Sonoro MAESTRO SO-1000 User manual

HI-FI INTERNET RECEIVER WITH POWERFUL DIGITAL
POWER AMPLIFIERS, CD PLAYER, PHONO AMPLIFIER,
DAB+ & BLUETOOTH®
Operating manual
MAESTRO
SO-1000
© sonoro audio GmbH 2019 73
GB

TABLE OF CONTENTS
1. Introduction................................................................................................. 78
1.1 Contact data .......................................................................................................................78
1.2 Intended use.......................................................................................................................79
2. GETTING TO KNOW YOUR MAESTRO.......................................................... 79
2.1 Scope of delivery...............................................................................................................79
2.2 Controls and ports............................................................................................................80
2.3 Technical data.....................................................................................................................85
2.4 Marks of approval and certificates................................................................................87
3. GETTING STARTED....................................................................................... 88
3.1 Unpacking MAESTRO......................................................................................................88
3.2 Inserting the battery in the remote control.................................................................88
3.3 Using the antennas............................................................................................................89
3.4 Speaker connections........................................................................................................90
3.5 Connecting PRE OUT jacks / 2.1 system .....................................................................92
3.6 Connecting a record player............................................................................................93
3.7 Connecting the power cord...........................................................................................94
3.8 Performing initial setup....................................................................................................95
4. BASIC OPERATION....................................................................................... 97
5. USING THE MENUS ...................................................................................... 99
6. DISPLAY ICONS.......................................................................................... 100
7. FM RADIO MODE....................................................................................... 101
7.1 Operation..........................................................................................................................101
7.2 Setup menu...................................................................................................................... 102
8. DAB RADIO MODE..................................................................................... 103
8.1 Operation ......................................................................................................................... 103
8.1 Setup menu...................................................................................................................... 104
© sonoro audio GmbH 201974

TABLE OF CONTENTS
9. INTERNET RADIO MODE.......................................................................... 105
9.1 Operation......................................................................................................................... 105
9.2 Setup menu...................................................................................................................... 106
9.3 Station List ........................................................................................................................ 106
9.4 Using the web portal ......................................................................................................107
10. BLUETOOTH MODE ................................................................................... 108
10.1 Pairing................................................................................................................................ 108
10.2 Operation......................................................................................................................... 109
10.3 Setup menu...................................................................................................................... 109
11. AUX IN 1 MODE ......................................................................................... 110
11.1 Operation..........................................................................................................................110
11.2 Setup menu.......................................................................................................................110
12. AUX IN 2 MODE ..........................................................................................111
12.1 Operation..........................................................................................................................111
12.2 Setup menu.......................................................................................................................111
13. OPTICAL MODE ......................................................................................... 112
13.1 Operation..........................................................................................................................112
13.2 Setup menu.......................................................................................................................112
14. COAXIAL MODE......................................................................................... 113
14.1 Operation..........................................................................................................................113
14.2 Setup menu.......................................................................................................................113
15. CD MODE................................................................................................... 114
15.1 Operation..........................................................................................................................114
15.2 Setup menu.......................................................................................................................115
© sonoro audio GmbH 2019 75
GB

16. PHONO MODE........................................................................................... 116
16.1 Operation..........................................................................................................................116
16.2 Setup menu.......................................................................................................................116
17. STREAMING SERVICES................................................................................117
17.1 Operation..........................................................................................................................118
17. 2 Setup menu.......................................................................................................................119
18. MY MUSIC MODE....................................................................................... 120
18.1 Operation..........................................................................................................................120
18.2 Setup menu.......................................................................................................................122
19. SLEEP TIMER.............................................................................................. 123
20. SYSTEM SETTINGS..................................................................................... 124
20.1 Accessing the system settings.....................................................................................124
20.2 Equalizer.............................................................................................................................124
20.3 Network..............................................................................................................................125
20.4 Time/date ..........................................................................................................................125
20.5 Inactive standby...............................................................................................................125
20.6 Language...........................................................................................................................126
20.7 Factory Reset ....................................................................................................................126
20.8 Software update ..............................................................................................................126
20.9 Setup Wizard ....................................................................................................................126
20.10 Info.......................................................................................................................................126
20.11 Privacy policy....................................................................................................................126
20.12 Backlight.............................................................................................................................126
21. USING UNDOKTM APP TO CONTROL MAESTRO......................................... 127
22. ROOM CORRECTION APP.......................................................................... 129
TABLE OF CONTENTS
© sonoro audio GmbH 201976

TABLE OF CONTENTS
23. TROUBLESHOOTING.................................................................................. 133
24. CLEANING.................................................................................................. 136
25. WARRANTY ............................................................................................... 137
© sonoro audio GmbH 2019 77
GB

