Sony SLV-AV100U User manual

SONY.
Integrated |
Amplifier|Video
Cassette Recorder
Operating Instructions
VHS
lic FFa
verplis+.
SLV-AV100U/C

WARNING
To prevent fire or shock hazard, do not expose
the unit to rain or moisture.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
This symbol is intended to alert the user to
the presence of uninsulated “dangerous
voltage” within the product’s enclosure that
may be of sufficient magnitude to constitute
a risk of electric shock to persons.
This symbol is intended to alert the user to
the presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
CAUTION
To prevent electric shock, do not use this polarized AC plug
with an extension cord, receptacle or other outlet unless the
blades can be fully inserted to.prevent blade exposure.
Precautions
Safety
¢ Operate the unit only on 120 V AC, 60 Hz.
¢ If anything falls into the cabinet, unplug the unit and
have it checked by qualified personnel before operating it
any further.
* One blade of the plug is wider than the other for the
purpose of safety and will fit into the power outlet only
one way. If you are unable to insert the plug fully into the
outlet, contact your Sony dealer.
¢ Unplug the unit from the wall outlet if you do not intend
to use it for an extended period of time. To disconnect the
cord, pull it out by the plug, never by the cord.
Installing
¢ Allow adequate air circulation to prevent internal heat
buildup.
¢ Do not place the unit on surfaces (rugs, blankets, etc.) or
near materials (curtains, draperies) that may block the
ventilation slots.
¢ Do not install the appliance in a confined space, such as a
bookcase or built-in cabinet.
¢ Do not install the unit near heat sources such as radiators
or air ducts, or in a place subject to direct sunlight,
excessive dust, mechanical vibration or shock.
2 Introduction
¢ Do not install the unit in an inclined position. It is
designed to be operated in a horizontal position only.
¢ Keep the unit and cassettes away from equipment with
strong magnets, such as microwave ovens or large
loudspeakers.
* Do not place heavy objects on the unit.
¢ Ifthe unit is brought directly from a cold toa warm
location, moisture may condense inside the VCR and cause
damage to the video head and tape. When you first install
the unit, or when you move it from a cold toa warm
location, wait for about one hour before operating the unit.
information
For customers in the USA’
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following
measures:
¢ Reorient or relocate the receiving antenna.
¢ Increase the separation between the equipment and
receiver.
¢ Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
¢ Consult the dealer or an experienced radio/TV technician
for help.
You are cautioned that any changes or modifications not
expressly approved in this manual could void your authority
to operate this equipment.
Caution
Television programs, films, video tapes and other materials
may be copyrighted. Unauthorized recording of such
material may be contrary to the provisions of the copyright
laws. Also, use of this recorder with cable television
transmission may require authorization from the cable
television transmission and/or program owner.
Owner's record
The model number is located at the rear and front of the unit
and the serial number on the top. Record these numbers in
the spaces provided below. Refer to them whenever you call
upon your Sony dealer regarding this product.
Model No.
Serial No.

Table
of
contents
Getting
Started
4 Step1: Unpacking
5 Step2: Setting up the remote commander
6 Step3: Speaker systems hookup
8 Step4: Various audio/video hookups
11. Step5: TV antenna or cable hookups
30 Adjusting the SOUND SET with EASY SET UP
33 = Setting the clock
35 ~—- Setting up cable box contro}
39 _— Presetting channels
43 = Setting up VCR Plus+ *
45‘ Presetting radio stations
Basic VCR / Radio Operations
47 ‘Playing a video tape
49 Using the pre-programed sound fields
50 ~=Recording TV programs
51 ~—- Recording TV programs using VCR Plus+
54 Setting the timer manually
56 Checking/changing/cancelling timer settings
58 Listening to the radio
Audio/Video Equipment Operations
59 Selecting the equipment
62 Controlling VCRs
64 Controlling the TV
66 Playing back a CD
67 Controlling a cassette deck
69 Controlling a DAT deck
71 ~— Controlling an MD deck
73 ~=—- Controlling an LD player
m2 Sound Field Operations
75 ‘Taking advantage of the sound fields
77 ‘Getting the most out of Dolby Pro Logic Surround*? sound
78 Customizing the sound fields
82 Reconfiguring the PROLOGIC and THEATER sound fields
Advanced VCR Operations
84 Playing/searching at various speeds
85 _ Recording TV programs using the quick timer
86 Recording stereo and bilingual programs
87 Searching using the index function
88 Adjusting the picture
* VCR Plus+ and PlusCode 89 Changing menu options
are trademarks of Gemstar res =
Development Corporation. Editing
VER Ein vores 90 Recording from another VCR or-LD player
manufactured under
license from Gemstar
Development Corporation. Additional Information
91 Customizing the remote commander function buttons
* This unit uses the Dolby 92 General setup information
Surround system, 94 = Troubleshooting
manufactured under 97 Specifications
Hesnse front Dolby 98 Index to parts and controls
Laboratories Licensing 103 Index
Corporation.
:
;
DOLBY, the double-D Back Quick reference to using the VCR
symbol 0d, and PRO Cover
LOGIC are trademarks of
Dolby Laboratories
Licensing Corporation.
Introduction |

