Sonorix A5 User manual

1
A5
Bluetooth
TTS
Car Kit

2
CONTENTS
Introduction 3
Product Functions & Features 3
What’s included in the Package 3
Description of Parts 3
Charging the Battery 4
Switching the A5 ON/OFF 4
Pairing and Connecting A5 with Bluetooth Devices 4
Using A5 for Handsfree Operation 5
Using A5 for Music 6
Using A5 for TTS (Text-To-Speech) 7
Specifications 7
Safety Instructions
zCheck the laws and regulations on the use of mobile phones and
handsfree equipments in areas you intend to use.
zAs much as possible, do not manipulate the buttons of the device
while driving.
zDo not expose the device to direct sunlight especially on the
dashboard of car in hot summer as it may cause product deformation
and even battery explosion. For safety, store the device in glove or
console box when not in use.
zWhen cleaning the device, do not use any type of abrasive pad,
scouring powder or solvents as these may render the finish dull
permanently.
zUse only designated car charger included in package to charge the
device.
zWhen using the device for the first time, charge the battery fully to
optimize battery life.
zDo not use in places like hospitals, airplanes etc. where use of
electronic devices is prohibited.
zDo not expose the device to extremes of temperature, moisture and
vibrations.
zRisk of explosion if battery is replaced by an incorrect type.

3
Introduction
sonorix A5 is a premium Bluetooth TTS car kit for handsfree operations at its best. It functions
as 'Car Handsfree Kit' or 'Portable Speaker' when linked to Bluetooth phones supporting A2DP,
Headset and Handsfree profiles.
A5 integrates TTS (Text-To–Speech) function not to mention the various useful handsfree
functions and allows you to listen to music saved in your phone. A5 will provide you with
maximum comfort and satisfaction for all of your handsfree needs whether you use the device
in car, outdoor or in office.
We hope you enjoy the unique features provided by sonorix.
Product Functions & Features
zBluetooth V2.1 compliant
zDSP for enhanced echo and noise cancellation
zSupportsA2DP,AVRCP, Headset and Handsfree profiles
zSupports TTS (Text-to-Speech) function
z4 easy to use buttons
zRobust speaker with built-in microphone
zBuilt-in Li-Polymer battery for long lasting play
zSimple charging via DC car charger
What’s included in the Package
zBluetooth TTS Car Kit A5 with Sun Visor Clip
zCar Charger
zUser Manual
Description of Parts
Speaker Volume U
p
Microphone
MFB
LED
Charging Port (USB) Sun Visor Clip
Mute
Volume Down

4
Charging the Battery
zWhen battery voltage drops below 3.4V, LED indicator will flash red every 5 seconds with
speaker tone generated every 30 seconds followed by voice prompt “Battery Low”.
zWhen battery voltage drops below 3.2V, A5 will automatically power off.
zTo charge the battery, insert the charger into cigar jack input of car and then plug the mini
USB end into USB port of A5.
zDuring charging, the LED indicator will light up red and when fully charged, the red LED
indicator will turn off.
Switching the A5 ON/OFF
zTo switch on A5, press and hold MFB for 3 seconds until LED indicator turns on blue.
Speaker tone will be generated followed by voice prompt “Power On”.
zTo switch off A5, press and hold MFB for 6 seconds until LED indicator turns on red.
Speaker tone will be generated followed by voice prompt “Power Off”.
Pairing and Connecting A5 with Bluetooth Devices
Function Action / Button Press Speaker
Tone (‘DU’) Voice
Prompt
Pairing
Mode
To put A5 in pairing mode, first make
sure it is in power off mode. Press
and hold MFB continuously until LED
indicator flashes red and blue. Single Tone
Pairing phone.
Please put your
phone in pairing
mode and enter
PIN code 0000
Pairing
Mode
Duration
Pairing mode lasts for 2 minutes and
if pairing is not established, you will
hear voice prompt. -
Paring failed,
please put your
phone in paring
mode and try
again
Pairing
Successful
From a Bluetooth phone or PC,
search for sonorix A5. When
prompted for pinkey, enter ‘0000’. If
pairing is successful, blue LED will
flash once followed by speaker tone
and voice prompt.
For some phones, you may need to
establish the Bluetooth connection
separately after pairing. Please refer
to your phone manual for details.
Single Tone Pairing
Successful

