Axxess AXPIO-JT1 User manual

AXPIO-JT1
INSTALLATION INSTRUCTIONS
AxxessInterfaces.com © COPYRIGHT 2021 METRA ELECTRONICS CORPORATION REV. 6/18/21 INSTAXPIO-JT1
Product Info
TOOLS & INSTALLATION ACCESSORIES REQUIRED
• Panel removal tool • Phillips screwdriver
TABLE OF CONTENTS
Dash Disassembly ..................................................2
Kit Assembly
- Radio provision ...................................................2
- Pioneer Modular DDIN radio provision ..............3
Axxess Interface Installation .................................4
Jeep Gladiator 2020-Up
Note: This kit will function in both Single-Zone and Dual-Zone vehicles.
Single-Zone vehicles will only get status feedback of the HVAC functions ,
while Dual-Zone vehicles can also be controlled through the radio screen .
All HVAC functions will be retained. Compass is only retained on vehicles
equipped with the UConnect 3 (5" touchscreen). The External Speaker is
only required in vehicles with safety group features .
Attention! Designed for Pioneer’s DMH-W4600NEX/WC4660NEX.
Pioneer 9" DMH-WC6600NEX will require minor custom mounting
along with the Metra 109-UN02 (sold separately)
KIT COMPONENTS
• A) Radio bezel • B) Shallow mount brackets • C) Modular radio brackets • D) Panel clips (4)
A B C D
WIRING & ANTENNA CONNECTIONS
Wiring Harness: Included with kit
Antenna Adapter: 40-EU10 • 40-GPS-PIO (included)

2
DASH DISASSEMBLY KIT ASSEMBLY
1. Unclip and remove the panel below the
steering column. (Figure A)
2. Unclip the climate control panel and set
aside. (Figure B)
3. Remove (2) Phillips screws securing
the radio trim panel, then unclip and
remove the panel. (Figure C)
4. Remove (4) Phillips screws securing the
radio, then unplug and remove.
(Figure A)
(Figure B)
(Figure C)
(Figure A)
(Figure B)
Radio provision
1. Secure the shallow radio brackets to
the radio using screws supplied with the
radio. (Figure A)
2. Locate the factory wiring harness and
antenna connector in the dash and
complete all necessary connections to
the radio. Metra recommends using
the proper mating adapter from Metra
and/or Axxess. Test the radio for proper
operation.
3. Place the radio into the dash, then
secure using the factory screws.
4. Attach (4) panel clips provided onto the
radio bezel, then attach the bezel over
the radio. (Figure B)
5. Reassemble the dash in reverse
order of disassembly to complete the
installation.

3
REV. 6/18/21 INSTAXPIO-JT1
KIT ASSEMBLY
(Figure C)
(Figure A)
(Figure B)
Pioneer Modular DDIN radio provision
1. Secure the radio display to the modular
radio brackets using (6) screws supplied
with the radio. (Figure A)
Note: Reference the installation manual
provided with the radio for which
hardware to use. The display screen and
radio chassis use two different types of
screws.
2. Secure the radio chassis to the radio
display/bracket assembly using (4)
screws supplied with the radio. (Figure B)
3. Route the RGB extension cable from the
radio chassis to the display screen, then
connect it to the display screen.
4. Locate the factory wiring harness and
antenna connector in the dash and
complete all necessary connections to
the radio. Metra recommends using
the proper mating adapter from Metra
and/or Axxess. Test the radio for proper
operation.
5. Place the radio display into the dash,
then secure using the factory screws.
6. Attach (4) panel clips provided onto the
radio bezel, then attach the bezel over
the radio. (Figure C)
7. Reassemble the dash in reverse order of
disassembly to complete the installation .

