Sony Ericsson Z310 User manual

This is the Internet version of the user'sguide. © Print only for private use.

This is the Internet version of the user'sguide. © Print only for private use.
1
Contents
Getting to know your phone . . . . . . . . . . . . . . . . . . 6
Calling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Imaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Entertainment . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Connectivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
More features . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Important information . . . . . . . . . . . . . . . . . . . . . . 77
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
You can find support, information and content downloads
at www.sonyericsson.com/support.

This is the Internet version of the user'sguide. © Print only for private use.
2
Sony Ericsson
GSM 900/1800/1900
This User guide is published by Sony Ericsson Mobile
Communications AB or its local affiliated company, without any
warranty. Improvements and changes to this User guide necessitated
by typographical errors, inaccuracies of current information, or
improvements to programs and/or equipment, may be made by Sony
Ericsson Mobile Communications AB or its local affiliated company
at any time and without notice. Such changes will, however, be
incorporated into new editions of this User guide.
All rights reserved.
©Sony Ericsson Mobile Communications AB, 2006
Publication number: EN/LZT 108 9014 R1A
Please note: Some of the services in this User guide are not supported
by all networks. This also applies to the GSM International Emergency
Number 112.
Please contact your network operator or service provider if you are in
doubt whether you can use a particular service or not.
Please read the Guidelines for safe and efficient use and the Limited
warranty chapters before you use your mobile phone.
All illustrations are for illustration only and may not accurately depict
the actual phone.
Your mobile phone has the capability to download, store and forward
additional content, e.g. ringtones. The use of such content may be
restricted or prohibited by rights of third parties, including but not
limited to restriction under applicable copyright laws. You, and not
Sony Ericsson, are entirely responsible for additional content that
you download to or forward from your mobile phone. Prior to your
use of any additional content, please verify that your intended use is
properly licensed or is otherwise authorized. Sony Ericsson does not
guarantee the accuracy, integrity or quality of any additional content
or any other third party content. Under no circumstances will Sony
Ericsson be liable in any way for your improper use of additional
content or other third party content.

This is the Internet version of the user'sguide. © Print only for private use.
3
PlayNow™ and MusicDJ™ are trademarks or registered trademarks
of Sony Ericsson Mobile Communications AB.
Bluetooth™ is a trademark or registered trademark of Bluetooth SIG
Inc.
T9™ Text Input is a trademark or a registered trademark of Tegic
Communications. T9™ Text Input is licensed under one or more
of the following: U.S. Pat. Nos. 5,818,437, 5,953,541, 5,187,480,
5,945,928, and 6,011,554; Canadian Pat. No. 1,331,057, United
Kingdom Pat. No. 2238414B; Hong Kong Standard Pat. No.
HK0940329; Republic of Singapore Pat. No. 51383; Euro.Pat.
No. 0 842 463 (96927260.8) DE/DK, FI, FR, IT, NL, PT, ES, SE, GB;
and additional patents are pending worldwide.
Java and all Java based trademarks and logos are trademarks or
registered trademarks of Sun Microsystems, Inc. in the U.S. and
other countries/regions. End-user license agreement for Sun™
Java™ JME™.
1 Restrictions: Software is confidential copyrighted information of
Sun and title to all copies is retained by Sun and/or its licensors.
Customer shall not modify, decompile, disassemble, decrypt,
extract, or otherwise reverse engineer Software. Software may
not be leased, assigned, or sublicensed, in whole or in part.
2 Export Regulations: Software, including technical data, is subject
to U.S. export control laws, including the U.S. Export
Administration Act and its associated regulations, and may be
subject to export or import regulations in other countries/regions.
Customer agrees to comply strictly with all such regulations and
acknowledges that it has the responsibility to obtain licenses to
export, re-export, or import Software. Software may not be
downloaded, or otherwise exported or re-exported (i) into, or to a
national or resident of, Cuba, Iraq, Iran, North Korea, Libya,
Sudan, Syria (as such listing may be revised from time to time) or
any country/region to which the U.S. has embargoed goods; or (ii)
to anyone on the U.S. Treasury Department's list of Specially
Designated Nations or the U.S. Commerce Department's Table of
Denial Orders.

This is the Internet version of the user'sguide. © Print only for private use.
4
3 Restricted Rights: Use, duplication or disclosure by the United
States government is subject to the restrictions as set forth in the
Rights in Technical Data and Computer Software Clauses in
DFARS 252.227-7013(c) (1) and FAR 52.227-19(c) (2) as applicable.
Part of the software in this product is copyright © SyncML initiative
Ltd. (1999-2002). All rights reserved.
Other product and company names mentioned herein may be the
trademarks of their respective owners.
Any rights not expressly granted herein are reserved.
Note: Sony Ericsson advised users to backup their personal data
information.
All illustrations are for illustration only and may not accurately
depict the actual phone.

This is the Internet version of the user'sguide. © Print only for private use.
5
User guide symbols
The following instruction symbols appear in this User
guide:
}
Use the navigation key to scroll and select
% 14 Navigating the menus.
Press the navigation key centre.
Press the navigation key up.
Press the navigation key down.
Press the navigation key to the left.
Press the navigation key to the right.
%
See also page ...
Note
Indicates that a service or function is network- or
subscription-dependent. Because of this, all menus
may not be available in your phone. Consult your
network operator for more information.