1. INTRODUCTION
Thank you for purchasing MAESTRO. This operating manual and the safety manual
provide all the information required for trouble-free and safe operation of MAESTRO.
1.1 CONTACT DATA
Address sonoro audio GmbH,
Nordkanalallee 94, D-41464 Neuss, Deutschland
Phone [phone]
Fax [phone]
E-mail [e-mail]
Internet www.sonoro.de
• Read the operating manual and the safety manual in their entirety before using
MAESTRO.
• Keep the operating manual and safety manual for future reference.
• If you pass MAESTRO on to a third party, please provide them with the operating
manual and safety manual as well.
• Failure to follow the operating manual and safety manual can result in serious injury or
damage to MAESTRO.
• We assume no liability for damage resulting from failure to observe the instructions in
this operating manual and safety manual.
The images in this operating manual are intended to illustrate the actions necessary to
operate MAESTRO.
Enjoy your MAESTRO!
© sonoro audio GmbH 201978

1.2 INTENDED USE
MAESTRO is intended for personal use only. It is not intended for commercial use.
MAESTRO is solely intended for the following tasks:
• Operation of external speakers with an impedance of 4 Ω ...16 Ω.
• Playback of FM/DAB+/Internet radio and music streaming services.
• Playback of 12 cm audio CD and MP3/WMA CD disc.
• Audio playback from external devices connected via AUX In, USB port
phono input, optical input or coaxial input.
• Audio playback from Bluetooth-enabled devices (e.g. mobile phones).
• Music stream to Bluetooth headphone devices.
• Charging of external devices that are connected via the USB port.
Any other use is considered improper use and is prohibited. We assume no liability for
damages resulting from improper use.
2. GETTING TO KNOW YOUR MAESTRO
2.1 SCOPE OF DELIVERY
In addition to the MAESTRO itself, the following accessories are also included in the scope
of delivery:
• Remote control
• One button cell (CR2032, 3 V)
• Power cable
• FM/DAB cable antenna
• FM/DAB telescopic antenna
• External WiFi antenna
• Quick start guide
• Operating manual
• Safety manual
• Greeting card
• sonoro audio collection flyer
• Gloves
© sonoro audio GmbH 2019 79
GB

2.2 CONTROLS AND PORTS
FRONT VIEW
1. Standby button ( )
2. Infra-red sensor & light sensor
3. Headphone jack ( )
4. Play/pause button ( )
5. Stop button ( )
6. Left button, skip previous ( )
7. Right button, skip next ( )
8. CD mode (CD)
9. Phono mode (PHONO)
10. Music streaming services ( )
11. Back button ( )
12. CD slot
13. CD eject button ( )
14. Display
15. FM radio mode (FM)
16. Bluetooth mode ( )
17. DAB radio mode ( )
18. Auxiliary input 1/2 mode(AUX)
19. Internet radio mode ( )
20. Optical/coaxial input mode
(DIGITAL)
21. Favourite button (FAV)
22. Setup button (SETUP)
23. Select button (OK)
24. Volume knob, navigation knob
© sonoro audio GmbH 201980

REAR PANEL
MAESTRO SO-1000
Rear panel artwork
Date: 07.09.2019
Rev. 4.1
MAESTRO
REAR VIEW
25. AC socket
26. Heatsink
27. Speaker output terminals
28. Pre-amplifer output
29. Auxiliary input 1 (RCA)
30. Auxiliary input 2 (3.5mm)
31. Phono Ground (GND)
32. Phono input
33. Optical input
34. Coaxial input
35. USB port
36. LAN RJ45 jack
37. Mains ON/OFF switch
38. External WiFi antenna jack
39. Rear panel ventilation holes
40. DAB/FM antenna jack
25 26 27 28 29 30 313233 34 35 36
37 38 39 40
© sonoro audio GmbH 2019 81
GB

BOTTOM VIEW
41. Bottom ventilation holes
NOTICE!
Risk of damage!
Do not block the rear panel and bottom ventilation holes.
© sonoro audio GmbH 201982

REMOTE CONTROL
42. Standby button ( )
43. Setup button (SETUP)
44. DAB radio mode ( )
45. FM radio mode (FM)
46. CD mode (CD)
47. Music streaming services ( )
48. Phono mode ( PHONO )
49. Auxiliary input 1/2 mode (AUX)
50. Play/pause button ( )
OK button
51. Left button, skip previous ( )
52. Volume down button (−)*
53. Equalizer setting button (EQ)
54. Bass setting button (BASS)
55. Preset station buttons (0-9)
56. Information button (INFO)
57. Mute button ( )
58. Internet radio mode ( )
59. Bluetooth mode ( )
© sonoro audio GmbH 2019 83
GB

