Porsche Mobile Charger Release note

Porsche Mobile Charger
Porsche Mobile Charger
Good to know – Driver’s Manual

06/2023
Porsche, the Porsche Crest, Panamera, Cayenne and
Taycan are registered trademarks of Dr. Ing. h.c. F.
Porsche AG.
Printed in Germany.
Reprinting – even of excerpts – or duplication of any
kind are only permissible with the written authorisa-
tion of Dr. Ing. h.c. F. Porsche AG.
© Dr. Ing. h.c. F. Porsche AG
Porscheplatz 1
70435 Stuttgart
Germany
Driver’s Manual
Always keep this operating manual and hand it over
to the new owner if you sell your charger.
Due to dierent requirements in various countries,
the information in the thumb index tabs of this man-
ual will be dierent. To ensure that you are reading
the thumb index tab that applies to your country,
compare the article number of the charger shown in
the “Technical Data” section with the article number
on the identication plate on the charger.
Suggestions
Do you have any questions, suggestions or ideas re-
garding your vehicle or this manual?
Please write to us:
Dr. Ing. h.c. F. Porsche AG
Vertrieb Customer Relations
Porscheplatz 1
70435 Stuttgart
Germany
Equipment
Because our vehicles undergo continuous develop-
ment, equipment and specications may not be as
illustrated or described by Porsche in this manual.
Items of equipment are not always according to the
standard scope of delivery or country-specic vehicle
equipment
For more information on retrot equipment, please
contact a qualied specialist workshop. Porsche rec-
ommends a Porsche partner as they have trained
workshop personnel and the necessary parts and
tools.
Because of dierent legal requirements in individual
countries, the equipment in your vehicle may vary
from what is described in this manual. If your Porsche
is tted with any equipment not described in this
manual, your qualied specialist workshop will be
glad to provide information on the correct operation
and care of the items concerned.

1
DANGER
WARNING
CAUTION
NOTICE
About this Owner's Manual
Warning notices and symbols
Various types of Warning notices and symbols are
used in this Driver's Manual.
Serious injury or death
Failure to observe Warning notices in the "Danger"
category will result in serious injury or death.
Possible serious injury or
death
Failure to observe Warning notices in the "Warning"
category can result in serious injury or death.
Possible moderate or mi-
nor injury
Failure to observe Warning notices in the "Caution"
category can result in moderate or minor injuries.
Possible vehicle damage
Failure to observe Warning notices in the "Notice"
category can result in damage to the vehicle.
Information
Additional information is indicated by “Information”.
bConditions that must be met in order to use a
function.
eInstruction that you must follow.
1. If an instruction comprises several steps, these
are numbered.
2. Instructions that you must follow on the cen-
tral display.
gNotice on where you can nd further important
information on a topic.
Further Information
You can access the full Driver's Manual at the follow-
ing web address:
https://tinyurl.com/porsche-e-help

2
Table of contents
To the Driver's Manual
Key to pictograms. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Security
Safety instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Intended use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Scope of delivery. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Overview
Charger control unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Requirements and conditions
Selecting the installation location. . . . . . . . . . . . . . . . . 6
Requiredtools. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Installing
Installing the wall mount. . . . . . . . . . . . . . . . . . . . . . . . . 6
Set up
Vehicle charging cables and supply cables. . . . . . . . . 8
Operating
Operating instructions. . . . . . . . . . . . . . . . . . . . . . . . . . 12
Charge. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Control panel status indicators and error mes-
sages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Transport. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Cleaning and maintenance. . . . . . . . . . . . . . . . . . . . . . . 20
Disposal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Technical Data
Identication plate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Production information. . . . . . . . . . . . . . . . . . . . . . . . . 24
Importers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Index. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

