XM-255EX/255NX
SERVICE MANUAL
STEREO POWER AMPLIFIER
SPECIFICATIONS
Canadian Model
AEP Model
E Model
XM-255EX
UK Model
XM-255NX
Photo : XM-255EX

2
Specifications ............................................................................. 1
1. GENERAL ....................................................................... 3
2. DISASSEMBLY
2-1. Main Board Removal ...................................................6
3. DIAGRAMS
3-1. Block Diagram..............................................................7
3-2. Printed Wiring Boards ..................................................8
3-3. Schematic Diagrams .....................................................9
4. EXPLODEDVIEW...................................................... 10
5. ELECTRICAL PARTS LIST.................................... 10
TABLE OF CONTENTS

3
SECTION 1
GENERAL This section is extracted from
instruction manual.

4

5

6
SECTION 2
DISASSEMBLY
Note : Follow the disassembly procedure in the numerical order given.
2-1. MAIN BOARD REMOVAL
1 Two screws (+BTP3x4)
4 Screw
(+BTP3x8)
5 Two screws
(+BTP3x6)
Heat sink
8S crew
(+BTP3x4)
9 Screw
(+BTP3x4)
6 Two screws
(+BTP3x6)
2 Two screws (+BTP3x4)
3 Bottom plate
7 Two screws (+BTP3x8)
0 Main board ( Remove the direction of arrow)


XM-255EX/255NX
7
7
SECTION 3
DIAGRAMS
3-1. BLOCK DIAGRAM
DIFFERENTIAL
AMP
Q403
31
PRE AMP
IC101(2/2)
LPF
IC201(2/2)
CNJ301(4P)
INPUT
FILTER
(MONO)
HIGH
LEVEL
INPUT
L
R
2
CN201
3 1
FILTER
IC301(2/2)
3 1
VR101
VR101(3/4),VR101(4/4)
SW501
FILTER
LPF
OFF
DRIVE AMP
Q404
SWITCH
Q401
DRIVE AMP
Q408
BIAS
Q406,407
POWER AMP
Q410
POWER AMP
Q411
DIFFERENTIAL
AMP
Q402
DRIVE AMP
Q405
DRIVE AMP
Q409
SPEAKER
OUT
L+R MONO
CNJ101
(3/4)
OUTPUT
L
(THROUGH)
CNJ101
(4/4)
LEVEL
VR102
VR102(2/2)
TEST TONE +B
1
OP AMP
OP AMP
IC401 (1/2)
2
37
IC401 (2/2)
5
6
B+
B+
B–
B–
OVER LOAD
DET
Q312
L
R
DIFFERENTIAL
AMP
Q303
57
PRE AMP
IC101(1/2)
SW501
LPF
IC201(1/2)
OUTPUT
FILTER
5 7
FILTER
IC301(1/2)
5 7
VR101
VR101(1/4),VR101(2/4)
SW501
FILTER
D905
OVER
CURRENT
POWER/PROTECTOR
LPF
OFF
DRIVE AMP
Q304
SWITCH
Q301
DRIVE AMP
Q308
BIAS
Q306,307
POWER AMP
Q310
POWER AMP
Q311
DIFFERENTIAL
AMP
Q302
DRIVE AMP
Q305
DRIVE AMP
Q309
CNJ101
(1/4)
INPUT
R
(THROUGH)
CNJ101
(2/4)
LEVEL
VR102
VR102(1/2)
CN101
REMOTE
PROTECT
LATCH
Q904,905
(20A)
09
F901
DC-DC CONVERTER
CONTROL
IC901
T901
DC-DC CONVERTER
TRANSFORMER
LED
DRIVE
SWITCH
Q909,910
TH901 TH902
+12V
PH901
DC DET
B+
D905
LED
DRIVE
SWITCH
Q911,913
D906
LED
DRIVE
SWITCH
Q914,915
D907
D906
OFFSET
D907
THERMAL
16 114
12
ON/OFF
CONTROL OSC
3
(CURRENT CHECK)
RECT
D908,909
PROTECT
LATCH
Q906,907
OFFSET DET
Q953-954
LINE CONTROL
Q941,942
(CURRENT CHECK)
DRIVER
Q946,949
B+
SWITCH
Q901,902
B+
ON/OFF
DRIVE
Q947
ON/OFF
DRIVE
Q948
+REG
Q944
-REG
Q933
6
OVER LOAD
DET
Q412
10 9
VCC
Q908
D904
• Signal path
F: AUDIO
POWER
ON/OFF
Q903
THIS NOTE IS COMMON FOR
PRINTED WIRING BOARDS AND
SCHEMATIC DIAGRAMS.
(In addition to this, the necessary
note is printed in each block.)
For schematic diagrams.
Note:
• All capacitors are in µF unless otherwise
noted. pF:µµF 50 WV or less are not in-
dicated except for electrolytics and
tantalums.
• All resistors are in Ωand 1/4W or less un-
less otherwise specified.
•C: panel designation.
•U: B+ Line.
• Power voltage is dc 14.4V and fed with
regulated dc power supply from ACC and
BATT cords.
• Voltages and waveforms are dc with re-
spect to ground under no-signal condi-
tions.
no mark : POWER ON
*: Impossible to measure
• Voltage are taken with a VOM (Input im-
pedance 10 MΩ).
Voltage variations may be noted due to
normal production tolerances.
• Signal path.
F: AUDIO
For printed wiring boards.
Note:
•X:partsextractedfromthe compo-
nent side.

