Sony Ericsson K770i User manual

Welcome to your new phone, designed for
Vodafone Mobile Internet – the internet is
now mobile!
Life is short, so we’ll assume that you’ve used
a mobile phone before. This quick guide will
just focus on the things
that might be different.
We’ll also show you some
of the other features and
services that you can use
to make the most of now.
If you need more help,
see the User Guide or
your local Vodafone
website.
Setting up your phone
What the keys do
What the keys do 2
Entering text
Other differences
Making voice and video calls
Using the camera
Sending messages
Vodafone Mobile Internet
Downloading stuff
Other features
Music player
2
3
4
5
6
7
8
10
12
14
15
16
K770 UK.indd 1 22/8/07 10:27:10

2
Setting up your phone
Before you can start exploring your new phone,
you’ll need to set it up.
Insert your Vodafone SIM card as shown.
Make sure the gold contacts and the cut-off
corner are positioned correctly.
Insert a memory card (Memory Stick™ Micro),
if one is supplied. This increases the phone’s
memory.
Replace the battery and cover as shown, and
charge it if necessary. See the User Guide for
full details on charging.
Press and hold the top power key to
turn it on (or off).
When prompted, select Normal mode
– select Flight mode only when you don’t
want the mobile signal activated.
Then you’ll be taken through a basic setup.
•
•
•
•
•
•
K770 UK.indd 2 22/8/07 10:27:12

3
What the keys do
The navigation key. Press it in [ ] to select the option
in the bottom centre of the screen. In the Home screen
this opens the main Menu.
Press it up pfor Vodafone live! (ofine), right ufor My
Files, down qfor Contacts, and left tfor Messaging.
The Call key makes and answers calls. In the Home
screen, it opens Call history.
The End key ends calls. Press it to return to the Home
screen.
The soft keys select the options on the bottom left or
right of the screen. In standby mode the left soft key
opens the main Menu, the right soft key opens the
Toolbar.
The Toolbar lets you view and open bookmarks,
shortcuts, applications, and recent calls and messages.
Press it again to return to the previous screen. Press t
uto move between the Toolbar tabs.
The Clear key. Deletes items, text and numbers.
Back key. Press to take you back to a previous menu or
screen. Press and hold to return to the standby screen.
K770 UK.indd 3 22/8/07 10:27:17

4
What the keys do 2
Camera key
Volume keys
Charger/headphones
port
Power keyCover unlock
K770 UK.indd 4 22/8/07 10:27:21

5
Entering text
Switching text entry modes
To switch between predictive text [T9] and
multitap [Abc], press and hold the *key.
Briey pressing the *key also cycles
through the different upper and lower case
options in the text entry modes.
Predictive text
If you’re happy with a word or letter
combination, press the navigation key uto
OK it.
To see the other word or letter options, press
the qkey.
Symbols and numbers
Press the 1key repeatedly for commonly-
used symbols (in predictive text mode press
the 1key then repeatedly press the qkey).
•
•
•
•
•
Different phones sometimes use
different ways of entering text, but it
doesn’t take long to get used to it.
For other symbols press More > Add
symbol.
Press the #key for a space.
Press and hold a number key to enter that
number.
•
•
•
K770 UK.indd 5 22/8/07 10:27:21

6
Other differences
Turn silent mode on
To switch to silent (vibrate only) mode, press
and hold the #key when you’re in the Home
screen. To turn your ringtone back on, press and
hold it again.
Key lock
In standby mode, press *and then the right
hand soft key. You’ll see the ‘lock’ icon on the
screen. Press the same keys again to release the
keyboard.
3G (also known as UMTS)
The Vodafone 3G network is a more modern,
faster mobile network. As well as letting you
make video calls, you should also nd that
downloads are signicantly quicker, videos and
music can be streamed straight to your phone,
and browsing in Vodafone live! and the mobile
internet should be much snappier.
Here are some more differences you
may nd between this phone and your
last one.
So you can do a lot more in the ve minutes
before the train arrives.
To nd out if you’re in a 3G area, look for the
3G symbol in the upper menu bar of the
screen.
You’ll still be able to use the existing 2.5G
network at all other times.
•
•
K770 UK.indd 6 22/8/07 10:27:21