To the Driver's Manual
3
To the Driver's Manual
Key to pictograms
Depending on the country, various pictograms may
be attached to the charger.
Operate the charger within a temperature
range from -30°C to +50°C.
The charger should not be operated at alti-
tudes of more than 4,000 m above sea level.
The charger is equipped with a non-
switched protective conductor.
The charger is equipped with a switched
protective conductor.
Dispose of the charger in compliance with
all applicable disposal regulations.
Do not use extension cables or cable reels.
Do not use (travel) adapters.
Do not use multiple sockets.
Do not use chargers with damaged electron-
ics or connecting cables.
Risk of electric shock due to uninten-
ded use.
Observe the operating instructions
provided, particularly the warnings
and safety instructions.
The surface of the charger can be-
come very hot.
Do not operate the charger in non-earthed
mains supply systems (e.g. IT networks).
Operate the charger only in earthed mains
supply systems.
Indicates the type 1 plug with a voltage
range ≤ 250 VAC.
Indicates the type 2 plug with a voltage
range ≤ 480 VAC.

4
Security
1. Time of printing. Further information is available from your Porsche partner.
DANGER
DANGER DANGER
WARNING
Security
Safety instructions
Electric shock, short cir-
cuit, re, explosion
Use of a damaged or faulty charging cable or elec-
trical socket, improper use of the charger or failure
to observe the safety instructions can cause short
circuits, electric shocks, explosions, re or burns.
eDo not use a damaged and/or soiled charger.
Check the cable and plug connection for damage
and soiling before use.
eOnly connect the charger to properly installed
and undamaged electrical sockets and fault-free
electrical installations.
eDo not use extension cables, cable reels, multiple
sockets or (travel) adapters.
eDisconnect the charger from the mains supply
during thunderstorms.
eDo not modify or repair any of the electrical com-
ponents.
eNever immerse the charger or plugs in water or
spray them directly with water (e.g. high-pres-
sure cleaning equipment or garden hoses).
eOnly clean the charger when the control unit has
been fully disconnected from the mains supply
and from the vehicle. Use a dry cloth for clean-
ing.
Electric shock, re
Incorrectly installed electrical sockets can cause
electric shock or re when the high-voltage battery
is charged using the vehicle charge port.
eInstallation and initial operation of the electrical
socket for the charger may only be carried out by
a qualied, electrically skilled person. The quali-
ed electrician is fully responsible for compliance
with the relevant standards and regulations.
eThe cross-section of the power cable for the
electrical socket must be dened in accordance
with the wire length and the locally applicable
regulations and standards.
eThe electrical socket used for charging must be
connected to a separately fused electric circuit
that complies with local laws and standards.
eThe charger is intended for use in private and
semi-public areas, e.g. private properties or
company car parks. In some countries, e.g. in
Italy and New Zealand1, mode 2 charging is pro-
hibited in public areas.
Further information is available from your Por-
sche partner and from your local power supplier.
eUnauthorised persons (e.g. playing children)
must not have access to the charger and the
vehicle during unsupervised charging.
ePlease read the safety instructions in the instal-
lation manual and the Driver’s Manual.
Electric shock, re
Incorrect handling of the plug contacts can lead to
electric shock or re.
eDo not touch the contacts on the vehicle charge
port and charger.
eDo not insert any objects into the vehicle charge
port or charger.
eProtect electrical sockets and plug connections
against moisture, water and other liquids.
Flammable or explosive
vapours
Components of the charger can cause sparks and
ignite ammable or explosive vapours.
eTo reduce the risk of explosion – particularly
in garages – make sure that the control unit is
located at least 50 cm above the oor during
charging.
eDo not install the charger in potentially explosive
atmospheres.
Observe the following instructions and recommenda-
tions in order to guarantee uninterrupted charging
with the charger:
–Before installation, check that the necessary
power for charging a vehicle can be continuously
provided with the currently available domestic
installation. If necessary, protect the domestic
installation with an energy management system.
–The charger should preferably be operated in
earthed mains supply systems. The protective
conductor lead must be properly installed.