4
AXXESS INTERFACE INSTALLATION
• Provides accessory power (12-volt 10-amp)
• Retains R.A.P. (retained accessory power)
• Provides NAV outputs (parking brake, reverse, speed sense)
• Allows visual of HVAC and gauges on Pioneer screen
• Allows adjustment of HVAC functions through Pioneer screen
• Retains audio controls on the steering wheel
• Allows for auto stop/start override (if equipped)
• Works in both Single and Dual-zone vehicles
• Retains safety chimes
• Designed for amplified or non-amplified vehicles
• Micro-B USB updatable
• Allows the retention and adjustment of the OE Personalization Settings
• Plug-n-Play installation
• Designed for Pioneer’s DMH-W4600NEX/WC4660NEX
• Painted scratch resistant matte black to match the OE finish
• Includes radio antenna adapter & antenna adapter for GPS
• Includes water resistant -IP68 rated direct OE camera replacement
• Includes a 3' USB/AUX/HDMI® replacement cable with panel
FEATURES
• Crimping tool and connectors, or solder gun, solder, and heat shrink
• Tape • Wire cutter • Zip-ties
TOOLS REQUIRED
• LD-CH5-PIO • LD-CHRYHAZ2T • LD-2PIN-CAN
• Radio interface • Jeep Camera (JP-JTKT) • PR04AVIC-PIO
• External Speaker • AXUSB-RAM1
AXUSB-RAM1 Installation .............................................................................................................. 5
Camera Removal ....................................................................................................................... 6-8
Assembly .......................................................................................................................................9
Wiring ...........................................................................................................................................10
USB Replacement & Camera Installation ....................................................................................11
Interface Installation ...................................................................................................................12
Dash Assembly ............................................................................................................................. 13
Radio Operation ...................................................................................................................... 14-15
Specifications ...............................................................................................................................16
COMPONENTS
TABLE OF CONTENTS

5
REV. 6/18/21 INSTAXPIO-JT1
AXUSB-RAM1 INSTALLATION
1. Remove the screw located above the window switches. Then with a panel
tool, pop off the entire instrument panel trim from its retaining clips.
(Figure A & B)
2. Disconnect the wiring harness connector, then unclip and remove the
Media Hub from the backside of the panel. (Figure C)
3. Snap in the AXUSB-RAM1 and route the harness to the radio location.
Note: A Micro HDMI to HDMI cable is necessary if HDMI input is desired.
(sold separately)
Attention! USB Type-C adapter may be necessary. This is supplied with the
Pioneer Radio.
Note: Refer to the Pioneer Radio installation manual.
4. Once the AXUSB-RAM1 is installed, this portion of the dash can be
reassembled.
(Figure A)
(Figure C)
(Figure B)

6
1. Remove the eight 5/32 bit screws from the
tailgate panel. (Figure A)
2. Remove the panel and safely set aside.
3. Remove the two 5/32 bit screws from the
smaller blue panel. (Figure B)
4. Remove the panel and safely set aside.
NOTE: Some trucks that do not have a bed cover
may look different. Make sure to safely remove
all screws and panels and set aside before
lifting up the tailgate.
CAMERA REMOVAL
(Figure A)
(Figure B)

7
REV. 6/18/21 INSTAXPIO-JT1
Unplug the pink camera cable and set aside. For
this install the pink cable will not be used so iBEAM
suggests ziptieing the cable back so there is no
rattle in the tailgate.
Remove the retention clip around the camera. Slide
in the direction of the arrow and set aside, this
will be needed this later when installing the new
camera.
There is a clip below the area highlighted in Figure
B. Press that clip in and slide the camera out
towards the front side of the tailgate.
CAMERA REMOVAL (CONT)
(Figure A) (Figure B)

8
1. . This iBEAM kit covers the two options equipped
on the Jeep Gladiator.
• Figure A reverse or backup camera, The
bracket with the number 1 is for the backup
camera version.
• Figure B surround view or 360, The bracket
with the number 2 is for the surround view
version.
NOTE: This kit does not RETAIN the 360 system. It
replaces the backup camera of the system. The 360
or surround view system will be lost.
2. Both types of cameras are removed the same
way. Remove the three torx T6H screws from the
back of the camera housing.
3. . Remove the bracket and camera. Retain if the
the system will need to go back to factory.
CAMERA REMOVAL (CONT.)
(Figure A) (Figure B)

