LEDDOO ATHENA User manual

USER MANUAL ATHENA

Download Smart Garden App
Smart Garden App allows you to control and customize
your controls for Smart Solar Table Lamp via your smart device.
Search for the latest version on Apple App store
or Google Play
ATHENA

1
CONTENTS
02
03
07
12
IMPORTANT SAFETY INSTRUCTIONS
GETTING TO KNOW SMART SOLAR LAMP
USING YOUR SMART SOLAR LAMP
TROUBLESHOOTING
ATHENA

2
IMPORTANT SAFETY INSTRUCTIONS
GETTING TO KNOW SMART SOLAR LAMP
USING YOUR SMART SOLAR LAMP
TROUBLESHOOTING
IMPORTANT SAFETY INSTRUCTIONS
Read All Instructions Before Use And
Save For Future Reference
This is an electric lamp-not a toy!
To avoid risk of re, burns,personal injury and
electric shock,it should not be played with or placed
where small children can reach it.
SAVE THESE INSTRUCTIONS
ATHENA

3
Getting to Know Smart Solar Lamp
In The Box
Smart Solar Lamp x 1
USER MANUAL
IInnssttrruuccttiioonn MMaannuuaall xx 11
Smart Solar Lamp x 1
ATHENA

4
Specications
Model
Power Supply
Power
Input Power
Solar Panel
Body Material
IP Grade
Supported OS
Bluetooth
Voice Control
Athena
Max. 4W
1 x 3.7V 2200mAh Li-Ion Battery
5V 1A
6V Monocrystalline
ABS + PC shade
IP54
Android 5.0 or iOS 9.0 and above
4.0 and above
Alexa & Google Assistant
(only available when connect to Galaxy link light)
USER MANUAL ATHENA

5
Before first use
min.8h
1X
mm
L W H
140 140 230
H
WL
ON OFF
ATHENA

6
How to Charge
Method 1
Lift the silicone seal ring
Plug-in USB Type C Charge Cable and connect to the main
power via an adaptor
Remove the USB Type C charging Cable when Full Charged
Put Lamp in Sunlight for ≥8h
Cover the silicone seal ring
-
Switch button turns Red when Charging
Switch button turns Green when Full Charged
able when charging by cable)
USB Type-C
input, 5V 1A
Method 22
ATHENA

7
Using Your Smart Solar Lamp
Connecting with Smart Device
3. Press the Power button to turn on the lamp
(if the lamp has been paired with another device
1. Download “Smart Garden” from Google Play
or AppleApp Store and install. Register as
instructed
before, please reset the lamp, see page 10)
4. Open App, follow the on-screen instructions to
add your lamp
2. Make sure your smart device’s bluetooth, cellular
and location have turned on before pairing
.
ON OFF
3sec
ATHENA

8
Controlling with APP
Always make sure your smart device’s bluetooth have turned on to control the lamp
About
Static Color Settings
Dynamic Scene Settings
Music Rhythm
Quick Linkage
Power On/O󰀨
Information about the device or
Low Power Setting
other
Customize the color or brightness
Select the rhythm collected by mic of smart
Select a preset Scene(6 Scene available),
edit or add a new scene?
device.
The device needs to be under gateway for the
intelligent linkage configuration to take effect.
tap to turn ON/OFF the lamp
Lower the brightness when battery is low
ATHENA

9
Using Your Smart Table Lamp
Controlling without Smart Device
The lamp can also been controlled without Smart device:
Press the power button once to switch mode between:
1. Mode A: Lamp breathe twice, then turn to Photosensitive* mode
2. Mode B: Constant Lighting
If lamp has connected to a smart device before, the lamp will automatically use color&brightness setting
from last time.
ON OFF
3sec
ATHENA

10
Switch to a new device/Reset the lamp
1. Hold power button for 3 seconds, the lamp
and automatically turn to pairing mode
2. Make sure your new device’s bluetooth, cellular
3. Open App on new device, follow the on-
screen instructions to add your lamp.
and location have turned on
4. If you only want to reset the lamp, can press
the power button after 10 seconds to exit blue
3sec
ON OFF
ATHENA

11
Using Your Smart Table Lamp
Create Group with other Lamps
1. Make sure all lamps have connected to your
device and controlable before create group
3. Touch ‘Create Group’ on the menu list
2. Enter any lamp’s control panel, touch the ‘Pencil’
logo on right top side of screen
4. Add the lamp you need and touch ‘Save’ on
top right side of screen, then you can see the
group in your device list
1
2
3
ATHENA

12
Troubleshooting
Connecting
Problem
Failure
Can not turn o󰀨
the lamp
Lamp Flashing
Can not turn on
the lamp
During Charging
Reason Reason
Cannot nd Smart Lamp
on App when adding lamp
Cannot exit blue ashing
paring mode
Lamp is out of power
Lamp is charging by cable
Current adaptor’s charging
power is too low, cannot
properly charge the lamp
Wait 10 seconds then click
the button to turn o󰀨
When lamp is connected and
accidentally enter the pairing
mode, when connecting
with smart device again, the
progress is very slow and
nally lead to pairing failure.
Charge the lamp, delete
the lamp on App to save
the power if long time not
Make sure Bluetooth,
Cellular and Location have
turned on and Smart Garden
App is authorized to use
above function.
Remove the previous
lamp on App and hold
the power button to blue
ashing pairing model to
connect again function.
using the lamp
Lamp is designed for
higher Safety purpose to
not open when charging
by cable
Change to a adaptor with
higher power ( ≥5V 1A)
ATHENA

13
Instructions:
This light-set can be used outdoors.
Please keep all the relevant information for future reference!
GB
This unit contains rechargeable batteries. Switch the ON/OFF switch to “ON”. The
unit is ready to be used now. Place the solar panel in a way that it will collect as much
daylight as possible (not right under a tree, in the shade). When it starts to get dark,
a light/dark sensor will switch the unit on automatically. After 6-8 hours the lights will
automatically stop burning. Then the next day, batteries will be recharged again by
the daylight. Please note that a sunny, bright day will make the LED’s light up longer
and brighter and a dark, cloudy day will make the light shorter and dimmer.
The batteries in this set are replaceable.If you wish to replace the batteries, please
acquire at your local garden center or hardware store for rechargeable batteries that
match the technical specications of the battery(ies)used in this lighting set, for safe a
nd proper functioning.
Please note: Prior to rst use, the solar light must be charged for 1 or 2 days in
direct sunlight, with the switch turned on. This will benefit the lifetime of the bat-
tery(ies) and assures proper functioning of the lighting set.