Scope of delivery
5
–When installing a new electrical socket, select an
industrial electrical outlet with the highest pos-
sible power available (adapted to the domestic
electric installation) and have it put into opera-
tion by a qualied electrician.
–Where technically possible and legally permissi-
ble, the electric installation must be dimensioned
in such a way that the maximum nominal power
of the electrical socket used is available for
charging the vehicle.
–In order to make full use of the charger and to
ensure fast vehicle charging, use either NEMA
electrical sockets with the highest possible cur-
rent rating appropriate for the power plug or in-
dustrial electrical outlets to IEC 60309.
–When charging the high-voltage battery via the
household/industrial electrical outlet, the elec-
trical installation may be loaded to its maximum
capacity.
Porsche recommends that you have electrical
installations used for charging checked regularly
by a qualied electrician. Ask a qualied electri-
cian which inspection intervals are appropriate
for your installation.
–To prevent overheating of the electrical installa-
tion, the charging current for household cables
is automatically limited on delivery. Have a quali-
ed electrician bring the charger into operation
and set the charging current limit as required for
the domestic installation.
gRefer to chapter "Charging current limiting" on
page 13.
Intended use
Charger with integrated control and protection for
mode 2 charging, for charging vehicles with high-
voltage batteries that meet the generally applicable
standards and directives for electric vehicles.
eAlways use the appropriate device version for the
local mains supply.
gRefer to chapter "Technical Data" on page 22.
The charger may only be used as a combination of
supply cable, control panel and vehicle cable.
Scope of delivery
Fig.1: Overview of Charger:
ASupply cables (detachable from control panel)
BSupply cable connection plug on the control panel
CPower plug for connecting to the mains supply
DVehicle plug (connector plug for the vehicle)
EVehicle cable (permanently installed on control
panel)
FControl panel
Overview
Charger control unit
Fig.2: Control unit
AON/OFF button with indicator light and addi-
tional charging current limiting function
BPower supply/domestic connection indicator
light
Vehicle indicator light
Control unit indicator light
CReset button with indicator light
The operating state of the control unit and charging
current limiting can be set using the ON/OFF button
.
The control unit can be reset using the reset button
if residual current is detected.

6
Requirements and conditions
DANGER
The indicator lights A– C(Fig.2) indicate the op-
erating state of the control unit, whether charging
current limiting is set and possible faults by means of
dierent colours, illumination and ashing.
gRefer to chapter "Control panel status indicators
and error messages" on page 15.
Requirements and conditions
Selecting the installation location
Electric shock, re
Improper use of the charger or non-compliance with
the safety instructions may result in short circuits,
electric shocks, explosions, re or burns.
eDo not install the basic wall mount in potentially
explosive atmospheres.
eTo reduce the risk of explosion - particularly in
garages - make sure that the control unit is
located at least 50 cm above the oor during
charging.
eObserve the locally applicable electrical installa-
tion regulations, re protection measures, acci-
dent prevention regulations and escape routes.
The basic wall mount is designed for indoor and out-
door installation.
The following criteria must be considered when se-
lecting a suitable installation location:
–Install the electrical socket and basic wall mount
preferably in a covered area protected against
direct sunlight and rain (e.g. in a garage).
–Do not spray the basic wall mount directly with
water (e.g. high-pressure cleaning equipment or
garden hoses)
–Do not install the basic wall mount under sus-
pended or hanging objects.
–Do not install the basic wall mount in stables,
livestock buildings or locations where ammonia
gases occur.
–Install the basic wall mount on a smooth surface.
–In order to ensure secure fastening, check the
condition of the wall before installing.
–Install the basic wall mount so that it is not near
pathways and the charging cables do not cross
any pathways.
–Install the basic wall mount so that the distance
between the plug and the socket does not ex-
ceed the length of the available supply cable.
–Install the electrical socket as close as possible
to the preferred vehicle parking position. Take
the orientation of the vehicle into account.
–The distance of the electrical socket from the
oor and ceiling should be selected in compli-
ance with national regulations and standards so
that comfortable use is ensured.
gRefer to chapter "Safety instructions" on page 4.
Requiredtools
–Level
–Power drill or power hammer
–Screwdriver
Installing
Installing the wall mount
Installing the basic wall mount
Fig.3: Drilling dimensions
1. Mark the drill holes on the wall.
2. Drill the mounting holes and insert dowels.
3. Press the standard wall mount 2(Fig.3) into the
cable guide 1(Fig.3) from the front.
4. Screw the basic wall mount onto the wall.
Information
Attach the wall mount at a height of at least 1 m.