8
XM-255EX/255NX
8
• IC BLOCK DIAGRAM
IC901 TL494CN
4
12 3 5 6 7 8
91016 15 14 13 12 11
ERROR
0.1V
REG.
REF.
OSC
ERROR
3-2. PRINTED WIRING BOARDS
• Semiconductor
Location
D301 F-4
D302 G-4
D401 D-4
D402 E-4
D501 B-2
D903 C-5
D904 D-7
D908 A-3
D909 B-3
D912 C-5
IC101 F-3
IC201 D-3
IC301 D-2
IC401 B-2
IC901 C-6
Q301 F-4
Q302 G-4
Q303 F-4
Q304 F-5
Q305 G-5
Q306 G-5
Q307 G-5
Q308 G-5
Q309 G-5
Q310 F-6
Q311 G-6
Q312 G-6
Q401 D-4
Q402 E-4
Q403 D-4
Q404 D-5
Q405 E-5
Q406 E-5
Q407 E-5
Q408 D-5
Q409 E-5
Q410 D-6
Q411 E-6
Q412 E-6
Q901 C-7
Q902 C-7
Q903 C-7
Q904 D-7
Q905 D-7
Q906 D-7
Q907 D-7
Q908 D-7
Q941 C-5
Q942 C-4
Q943 A-2
Q944 A-2
Q946 B-5
Q947 A-6
Q948 B-6
Q949 B-5
Q963 C-4
Q964 D-4
Q965 C-4
Ref. No. Location
• WAVEFORMS
1
2
3
4
12.8Vp-p
31
µ sec
12Vp-
p
31 µ sec
28Vp-
p
31 µ sec
56Vp-
p
31 µ sec
SW501
TEST
TONE
SW101
FILTER
OFF
LPF
VR101
FILTER
VR102
LEVEL
(THROUGH)
Q411
Q310
Q311
CN201
SPEAKER OUT
REMOTE
+12V
GND
L
L+R MONO
R
CNJ301
HIGH LEVEL
INPUT
R
OUTPUT
L
L
R
L
R
L
R
L
R
(MONO)
INPUT
IC301
IC901
9
8
16
1
IC201
IC401
IC101
ZD910
ZD911
D501
Q946
T901
Q949
ZD913
Q942
Q941
D912
D903
Q964
Q965
Q963
Q401
D401Q403
Q402
D402
Q407
Q412
Q906
Q904
Q903
Q902
ZD901 ZD902
D904
Q908
Q905
Q907
Q312
Q303
D301
Q307
Q302
D302
Q944 Q943
EE
85
41
85
41
SW101
CNJ101
E
E
E
1
E
E
E
E
E
E
E
E
E
E
S
S
E
Q901
CN901
V+
GND
THR
CUR
OFF
CN901
F901
PL901
Q301
Q304
Q305
D908
D909
Q308
Q309
E
E
E
E
E
E
Q306
Q406
Q409
Q405
Q408
Q404
Q948
Q947
E
E
E
E
E
E
E
SW501
85
41
85
41
-1
-2
VR101
-1-2
VR102
E E
E
E
E
E
E
E
E
E
E
EE
-3-4
R512 R506
R510 C504
C503
R511
R508
R509
C501
R503
R501
R502
R505
R507
R504C502
J195
R115 R215
R216
R116
R117
R217
J196
J193
C118
C218 R191
R212
J194
R112
R113
R213
C200 R957
C937
C934 R958
J192
J190
J995 C100
C116
C117
C217
R201
R202
C221
C222
R101
R102
R104
C203
R205 C207
R206 C206
C505
R105
R203 R204
R103 C107
R107 C106
J197
R514
C204
R106 C103
C104
R210
R110
C947
C933
R948
R947
R949
R941
R943 R944
TH902
R953
R954
R952
C962
R962
R955
R961 R965
R963
C931 R960
R964
R907
R915
R913
R918
J994
R959
R916
R917
J991
R401
R405
R406
R413
R410
R404
R403
R407 R411
R412
J491
R402
R416
R415
R419
R414
R422
R421
R424
R418
R909
R910
R911 R912
R919
R921 R920
J922
R923
R922 C912
R926 C913
R925
R924
R940
R938
R939
R930
C902
R902 R901
R903
C903
R904
R905
R906
R423
R323
R324
R321
R322
R315
R314
R316
R318
R305
R306
R313
R310
R304
R303
R307
R311
R312
R302
R956
R301
R319
R945
R946
C402
C216
R914
C908
C302
C210
C943
C941
C944
L901
J934 J933
J917
J931 C906
C904
J924
J925
J923
J922
J921
C401
C403
J410
J935
C901
J944
J943
J945
J940
J941
J939
J938
J937
C910
C907
J936
C909
J951
C408
J431
J331
J952
R420
TH901
R426 R425
R326 R325
C308
R320
J311
J314
R317
C304
R309
R308
C303
J313
J427 J321
J323
J322
J423
J421
J422
J315
C301
J111
J103
J112
J113
J115 J114
C209
J107
J108
C105
J109 J110
R139
R239
J101
J102
C102
J105
J104
J106
C201
C101
C202 J118 C212
R111
J117
J119
C936
R211
J120
J327
C112
C211
C110
C213
C111
J122
J121
J123
J126 C214
C113
C114
J511
J513
J510
C951
C950
C949
J911 J913
J512
C945
C946
R951 R950
J912
C952 C953
C948
J914
J928
J915
J916
C961
J920
C930
J918
J919
C905
J932
R409R408
J411
J412
R417
C404
J420
J329
J328
J325
J326
J429
J428
J425
J426
J312
J415
PH901
F901
20A
Q410
87
A
B
09 65432
C
E
D
G
F
1
MAIN BOARD
11
1-677-608-
09 2
B
A
11-677-341- 11
R934
R928
R927
R931
R929
R933
R932
R980
R937
R936
R935
R942
Q911
Q913
Q914
Q910
Q909
D906 D907 D905
PN901
Q915
LED BOARD
E
E
E
EE
E
V+
GND
THR
CUR
OFF