48 AT ABSA IPP IP PLE NEP LANES IAS SIMII SII LS ESI SERA EAAOP IT OPS 0 0 A000
Step 1 Unpacking
Check that you have received the following items with the unit:
e Remote commander e AM loop antenna
¢ Size AA (R6) batteries ¢ FM wire antenna
¢ 75-ohm coaxial cable with
F-type connectors
¢ Video cable
(1 phono to 1 phono)
4 Getting Started

Setting up the remote commander
Inserting the batteries
Insert two size AA (R6) batteries matching the + and — on the batteries to the diagram inside
the battery compartment.
Using the remote commander
You can use this remote commander to operate this unit, a TV, other VCRs, an LD deck, CD
player, cassette deck, DAT deck, and MD deck (all equipment must be made by Sony).
For details on how to operate other equipment with this remote commander, see “Audio/
Video Equipment Operations” from page 59.
Notes
¢ The remote commander is initially set to control this unit. However, if it doesn’t control the unit, press
VHS TUNER first. If the remote commander still doesn’t operate, read “Controlling VCRs” on page 62
first.
¢ With normal use, the batteries should last about three to six months.
¢ If you do not use the remote commander for an extended period of time, remove the batteries to avoid
possible damage from battery leakage.
¢ Do not use a new battery with an old one.
* Do not use different types of batteries.
-Getting Started
5

Speaker systems hookup
To get the best possible sound from the unit, connect front (left and right), center, and rear
(left and right) speakers. You need to connect either the center or rear speakers as well as the
front speakers to enjoy Dolby Pro Logic Surround sound.
Before you connect...
¢ Prepare speaker cords (one for each speaker) (not supplied).
¢ Be sure to match the speaker cords to the appropriate terminals on the components: + to +,
and — to ~. (If the cords are reversed, the sound will be distorted and the bass sound will
not be reproduced well.)
¢ Do not connect the AC power cord until you finish all the connections through “Step 5:
TV antenna or cable hookups” on page 11.
¢ Be sure to make connections firmly to avoid hum and noise.
Rear right speaker Center speaker Rear left speaker
5 Active woofer
Front right speaker Front left speaker
1 Connect the front speakers to the FRONT FRONT SPEAKERS
SPEAKERS LR connectors. 8
Twist about 15 mm of the stripped ends of the cord. Then
insert the stripped ends into the connectors as shown on the
right.
he
2
(+)
tk
2 Connect the center speaker to the SURROUND
SPEAKERS CENTER connectors.
Repeat step 1 above for the center speaker.
If you don’t have a center speaker, skip this step.
SURROUND
SPEA
HEAR KERS
6 Getting Started

Connect the rear speakers to the SURROUND
SPEAKERS REAR UR connectors.
Repeat step 1 above for the surround speakers.
If you don’t have rear speakers, skip this step.
SHBBOUND
7 SPEAK R
“REAR.| ERS
Note
¢ Be sure to connect both left and right speakers. If you connect only
one speaker, the rear speaker won't reproduce the sound.
Placing the speakers
For optimum surround sound effect, place your speakers as shown below.
Rear speaker
60-90 cm
45° Front speaker
a @& oO
Tips
*¢ Position the center speaker so the face of the speaker is aligned evenly with, or slightly behind the faces of
the front left and right speakers.
¢ Mount the surround (rear) left and right speakers on the walls so they face each other.
¢ Position the front left and right speakers and center speaker as close to the same height as possible.
Connecting an active woofer
For further sound improvement, connect an active woofer to MIX OUT with an audio cable
(not supplied). The active woofer will increase bass response. The position of the active
woofer does not affect the sound quality very much.
This unit Active woofer
i
Audio cable (not supplied)
Listening through the headphones
Connect the headphones to PHONES. No sound will be reproduced from the speakers.
PHONES et
Getting Started 7