9
REV. 6/18/21 INSTAXPIO-JT1
A S S E M B LY
(Figure A) (Figure B)
1. Place the wire from the aftermarket camera
through the hole between the numbers and
the arrow.
2. Keep the orienitation correct as to not mount
the camera incorrectly. The top of the factory
housing is the longer part of the housing.
The top of the camera is indicated by the QC
sticker and the top of the bracket is indicated
by the arrow pointing towards the top of the
factory housing.
3. Place the factory housing over the camera.
4. Replace the 3 factory screws. The positions
differ depending on the factory backup
camera (Figure A) or surround view or 360
camera (Figure B).

10
WIRING
1. Re-assemble the camera into the tailgate.
2. Run the wire, following the old camera wiring from
the tailgate to the truck bed. (Figure A)
3. Once inside the vehicle, you can power the camera
via a reverse trigger from the taillight. Connect
the RED wire to the reverse trigger. Connect the
BLACK wire to a chassis ground. The RED wire is also
located at the opposite end of the harness with the
YELLOW RCA if the user wants the camera powered
with an accessory circuit.
4. Run the wire down the length of the vehicle care-
fully. Make sure not to run near any objects that can
cause extreme heat or catch the wire. (Figure B)
5. Connect the YELLOW RCA to the aftermarket radio.
There is a Red wire with the RCA, this can be used
in two ways. This wire can bring a reverse trigger to
the front of the vehicle if the camera is powered in
the rear. This can also be used to power the camera
in the front if the camera is desired to be powered
via an accessory circuit.
Figure A Figure B

11
REV. 6/18/21 INSTAXPIO-JT1
• If power is required for the camera, the connection must be hardwired.
• This can be done at the radio using the Red wire for power, and the Black wire for ground.
• The Black Ground wire from the camera will have to be extended and routed to the front
with the video RCA.
Note: Remove the glovebox to route the camera RCA to the dash.
If equipped with TPMS, and you wish to add the visual to the Pioneer Radio screen:
• Route the LD-CAN3T harness behind the glovebox and connect to the junction pictured
below. Any available spot can be used. If no spots are available, unplug one of the 2-pin
connectors and connect to the other end of the LD-CAN3T. This will connect to the LD-CH5-
PIO 2-Pin labeled “CAN 3”.
If you do NOT have the LD-CAN3T:
• Connect Brown/White from the LD-2PIN-CAN to one of the 2-pins Yellow wire, then Brown
to the other wire in the 2-Pin. This will connect to the LD-CH5-PIO 2-Pin labeled “CAN 3”.
Brown/White = CAN LOW Brown = CAN High
Note: The glovebox must be removed to access this connection. Refer to photo for connection point.
USB REPLACEMENT & CAMERA INSTALLATION

