Introduction
Ascom MycoTM 4 supports streamlined workows, fast responses and fact-based
decisions. The enterprise-grade Ascom Myco 4 smartphone delivers actionable,
context-rich information to mobile personnel in healthcare, manufacturing, and
other demanding environments. The handset is based on AndroidTM 12 and
includes several Ascom solutions complementing the standard Android oering.
This Quick Reference Guide (QRG) provides a brief overview of the most common
features of your Ascom Myco 4 handset.
The images in the QRG are taken from a handset with an English user interface.
Some functionalities described in this QRG may dier from your handset
depending on system conguration. Images of the screen can also dier from how
the screen looks on your handset.
Remember to read the Safety Instructions included in the product delivery before
using the handset.
The information in this document is subject to change without notice.
Ascom Myco is a trademark of Ascom (Sweden) AB.
Android, Google, Google play and other related marks and logos are trademarks of Google LLC.
Table of Contents
© 2023 Ascom. All rights reserved. TD 93546EN / August 2023 / Ver. A
ascom © 2023 Ascom. All rights reserved. TD 93546EN / August 2023 / Ver. A
ascom
Handset
Handset Models
Buttons
Handset Views
Calling and Messaging
Text Input
Notication Overview
Manage Notications
Notication Drawer
Quick Settings
Handset security
1
2
2
3
4
4
Low Battery
True Hot Swap
Battery Replacement
Charging Methods
Desktop Charger
Handset Charging Rack
Battery Charging Rack
USB-C Cable
7
7
Overview
Views
Communication
Notication
Settings
Charging
8
8
9
9
10
11
11
12
5
5
6

© 2023 Ascom. All rights reserved. TD 93546EN / August 2023 / Ver. A
ascom © 2023 Ascom. All rights reserved. TD 93546EN / August 2023 / Ver. A
ascom
B Top Multifunction button KProximity sensor TWrist strap attachement
C Barcode scanner* L Receiver U Speaker
D Ascom IR location* MMain display V Exchangeable color sticker
E Microphone N Pull-cord port* W Multifunction button 2
F Multicolor LED O Back camera X Power button with biometric
reader
G Multifunction button 3 P Flashlight Y Charging connector
H Multifunction button 4 Q Clip Z USB-C port
IVolume buttons RBattery 8 Microphone
JFront camera S Battery cover lock
Handset
* Not available in the Slim model.
Buttons
Multifunction buttons
Depending on the conguration, these buttons can be used for dierent
purposes. For example, you can scan a barcode, send an alarm, start an app, or
use it as the Push-to-Talk (PTT) button.
Power Button (with biometric reader)
Press and hold to turn the handset on / o or restart it.
Press to lock and put the handset into sleep mode.
Press to wake up the screen from sleep mode.
Volume Button
Press up (+) to increase or press down (-) to decrease the volume level.
The handset is equipped with Power, Volume, and four Multifunction buttons.
1
Overview
Overview
2
B
C
F
E
G
H
I
M
N
V
T
Q
R
S
W
X
Y
Z
8
Handset Models
Ascom Myco 4 comes in three variants:
Ascom Myco 4, Wi-Fi With Ascom IR location, barcode scanner,
pull-cord port.
Ascom Myco 4, Cellular Wi-Fi With Ascom IR location, barcode scanner,
pull-cord port.
Ascom Myco 4 Slim, Wi-Fi No Ascom IR location, No barcode scanner,
No pull-cord port.
J
K
O
P
U
D
L

© 2023 Ascom. All rights reserved. TD 93546EN / August 2023 / Ver. A
ascom © 2023 Ascom. All rights reserved. TD 93546EN / August 2023 / Ver. A
ascom
Handset Views
To get to the All apps screen, swipe up from the bottom of the Home screen.
To get back to the Home screen, swipe down in the All apps screen, or press the
Back or Home button.
Home screen
Navigate between Views
All apps screen
Back
button Home button
4
Communication
NOTE:
Frequently used apps can be found in the shortcut panel of the Home screen.
If you can not nd the apps or want to change the shortcuts, contact your
system administrator for assistance.
Shortcut
panel
Views
3
The interface of the handset is divided into two separate views:
The Home screen is the main view of the handset, where you can s shortcuts to
access to dierent apps and functions.
The All apps screen is the view where you can nd all the apps that are installed
on the handset.
In the All apps screen, tap the Messages app*
icon . You can also open the app from the
Shortcut panel of the Home screen.
Tap the Start chat icon at the bottom
of the screen to write a new message or tap the
conversation to read and reply to it.
Choose between manually dialing the phone
number , choosing the contact from Favorites ,
Recent calls , or the Contacts .
In the All apps screen, tap the Phone app icon .
You can also open the app from the Shortcut panel
of the Home screen.
Calling and Messaging
Text Input
If several input languages are available, tap the Show language switch key to
change the input language. Tap the Show language switch key until the correct
language is displayed. Alternatively, press and hold the space bar and then select
the language in the opened window.
To use emojis, press and hold the Enter or Next key and then select the
Emoji key . To go back to the text input, tap ABC.
B
C
B
C
* Not available in Wi-Fi only models.

