SONIQ G75UW40A User manual

G75UW40A
75" UHD Android TV

-1-
CONTENTS
CAUTION ............................... ........................ ........... ............ ........ 2
........................................................................................ 5
CONTROL BUTTON ....................................................................................... 6
TERMINAL .................................................................................................... 7
......... .......................................................................8
SIMPLE TROUBLESHOOTING ......................................................................... 20
............ . .. .
STAND ASSEMBLY
.......... . .... .................................................................................. 4
ACCESSORY
REMOTE CONTROLLER
.......... ... ... .......................................................................11
MENU OPERATION
.......... ........ ... ... .......................................................................10
INITIAL SETUP
.............. ... ... .......................................................................19
SPECIFICATIONS

-2-
CAUTION

-3-
CAUTION

-4 -
ACCESSORY
There are these accessories in the carton, the style will be different according to the
product model.
Note：G75UW40A
Quick installation manual
M6*20 (X6)
Tipping prevention materials

-5-
1. Please disconnect all the cable connections before installation.
2. Lay the TV face down on a flat surface, on a blanket or towel to avoid damaging the screen.
3. Please keep the TV in a horizontal position and fix the standing base with screws.
Გ
stand of TV unit, in order to avoid damaging the TV unit.
Only use matching screws provided by manufacturer in the accessory bag to install the
Wall Mounting Instruction:
This TV is equipped with mounting holes of 600 x 400mm.If the thickness of the wall mount is 2mm,
4PCS of type PM8x12mm screws are required (the length of the screws fixed in the interior of the TV
should not be longer than 14mm) Recommend to use SONIQ wall mount and install by professional
people (do not operate while the TV is on).
MA X 12 mm
STAND ASSEMBLY
PP
PP

-6-
CONTROL BUTTON
Note:
The following is only functional schematic, And the actual position and arrangement of differect
models may be different. Some models has 5 buttons, some models has 7 buttons.
Middlekey
1: Remote control sensor.
2: Indicator LED: RED STANDBY.
3: Key board
: Standby or switch on the TV.
S
-(CH/VOL)+: hort press to change channel, long press to adjust sound volume.
CH+/-: Selecting channel.
+/-: Adjusting volume.
MENU : Menu button to open the menu.External signal input selection.
:
MENU
MENU

-7-
TERMINAL
The LED TV has many multimedia functions. It can be connected to many types of equipment.
The following paragraph shows how to connect to other Audio and Video devices.
Optical input
USB
USB
SONIQ does not supply
these cables.
REAR AV Connections (SIDE)
All the terminals are (from left to right):
HDMI4(ARC), ANT IN, USBTF, EARPHONE, YPbPr Input.
USBAll the terminals are (from left to right):
RJ45, OPTICAL output, AUDIO input(L/R), VIDEO, HDMI1, HDMI2. , HDMI3.
Note: VIDEO and YPbPr share one audio channel.When HDMI port get DVI signal, the
audio signal receives from the AV Audio channel.
REAR AV Connections
HDM I
HD MI
Red (audio R)
White(audio L)
Red(Pr or Cr)
R
W
R
Blue(Pb or Cb)
Green(Y)
B
G
Yellow (video)
Y
1WAN 2 34
GB R
GB R
GB R
VIDEO EQUIPMENT
Y
Y
W R
WR
W R
W R
USB2
4
ANT IN
MINI YPbPr Micro SD
ETHERNET
DIGITAL
AUDIO OUT
(OPTICAL) USB1
1 32
VIDEO EQUIPMENT with YPbPr
Router network interface

-8-
REMOTE!CONTROLLER
ƽ
ƽ
ƽ
ƽ
ƽ
ƽ
ƽ
ƽ
ƽ
ƽ
ƽ
Open the battery cover and insert 2 !AAA! batteries.
Point the remote control at the remote sensor located
on the unit.
When there is a strong ambient light source,
the performance of the infrared remote sensor may be
degraded, causing unreliable operation.
The recommended effective distance for remote is
about 16 feet (5 meters).
When the batteries become weak and the operating
distance of the remote control is greatly reduced, you
will need to replace the batteries.
If the remote control is not going to be used for a long
period of time, remove the batteries to avoid damage
caused by battery leakage or corrosion.
Do not mix old and new batteries or ALKALINE or
standard (CARBON-ZINC) or rechargeable
(NICKEL-CADMIUM) batteries.
Always remove batteries as soon as they become weak.
Weak batteries can leak and severely damage the
remote control.
Do not dispose of batteries in fire, they may explode
or leak.
Batteries should not be exposed to excessive heat such
as sunshine, fire or the like.
CAUTION!:!
Danger!of!explosion!may!occur!if!
battery!is!incorrectly!replaced.
The remote controller cannot be used unless it is within the receivable range. Before you
use the remote control, please make sure there's no obstacle between the remote control
and the receiver.

-9 -
O O OLL
launches the built-in virtual assistant.
Google Assistant

10
INITIAL SETUP
Note :!It!is!only!available!to!the!remote!control!with
Bluetooth.

11
MENU OPERATION
Open Google Assistant or start a voice search.

MENU OPERATION
Inpu t s
TV
Composite
Component
HDMI1
HDMI2
HDMI3

13
MENU OPERATION
Channel Installation Mode
Antenna
Cable
Antenna
Cable
Channel Installation Mode

-14 -
MENU OPERATION

-15-
Inputs
HDMI 3
HDMI 3
HDMI 2
HDMI 2
HDMI 1
HDMI 1
Composite
Composite
Component
Component
ConsumerElectronic Control(CEC)
HDMI control
Allow the TV to control HDMI devices
Saturation 50
HUE 0
Sharpness 10
Gamma
Middle
Contrast 50
Color Temperature
Advanced Video
Reset to Default
MENU OPERATION

-16-
MENU OPERATION

-17-
finishing
MENU OPERATION

-18-
Note:!It!is!only!available!to!the!remote!control!
with!Bluetooth.
MENU OPERATION