Various audio/video hookups
The following connections with various audio/video equipment are recommended
examples. The actual connections may vary depending on the equipment you have.
Before you connect....
¢ Prepare audio (not supplied) and video cables referring to the following table.
Audio cable Video cable
white (Q <CA n> White () Yellow <(ijmm————aEI > Yellow
Red (R) <( Emm Red (R)
Equipment Necessary cable for each piece of equipment
Tuner/CD player One audio cable
MD deck/DAT deck/cassette deck . Two audio cables
Satellite tuner/LD player/other VCR One video cable and one audio cable
TV One video cable and one audio cable
Monitor One video cable
¢ Turn off the power to all equipment before making any connections.
¢ Do not connect the AC power cord until all of the connections are complete.
¢ Be sure to make connections firmly to avoid hum and noise.
FM wire antenna
AUDIO 4% VIDEO
Cassette deck OUT OUT
AM too
p
antena = RECIN #4 44 REC OUT
cA: Signal flow
vy ¥ OUT
a HA i or
Other VCR
m> to wall outlet
8 Getting Started

Connect your audio/video equipment using audio
and video cables (not supplied) referring to the
illustration on page 8.
Make sure you connect the audio and video cable plugs to
jacks of the same color.
Connect the AC power cord to the wail outlet.
Connecting to the front VIDEO 2 INPUT jacks
Video game I
I
I AUDIO OUT
'¢ oe
i
e ik x
VIDEO AUdio/video Se | 075-0
cable (not [@90 Qo0dc= © |
| OUT Se a, CL
VIDEO CLAUDIO R
VIDEO 2 INPUT
cs : Signal flow
Notes
¢ Make sure you connect the audio/video plugs to jacks of the same color.
¢ If the other VCR is a monaural type, connect only the VIDEO and AUDIO L jacks.
Connecting to the AC OUTLET
You can connect an audio component (or components through an optional multi-outlet
extension cord) to AC OUTLET on the rear of the unit. The power is supplied to AC
OUTLET while the unit is turned on. The power supply stops when you turn off the unit.
Using this function, you can turn on and turn off all the audio components connected to AC
OUTLET at the same time if you leave those components’ power switches on.
Cautions
¢ Make sure you comply with the laws and regulations in your country for this connection.
¢ Make sure that the power consumption of the components connected to AC OUTLET doesn’t exceed 120
watts. Do not connect high-wattage electrical home appliances such as electric irons, fans, or TVs to this
outlet.
Notes
¢ The power will not be supplied to the components as long as the unit is turned off. Any electronic memory
of the components may be cleared if you make this connection.
¢ Some audio components may not turn on with this connection.
_ Getting Started 9

Step 4
10
Getting Started
Various audio/video hookups (continued)
Connecting FM/AM antennas
To receive radio broadcasts with this unit, connect the FM/AM antennas (supplied).
FM wire antenna
After connecting
the
wire
antenna,
Adjust
the
keep
it
as
direction.
horizontal
as
possible.
If AM reception is poor
We recommend that you purchase and connect the optional Sony antenna to the unit if
reception is weakened by ferroconcrete used in the construction of your apartment or
building.
If you have poor FM reception
Connect a 75-ohm coaxial cable (not supplied) to an FM outdoor antenna.
FM outdoor antenna
\ Receiver
ANTENNA
Note
* To prevent noise pick-up, keep the AM loop antenna away from the unit and TV. When the noise is not
cleared yet, turn off the TV. Bs