60. Optical/coaxial input mode (DIGITAL)
61. Right button, skip next ( )
62. Volume up button (+)*
63. TREBLE setting button (TREBLE)
64. Sleeper timer button (SLEEP)
65. Infra-red transmitter
66. Battery compartment
*Navigation buttons (+,−)
© sonoro audio GmbH 201984

Specification Value
Dimensions (W×D×H) approx. 432 x 277 x 120 mm
Weight approx. 6.0 kg
Operating temperature 0°C ~ +40°C
Load impedance 4-16 Ω
Rated output power
1KHz, THD+N <0.1%
(AES17)
170 W x 2 @ 4Ω
100 W x 2 @ 8Ω
Frequency response 20 Hz ~ 20 KHz
Display 2.8“ TFT colour display
Frequency range, FM 87.50 MHz–108.00 MHz
DAB/DAB+ Band III, 174.928 MHz–239.200 MHz
Internet radio More than 25,000 stations worldwide
Station presets 10 for each FM | DAB/DAB+ | Internet radio | Spotify
8 for each TIDAL | Napster | Deezer | Qobuz | Amazon Music
CD support formats
CD-DA (12cm), CD-R*, CD-RW*
Audio CD, MPEG 1 Layer 3 (MP3), Windows Media Audio
(WMA, DRM not supported)
Sampling rate 16KHz~48KHz, bit rate max. 320kbps
(* Playback dependent on quality of recording and medium)
USB charging Output: DC 5V 2.1A
USB playback Compatibility system: FAT 16, FAT 32 (not compatible with
NTFS or other systems)
AUX-IN Port 1 : RCA jack sensitivity: 1000 mV
Port 2 : 3.5 mm jack sensitivity: 300 mV
OPTICAL-IN (TOSLINK),
COAXIAL-IN (S/PDIF)
Supports linear PCM
Sample rate: 28 KHz-216 KHz, Channel: Stereo 16 bit, 24 bit
2.3 TECHNICAL DATA
© sonoro audio GmbH 2019 85
GB

Phono in For Moving Magnet (MM) pickup system
Input sensitivity: 5 mV / 47 KΩ
Pre-amplifier output 2 Vrms / 1.5 KΩ
Streaming Bluetooth | Spotify | TIDAL | Napster | Deezer | Qobuz |
Amazon Music | DLNA | UPnP
Network supported
IEEE 802.11 a/b/g/n, 2.4 & 5GHz bands, Ethernet
2.412GHz-2.472GHz / 5.18GHz - 5.32GHz / 5.50GHz-
5.70GHz
Max. transmitted power < 20 dBm
Encrypted key WEP, WPA, WPA2 (PSK), WPS
Bluetooth Version 3.0, Profile : AVRCP v1.4, A2DP 1.2, HSP v1.2
2.402GHz-2.480GHz
Max. transmitted power < 10 dBm
My music support media
formats
Codec Maximum supported bit rate
AAC (LC, HE, HEv2) 320 kbits/sec
FLAC(1) 1.5 Mbits/sec
LPCM(2) 1.536 Mbits/sec
MP3 320 kbits/sec
WAV 1.536 Mbits/sec
WMA(3) 320 kbits/sec
All codecs support 2 channels coded files only.
All codecs support smaple rate up to 48 kbits/sec
(include 32 and 44.1 kbits/sec)
Files which have Digital Rights Management (DRM)
protection applied will not be playable on MAESTRO.
(1) 16 and 24 bit samples are supported in FLAC files.
(2) The maximum supported bit-rate is for 48 kHz sampling,
2 channels and 16-bits per sample.
(3) WMA Lossless, WMA Voice, WMA 10 Professional, and
files which have DRM protection are not supported,
sample rate 48 KHz.
Battery CR2032 (remote control)
Standby Power < 1.0 W
Network Standby < 2.0 W
© sonoro audio GmbH 201986

2.4 MARKS OF APPROVAL AND CERTIFICATES
The Bluetooth® word mark and logos are
registered trademarks owned by the Bluetooth SIG, Inc.
and any use of such marks by sonoro audio GmbH is
under license. Other trademarks and trade names are
those of their respective owners.
UPnP™ is a trademark of the UPnP™ Forum.
The Spotify software is subject to third party licenses
found here:
http://www.spotify.com/connect/third-party-licenses
Napster and Napster logo are registered trademarks of
Rhapsody International Inc registered in the United States
and other countries.
TIDAL and TIDAL logo are registered trademark of
Aspiro AB in the European Union and other countries.
Deezer and Deezer logo are international trademarks of
Deezer S.A., registered in France and other countries.
Qobuz and its logo are registered trademarks of
Xandrie S.A.
Amazon, Amazon Music Unlimited and all related logos are
trademarks of Amazon.com, Inc. or its affiliates.
© sonoro audio GmbH 2019 87
GB