5
Using A5 for Handsfree Operation
Speaker
Tone (‘DU’) Voice
Prompt
Function Action / Button Press
If the Bluetooth link between A5 and
phone is disconnected, speaker will
generate 3 consecutive tones every
minute and if connection doesn’t
resume within 10 minutes, speaker
will generate two consecutive tones
with voice prompt “Power off”
Three
consecutive
tones Power Off
Connection
State
Reconnect
Function In idle mode, to reconnect A5 to
mobile phone, short click MFB. - Phone is ready for
use
Action / Button Press Speaker
Tone (‘DU’) Voice
Function Prompt
On an incoming call, bell will ring
from phone and car kit. If your phone
supports PhoneBook profile, caller
name will be heard. To answer call,
short click MFB.
- Caller Name
Answer Call or Number
To make a call, first dial from phone
and call will be automatically
transferred to car kit. For some
phones, you have to transfer call to
A5 by pressing ‘Vol Up’ button for 3
seconds after dial tone gets through.
Make Call - -
Redial
To redial, double click MFB. For
some phones, when MFB is double
clicked, it first displays the numbers
last called or received. In this case,
double click MFB again to redial.
Note: Some phones allow direct
redialing by double clicking MFB.
- Redialing
Voice Dial
To voice dial, make sure your phone
supports voice dialing function and
that it is activated and voice tags
have been recorded. In idle mode,
long click MFB for 3 seconds to
initiate voice dial. Follow the rest of
the instructions from phone.
Single Tone
End Call To end call first, short click MFB
during ‘Talk Mode’. If other party ends
the call first, A5 automatically returns
to handsfree standby mode. End Call

6
Using A5 for Music
Music
Function Action / Button Press Speaker
Tone (‘DU’) Voice
Prompt
Play Music To play music, manipulate the music
menu or button from phone or click
MFB once. - -
Pause
Music To pause, short click MFB. - -
Next Song To skip to next song, long click
Volume Up(<) button for 3 seconds. - -
Previous
Song
To play previous song, long click
Volume Down(>) button for 3
seconds. - -
Volume
Control Short click (<) or (>) buttons to adjust
volume. - -
Function Action / Button Press Speaker
Tone (‘DU’) Voice
Prompt
End Dialing If other party doesn’t answer call, you
can end the dialing by short clicking
MFB. End Call
Reject Call To reject incoming call, long click
MFB for 3 seconds. Single Tone Reject Call
Successful
Volume
Control Short click (<) or (>) buttons to adjust
volume. - -
Microphone
Mute
During handsfree mode, to mute the
microphone, short click Mute button.
Mute status is indicated by red LED
flash. To cancel mute function, short
click Mute button. Blue LED will flash
once and then turn off.
- -
Call Transfer During talk mode, to transfer call from
A5 to phone or vice versa, long click
Vol Up (<) button for 3 seconds. Single Tone -