12
INTERFACE INSTALLATION
If the vehicle is equipped with rear parking sensors that you wish to retain:
• Install the provided speaker in the dash prior to assembling the radio components.
• Make sure this is mounted in a location suitable for the driver to hear.*
* Audio level for the speaker can be changed via the radio, once installed.
From the LD-CH5-PIO:
The following connections should be made just prior to final installation to test all functions of
the new radio.
• Connect the 16-pin connector into the Radio Interface.
• Connect the 22-pin connector into the Radio Interface.
• Connect the External Speaker to the 2-Pin labeled “EXT SPKR”.
• Connect the 18-pin plug into the PR04AVIC-PIO Radio Harness.
• Connect the small 4-pin straight connector directly into the radio. (Metra Adapter Input)
• Connect the plug labeled “AUX IN” to the AUX-Input on the radio.
• Disregard the Red/White RCA pair, it will not be used in this application.
Connect the RCA pair from the AXUSB-RAM1 instead.
• Disregard the Yellow RCA, It will not be used in this application. (See Camera Installation).
• Connect the Yellow Male RCA from the JP-JTKT Installation to the Rear Camera input.
• Connect the 40-GPS-PIO To the radio and to the GPS antenna in the vehicle.
This can be Blue, or Yellow in color.
Note: Alternatively, the GPS antenna supplied with the Pioneer radio can be used.
• Connect the 40-EU10 to the radio and to the FM/AM antenna in the vehicle. White in color.
• Connect and route the microphone provided with the Pioneer radio to a suitable location.
• Connect the 2-Pin labeled “CAN 2” to the LD-CHRYHAZ2T.
• Connect the 2-Pin labeled “CAN 3” to the LD-2PIN-CAN, or LD-CAN3T for TPMS.
• Connect the LD-CHRYHAZ2T and the Start/Stop button harness into the climate control panel.
• Connect the LD-CHRYHAZ2T into the harness previously removed from this panel.
• Connect the LD-CH5-PIO into the vehicles harness, then test the operation of the kit.
Note: Refer to Pioneer Installation manual supplied with radio for additional details.
• Select the Vehicle Type in the “Car Features” menu. (see radio screenshots).
Important! Verify the backup camera installation, HVAC status & control, Steering wheel audio
controls and External Speaker output prior to completing dash assembly.

13
REV. 6/18/21 INSTAXPIO-JT1
DASH ASSEMBLY
Once all functions are verified:
• Mount the radio into place using the (4) screws removed from dash disassembly.
• Attached the supplied radio faceplate and secure it with two screws below the radio.
• Snap the climate panel into the dash the same way it was removed.

14
RADIO OPERATION
Car Features – The source for accessing all vehicle information and options.Vehicle Selection – Allows you to select the vehicle the radio is being installed in.
• Vehicle type must be selected to activate menu & HVAC functions, as well as steering wheel
controls. Press Make to change the vehicle type. Then press Confirm. The radio will then reset
and lock in the selected vehicle.

15
REV. 6/18/21 INSTAXPIO-JT1
RADIO OPERATION (CONT)
HVAC Operation – HVAC Status and Control Screen. Customizations Menu – Allows full control of vehicle personalization options.
• Access this menu by selecting the gear icon on the previous screenshot.
Vehicle Info Screen – Displays various information of the vehicle (TPMS, Park Position, Lights). About Screen – Feedback screen for interface software information.

KNOWLEDGE IS POWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.edu or call
386-672-5771 for more information and take steps
toward a better tomorrow.
®
Metra recommends MECP
certified technicians
AxxessInterfaces.com © COPYRIGHT 2021 METRA ELECTRONICS CORPORATION REV. 6/18/21 INSTAXPIO-JT1
INSTALLATION INSTRUCTIONS
AXPIO-JT1
Having difficulties? We’re here to help.
Contact our Tech Support line at:
386-257-1187
Or via email at:
[e-mail]
Tech Support Hours (Eastern Standard Time)
Monday - Friday: 9:00 AM - 7:00 PM
Saturday: 10:00 AM - 7:00 PM
Sunday: 10:00 AM - 4:00 PM
• RCA output for aftermarket radios or monitors
• Can be viewed while driving with compatible monitor
• ABS plastic housing to mount camera
• (4) Stainless steel screws provided for mounting
• Direct OE replacement
• Resolution: 550 TV Lines
• Selectable parking lines
• Viewing angle - 160 degrees
• Water resistant - IP68
Kit Includes
• 1 camera and extension cable
• Front and back - ABS camera housing
• 4 stainless steel screws
• Instruction booklet
6.4 FT26 FT
3.9 FT
RED wir
e at the RCA is the same wire as in the
back of the extension harness
RED wire = Camera power
BLACK wire = Chassis ground
SPECIFICATIONS
