Sony Ericsson T280A User manual

T280a
User guide
This is the Internet version of the User's guide. © Print only for private use.

2
Congratulations on your purchase of the
Sony Ericsson T280a. For additional phone content,
go to www.sonyericsson.com/fun. Register now to get
free online storage and special offers at
www.sonyericsson.com/myphone. For product support,
go to www.sonyericsson.com/support.
Instruction symbols
The following instruction symbols appear in this User guide:
> Use the navigation key to scroll and select.
Press the navigation key up.
Press the navigation key down.
Press the navigation key to the left.
Press the navigation key to the right.
Note
Tip
Warning
Indicates that a service or function is network- or
subscription-dependent. All menus or functions
may not be available in your phone. Consult your
network operator for more information.
This is the Internet version of the User's guide. © Print only for private use.

3
Prepare the phone
To insert the SIM card and battery
1Remove the battery cover. Slide the SIM card into
its holder with the contacts facing down.
2Insert the battery with the label side up and the
connectors facing each other. Replace the battery
cover as shown in the picture.
Do not force the battery cover into place. Slide the
battery cover carefully onto the phone and close it.
This is the Internet version of the User's guide. © Print only for private use.

4
Charge the battery
1The phone battery is partly charged when you buy it.
Connect the charger to the phone. It takes
approximately 2.5 hours to fully charge the battery.
Press a key to illuminate the screen.
2To remove the charger, tilt the plug upwards.
You can use the phone during charging. You can
charge the battery for more or less than 2.5 hours.
Interrupted charging will not damage the battery.
This is the Internet version of the User's guide. © Print only for private use.

5
Turn the phone on
1Press and hold down .
2Enter your PIN if requested. To correct mistakes,
select Delete.
3Select OK.
4Select a language.
5Enter the time and date and
select Save.
To turn the phone off
•Press and hold down .
Standby
After you have turned the phone on and entered your PIN,
the name of your operator appears on the screen. This
is called standby. You can now make and receive calls.
This is the Internet version of the User's guide. © Print only for private use.

6
SIM and PIN
SIM card
The SIM (Subscriber Identity Module) card, which
you get from your network operator, contains
information about your subscription. Always turn
off your phone and detach the charger before
you insert or remove the SIM card.
PIN code
You may need a PIN (Personal Identification Number) to
activate the services in your phone. Your PIN is supplied
by your network operator. Each PIN digit appears as *,
unless it starts with emergency number digits, for example,
112 or 911. You can call an emergency number without
entering a PIN.
You can save contacts on the SIM card before
removing it from your phone. Contacts may also
be saved in the phone memory. See Contacts
on page 17.
If you enter the wrong PIN three times in a row,
PIN blocked. Enter PUK provided by your operator.
appears. To unblock it, you need to enter your PUK
(Personal Unblocking Key).
This is the Internet version of the User's guide. © Print only for private use.

7
Menu overview
Extras Calendar, Timer, Stopwatch,
Calculator, Games, My files
Internet Homepage, Bookmarks, Go to URL,
View, Advanced
FM Radio
Camera Take pic., Camera pics, Slide show,
Settings
Messaging Write new, Inbox, Call voicemail,
Drafts, Sent messages,
Saved msgs, Templates,
Delete messages, Settings, Memory
status
Alarms
Calls Call list, Time and cost, Call settings
Contacts View contacts, Find contact,
Add contact, My number, Voicemail,
Delete contacts, Speed dial,
Copy contacts, Send contacts,
Settings
Settings Sound & alerts, Wallpaper, Theme,
Time and date, Language, Bluetooth,
Select network, Internet settings,
Advanced, Phone status
Some menus and icons in this document may vary
depending on operator, network or subscription.
This is the Internet version of the User's guide. © Print only for private use.

8
Phone overview
Selection key
Volume
keys
Navigation
key with
shortcuts
Call key
Keylock
End key,
On/off
key
Stereo handsfree and battery
charger connector
This is the Internet version of the User's guide. © Print only for private use.

9
Network coverage
The network bars show the strength of the GSM network
in your area. Try moving to another location if you have
trouble calling and network coverage is poor. No network
means you are not in range of a network.
Battery status
= Good network coverage
= Average network coverage
= The phone battery is fully charged
= The phone battery is empty
Battery
status
Network
coverage
This is the Internet version of the User's guide. © Print only for private use.

10
Screen icons
These icons may appear on the screen.
Icon Description
Battery icon. A completely green icon means that
the battery is fully charged
You have missed a call
Divert calls is activated
The phone is set to silent
The keypad is locked
You have received a text message
You have received a picture message
An alarm is activated
Ongoing call
The loudspeaker is on
The FM radio is playing
The Bluetooth function is activated
This is the Internet version of the User's guide. © Print only for private use.

11
Shortcuts
From standby you can use the navigation keys
to go directly to a function:
•Press to write a text or picture message.
•Press to go to the camera.
•Press to play the FM radio.
•Press to go to your contacts.
To navigate the menus
1From standby select Menu.
2Press , , , and select
amenu.
To go back one step in the menu
•Select Back.
To return to standby
•Press .
To lock the keypad
•Press and select Lock keys.
To unlock the keypad
•Press and select Unlock.
To set the phone to silent
•Press and hold down .
To call your voicemail service
•Press and hold down .
This is the Internet version of the User's guide. © Print only for private use.

12
Calling
You must turn on the phone and be within range
of a network.
To make a call
1From standby enter the area code and phone number.
2Press .
To end a call
•Press .
To answer a call
•Press .
To reject a call
•Press .
To turn off the ringtone when receiving a call
•Select Silent to turn off the ringtone without answering
the call.
To turn the loudspeaker on during a call
•Select Options >Turn on speaker.
To change the ear speaker volume during a call
•Press or .
Do not hold the phone to your ear when using
the loudspeaker. This could damage your hearing.
This is the Internet version of the User's guide. © Print only for private use.