Installing
7
Installing the connector fastener
Fig.4: Distance between wall mount and connector fastener
When installing the connector fastener, ensure a dis-
tance of 200mm from the basic wall mount.
Fig.5: Drilling dimensions
1. Remove the connector fastener 1(Fig.5) from
the cover 2(Fig.5).
2. Mark the drill holes on the wall.
3. Drill the mounting holes and insert wall plugs.
4. Screw the connector fastener 1(Fig.5) onto the
wall.
5. Fit the cover 2(Fig.5) onto the connector fas-
tener 1(Fig.5) from below and push up.
Attaching the control unit to the wall
mount
Fig.6: Attaching the control unit
1. Route the vehicle cable through the lower open-
ing of the basic wall mount, place the bottom of
the control unit on the locking tab and push back
to engage.
2. Guide the supply cable through the upper open-
ing in the basic wall mount and lock the circlip by
pushing it to the le.
3. Insert the vehicle plug in the connector fastener.

8
Set up
NOTICE
Set up
Vehicle charging cables and supply
cables
Information on vehicle charging cables
and plugs
Dierent vehicle charge ports Aand vehicle plugs B
are available depending on the vehicle equipment.
IEC 62196-2/
SAE-J1772-2009
Type 1
IEC 62196-2
Type 2
GB/T 20234.2
Type GB
Selecting a Supply cable
For regular charging with optimum charging speed,
use only the supply cables listed below. The maxi-
mum achievable charging power is up to 11 kW (de-
pending on the power supply/domestic connection
and the on-board charger).
gRefer to chapter "Technical Data" on page 22.
Use only supply cables approved for the country you
are in. The following supply cables are approved for
specic countries and are dened in the tables below.
Country Supply cables
for industrial
electrical out-
lets
Supply cables
for household
electrical out-
lets
Russia, Uk-
raine
5, 6, 7, 8 C
Abu Dhabi,
Israel, Sin-
gapore
5, 6, 7, 8 Charging not
permitted at
household elec-
trical outlets
Argentina 5, 6, 7, 8 C
Bolivia, Par-
aguay, Uru-
guay, St.
Marteen, St.
Martin
5, 6, 7, 8 B
Chile 5, 6, 7, 8 D
Peru 5, 6, 7, 8 A
Country-specic approval of supply cables (exam-
ples)

Set up
9
1. Time of printing. Further information is available from your Porsche partner.
2. for Mexico: 12A
Supply cables for industrial electrical out-
lets
1
NEMA 14-30
2
NEMA 14-50
3
NEMA 6-30
4
NEMA 6-50
5
IEC 60309-2
CEE 230 V/16 A 6 h
6
IEC 60309-2
CEE 230 V/32 A 6 h
7
IEC 60309-2
CEE 400 V/16 A 6 h
8
IEC 60309-2
CEE 400 V/32 A 6 h
9
WCZ8 20 A
Supply cables for household electrical out-
lets
If no industrial electrical outlet is available, the supply
cables listed below can also be used for charging
with reduced charging speed.
eIn some countries, e.g. in Abu Dhabi, Israel and
Singapore1, to charge from household electrical
outlets is prohibited. Further information is avail-
able from your Porsche partner.
A
NEMA 5-15
Type B 2
B
WCZ8 15 A
C
CEE 7/5; CEE 7/7
Type E/type F
(Safety plug)
D
BS 1363
Type G

