SONIQ MB206K-AU User manual

MB130724-01
Printed in China
MB206K-AU
www.soniq.com
HOTLINE
AUSTRALIA :1300765 663
NEW ZEALAND:0800 100 236
Bluetooth Speaker
MB206R-AU

Congratulations on your purchase of this quality product. Bluetooth
Speaker system will bring an exciting sonic dimension to music and
multimedia presentations. Before attempting to operate the unit,
please read this manual carefully to avoid electrical shock, personal
injury, and damage to the product.
2. Refer all serving to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as power supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus
has been exposed to moisture.
3. To reduce the risk of fire or electrical shock, do not expose this
product to rain or moisture.
4. The product must not be exposed to dripping and no object filled
with liquids such as a vase should be placed on the product.
5. Please keep the unit in a well-ventilated area.
6. No naked flame sources such as candles should be placed on
the product.
7. Disposal of this product should be in accordance with local
regulations. If you are not sure how to proceed, contact your
local authority.
8. Clean only with a slightly moist, lint-free cloth.
9. Do not install near any heat sources such as radiators, heat,
registers, stoves or other apparatus that produce heat.
Safety Instruction
Contents
The European directive 2002/96/EC on Waste Electrical and Electronic
Equipment (WEEE) electrical appliances must, requires that old household
not be disposed of in the normal unsorted municipal waste stream.
Old appliances must be collected separately in order to optimize the recovery
and recycling of the materials they contain, and reduce the impact on human
health and the environment. When you dispose of the appliance, it must be
separately collected. Consumers should contact their local authority or retailer
for information concerning the correct disposal of their old appliance.
Disposal of old electrical appliances
Trouble shooting.................................................................... 9
Caution:
1. The safety and operating instructions should be retained for
future reference. Follow all operating and use instructions.
10. Only use attachments/accessories specified by manufacturer.
11. Unplug this apparatus during lightning storms or if it’s unused
for a long period of time, such as a holiday.
12. Opening or removing covers may expose you to risk or
electrocution or other hazard and may void the warranty.
We strongly suggest you study the Safety instruction carefully.
Safety instruction.................................................................... 2
Product components............................................................... 3
Basic operation...................................................................... 4
Bluetooth connection.............................................................. 5
Audio connection.................................................................... 7
USB connection..................................................................... 8

~220-240V/50Hz
3
Production component
4
Using the Speaker
Basic Operations
2. /M: Press the /MODE button to turn the unit on.
Press and hold this button to turn to the STANDBY mode.
3. Mode selection: press /MODE repeatedly to select modes:
Bluetooth, Audio, USB. And the indicator lights use different
colors and flash status to show the mode status.
a) Every time you power the system on, it automatically enters
the first mode: Bluetooth, the indicator flashes blue quickly,
it’s inBluetooth pairing status.
b) Press /M button once to enter the second mode: Audio,
when the indicator flashes yellow still, it enters the Audio mode.
c) Press /M button twice to enter the third mode: USB, the
indicator flashes yellow slowly, it enters the USB mode.
4. : Press the PHONE button to pick up a phone call.
5. : Press the PLAY/PAUSE button to pause the music, press
again to resume playback.
6. / : Press the PREVIOUS /NEXT buttons briefly to
skip to the previous or next tracks/songs.
7. VOL+/VOL- : Press the VOL+/VOL- buttons to adjust the volume
to a comfortable level.
8. MIC: The MIC is for speaking when answering a phone call, if the
caller can not hear you, please speak closer to speaker
system microphone.
Indicator light
Speaker
USB Port
Speaker ventilation
Play/Pause
Phone button
Previous/Volume down
Standby/Mode
Microphone
Next/Volume up
Power on/off
Power supply
Audio input L/R
Front panel
Rear panel
1. Power ON/OFF: Press the POWER ON/OFF button on the rear
panel to power on or off the unit.