This is the Internet version of the user'sguide. © Print only for private use.
6
Getting to know your phone
Charger and USB connector
Volume
buttons
Selection key
Back key
Activity menu
key
Navigation key
Selection key
C key
On/off key
Infrared port
Microphone

This is the Internet version of the user'sguide. © Print only for private use.
7
The icon display lights up when the phone is in silent
mode and shows information about new events and
battery charging. The external display shows
information such as time. Press a volume button to
activate the external display.
External
display
Camera lens
Icon display

This is the Internet version of the user'sguide. © Print only for private use.
8
Menu overview
PlayNow™* Internet* Entertainment
Online services*
Games
MusicDJ™
Record sound
Camera Messaging Camera album
Write new
Inbox
Email
RSS reader
Drafts
Outbox
Sent messages
Saved messages
My friends*
Call voicemail
Templates
Settings
File manager Contacts** Alarms
Camera album
Ringtones
Pictures
Themes
Web pages
Games
Applications
Other
New contact
Calls*** Organizer Settings
All tab
Answered tab
Dialled tab
Missed tab
Applications
Calendar
Tasks
Notes
Calculator
Synchronization
Timer
Stopwatch
Code memo
General
Sounds & alerts
Display
Calls
Connectivity*

This is the Internet version of the user'sguide. © Print only for private use.
9
Status bar icons
*Some menus are operator-, network- and subscription-dependent.
**Options when phone contacts are set to default. Options change
when SIM contacts are set to default.
***Use the navigation key to move across tabs in submenus. For
more information % 14 Navigating the menus.
Icon Description
GSM network signal strength.
Battery status.
Battery charging, appears with battery status icon.
Missed an incoming call.
Call and messaging alerts off, alarm on.
Text message received.
Email message received.
Picture message received.
Ongoing call.
Calendar reminder.
Task reminder.

This is the Internet version of the user'sguide. © Print only for private use.
10
Assembling your phone
Insert the SIM card and the battery to use your phone.
SIM card
When you register as a subscriber with a network operator,
you get a SIM (Subscriber Identity Module) card. The SIM
card keeps track of your phone number, the services
included in your subscription, and your contacts
information, among other things.
To insert SIM card and battery
1Remove the battery cover.
2Slide the SIM card into its holder with the contacts
facing down.
3Insert the battery with the label side up and the
connectors facing each other.
4Slide the battery cover into place.
Save contacts information on your SIM card before
you remove it from another phone. Contacts may
have been saved in the phone memory
% 28 Contacts.

This is the Internet version of the user'sguide. © Print only for private use.
11
To charge the battery
1Connect the charger plug to the phone and to the mains.
The flash symbol on the charger plug must face
upwards.
2It may take 30 minutes for the battery icon to appear on
the screen.
3Wait approximately 2.5 hours or until the battery icon
indicates a full charge.
4Remove the charger plug by tilting it upwards.
Some functions use more battery power than others
so that your phone need more frequent charging.Talk
time or standby time may become shorter in time
and you may need a new battery. Only use Sony
Ericsson-approved batteries.
% 82 Battery.

This is the Internet version of the user'sguide. © Print only for private use.
12
PIN
You may need a PIN (Personal Identification Number) from
your network operator for your SIM card. When you enter
the PIN, each digit appears as *, unless it starts with
emergency number digits, for example 112 or 911. This is
so you can make emergency calls without entering a PIN.
% 28 Emergency calls. Press to delete numbers.
To turn the phone on and off
1Press and hold to turn the phone on and off.
2Enter your SIM card PIN, if requested.
3At first start-up, select the language for phone menus.
4}Yes if you want the setup wizard to help you with
instructions and tips. You have now reached standby
and are ready to make and receive calls.
If you enter the wrong PIN three times in a row, the
SIM card is blocked % 70 SIM card lock.

This is the Internet version of the user'sguide. © Print only for private use.
13
Shut down menu
Use the shut down menu to turn off the phone, turn silent
mode on or activate a profile. For more information about
profiles % 66 Profiles.
To open the shut down menu
Press and select an option from the list.
Making calls
During an incoming call, the keypad and outer rim of the
phone light up % 54 Light effects.
To make and receive calls
•Enter an area code and phone number. }Call to make
the call. }End call to end the call.
•When the phone rings }Answer to answer the call.
Help in your phone
Help and information are available in your phone at any
time.
To use the setup wizard
From standby select Menu }Settings }General }Setup
wizard and select an option:
• Settings download or
•Basicsetupor
• Tips and tricks.
Select Settings download to automatically receive the
settings you need for MMS and Internet usage. No
personal data will be transferred to or processed by
Sony Ericsson. Contact your network operator or
service provider for more information.