10
Set up
DANGER
DANGER
E
M09A-15
Type I
F
SEV 1011
Type J
G
DS 60884-2-D1
Type K
H
CEI 23-16-VII
Type L 16 A
(5 mm)
I
IA6A3 (BS 546)
Type M
NEMA 6-50 / NEMA 14-50 (additional in-
formation)
Information
Scope
This usage recommendation applies only to regions
with NEMA 6-50 / NEMA 14-50 standard.
Charging your vehicle may result in high electric cur-
rents. For safety reasons, it is absolutely essential
that you use only components approved for this and
that the entire charging equipment is installed cor-
rectly.
General safety instructions
Electric shock and re!
Incorrect use of the charging equipment and failure
to observe the installation and safety instructions can
lead to a short circuit, electric shock, explosion, re or
burns.
ePay attention to the installation instructions in
the charging equipment manual.
ePay particular attention to all safety and warning
notices there.
eHave the installation carried out by a person with
the necessary electrical training and specialist
knowledge.
eAlso observe the national regulations for carrying
out electrical installations.
Power socket requirements
Unsuitable mains sockets
An unsuitable mains socket can cause a short circuit,
electric shock, explosion, re, or burns.
eOnly use only a type of mains socket that is
suitable for this installation (see Suitable types
of mains sockets/power plugs).
eOnly use mains sockets that meet the require-
ments for the quality of contact surfaces and
fastening (see Requirements for the quality of
mains sockets).
eAvoid direct contact between the terminal
screws and the wire. Preferably, use wire end
ferrules.
eAvoid jamming the cable on the insulation.
Suitable mains socket/power plug types
NEMA 6-50
Socket/connector
NEMA 14-50
Socket/connector

Set up
11
1. Time of printing. Further information is available from your Porsche partner.
DANGER
DANGER
DANGER
Mains sockets quality requirements
AContact surface only half plug contact height
BContact surface over the entire plug-in contact
height
CSmall contact surface between clamping screw
and strand.
DBroad surface contact area between between
clamping plate and strand
Line installation requirements
Unsuitable power cable
The use of unsuitable power cables or excessive
electrical currents can cause a short circuit, electric
shock, explosion, re or burns.
eThe cable must have a 50-amp fuse.
eOnly use copper cables with a minimum cross-
section of 8 AWG, or preferably 6 AWG.
Outdoor installation requirements
Direct contact with rain
If the charging equipment is used outdoors, direct
contact with rain can cause a short circuit, electric
shock, explosion, re or burns.
ePrevent the charging equipment from coming
into direct contact with rain.
eUse a NEMA 3R rainproof enclosure.
Changing supply cables
Electric shock
Risk of serious or fatal injury from electric shock.
eBefore changing the supply cable, always unplug
the supply cable from the electrical socket and
disconnect the vehicle cable from the vehicle
charge port.
eOnly change cables in a dry environment.
eOnly use the control unit with vehicle cable in
conjunction with a supply cable included in the
scope of supply or a supply cable approved by
Porsche.
gRefer to chapter "Scope of delivery" on page 5.
eIn some countries, e.g. in Norway or Japan1,
changing the supply cable is prohibited. Further
information is available from your Porsche part-
ner.
Fig.7: Plug of the supply cable connection on the control
unit.
The plug of the supply cable connection can be re-
moved and inserted at the top of the control unit.

