANs
Figure 1-2 applied to LANs

CSE-M73A User Manual Ver. 1.0
- 6 - https://www.ezTCP.com
⚫Applied to the Internet on Cable Networks
Figure 1-3 applied to the Internet on cable networks
⚫Applied to the Internet with an IP Share Router
Figure 1-4 applied to the Internet with an IP share router
⚫An Example for Multiple Monitoring System
Figure 1-5 an example for multiple monitoring system

CSE-M73A User Manual Ver. 1.0
- 7 - https://www.ezTCP.com
1.3 Specification
1.3.1 Hardware
Power
Input Voltage
DC 5V (±10%)
Current
approximately 100mA (typical condition)
Dimension
64.3mm x 40mm x 17mm
Weight
approximately 17g
Serial Port
Serial
3.3V level with 5V tolerant input
RS232, RS422 and RS485
Network
Ethernet 10Base-T or 100Base-TX (Auto-Sensing)
Auto MDI / MDIX cable auto-sense
Temperature
Operating: -40 ~ 85℃/ Storage: -40 ~ 85℃
RoHS
RoHS Compliant
1.3.2 Software
Protocol
TCP, UDP, IP, ICMP, ARP, DHCP, PPPoE, Telnet, DNS Lookup, DDNS,
TELNET COM port Control Option (RFC 2217), SSL, SSH
Diagnose
Online Debugging Function
Operation
mode
Normal
For Normal Data Communication
ISP
For Upgrading F/W
Serial Configuration
For Configuration via Serial
Communicat
ion mode
TCP Server
TCP Passive Connection
TCP Client
TCP Active Connection
AT Command
TCP Passive / Active Connection
UDP
UDP –No Connection
Major
Utilities
ezManager
Configuration Utility for MS Windows
(Supports Downloading F/W)
ezVSP
Serial to TCP/IP Virtual driver for MS Windows

CSE-M73A User Manual Ver. 1.0
- 8 - https://www.ezTCP.com
1.4 Dimension
그림 1-1 Dimension
 According to conditions of soldering components, the dimensions might be differed
with the above figure. Thus, we recommend giving some extra spaces about 1 ~ 2
mm.

CSE-M73A User Manual Ver. 1.0
- 9 - https://www.ezTCP.com
1.5 Interfaces
Figure 1-6 Interface
1.5.1 RS232 Port (JP1 and JP2)
CSE-M73A has an RS232 port for serial device (300bps ~ 230,400bps). This port is
interfaced with JP1 and JP2. It supports RTS/CTS hardware flow control and pins which have
the same number of JP1 and JP2 are connected each other.
Number
Name
Description
Level
I/O
Etc.
1
VCC
DC 5V Power
-
-
required
2
RXD
Receive Data
RS232
IN
required
3
TXD
Transmit Data
RS232
OUT
required
4
GND
Ground
-
-
required
5
RTS
Request To Send
RS232
OUT
optional
6
CTS
Clear To Send
RS232
IN
optional
Table 1-1 pin assignment of the RS232 port

CSE-M73A User Manual Ver. 1.0
- 10 - https://www.ezTCP.com
1.5.2 RS422 and RS485 port (JP4 and JP5)
CSE-M73A has a port for RS422 or RS485. This port is interfaced with JP4 and JP5. The
pins which have the same number of JP4 and JP5 are connected each other. When you
connect your device, remember that a pin should be connected with the one which has the
same polarity. Of course, an output pin (Transmit-TX or TXD) has to be connected to an
input pin (Receive-RX or RXD).
Number
Name
Description
Level
I/O
Etc.
1
VCC
DC 5V Power
-
-
required
2
TRX+
(RS422) Transmit Data +
RS422
IN
required
(RS485) Data +
RS485
3
TRX-
(RS422) Transmit Data -
RS422
OUT
required
(RS485) Data -
RS485
4
GND
Ground
-
-
required
5
RX+
(RS422) Receive Data +
RS422
OUT
optional
6
RX-
(RS422) Receive Data -
RS422
IN
optional
Table 1-2 pin assignment of the RS422/485 port
 In some environments, to prevent reflection wave, two terminal resistors may be
needed at the end of the RS422 and 485 networks.
1.5.3 UART port (JP3)
Number
Name
Description
Level
I/O
Etc.
1
VCC
DC 5V Power
-
-
required
2
RXD
Receive Data
3.3V
IN
required
3
TXD
Transmit Data
3.3V
OUT
required
4
GND
Ground
-
-
required
5
RTS
Request To Send
3.3V
OUT
optional
6
CTS
Clear To Send
3.3V
IN
optional
Table 1-3 pin assignment of the UART port

CSE-M73A User Manual Ver. 1.0
- 11 - https://www.ezTCP.com
The DC electrical characteristics of the JP3 are followed
Symbol
Description
Min
Max
Unit
VIL
voltage input of LOW
- 0.3
0.8
Volt
VIH
voltage input of HIGH
2.0
5.5
VOL
voltage output of LOW
-
0.4
VOH
voltage output of HIGH
VCC –0.4
-
Table 1-4 electrical characteristics of the JP3
1.5.4 Ethernet Interface
Since part of CSE-M73A network is composed of Ethernet, UTP cable may be connected.
It will automatically sense 10Mbits or 100Mbits Ethernet and connect itself. It also provides
auto MDI/MDIX function that can automatically sense 1:1 cable or cross over cable.
Each Ethernet device has its own unique hardware address. The hardware address of CSE-
M73A is set in the factory before being shipped to the market. (The hardware address is
also known as the MAC address)
Figure 1-7 the Ethernet interface
1.5.5 ISP Jumper
You can change the operation mode of CSE-M73A to ISP or Serial Configuration mode
by using this jumper.
1.5.6 Power
Input voltage is DC 5V for CSE-M73A. To supply power, all VCC and GND pins on JP1 ~
JP5 are available.