7
Using A5 for TTS (Text-To-Speech)
TTS
Function Action / Button Press Speaker
Tone (‘DU’) Voice
Prompt
TTS
Language
Selection
A5 supports 5 languages, that is,
English, German, French, Spanish
and Italian. In idle state without
Bluetooth connection with phone,
long click Volume Up(<) button for 3
seconds. To select next language,
long click Volume Up(<) button for 3
seconds and so on. Once you hear
the desired language, it will be saved
if you stop manipulating the Volume
Up(<) button.
-
Select this
language
Start TTS In idle state and with TTS function
off, click and hold (<) and (>) buttons
at the same time for 3 seconds. - Voice prompt on
Close TTS In idle state and with TTS function
on, click and hold (<) and (>) buttons
at the same time for 3 seconds. -
Voice prompt off
Specifications
Standards Bluetooth Specification V2.1
RF Frequency Range 2402 ~ 2480 MHz
Profiles Supported A2DP, AVRCP, Headset, Handsfree
Transmission Power 0.25 ~ 2.5mW (Class 2)
Distance 10m (in open space)
Receiver Sensitivity -90 dBm
Audio Output > 1.5W
Transmission Power Max 4 dBm
Battery Type Lithium Polymer Battery 3.7V, 700mAH
Battery Life Standby : 250 hrs, ContinuousTalk Time : 10 hrs
Charging Time 2~ 3 hrs
Charging Voltage DC +5V
MFB (Multi-Function Button), Mute Button,
Buttons Volume Up/Down
Weight 93.5g (Including sun visor clip)
Operating Temp. & Humidity -10 ~ +50°C, Rel. Humidity 0 ~ 95%
Certification BQB, FCC, CE, MIC

8
Product Warranty
* OpenBrain Technologies warrants this product
ainst all defects in material and
orkmanship for a period of one year from
he date of purchase by end user. The
ions for warranty are as follows:
* The warranty is valid only if the original
eceipt issued to the original purchaser by the
is presented with the product to be
epaired or replaced.
* he warranty is void if the serial number, date
f purchase and product label had been
moved.
* The warranty does not cover any failure or
age of the product due to normal wear
ear, physical abuse, improper
ion, misuse, modification or repairs by
horized third parties.
* OpenBrain Technologies does not assume
esponsibility for any loss or damage incurred
ing shipment and as a result of force
jeure.
* OpenBrain Technologies is not liable for any
consequential damages arising
om the use or misuse of the product.
* All warranty claims are limited to repair or
eplacement of the defective product at the
etion of OpenBrain Technologies.
* OpenBrain Technologies repairs or replaces
he product, the repaired or replaced product
arranted for the remaining time of
he original warranty period. Repair or
eplacement may involve the use of
unctionally equivalent reconditioned units.
art or product becomes the
operty of OpenBrain Technologies.
* Consumable components, such as batteries,
e not included in the warranty obligation.
Disclaimer Notice
The manufacturer shall not be liable for errors
contained herein or for incidental or
consequential damages in connection with the
furnishing, performance or use of this
material. This document contains proprietary
information, which is protected by
international patent applications and
copyright. All rights reserved. No part of this
document may be copied, reproduced or
translated without prior written consent of the
manufacturer. The manufacturer reserves the
right to revise this publication and to make
changes from time to time in the contents
hereof without obligation to notify any person
of such revisions or changes. The
manufacturer also reserves the right to
change the specifications without notice.
ag
w
t
condit
r
dealer
r
T
o
re
dam
and t
installat
unaut European CE notice to users and
product statements
This product is CE marked according to the
provisions of the R & TTE Directive (99/5/EC).
Hereby, OPENBRAIN Technologies Co., Ltd,
declares that this product is in compliance
with the essential requirements and other
relevant provisions of Directive 1999/5/EC.
For further information, please contact
http://www.openbrain.co.kr
r
dur
ma
incidental or
fr
r
sole discr
If FCC notice to users and product
statements
THIS DEVICE COMPLIES WITH PART 15 OF
THE FCC RULES. Operation is subject to the
following two conditions; (1) this device may
not cause harmful interference, and (2) this
device must accept any interference received,
including interference that may cause
undesired operation. CAUTION: Changes or
modifications not expressly approved by the
party responsible for compliance could void
the user’s authority to operate the equipment.
t
shall be w
t
r
f
Replaced p
pr
ar
WEEE Directive 2002/96/EC Art. 11(2)
The use of the symbol indicates that this product may not be treated as
household waste. By ensuring this product is disposed of correctly, you will help
prevent potential negative consequences for the environment and human health,
which could otherwise be caused by inappropriate waste handling of this product.
For more detailed information about recycling of this product, please contact your
local city office, your household waste disposal service or the shop where you
purchased the product.