* DSS® is a registered
trademark of
DIRECTV, Inc., a
unit of Hughes
Electronics
Corporation.
TV antenna or cable hookups
Selecting the best hookup option
There are many ways in which your VCR can be hooked up. To hook up your VCR so that it
works best for you, first scan through the table below. Then use the accompanying diagrams
and procedures on the following pages to set up your VCR.
If you have Use Refer to
TV that has video input Video (V) hookup, then follow one Page 12
: of the hookups below.
Cable box that is compatible with the Hookup 1 Pages 13 to 15
VCR’s cable box control feature
No cable box or incompatible cable box Hookup 2 Pages 16 to18
‘with only a few scrambled channels
Antenna only, no cable TV Hookup 3 Pages 19 to 21
Incompatible cable box with many Hookup 4 Pages 22 to 24
scrambled channels
DSS* receiver Hookup 5 Pages 25 to 26
Incompatible cable box with only a few Hookup 6 Pages 27 to 29
scrambled channels, using an A/B switch
After you’ve completed the connections, follow the instructions for setup. During setup, if
you need more details on the procedure described, page numbers are provided where you
can find complete, step-by-step instructions.
After you’ve completed the setup, you’re ready to use your unit’s VCR. Procedures differ
depending on the hookup you used. For an overview, refer to “Quick reference to using the
VCR” on the back cover.
Before you get started
¢ Turn off the power to all equipment.
* Do not connect the AC power cords until all of the
connections are completed.
¢ Be sure you make connections firmly. Loose connections
may cause picture distortion.
¢ If your TV doesn’t match any of the examples provided,
see your nearest Sony dealer or qualified technician.
_ Getting Started 11
5
pezezs

a
Step 5 TV antenna or cable hookups (continued)
Video (V) hookup
You will get a better picture by connecting your TV (monitor) to MONITOR VIDEO OUT
jack as the illustration shown on page 8.
If you’re no planning to use your unit’s VCR to record programs
You’re finished setting up the unit’s VCR after you’ve made the connections shown on page
8.
If you want to record off-air or off your cable TV system
; Complete these connections first, and then go to the following pages for antenna or cable
( hookups.
Caution
Connections between the VCR’s VHF/UHF connector and the antenna terminals of the TV receiver should
be made only as shown in the following instructions. Failure to do so may result in operation that violates
: the regulations of the Federal Communications Commission regarding the use and operation of RF devices.
i Never connect the output of the VCR to an antenna or make simultaneous (parallel) antenna and VCR
connections at the antenna terminals or your receiver.
Notes to CATV system installer
: This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that
i provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be
connected to the grounding system of the building, as close to the point of cable entry as practical.
12 Getting Started

Using cable box
control
A Cable Mouse is available as an optional
accessory for this model. You can order
directly from Sony by calling 1-800-488-7669 -
and asking for Cable Mouse
RM-CM101.
$14.95 + $3.00
(shipping, handling
and aplicable sales tax)
Recommended use
You should use this hookup if you have a cable box, especially if your
cable system scrambles all or most channels. This hookup allows the
VCR’s cable box control feature to control the channel on the cable box,
simplifying the recording process. A list of compatible cable boxes is on
page 36.
What you can do with this hookup
¢ Record any channel using the VCR’s cable box control feature to select
channels on the cable box
What you can’t do
¢ Record with the cable box turned off
¢ Record one channel while watching another channel
Cable Mouse
n
(not supplied) peactry
VHF/UHF
Match the type of
connector on your
TV: A, B, or C.
For connector types
B and C, no UHF
connection is
required.
Positioning the Cable Mouse
Place the Cable Mouse so that it hangs out
over the cable box front.
Side view
_ Getting Started 13

'
:
g
3
t
eres ne ne ae
Step 5 TV antenna or cable hookups (continued)
Hookup 1: VCR setup
1 Set the RF UNIT switch to CH 3 or CH 4, whichever
channel is not used in your area. If both are used, set
the switch to either channel.
For details, see page 92.
If you made V connections (from page 12), you can
skip this step.
RF UNIT
CH3
CH4
0
eee:
a SS
[eats cocoe | Co es®
ef
eae
2 Turnon your cable box.
3 Press EASY SET UP on the VCR.
@ The CLOCK SET menu appears. Set the date and time
and press EXECUTE. For details, see page 33.
FruP GL OCK SET
(7171997 WED 12:00M
?
: [ts
: [es]
: (EXECUTE)
@ The CABLE BOX CONTROL menu appears. Select
ON. For details, see page 35. :
© Enter your cable box code number and press
CURSOR.
> [EXECUTE
14 Getting Started
© Select your cable box output channel and press
EXECUTE.
SELECT : [#4
SET : lee
NEXT : (EXECUTE!
@ The CENTER MODE selection menu appears.
Select the center mode and press EXECUTE.
For details, see page 30.
© The TEST TONE selection menu appears.
Set the volume of the center and rear speakers and
press EXECUTE.
For details, see page 31.
4
Normal display