CSE-M73A User Manual Ver. 1.0
- 12 - https://www.ezTCP.com
1.5.7 System LED
⚫RJ45
There are 2 LEDs in the RJ-45 connector. Each lamp shows the following status:
Mode
Color
Status
Description
Normal
Yellow
Blinks in every
second
Obtaining an IP address
Blinks 4 times at
once
Without obtaining an IP address under
DHCP or PPPoE network
ON
On TCP connection
Green
ON
Connecting with Ethernet
OFF
Before connecting with Ethernet
Blinking
Sending or Receiving data from
Ethernet
ISP
Both
OFF
In the ISP mode
Serial
Configuration
Both
Blinks
simultaneously
In the Serial Configuration mode
Table 1-5 Status of the system LED
⚫Power LED
Mode
Color
Status
Description
Common
Red
ON
Supplying the Power
Table 1-6 Power LED

CSE-M73A User Manual Ver. 1.0
- 13 - https://www.ezTCP.com
2 Installation and Test
2.1 Installation
Before testing the CSE-M73A, users should connect both serial and Ethernet port to a PC.
It is fine that the Ethernet connection includes network hubs.
Figure 2-1 connection between M73A and a PC
Procedures for the test are followed.
2.1.1 Setting Network Aera
This step is for setting both CSE-M73A and users’PC to be located the same network. If
only they are, the TCP connection between them can be established.
⚫Setting of the PC
Set the IP address to the Ethernet adapter of the PC connected to the product as
follows.
Figure 2-2 Setting IP address of the PC

CSE-M73A User Manual Ver. 1.0
- 14 - https://www.ezTCP.com
⚫Setting of CSE-M73A
CSE-M73A uses ezManager as it’s a configuration program. ezManager is for MS
Windows, and it doesn’t need installation.
All environmental variables are set to the factory default values, so they must be
changed to suit the purpose of use in order to apply them to the actual system. The
following table shows the default values of the main environmental variables. For test
operation, please keep the CSE-M73A's IP address and all environment values as the
default settings below.
Name
Default Values
Network
Local IP Address
10.1.0.1
Subnet Mask
255.0.0.0
Option
TELNET
Checked
IP Address Search
Checked
Serial Port
(COM1)
Serial Type
RS232
Baud Rate
19,200bps
Parity
NONE
Data Bits
8
Stop Bit
1
Flow Control
NONE
Communication mode
TCP Server
Local Port
1470
Table 2-1 Default values of Major parameters
 Users can download the latest version of ezManager on our website.

CSE-M73A User Manual Ver. 1.0
- 15 - https://www.ezTCP.com
2.2 Simple Test
If you press the [Simple Test] button, test program will be shown on your screen.
⚫Connecting to the CSE-M73A via LAN
Figure 2-3 settings for TCP connection
①Select [TCP Client]
②Input correct IP address and port number of CSE-M73A
③Clink the [Connect] button. (In case of TCP Server, it will be [Listen] button)
⚫Opening RS232 Port
Figure 2-4 opening COM Port
④Select COM port which the CSE-M73A is connected to
⑤Make sure that all the parameters are the same with M73A
⑥Press the [Open] button

CSE-M73A User Manual Ver. 1.0
- 16 - https://www.ezTCP.com
⚫Confirm the TCP Connection and COM port status
Figure 2-5 TCP Connected message
⑦Check the message if the TCP connection is established
Figure 2-6 COM Port open message
⑧Check the message if the COM port has been opened

CSE-M73A User Manual Ver. 1.0
- 17 - https://www.ezTCP.com
⚫Data transmission test
Figure 2-7 successful data transmission
⑨Click the [Send data] on the LAN part
⑩Check the data have been shown from the step ⑨
Figure 2-8 LAN →RS232
⑪Press the [Send data] on the RS232 part
⑫Check the data have been received from the step ⑪
Figure 2-9 RS232 →LAN

CSE-M73A User Manual Ver. 1.0
- 18 - https://www.ezTCP.com
3 Configuration
3.1 Configuration with ezManager
Figure 3-1 initial appearance of ezManager
3.1.1 Configuration via LAN
⚫Checklists
Make sure the connection between your PC and CSE-M73A. If they are the same
network, [MAC Address search] button can be used. If they aren’t, only [IP Address
search] is allowed to use.
⚫Procedures
Figure 3-2 procedures for configuration via LAN

CSE-M73A User Manual Ver. 1.0
- 19 - https://www.ezTCP.com
3.1.2 Configuration via Serial
⚫Checklists
Make sure the connection between your PC and CSE-M73A using RS232 cross cable.
To use this, CSE-M73A has to be operating in the [Serial Configuration] mode. By
connecting the ISP jumper less than 1 second, you can enter the mode. After then,
read the setting via [Serial] tab on ezManager.
⚫Procedures
Figure 3-3 procedures for configuration via Serial
⚫Step 2, Reading
Figure 3-4 reading procedure via serial
①Choose the [Serial] tab
②Select the COM port which the M73A is connected with
③Open the COM port with the [Open] button
④Load the setting with [Read] button
 If you want to know more specific manners of setting, please refer to “ezManager
Users’ Manual”document.