12
Operating
1. Time of printing. Further information is available from your Porsche partner.
NOTICE
Disconnecting the supply cable
Fig.8: Disconnecting cables
bCharging of the high-voltage battery has ended
and the vehicle plug has been removed from the
vehicle charge port.
bThe plug has been disconnected from the elec-
trical socket.
1. Remove screw C(Fig.8) using a suitable tool.
2. Li lever A(Fig.8).
3. Pull out plug B(Fig.8) until you rst feel resist-
ance.
4. Close lever A.
5. Pull out plug Bfully.
Securing supply cables and plugs
Fig.9: Connecting cables and securing plugs
bLever A(Fig.9) is closed.
1. Insert plug B(Fig.9) into the control unit until
you rst feel resistance.
2. Li lever A.
3. Push in plug Bfully.
4. Close lever A.
5. Secure plug Bto the control unit with screw C
(Fig.9).
Operating
Operating instructions
Risk of damage to the charger
eAlways place the charger on a solid surface when
charging.
ePorsche recommends operating the charger in
the basic wall mount. In certain countries, e.g. in
Switzerland1, the charger may only be operated
in the basic wall mount.
gRefer to chapter "Installing the wall mount" on
page 6.
eDo not immerse the charger in water.
eProtect the charger from snow and ice.
eProtect the charger from potential damage due
to being driven over, dropped, pulled, bent or
crushed.
The charger must only be operated within a tempera-
ture range from –30 °C to +50 °C.
Information
−To prevent overheating during operation, avoid
exposing the charger to continuous direct sun-
light. If the control panel overheats, the charg-
ing process is interrupted automatically until the
temperature has sunk to the normal range.
−When driving abroad, always carry the appropri-
ate supply cable with you for use in the country
you are visiting.
−Dierent safety concepts with dierent device
types are prescribed, depending on the country.
Before driving abroad, ensure that the charger
may also be operated in the respective country.
Contact your Porsche partner or local power
supplier.

Operating
13
DANGER
Charge
Charging instructions
Vehicle charge port
For information on connecting and disconnecting the
vehicle cable to and from the vehicle charge port and
for the charging and connection status at the vehicle
charge port:
gRefer to the Driver’s Manual.
Charging times
For information on charging times:
gRefer to the Driver’s Manual.
The charging duration can vary depending on the
following factors:
–Current-carrying capacity of the electrical outlet
used
(domestic electrical outlet or industrial electrical
outlet)
–Country-specic mains voltage and electric cur-
rent
–Settings for charging current limiting on the con-
trol unit
–Fluctuations in the mains voltage
–Ambient temperature of vehicle and charger.
Charging times may be longer in the limit ranges
of the permissible ambient temperature.
gRefer to chapter "Technical Data" on page 22.
–Temperature of the high-voltage battery and
control unit
–Passenger compartment precooling/heating ac-
tivated
Information
Due to dierent national mains supply systems, var-
ious cable versions are supplied. This may result in
the full charging power not being available. Further
information is available from your Porsche partner.
Charging
Electric shock, re
Risk of serious or fatal injury due to re or electric
shock.
eAlways observe the specied order for the
charging procedure.
eDo not unplug the vehicle cable from the vehicle
charge port during charging.
eEnd the charging process before disconnecting
the vehicle cable from the vehicle charge port.
eDo not disconnect the charger from the electrical
socket during charging.
Possible faults are indicated by means of dierent
colours, illumination and ashing of indicator lights A
– C(Fig.2).
gRefer to chapter "Control panel status indicators
and error messages" on page 15.
Starting charging
1. Insert the plug into the electrical socket. The
indicator lights briey light up red.
2. Insert the vehicle plug in the vehicle charge port.
🡆The indicator light on the ON/OFF button
lights up yellow.
Following a successful self-test, all the indi-
cator lights light up green for 2 seconds.
For information on connecting the vehicle
cable to the vehicle charge port:
gRefer to the Driver’s Manual.
3. Charging starts automatically.
🡆The indicator light on the ON/OFF button
pulses green.
Charging is controlled by the vehicle.
The charge status is displayed in the vehicle.
Charging current limiting
The control panel detects the voltage and the avail-
able current automatically. Using charging current
limiting, full or half charging power (100% or 50%)
can be set. The last charging current set is saved.
To prevent overheating of the electrical installation
with household cables, the charging current is limited
at delivery to 50% when using household electrical
sockets gP.9.
Setting limitation of charging current
ePress On/O button for at least 2 seconds.
🡆Aer the limitation of charging current has
been set successfully, the indicator lights B
(Fig.2) ash green once.
The set power (50% or 100%) is indicated
to the le or right of the On/O button .