13
To make international calls
1From standby press and hold down until a + sign
appears on the screen.
2Enter the country code, area code (without the first
zero) and phone number.
3Press .
To view a missed call
•When Missed call is displayed, select Details.
To call back scroll to the number and press .
Call list
You can view information about recent calls.
To call a number from the call list
1From standby press .
2Scroll to the name or number and press .
To delete a number from the call list
1From standby press .
2Scroll to the name or number and select Options >
Delete >Yes.
Calls to the international emergency number 112
can still be made, even when the keypad is locked.
This is the Internet version of the User's guide. © Print only for private use.

14
Camera
Your phone has a digital camera to take pictures to save
or send. Pictures taken with the camera are saved in Menu
> Camera > Camera pics. The format is JPEG.
To start the camera and take a picture
1From standby press . You can see the subject
on the phone screen.
2Select Take pic. to take the picture.
3Select Save or Delete.
To delete a picture
1From standby select Menu > Camera > Camera pics.
2Scroll to a picture and select View.
3Select Options > Delete > Yes.
To send a camera picture as picture message
1From standby select Menu > Camera > Camera pics.
2Scroll to a picture and select View.
3Select Options > Send message > Options > Send
message > To:.
4Select Enter phone no. or Email address.
5Select OK > Options > Send message.
Pictures downloaded using picture messages,
Internet or Bluetooth are saved in Extras >
My files > My pictures.
See To send an item using Bluetooth on page 31.
This is the Internet version of the User's guide. © Print only for private use.

15
Messaging
Text messages (SMS)
You must have a service centre number, which is supplied
by your service provider and saved on the SIM card.
You may have to enter the number yourself. See
Troubleshooting on page 36.
To write and send a text message
1From standby press .
2Select Text message. Write the message and select
Options >Send message.
3Select an option.
4Select Send.
To view a received text message
1new message Read now? appears. Select View.
2Select the unread message.
To view messages saved in the inbox
•Select Menu >Messaging >Inbox.
To get delivery status of a sent message
1From standby select Menu >Messaging >Settings >
Delivery report.
2Select On. You will be notified when a message has
been successfully delivered.
See Entering text on page 23.
This is the Internet version of the User's guide. © Print only for private use.

16
Picture messages (MMS)
Picture messages can contain text, sound and images.
They are sent using MMS to a mobile phone. You need
the correct Internet settings in your phone to use this
function. See Internet on page 32.
To create a picture message
1From standby press .
2Select Picture messages > Options and select among
the options to create the message.
To send a picture message
1When the message is ready, select Options > Send
message > To:.
2Select Enter phone no. or Email address.
3Select OK > Options > Send message.
Sending and receiving phones must have
subscriptions that support picture messaging.
This is the Internet version of the User's guide. © Print only for private use.

17
Contacts
You can save contacts in the phone memory or on
the SIM card. You can copy contacts from the phone
memory to the SIM card or from the SIM card to the
phone memory.
To add a contact
1From standby select Contacts >Add contact.
2Select Save on SIM or Save in phone.
3Enter the name and select Options > OK.
4Scroll to the icon below the name.
5Enter the number and select OK.
6Select Save contact.
You can choose which contact information is shown as
default. If Phone contacts is selected as default, your
contacts show all the information saved in the phone.
If you select SIM contacts as default, your contacts show
names and numbers saved on the SIM card.
To select contacts view
1From standby select Menu > Contacts > Settings >
View Contacts.
2Select an option.
See Entering text on page 23.
You can enter the + sign and country code with all
phonebook numbers. They can then be used abroad or
at home. See To make international calls on page 13.
This is the Internet version of the User's guide. © Print only for private use.

18
To call a contact
1From standby press .
2Scroll to, or enter the first few letters of the contact.
3Press .
To edit a contact
1From standby press .
2Select a contact.
3Select Options > Edit.
4Edit the information and select Options > Save contact.
To delete a contact
1From standby press .
2Select a contact.
3Select Options >Delete contact.
To copy all contacts to the SIM card
•From standby select Menu > Contacts >Copy contacts
> Copy all to SIM.
To view your own phone number
•From standby select Menu > Contacts > My number.
This is the Internet version of the User's guide. © Print only for private use.

19
Contacts memory
The number of entries you can save in Contacts depends
on the capacity of your SIM card.
To check the Contacts memory status
•From standby select Menu >Contacts >Settings >
Memory status.
Speed dialling
Speed dialling lets you select nine contacts that you can
dial quickly. The contacts can be saved in positions 2-9.
To add contacts to speed dial numbers
1From standby select Contacts > Speed dial.
2Select a position number.
3Select a contact.
To speed dial
•From standby enter the position number and press .
Position 1 is set to voicemail number.
This is the Internet version of the User's guide. © Print only for private use.

20
FM radio
To listen to the FM radio
1Connect the handsfree to the phone.
2From standby press .
To control the radio
•Press or to search for FM radio channels.
•Press or to change the volume.
To save an FM radio channel
•Press and hold down – . The FM radio channel
is saved in Options > Channels. You can save up to 20
preset channels.
To listen to a saved FM radio channel
•When the FM radio is on, press – .
To exit the FM radio
•Select Back or press .
To minimize the FM radio on the screen
•Select Options > Minimize.
•Press to restore the FM radio on the screen.
To turn the FM radio off when minimized
•Press and select Back.
To view FM radio options
•When you play the FM radio, select Options.
This is the Internet version of the User's guide. © Print only for private use.
