SONIM XP152 0 BOLT SL
SONIM XP1520 BOLT SL IN-BOX ACCESSORIES
Battery Wall Charger USB-3.5mm Data Cable Screw Driver Rugged Pouch Belt Clip Car Charger Stereo Headset
Adaptor
Rugged BT PTT Headset Rugged BT RSM Rugged PTT Wired Headset XPand LoudSpeaker (XPand LS)
The Sonim XP1520 BOLT SL represents the optimal and aordable rugged choice for IT and Telecom Managers as well as independent
contractors in industries such as Construction, Transportation and Logistics, Heavy Manufacturing and Agriculture who make sourcing
decisions for mobile devices to be used by hundreds of related users. Equipped with AT&T’s enhanced Push-To-Talk functionality, the
Sonim XP1520 BOLT SL enables teams to work smarter with near-instantaneous one-to-one and one-to-many communications.
Combining the speed and reliability of 3G with ultra-rugged features, the Sonim XP1520 BOLT SL is the best solution to improve
productivity and safety of workers in challenging environments. Built to Sonim’s world class Rugged Performance Standards, the Sonim
XP1520 BOLT SL can be submerged in water, dropped onto concrete, driven over with a pickup truck without even missing a beat.
Sonim’s RPS standards go far beyond standard Mil-Spec certications allowing enterprises to keep critical business processes running
while access to a range of targeted professional accessories will further enhance the solution.
Additionally, the XP1520 BOLT SL provides the lowest total cost of ownership of any professional mobile device, thanks to the
industry-leading 3-year comprehensive warranty.
EXPERIENCE THE SONIM XP1520 BOLT SL
SONIM ENTERPRISE GRADE ACCESSORIES
RPS SONIM RUGGED PERFORMANCE STANDARDS CERTIFIED (RPS)
Tested and proven rugged
PUSH-TO-TALK
Connect instantly to a single contact or group
IP-68 SUBMERSIBLE TO 6.5 FT FOR 30 MIN IN WATER
Protected against damage from rain, fog, and salt air
IP-68 IMPERVIOUS TO DUST AND MICRO-PARTICLES
Non-porous casing blocks entry of micro-particles
BEYOND MIL SPEC-810G IMPACT PROOF
Withstands 6.5 ft drops onto concrete
ACTIVE NOISE CANCELLATION
Omni-directional microphone with noise cancellation
3-YEAR COMPREHENSIVE WARRANTY
Even covers accidental damage
LOUD AUDIO
23 mm speaker, protected by GORE™ Protective Vents
LONG BATTERY LIFE
Up to 12 hours of Talk/PTT Time or 875 hours of Standby Time
SCREEN TOUGHNESS
Corning®Gorilla® Glass for extreme shock &scratch resistance
SONIM STANDARD ACCESSORIES
V4.0

RUGGEDIZATION
•IP-68 certication, submersible up to 2 metres for 30 min
•MIL-810G certication (incl. salt, humidity, transport shock & thermal shock)
•Hardened rubber molded to Fiberglass casing mix by dual injection
•Rated to 6.5 ft drops onto concrete from any angle
•Vibration protection from 5Hz to 200Hz and shock resistant up to 4G
•Non-porous casing blocks entry of dust and micro-particles
•Operational range -5˚F to +130˚F
•Shock & scratch resistant 1.8 mm thick Corning®Gorilla®Glass screen
•Widely spaced keys for ease of use with gloved hands
•Impact resistant up to 4J on housing and 1J of impact energy on
screen (equivalent of a 10 cm drop of a 1kg steel ball on the display)
KEY FEATURES
•3G /HSPA/GSM/GPRS/EDGE
•Support for XPand modules
• Enhanced Push-to-talk capable
• 2 inch bright (typ. 280cd/m²) high-resolution display for high visibility
• Noise-cancelling microphone
•VGA still camera with LED Flash/torch light and video recording capability
•MicroSD card slot (up to 16 GB card)
•Multimedia : Media Player and FM Radio
CORE PLATFORM/FUNCTIONS
•MediaTek MT6276 platform (compliant to 3gpp Release 6 specications)
•Tri-band WCDMA (2100, 1900, 850 MHz)
•Quad-band GSM (850, 900, 1800,1900 MHz)
•GPRS, EDGE class 12
•HSDPA Category 8 (7.2 Mbps)
•HSUPA Category 6 (5.76 Mbps)
•Bluetooth 3.0 with DUN, HSP, HFP, OPP, PBAP, FTP, AVRCP, A2DP
•WAP 2.0 (XHTML)
• JAVA MIDP 2.0/CLDC 1.1 device
• SMS, MMS (text, image, audio, video) - up to 1000 messages
•Sonim PC Tools for contact and calendar synchronisation w/ MS Oce
support for Windows XP, Windows Vista (32 Bit), Windows 7 (32 and 64 Bit)
•Memory: Flash: 256 MB, RAM: 128 MB
• Language support: English and Canadian French
BATTERY
•1950 mAh battery with Talk Time of 12Hrs and Standby Time up 875Hrs on
3G Network
PHYSICAL CHARACTERISTICS
j
•Size: 126mm x 60mm x 25mm
•Weight: 185grams
•PTCRB/FCC/IC certications
•7 soft keys/8 programmable short-cuts
•3.5mm waterproof headset and USB data ports (proprietary cable)
•Dedicated volume and camera keys
DISPLAY
•2 inch, QVGA 240x320 resolution
•30x40mm for display bar + 9 rows of data
AUDIO SYSTEM
•One single 23mm speaker protected by waterproof
GORE™ Protective Vents
•Omni-directional microphone with noise cancellation
MULTIMEDIA
j
Audio Formats:
• MP3,AAC+, AAC, WAV
Midi, AMR
STANDARD SOFTWARE PACKAGE
•Standard services
SMS (incl. T9, Multitap modes), MMS 1.2
WAP 2.0 with support for WSP and HTTP
Polyphonic (MIDI) and MP3 ringtone supported
•Native Email Client - POP3/SMTP, IMAP4 and
secure Email support (SSL/TLS)
•XHTML web browser
IN-BOX ACCESSORIES
•Battery
• Electrical wall charger
•3.5 mm to USB adaptor
•USB cable
•Screwdriver
SONIM STANDARD ACCESSORIES
i
• Rugged pouch
•Belt clip
•Car charger
• Stereo wired headset
SONIM ENTERPRISE GRADE ACCESSORIES
i
•Rugged BT PTT Headset
•Rugged BT RSM (Remote Speaker Mic)
•Rugged PTT Wired Headset
•XPand Loud Speaker (XPand LS)
© 2013 by Sonim Technologies, Inc. All right reserved.
TECHNICAL SPECIFICATIONS
1520 BOLT SL
Video Formats:
•3gp, MPEG4 (simple prole)
H.263