Hookup 1: VCR Plus + channel setup
1 Find the VCR Plus+ Channel Listing in your
program guide. For details, see page 43.
2 If the channels in the program guide are different
from the channels that you actually use on your TV,
set the channels that are different as follows. For
details, see page 44.
@ Press MENU and select VHS MENU.
SOUND SET
@ Select SET VCR Plus+ CHANNELS.
TIMER SET / CHECK
TUNER PRESET
CLOCK SET.
CABLE BOX CONTROL
ADVANCED OPTIONS
SELECT : {# 4]
SET : [EXECUTE
Quit :
© Enter the program guide channel, then the channel
you use on your TV.
GUIDE_CH___TV_CH
Push keys to set
Program GUIDE CH
Or, push EXECUTE to see
VCR Plus+ CHANNEL LIST
Program guide channel
Your actual TV channel
© Press EXECUTE.
Getting Started
15

No cable box, or
incompatible cable
box with only a few
scrambled channels
8
3
*
3
4
rs
>
‘
é
4
)
‘
1
X
i
4
‘
Connect this cable
directly to your TV if
you don't have a
cable box:
LES as
16 Getting Started
(eee
ee
Te
el
Step 5 TV antenna or cable hookups (continued)
Recommended use
Use this hookup if you do not have a cable box. Also use this hookup if
your cable company cannot supply a cable box that is compatible with
the VCR’s cable box control feature, and your cable system scrambles
only a few channels.
What you can do with this hookup
¢ Record any unscrambled channel by selecting the channel on the VCR
What you can’t do
¢ Record scrambled channels that require a cable box
Rear of TV
Match the type
of connector on
your TV: A, B, or
C.
For connector
types B and C, no
UHF connection
is required.
Cable box

Hookup 2: VCR setup
1 Set the RF UNIT switch to CH 3 or CH 4, whichever
channel is not used in your area. If both are used,
set the switch to either channel.
For details, see page 92.
If you made V connections (from page 12), you can
skip this step.
RF UNIT
CH
CH4:
2 Press EASY SET UP on the VCR.
@ The CLOCK SET menu appears. Set the date and time
and press EXECUTE. For details, see page 33.
ET Ut CLOCK =ET
(3771997 WED 12:00m
SELECT :
SET :
NEXT : [EXECUTE
© The CABLE BOX CONTROL menu appears. Select
OFF and press EXECUTE. For details, see page 35.
: fey
: [EXECUTE!
© The TUNER PRESET menu appears. Set ANTENNA/
CABLE to CABLE and press EXECUTE. For details,
see page 39.
SELECT : [#4
NEXT : [EXECUTE]
* CANCEL : [EASY SET UP
© The AUTO PRESET starts.
EXECUTING
Nubbibtes,
Please wait=
Jett
© After completing AUTO PRESET, the CENTER MODE
selection menu appears.
Select the center mode, and press EXECUTE.
For details, see page 30.
: |EXECUTE)
© The TEST TONE selection menu appears.
Set the volume of the center and rear speakers and
press EXECUTE.
For details, see page 31.
SET UP is done
=>
4
Normal display
_ Getting Started 17

Pa © mah meine
27 AAA ANAL A AANA RRDAR IR ES a EY Pee ee:
Step
5
TV
antenna
or
cable
hookups
(continued)
Hookup
2:
VCR
Plus+
channel
setup
1 Find the VCR Plus+ Channel Listing in your
program guide. For details, see page 43.
2
If
the
channels
in
the
program
guide
are
different
from
the
channels
that
you
actually
use
on
your
TV,
set
the
channels
that
are
different
as
follows.
For
details,
see
page
44.
@ Press MENU and select VHS MENU.
SOUND SET
SELECT : [#4]
SET : (EXECUTE
Quit : [MENU]
@ Select SET VCR Plus+ CHANNELS.
TIMER SET / CHECK
ADVANCED OPTIONS
SELECT : {¢ #]
SET :
Quit : [MENU J
© Enter the program guide channel, then the channel
you use on your TV.
CR
GUIDE_CH» Tv gH
25-15)
Push keys to set
Program GUIDE CH
Or,
push to see
VCA Pius+ CHANNEL LIST
Program guide channel
Your actual TV channel
© Press EXECUTE.
18 Getting Started