14
Operating
DANGER
Deactivating and activating protective
conductor monitoring
Electric shock, short cir-
cuit, re, explosion
Using the charger without active protective conduc-
tor monitoring may result in electric shocks, short
circuits, res, explosions or burns.
eThe charger should preferably be operated in
earthed mains supply systems.
eOnly deactivate protective conducting monitor-
ing in non-earthed mains supply systems (e.g. IT
networks).
eActivate protective conducting monitoring in
earthed mains supply systems.
gRefer to chapter "Activating protective conductor
monitoring" on page 14.
Deactivating protective conductor monitor-
ing
bProtective conductor monitoring has interrupted
the charging process.
bA message relating to an interrupted or absent
protective conductor is indicated at the control
unit:
ON/OFF lights up red.
Power supply/domestic connection lights
up red.
Vehicle lights up red.
Control unit is o.
Reset is o.
1. Press the ON/OFF and Reset buttons.
Aer the control unit indicator light ashes 6
times, release the buttons.
2. Aer 1 second, press the ON/OFF and Reset
buttons again.
Aer the control unit indicator light ashes 6
times, release the buttons.
🡆Protective conductor monitoring is deacti-
vated automatically aer a short time.
The status display for deactivated protective
conductor monitoring is displayed on the
control unit:
ON/OFF pulses green.
Power supply/domestic connection
lights up yellow.
Vehicle lights up yellow.
Control unit is o.
Reset is o.
Activating protective conductor monitoring
ePress the ON/OFF and Reset buttons.
Aer the control unit indicator light ashes 6
times, release the buttons.
🡆The yellow power supply/domestic connec-
tion and Vehicle indicator lights go
out.
Activation of the protective conductor mon-
itoring is performed automatically aer a
short time.
The ON/OFF indicator light pulses green.

Control panel status indicators and error messages
15
Control panel status indicators and error messages
Pilot lights Meaning Remedy
ON/OFF lights up green.
Power supply/household connection is o.
Vehicle is o.
Control panel is o.
Reset is o.
The charger is ready but not charging. eStart charging process.
gRefer to chapter "Starting charging" on page 13.
ON/OFF pulses green.
Power supply/household connection is o.
Vehicle is o.
Control panel is o.
Reset is o.
The vehicle is charging with protective con-
ductor monitoring activated.
ON/OFF pulses green.
Mains supply/household connection lights up
yellow.
Vehicle is o.
Control panel is o.
Reset is o.
The power plug is overheated.
Possible cause: multiphase electrical socket
connected only as single phase.
Charging process is at reduced power.
The fault is automatically reset once the power plug has
cooled.
Until it has cooled, charging is only at reduced power.
eIf the fault persists, have the power supply/household
connection checked by a qualied electrician.
ON/OFF pulses green.
Mains supply/household connection lights up
yellow.
Vehicle lights up yellow.
Control panel is o.
Reset is o.
The vehicle is being charged with protective
conductor monitoring deactivated.
The vehicle should ideally be charged with protective conduc-
tor monitoring activated.
gRefer to chapter "Activating protective conductor monitor-
ing" on page 14.

16
Control panel status indicators and error messages
Pilot lights Meaning Remedy
ON/OFF pulses green.
Power supply/household connection is o.
Vehicle is o.
Control panel lights up yellow.
Reset is o.
The control panel is overheated.
Charging process is at reduced power.
The fault is automatically reset once the control panel has
cooled.
Until it has cooled, charging is only at reduced power.
eIf the fault persists, have the control panel checked by a
specialist dealer/ Porsche Partner.
ON/OFF lights up red.
Mains supply/household connection lights up
yellow.
Vehicle is o.
Control panel is o.
Reset is o.
The power plug is overheated.
The charging process is interrupted.
The fault is automatically reset and charging resumed once
the power plug has cooled.
eIf the fault persists, have the power supply/household
connection checked by a qualied electrician.
ON/OFF lights up red.
Power supply/household connection is o.
Vehicle is o.
Control panel lights up yellow.
Reset is o.
The control panel is overheated.
The charging process is interrupted.
The fault is automatically reset and charging resumed once
the control panel has cooled.
eIf the fault persists, have the control panel checked by a
specialist dealer/ Porsche Partner.
ON/OFF lights up red.
Power supply/household connection ashes
yellow.
Vehicle is o.
Control panel is o.
Reset is o.
The power supply/household connection
charging infrastructure is limited.
Possible cause: Undervoltage or poor mains
frequency.
The charging process is interrupted.
Aer the mains supply/household connection has stabilised,
the fault is automatically reset and charging resumed.
eIf the fault persists, have the power supply/household
connection checked by a qualied electrician.