© 2023 Ascom. All rights reserved. TD 93546EN / August 2023 / Ver. A
ascom © 2023 Ascom. All rights reserved. TD 93546EN / August 2023 / Ver. A
ascom
Swipe left or right to
clean the notication (if
allowed).
Manage Notications
Tap the Down arrow
icon or swipe the
notication down to
open the Notication
drawer.
Long press the
notication to open the
app that sent it.
Notication Overview
Notications appear in dierent places and formats, such as icons in the Status
bar or as detailed texts in the Notication drawer. In unlocked mode, notications
appear at the top of the screen.
There are three ways to manage notications on the lock screen:
Notications
5
To open the Notication drawer, swipe
down from the top of your screen.
You can open the Notication drawer in
unlocked mode and on the lock screen.
Notication Drawer
The Notication drawer shows a
list of notications, such as missed
calls, conversations, system and app
messages.
Incoming notications rst appear as
icons in the Status bar at the top of
the screen to show that there is new
information in the Notication drawer.
Back
button
Home
button
To hide the Notication drawer,
swipe upwards, tap outside the
drawer, or press the Back or
Home buttons.
Notications
6
1. Icon, for example "Contact icon"
2. Title / Headline
3. Timestamp
4. Expand indicator
5. Supporting text
6. Actions
7. App icon
E
DCB
F
H
G

© 2023 Ascom. All rights reserved. TD 93546EN / August 2023 / Ver. A
ascom © 2023 Ascom. All rights reserved. TD 93546EN / August 2023 / Ver. A
ascom
Quick Settings
The Quick Settings panel can be used to make some fast changes in your Ascom
Myco 4, such as alter the brightness of the screen or put the handset in battery
save mode.
You can open the Quick Settings panel both in unlocked mode and on the lock
screen.
Settings
7
Charging
8
Low Battery
True Hot-Swap
Ascom Myco 4 has an easily replaceable battery that can be changed without
powering down the handset or exiting your active apps. With hot-swap
functionality you can continue working and using your apps even when the battery
is being exchanged.
-When removing the battery, your handset is operational for another 60
seconds.
-If the battery is not replaced within 60 seconds, the handset switches o.
To turn the setting
on / o , tap the
corresponding icon.
To see a selection of
settings, swipe down
from the top of the
screen.
To open the whole
Quick Settings panel,
swipe down two times
from the top of the
screen.
If the battery level is low, charge the battery or change it to a fully charged one as
soon as possible.
20% A low battery level is indicated a warning signal and the Battery
may run out soon notication.
10% - 2% A very low battery level is indicated by a warning signal that sounds
at each battery percent change and the Battery may run out
soon notication.
Press Mute to silence the warning signal.
1% An empty battery is indicated by vibration and a warning signal that
sound every ve seconds, and the Battery may run out soon
notication.
Press Mute to silence the warning signal.
NOTE: The vibration will stay on even if the handset is placed into
the "Do Not Disturb" or "Silent" mode.
Handset security
The following recommendations are to ensure that the handset is accessible by
the intended personel only.
-Lock the device (turn o the screen) before leaving it unattended
-Avoid change in any setting that may degrade security e.g., increase the
screen timeout.
-Use one of the following screen lock methods
Screen lock
Go to Settings → Security → Screen lock.
Choose one of the following:
-Pattern to draw a pattern to unlock the handset.
-PIN to enter their PIN code to unlock the handset.
-Password to enter the password to unlock the handset.

© 2023 Ascom. All rights reserved. TD 93546EN / August 2023 / Ver. A
ascom © 2023 Ascom. All rights reserved. TD 93546EN / August 2023 / Ver. A
ascom
Press the clip once again. Insert a fully charged or new battery and press it in.
Slightly press on the battery and slide the battery cover lock to the left to lock
the battery.
The battery has been properly inserted if none of the battery parts is
detached.
Battery Replacement
The handset has a rechargeable battery that can be charged separately from the
handset. To charge it, use the Battery Charging Rack.
If you want to charge the handset, do it either with a Handset Charging Rack,
Desktop Charger or an USB-C cable.
With the Desktop Charger you can charge the handset.
Charging Methods
Slide the battery cover lock to the right to release the battery.
While pressing and holding the upper part of the clip B, lift the battery Cand
pull it out D.
Charging
Charging
910
Desktop Charger
Place the handset in the charging slot for handsets. Push the handset into
the charger to fully insert it. If the handset is correctly inserted, the charging
screen appears showing the battery charge level and the owner ID.
When the green check mark icon appears on the screen and the LED turns
green, the battery is fully charged.
Use the desktop charger to charge only the handset.
B
C
B
C
D
E
F
Handset Charging
Handset Disconnection
Tilt the handset towards you and then lift the handset upwards to remove it from
the charger.

© 2023 Ascom. All rights reserved. TD 93546EN / August 2023 / Ver. A
ascom © 2023 Ascom. All rights reserved. TD 93546EN / August 2023 / Ver. A
ascom
Charging
Charging
11 12
Place the handset in a charging slot. Push the handset into the charger to
fully insert it. If the handset has been correctly inserted, the charging screen
appears showing the battery charge level and the owner name.
When the green check mark icon appears on the screen and the LED turns
green, the battery is fully charged.
Handset Charging Rack
Handset Charging
Handset Disconnection
Tilt the handset towards you and then lift the handset upwards to remove it from
the charger.
Remove the battery pack from the handset and place it in the charging slot.
Secure the battery by moving the battery cover lock to the left.
If the battery has been correctly inserted, the LED turns amber to show that
the battery is charging.
When the LED turns green, the battery is fully charged.
Battery Charging Rack
Battery Charging
Battery Disconnection
Unlock the battery by moving the battery cover lock to the right.
Lift the battery and pull it out from the charger.
B
C
B
C
B
C
Open the charging port at the bottom of the handset.
Attach the USB-C cable to the charging port and connect USB power supply
to a power outlet.
When the LED turns green, the battery is fully charged.
Close the charging port to prevent dust damage.
USB-C Cable
B
C
D
E

Ascom (Sweden) AB
Grimbodalen 2
SE-417 49 Gothenburg
Sweden
Phone: [phone]
www.ascom.com
© 2023 Ascom. All rights reserved. TD 93546EN / August 2023 / Ver. A
ascom