This is the Internet version of the user'sguide. © Print only for private use.
14
To view information about functions
Scroll to a function }Info if available.
Navigating the menus
The main menus are shown as icons. Some submenus
include tabs.
•Press the centre of the navigation key to go to the
main menus from standby or to select menu items.
•Press , , or to scroll through menus and
tabs.
•Press to go back one level in the menus or to end
a function or application.
•Press and hold to return to standby.
•Press to select the options shown immediately
above these keys on the screen.
•Press to delete items.
•Scroll to a menu item }Info to get help on selected
features.
•}More to enter a list of options.
Shortcuts
From standby you can use the predefined shortcuts to go
directly to a function:
•Press to start the camera.
•Press to write a new text message.
•Press to add a new contact.

This is the Internet version of the user'sguide. © Print only for private use.
15
To edit a standby shortcut
1From standby select Menu }Settings }General
}Shortcuts.
2Select a shortcut you want to edit }Edit.
3Scroll to and select a function }Shortcut.
Activity menu
Use the activity menu to view and handle new events, and
access bookmarks and shortcuts.
To open the activity menu
Press and use and to select a tab.
Activity menu tabs
• New events – such as missed calls and new messages.
• Running apps – applications that are running in the
background.
• My shortcuts – shortcuts you can add, delete and put in
a different order.
• Internet – access the Internet and your bookmarks.
•If you want new events to appear as pop-up text instead
of in the activity menu, Menu }Settings }General
}New events }Pop-up.
File manager
Files such as pictures, sounds, themes, games and
applications are saved in folders in the phone memory in
the file manager. Unrecognized files are saved in the
Other folder.
File information
If a file is protected, you may not be able to copy or send it.
View file information by highlighting the file }More
}Information.

This is the Internet version of the user'sguide. © Print only for private use.
16
To move or copy a file
1From standby select Menu }File manager. Select
a folder and scroll to a file }More }Manage file.
2Select Move or Copy.
3Select a folder or }New folder.
4Name the folder }OK.
5}Paste.
To select several files
1From standby select Menu }File manager and select a
file }More }Mark.
2}Mark several or }Mark all. To select files scroll and
}Mark or }Unmark.
To check memory status
From standby select Menu }File manager }More
}Memory status.
Transferring files
For more information % 63 Transferring files.
Languages
Select the language for phone menus and for writing.
To change the phone language
•From standby select Menu }Settings }General
}Language }Phone language select a language.
•From standby press 0000 for English or press
8888 for Automatic language, or press 0008
for Chinese.
To select writing languages
1From standby select Menu }Settings }General
}Language }Writing language.
2Scroll and }Mark to select languages }Save.

This is the Internet version of the user'sguide. © Print only for private use.
17
Entering letters
To enter letters using multitap text input
Scroll to a function where text input is possible, for
example, Menu }Messaging }Write new }Text
message.
•Press – until the desired character appears.
•Press to shift between capitals and lower-case letters.
•Press and hold – to enter numbers.
•Press to delete letters and numbers.
•Press to add a space.
•Press for the most common punctuation marks.
Press and hold to change writing method..
T9™ Text Input
The T9™ Text Input method uses a built-in dictionary to
recognize the most commonly used word for each
sequence of key presses. This way, you press each key
only once, even if the letter you want is not the first letter
on the key.
Multitap input only applies when Latin characters are
selected as writing language.

This is the Internet version of the user'sguide. © Print only for private use.
18
To enter letters using T9™Text Input
1Scroll to a function where text input is possible, for example,
Menu }Messaging }Write new }Text message.
2For example, if you want to write the word “Jane”, press
, , , .
3If the word shown is not the one you want, press or
repeatedly to view alternative words. To accept a
word and add a space, press . To accept a word
without adding a space, press .
4Continue writing your message. To enter a punctuation
mark, press and then or repeatedly. Accept
and add a space by pressing .
To add words to the T9™Text Input dictionary
1While entering letters }More }Spell word.
2Edit the word by using multitap input. Use and
to navigate between letters. To delete a character, press
. To delete the entire word, press and hold .
3When you have edited the word }Insert. The word is
added to the T9™ Text Input dictionary. Next time you
enter this word using T9™Text Input, it appears as in
the alternative words.
To select another writing method
Press and hold to select another writing method.
Options list
}More to view options when entering letters.

This is the Internet version of the user'sguide. © Print only for private use.
19
Chinese input
This mobile phone has different input methods for entering
Chinese characters:
•Stroke input
•Pinyin input
You can use these methods, for example, to enter Chinese
names and Chinese short messages.
Switching between Chinese input methods
In the Chinese editing mode, you can select and switch
quickly to another input method by pressing and
holding .
General instructions
Regardless of which input method you choose, your phone
has a function to speed up the entry of Chinese characters.
Whenever you enter a stroke or a Pinyin letter, a candidate
row of the most frequently used characters containing that
stroke or relating to that letter appears at the bottom of the
screen.
If the character you want is not displayed in the candidate
row, press to present another candidate row. Continue
pressing until the character you want is displayed.
Alternatively, you can enter the next stroke or Pinyin letter,
and a new set of characters will immediately be displayed
in the candidate row. To go back to the previous row, press
. To select a character in the candidate row, press the
navigation key or press and hold the key corresponding to
the number above the character you want to enter.