7
Making voice and video calls
Choose a contact or enter a number
Press qto open your contacts list, and
choose a number to call (it must be a 3G
mobile to receive a video call, and you must
be in a 3G area).
Press the key. This opens your call
history, so you can choose a recent number.
Enter a number using the keypad.
Make a voice or video call
Press the key to make a voice call.
Press More > Make video call to make a
video call. If the 3G network isn’t available,
you can choose to make a voice call instead.
Start the Video call screen
In standby mode, press Menu > Organiser
& Tools > Video call to bring up the Video
•
•
•
•
•
•
Even though you’re miles apart, now
you can talk face to face.
call screen. The small screen shows what the
person you’re calling will see (you’ll see them
in the larger screen). Use a headset for the
best sound quality.
Adjust a video call
Press More for settings and other options, such
as swapping screens, and turning the camera
on and off.
Answer a call
Press the key.
You’ll see an on-screen alert if there’s an
incoming video call.
•
•
K770 UK.indd 7 22/8/07 10:27:22

8
Using the camera
Amazing things happen around us every day.
With your phone’s 3.2 megapixel camera, now
it’s easy to capture that moment. And it’s just as
easy to share it.
Turn the camera on
Turn the phone sideways, then press down
on the end of the lens cover where it says ‘3.2
megapixel’. Slide the lens cover open to turn
on the camera (even if you’re not in standby
mode). Close the lens cover to turn the
camera off and return to the previous screen.
To turn the ash light on, press *. For other
settings, see the next page.
Use the volume keys to zoom in or out, and
press the navigation key tor uto adjust the
brightness.
•
•
•
Take a photo
Press the camera key half way to set
the focus. When the green dot stops ashing,
press the key all the way down to take the
photo.
The photo is automatically saved in Menu >
My Files > Camera album.
Press to delete it. Press to take
another photo.
Send your photo
You can send your photo in a message to
another mobile, or to an email address. See the
Messaging section for more details.
Press Send > As message.
When you’ve taken your picture, press More
> Edit in PhotoDJ™ for a range of editing
options.
•
•
•
•
•
How many times have you thought
‘If only I had a camera with me’?
K770 UK.indd 8 22/8/07 10:27:22

9
You can also upload it to an online blog page
by choosing More > Blog this.
Camera and video settings
To change other settings, press Settings
when the camera is active.
Use the tukeys to choose from a range of
different options.
Many of the number keys act as shortcuts for
the most used settings. Press 0when the
camera is active to see a menu of shortcut
keys.
Take a video
To turn on the video recorder, press q[ ].
Press to start recording, and press it
again to stop.
Press More > Play to play it.
To send a video in a message, make sure that
the video length is set to For MMS.
•
•
•
•
•
•
•
•
View your photos and videos
Press View when the camera or video is
active.
•
K770 UK.indd 9 22/8/07 10:27:24

10
photo or to record a new sound.
Note: press Yes if asked to resize a photo, and
make sure you’re using For MMS mode for your
videos. If you add a video clip then you may not
be able to add anything else.
To see how your message will appear, press
.
Send your message
Press Continue.
To send to a mobile > Enter phone no.. To
send to an email address > Enter E-mail
addr.. To use a number or email address from
your phonebook > Contacts lookup.
Then press Send.
•
•
•
•
Sending messages
The best time to share your thoughts,
photos and videos is now.
Creating a multimedia message (MMS) is just
like writing a text message – but now you can
add photos, videos or sounds as well. So now
you can show as well as tell...
Start a new message
Press tin the Home screen, or go to Menu >
Messaging. Choose Create new > Message.
Add text
Just write your message using the keypad.
To send this as a text message, press
Continue. To add pictures, videos or sounds
(MMS messaging), press and hold qto
highlight icons in the lower menu bar.
Add more
Select the icon to add a photo, or
for videos and sounds. Select to take a new
•
•
•
K770 UK.indd 10 22/8/07 10:27:25

11
Note:
Try it out now: take a close-up
photo of your eye, and send
it to a friend saying ‘See you
later’...
If you’re sending an MMS to someone
whose mobile isn’t MMS compatible,
they’ll be sent a web address that they
can view your message on.
To send and receive emails on your
phone, please see the User Guide.
•
•
•
Vodafone Push Email
(also known as CPE)
With Vodafone Push Email
you can now have email
automatically forwarded
to your phone.
Go to Menu > Messaging > Email >
Settings then select New Account. Enter
your email account details (you may need
to contact your email service provider).
Once the service is set up, you can send
and read your emails in the Messaging
folder.
•
•
Continue More
Hi there - wait till you
see this!
Add picture
K770 UK.indd 11 22/8/07 10:27:25