Antenna hookup
Make
the
following
connections
if
you're
using
an
antenna
(if
you
don’t
have
cable
TV).
EXUse this hookup if you're using:
¢
VHF/UHF
antenna
(you
get
channels
2-13
and
channels
14
and
higher)
¢
UHF-only
antenna
(you
get
channels
14
and
higher)
¢ Separate VHF and UHF antennas
Rear of TV
VHF/UHF ;
=] A Match the type of
connector on your
VHF TV: A, B, or C.
B
(not supplied) YHF
or
'
'
’
'
ry
‘
‘
'
-
1
a
'
1
’
‘
'
‘
r
'
Le
VHF
Cc
(not supplied)
E]Use
this
hookup
if
you're
using
a
VHF-only
antenna
(you
get
channels
2-13
only)
Rear of TV
VHF/UHF watch the type of
connector on your
TV: A, B, or C.
For connector types
B and C, no UHF
connection is
required.
If
you
cannot
connect
your
antenna
cable
to
the
VCR
directly
If
your
antenna
cable
is
a
flat
cable
(300-ohm
twin
lead
cable),
attach
an
external
antenna
connector
(not
supplied)
so
you
can
connect
the
cable
to
the
VHF/UHF
IN
connector.
If
you
have
separate
cables
for
VHF
and
UHF
antennas,
you
should
use
a
U/V
band
mixer
(not
supplied).
For
details,
see
page
92.
Getting Started 19

Step 5
Hookup 6: VCR setup
1 Set the RF UNIT switch to CH 3 or CH 4, whichever
channel is not used in your area. If both are used, set
the switch to either channel.
For details, see page 92. If you made V connection
(from page 12), you can skip this step.
RF UNIT
CH3
CH4
[eave coco © |
2 Set the A/B switch to “A.”
3 Press EASY SET UP on the VCR.
@ The CLOCK SET menu appears. Set the date and time
and press EXECUTE. For details, see page 33.
ET UP CLOCK SET
(29/4 71997 WED 12:00
SELECT : (#4
SET 1 [e
*
NEXT : (EXECUTE!
@ The CABLE BOX CONTROL menu appears. Select
OFF and press EXECUTE. For details, see page 35.
CABLE BOY
CABLE BOX CONTROL
CABLE MOUSE [ON SFE
: fes
+ [EXECUTE
© The TUNER PRESET menu appears. Set ANTENNA/
CABLE to CABLE and press EXECUTE. For details,
see page 39.
: (EXECUTE
CANCEL : [EASY SET_UP|
28 Getting Started
TV antenna or cable hookups (continued)
© The AUTO PRESET starts.
AUTO PRESET
EXECUTING
NAbthbbta,
Please wait—
Seti
© After completing AUTO PRESET, the CENTER MODE
selection menu appears.
Select the center mode, and press EXECUTE.
For details, see page 30.
CENTER MODE
© The TEST TONE selection menu appears.
Set the volume of the center and rear speakers and
press EXECUTE.
For details, see page 31.
ET Ul
TEST TONE
SET UP is done
SELECT :
END :
4
Normal display
4 Preset the cable box output channel (usually 2, 3 or
4). For details, see page 35.
@ Press MENU. Then press CURSOR #/¥ to move the
cursor (8) to VHS MENU, and press EXECUTE.
@ Select TUNER PRESET.
TIMER SET / CHECK
TUNER PRESET
CLOCK SET
SET VCR Plus+ CHANNELS
CABLE BOX CONTROL
ADVANCED OPTIONS
SELECT :
© Enter the cable box output channel. Set MANUAL
SET to ADD and press EXECUTE.
TUMER PRE SET
ANTENNA / CABLE/A
AUTO PRESET
fASNUAL SET
AFT
FINE TUNING
SELECTCH -:
ADD/ERASE -
