SONICWARE ELZ_1 Version 4 Manual Supplement Rev. 1.0
1
ELZ_1 Version 4 Manual Supplement
Rev.1.0

SONICWARE ELZ_1 Version 4 Manual Supplement Rev. 1.0
2
1About this manual
This manual explains features added in the Version 4 SYSTEM
firmware.
2Added MIDI OUT function
NOTE ON/OFF, PROGRAM CHANGE, and MIDI clock transmission
functions have been added.
2.1 Setting the MIDI OUT channel
①Press the MENU button.
②Use the DOWN and UP buttons to select MIDI.
③Use the DOWN and UP buttons to select TX CHANNEL, and press
the OK button.
④Use the DOWN and UP buttons to select the desired channel and
press the OK button.
HINT
 The setting range is 01 –16 and Off.
2.2 Setting the CLOCK OUT
①Press the MENU button.
②Use the DOWN and UP buttons to select MIDI.
③Use the DOWN and UP buttons to select CLOCK OUT, and press
the OK button.
④Use the DOWN and UP buttons to select ON/OFF and press the
OK button.

SONICWARE ELZ_1 Version 4 Manual Supplement Rev. 1.0
3
3Saving USB MIDI Mode
MIDI HOST MODE and MIDI DEVICE MODE settings will be saved
even when the power is turned off.
HINT
 When the USB host cable is unplugged from the ELZ_1, USB
MIDI will be OFF.
4Changing the MENU
The following menu items have been changed.
MENU
SUB MENU
NOTE
PATTERN
-
Independent from SEQUENCER
MIDI
TX CHANNEL
Newly added
CLOCK
-
Independent from SEQUENCER
CLOCK
SOURCE
Name changed from CLOCK
CLOCK
SYNC OUT
Newly added in place of SYNC Thru
in SOURCE.
SONICWARE INC.
www.sonicware.jp
ELZ_1_AD3M_EN_A