12
Vodafone Mobile Internet
Now when you press the live! soft key on
your phone, you’ll get access to the whole of the
mobile internet!
You’vegotGoogle™whenyouneedit.You’ve
gotlive sport.Andyou’vegotyouremailontap.
Youcancatchbreakingnewsfromthe backofa
cab.YoucanevenbidoneBaywhenyou’reout
forlunch.
And you can do all of this on phone-friendly web
pages that look as good on your mobile as they
do on your PC.
Connect to the Mobile Internet
In the Home screen, simply press
[ live!], or pand select Homepage.
To open a link, select it and press .
Use the onscreen navigation links or More to
bookmark a page, zoom in or out, or to go to
another page.
•
•
•
The internet is now mobile!To exit the Mobile Internet, press press .
Vodafone live!
Just click on live! to take you to the best of
the web.
Use bookmarks
You can save and revisit pages just like a web
browser.
To save a page, press More > Tools > Add
bookmark.
To go to a saved page, press More > Go to >
Bookmarks.
To view selected Vodafone live! links without
connecting, press pthe Home screen.
Choose a Vodafone live! service and press
to connect to it.
To go directly to your bookmarks, press
pin standby mode, and then choose
Bookmarks.
You can also press Toolbar in the Home
screen and select your bookmarks or links.
•
•
•
•
•
•
•
K770 UK.indd 12 22/8/07 10:27:27

13
Because Vodafone live! is
changing all the time,
your Home page may
look different to the one
shown here
Get the latest news and sport info, as it
happens, with video clips and photos
Download full music
tracks and videos, as
well as ringtones, games,
and wallpapers
Keep the conversation
going in your favourite
blogs, chat rooms,
and
forums
Search with Google™ to
nd pretty much anything
With eBay and online
shopping, you never need
to miss a bargain
Watch TV, movie trailers
and YouTube clips
You’ve got mail? Now
you can check your email
accounts on your phone
K770 UK.indd 13 22/8/07 10:27:28

14
Downloading stuff
You can either download stuff while browsing
Vodafone live!, or by using your phone’s built-in
links. Either way, the process is simple, as any
charges are billed to your phone.
Don’t worry, you’ll always see how much it is,
and you’ll always be asked to conrm that you
want to go ahead.
Download from a built-in link
Each folder in My Files contains links to the
appropriate downloads section in Vodafone
live!.
For example, to download a new ringtone:
In the Home screen, press u[My Files] >
Music.
Select More Ringtones, then choose a
ringtone to download from the thousands
available. You’ll usually be able to hear it rst.
•
•
Make your phone all your own by
downloading new ringtones, games,
music, wallpapers and more.
Follow the onscreen instructions to
download it. It will be saved on your phone in
My Files > Music.
Use your download
Find your download in Menu > My Files, and
then highlight it.
To set a sound as your new ringtone,
highlight it and press More > Use as >
Ringtone.
To set a picture as your new background
wallpaper, highlight it and press More > Use
as > Wallpaper.
•
•
•
•
K770 UK.indd 14 22/8/07 10:27:28

15
Other features and services
Vodafone Full Track Music Downloads
Now you can download music whenever you
want. Go to Menu > Music Player > Download
Music. Choose from a huge selection of current
and classic tracks. Only in a 3G area.
Mobile TV
A great way to get video news and
entertainment, TV shows and sport.
When you’re in a 3G area, go to Menu >
Entertainment > Mobile TV, then choose a TV
Pack to sign up to. Choose a channel – this will
be streamed to you directly, so you don’t have
to store it. See the Vodafone website for more
details.
Find out about a few other things you
can do with your phone that you might
not discover otherwise.
K770 UK.indd 15 22/8/07 10:27:28

16
Music player
Create a playlist
To create a new playlist, press Menu > Music
Player > Playlists > New playlist. Enter a
name for it, then add the tracks you want.
Choose your playlist and press Play.
Using the controls:
Use the navigation key to control playback:
press the centre key to play or pause a
track or video.
Press uto go to the next track, or press and
hold to fast forward. Press tto go back or
press and hold to rewind. Press por qto
scroll through your playlist tracks.
Usethe suppliedremotecontroland
headphonesforthebestlisteningexperience.
•
•
•
•
•
You can use the music player on your phone by downloading music and videos
from Vodafone live!. Otherwise you will need to install some software on your PC to
transfer music and videos from your PC to the memory in your phone. Please see
the User Guide for full details, and for instructions on installing the drivers and using
the Disc2Phone software, and also attaching the USB cable.
K770 UK.indd 16 22/8/07 10:27:33