3. GETTING STARTED
3.1 UNPACKING MAESTRO
1. Take MAESTRO out of the packaging and check whether MAESTRO or the
individual parts exhibit damages. If this is the case, do not use MAESTRO.
Should you detect any damage, contact your dealer or sonoro audio GmbH
customer support immediately.
2. Check to make sure that the delivery is complete (see chapter “Scope of delivery”).
3. Place MAESTRO at a suitable location. If you want to put your MAESTRO on a
natural wood surface, please make sure that it is suitable. On oiled and waxed
surfaces, stains may occur.
4. Remove the protective film from the display.
3.2 INSERTING THE BATTERY IN THE REMOTE CONTROL
1. Open the battery compartment cover on the back of the remote control by turning
it anticlockwise using a small coin.
2. Insert the supplied batteries (CR2032, 3 V) with the label (+) side up.
3. Replace and close the battery compartment cover by turning the cover clockwise
using a small coin.
Do not block the infra-red sensor on the MAESTRO and the infra-
red transmitter on the remote control during use.
© sonoro audio GmbH 201988

3.3 USING THE ANTENNAS
1. The scope of supply contains a cable antenna and a rod antenna.
For optimum radio reception, one of the two antennas must be used.
2. Screw the desired antenna located on the back of MAESTRO to the FM/DAB
antenna connector.
For good FM/DAB radio reception, the two ends of the cable
antenna should form a ‚T‘ (dipole) with the connection cable.
A: Recommended alignment for FM
B: Recommended alignment for DAB
For even better reception, connect MAESTRO to a suitable house
antenna.
3. If you are using the cable antenna, unfold the cable antenna and align the antenna
so that you have the best possible reception.
4. If you are using the rod antenna, pull the rod of antenna apart and align the antenna
so that you have the best possible reception.
5. Screw the desired Wi-Fi antenna located on the back of MAESTRO to the WiFi
antenna connector. Lift Wi-Fi antenna upwards.
6. If you want to connect MAESTRO to your network using an Ethernet cable, connect
an Ethernet cable from LAN port on the back of MAESTRO to your router.
© sonoro audio GmbH 2019 89
GB

3.4 SPEAKER CONNECTIONS
NOTICE!
Risk of damage!
• Disconnect the power plug from the power outlet before
connecting the speakers.
• Never touch the speaker terminals while the power cord is
connected. Doing so could result in electric shock.
• Use speakers with an impedance of 4 – 16 Ω.
Speakers can be connected to MAESTRO as shown below.
Speakers
© sonoro audio GmbH 201990

Connecting the speaker cables
1. Remove approximately 10 mm of insulation from the end of each speaker cable.
Then, twist the bare wires of the cable firmly together.
2. Unscrew the knob.
3. Insert one bare wire into the hole in the side of each terminal.
4. Tighten the knob to secure the wire.
Using a banana plug
1. Tighten the knob.
2. Insert the banana plug into the end of the terminal.
When connecting the speaker cable, take notice of the followings:
• Do not let the bare wires of the speaker cable touch one another.
• Do not let the bare wires of the speaker cable come into contact
with MAESTRO’s rear panel and screws.
+ (red)
- (black)
Banana plug
© sonoro audio GmbH 2019 91
GB

SUBWOOFER
(L) (R)
3.5 CONNECTING PRE OUT JACKS / 2.1 SYSTEM
The pre-outs allow you to connect active subwoofers, another power amplifier, mixer,
recorder, etc.
The following illustration shows how to connect an active subwoofer to MAESTRO.
Select the option 2.1 System in the EQUALIZER menu. Then choose at MAESTRO the
same crossover frequency as on your active subwoofer.
MAESTRO allows you to select the following crossover frequencies:
60Hz, 70Hz, 80Hz, 90Hz, 100Hz, 110Hz, 120Hz, 140Hz 160Hz and 180Hz.
Choose a low frequency, e.g. 60Hz, for very large subwoofers and higher frequencies for
smaller subwoofers. Follow the instructions and recommendations of your subwoofer.
Select one of the crossover frequencies and confirm with the „OK“ button.
The speakers connected to the MAESTRO (L and R) are then operated via a
Linkwitz high pass filter 2nd order.
This has the advantage that the L and R speakers are relieved of low tones, and the
entire 2.1 system gains dynamic and maximum volume.
The volume knob on the active subwoofer adjusts the desired bass volume.
Ideally you start with a very low volume and then increase slowly, until the subwoofer is
just heard.
Adjusting the volume, loudness and tone on MAESTRO has effect
on the PRE OUT jacks.
© sonoro audio GmbH 201992