Control panel status indicators and error messages
17
Pilot lights Meaning Remedy
ON/OFF lights up red.
Power supply/household connection is o.
Vehicle ashes yellow.
Control panel is o.
Reset is o.
The vehicle charging system has malfunc-
tioned.
The charging process is interrupted.
Aer the vehicle charging system has stabilised, the fault is
automatically reset and charging resumed.
eIf the fault persists, have the vehicle checked by a spe-
cialist dealer/Porsche Partner.
ON/OFF lights up red.
Power supply/household connection is o.
Vehicle is o.
Control panel ashes yellow.
Reset is o.
The supply or vehicle cable is faulty.
Possible cause: The coding resistances of
the supply and vehicle cables do not match.
The charging process is interrupted.
eHave the supply or vehicle cable replaced by a specialist
dealer/Porsche Partner.
ON/OFF lights up red.
Power supply/household connection is o.
Vehicle lights up red.
Control panel is o.
Reset is o.
The vehicle charging system has malfunc-
tioned.
The charging process is interrupted.
eEnd the charging process from the vehicle and disconnect
the vehicle cable from the vehicle charge port.
eDisconnect charger from mains supply and reconnect af-
ter 60 seconds.
eRestart charging process.
gRefer to chapter "Starting charging" on page 13.
eIf the fault persists, have the vehicle checked by a spe-
cialist dealer/Porsche Partner.
ON/OFF lights up red.
Power supply/household connection ashes
red.
Vehicle is o.
Control panel is o.
Reset is o.
There is overvoltage in the power sup-
ply/household connection charging infra-
structure.
The charging process is interrupted.
eDisconnect charger from mains supply and reconnect af-
ter 60 seconds.
eIf the fault persists, have the power supply/household
connection checked by a qualied electrician.

18
Control panel status indicators and error messages
Pilot lights Meaning Remedy
ON/OFF lights up red.
Power supply/household connection is o.
Vehicle is o.
Control panel lights up red.
Reset is o.
The control panel has a technical fault.
The charging process is interrupted.
eDisconnect charger from mains supply and reconnect af-
ter 60 seconds.
eIf the fault persists, have the control panel checked by a
specialist dealer/ Porsche Partner.
ON/OFF lights up red.
Power supply/household connection is o.
Vehicle is o.
Control panel ashes red.
Reset is o.
The control panel has a technical fault (self-
test failed).
The charging process is interrupted.
eDisconnect charger from mains supply and reconnect af-
ter 60 seconds.
eIf the fault persists, have the control panel checked by a
specialist dealer/ Porsche Partner.
ON/OFF lights up red.
Power supply/household connection lights up
red.
Vehicle lights up red.
Control panel is o.
Reset is o.
The power supply/household connection
charging infrastructure is insucient: The
protective conductor is interrupted or not
present.
Protective conductor monitoring has inter-
rupted the charging process.
eOnly non-earthed mains supply systems (e.g. IT net-
works): If necessary, charge the vehicle with protective
conductor monitoring deactivated.
gRefer to chapter "Deactivating protective conductor
monitoring" on page 14.
eOnly earthed mains supply systems: Have the control
panel checked by a specialist dealer/ Porsche Partner and
the power supply/household connection checked by a
qualied electrician.
ON/OFF lights up red.
Power supply/household connection lights up
red.
Vehicle lights up red.
Control panel lights up red.
Reset is o.
The indicator light in the Reset button on
the control unit is defective.
The charging process is interrupted.
eHave the control panel replaced by a specialist dealer/
Porsche Partner.