56
Using the Speaker
Bluetooth pairing operation
2. Turn on the Bluetooth feature on your phone/music device.
3. Turn on the system, when the indicator light flashes blue, it is in
pairing mode.
4. Do a Bluetooth search with your phone or music device. Then the
phone/music device will search for the speaker system.
5. Select Mb206 from the list of found devices.
6. Select OK or Yes to pair the two devices. For some devices, you
may need to put in the 0000 as password to pair them.
7. When they are paired successfully, you will hear a signal, and the
Bluetooth indicator will flash blue.
Note: The system will memorize the last paired device in Bluetooth.
If you turn off or power off the Bluetooth function of the device and
the unit and then turn on, the system will automatically reconnect
with your device/phone if it’s in Bluetooth search range.
Using the Speaker
Receive a call
When a call is coming while paired with a phone via Bluetooth, the
music will stop playing automatically.
You can transfer the call from the speaker system to your phone, or
you can power off the speaker if you do not want conversation
broadcast over the speaker.
Once the call has ended, it depends entirely on your mobile phone
whether the current track will return to playback or not.
Operations when there is a phone call
1. Pick up a call: Press the PHONE button to pick up a call.
2. When you are talking through the speaker, press the VOL+/VOL-
button to adjust the volume.
3. If you do not want to talk by the speaker system, press and hold
the button to disconnect Bluetooth with the phone.
4. Hang up a call: Press the PHONE button to hang up a call.
Important notes
1. The unit can only be connected and play contents from one
device at a time.
2. To connect to a different device, you must turn off the Bluetooth
function on your phone device, or un-pair from the current paired
device, then manually pair the device with the speaker system.
3. Some devices, such as an iPhone, may connect immediately in
pairing, some may take as long as 60 seconds to connect, this
is not a malfunction.
To listen to music via a wireless connection, you need to pair the
speaker system with a Bluetooth phone/music device.
1. Turn off any Bluetooth devices(phone/music device) previously
paired with your phone or music device.
You can control the playback by the phone device or buttons on the
front panel. System volume can be adjusted by pressing and holding
VOL-/VOL+ button.
Playback operation
To disconnect the device
a) Turn off the Bluetooth function on the phone/music device.
b) Press and hold the button to disconnect the Bluetooth. In this
status, you have to manually pair the devices again. You can
follow the steps 2-6 of PAIRING OPERATION.

78
USB Connection
You can enjoy music through a USB device.
1. Insert the USB device into the USB port on the rear panel.
2. Press the /M button until the indicator flashes yellow slowly to
enter USB mode.
3. The music starts playing automatically if any of the USB devices
inserted.
4. The playback is controlled by the buttons on the front panel of the
system, and system volume can be adjusted by pressing and
holding VOL+/VOL- button.
Note:
2. Depending on the amount of date and media speed, it may take
3.
4. In some cases, some files may not play even when they are in a
USB Charging
Use the USB port to charge the USB music devices. When a USB
device is inserted, the system will charge the device if the power is
low.
Using the Speaker
Audio Connection
To listen to music using a wired connection, connect your music
device to the L/R Audio Input Ports using the included audio cable.
1. Press the /M button until the indicator flashes yellow still to
enter Audio mode.
2. The playback operation is controlled by the audio device, not the
system.
3. You can only control the system volume by VOL+/VOL- buttons
on the front panel of the system.
NOTE:
1. The Audio port does not work as a headphone jack.
2. Whenever you connect the audio cable, the status indicator will
shine in yellow still.
3. The functions on the speaker will not work with the audio cables
connected.
4. With the audio connected, you can enjoy music via a connected
computer or other audio devices.
Using the Speaker
1. USB-extension cable should have a max. length of 0.5m.
This is not a malfunction.
longer for the system to read the contents of the media device.
The unit supports an USB of max. capacity 32GB.
supported format.

9
Trouble shooting
For your convenience, we list some methods to solve some common
problems you may encounter when you use the system. Contact the
nearest maintenance center if the problems occurs repeatedly.
Specifications
Output power: 5Wx 2
Power supply: AC220-240V~50Hz
Bluetooth version: CSRV2.1 + EDR
Bluetooth distance: up to 10 meters in the open air
Connections: Audio input, USB
The speaker turns off
automatically
No connections
Make sure the Bluetooth device is
properly paired.
Check the Bluetooth device is not out
of the range.
Check if the power cable is connected
properly.
Not functioning correctly Try to power off the system and restart
it again.
Problems Solutions
Waste electrical products should not be disposed of with
household waste. This equipment should be taken to your
local recycling center for safe disposal.
Specification
Trouble shooting