XM-255EX/255NX
9
9
3-3. SCHEMATIC DIAGRAMS

11
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C906 1-126-933-11 ELECT 100uF 20% 16V
C907 1-130-471-00 MYLAR 0.001uF 5% 50V
C908 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C909 1-128-551-11 ELECT 22uF 20% 25V
C910 1-128-551-11 ELECT 22uF 20% 25V
C912 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C913 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C930 1-107-701-11 ELECT 47uF 20% 25V
C931 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C933 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C934 1-115-340-11 CERAMIC CHIP 0.22uF 10% 25V
C936 1-104-665-11 ELECT 100uF 20% 25V
C937 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C941 1-130-491-00 MYLAR 0.047uF 5% 50V
C943 1-111-042-11 ELECT 2200uF 20% 16V
C944 1-111-042-11 ELECT 2200uF 20% 16V
C945 1-126-933-11 ELECT 100uF 20% 16V
C946 1-126-933-11 ELECT 100uF 20% 16V
C947 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C948 1-126-954-11 ELECT 3300uF 20% 35V
C949 1-126-954-11 ELECT 3300uF 20% 35V
C950 1-130-495-00 MYLAR 0.1uF 5% 50V
C951 1-130-495-00 MYLAR 0.1uF 5% 50V
C952 1-126-963-11 ELECT 4.7uF 20% 50V
C953 1-126-963-11 ELECT 4.7uF 20% 50V
C961 1-107-701-11 ELECT 47uF 20% 25V
C962 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
< CONNECTOR >
CN101 1-694-691-11 TERMINAL BOARD (3P)(REMOTE/+12V/GND)
CN201 1-694-690-11 TERMINAL BOARD (4P)(SPEAKER OUT)
< JACK >
CNJ101 1-779-078-41 JACK, PIN 4P (INPUT/OUTPUT)
CNJ301 1-794-219-11 CONNECTOR (4P)(HIGH LEVEL INPUT)
< DIODE >
D301 8-719-801-78 DIODE 1SS184-TE85L
D302 8-719-801-78 DIODE 1SS184-TE85L
D401 8-719-801-78 DIODE 1SS184-TE85L
D402 8-719-801-78 DIODE 1SS184-TE85L
D501 8-719-801-78 DIODE 1SS184-TE85L
D903 8-719-801-78 DIODE 1SS184-TE85L
D904 8-719-801-78 DIODE 1SS184-TE85L
D908 8-719-912-51 DIODE ESAC25-02C
D909 8-719-918-73 DIODE ESAC25-02N
D912 8-719-801-78 DIODE 1SS184-TE85L
< FUSE >
F901 1-532-732-11 FUSE (BLADE TYPE)(AUTO FUSE)(20A)
< IC >
IC101 8-759-394-81 IC NJM4559M-TE2
IC201 8-759-394-81 IC NJM4559M-TE2
IC301 8-759-970-66 IC LM833M-FL63
IC401 8-759-394-81 IC NJM4559M-TE2
IC901 8-759-904-94 IC TL494CN
< JACK >
J190 1-216-295-00 SHORT 0
J191 1-216-295-00 SHORT 0
J192 1-216-295-00 SHORT 0
J193 1-216-295-00 SHORT 0
J194 1-216-295-00 SHORT 0
J195 1-216-295-00 SHORT 0
J196 1-216-295-00 SHORT 0
J197 1-216-295-00 SHORT 0
J491 1-216-295-00 SHORT 0
J991 1-216-295-00 SHORT 0
J992 1-216-296-00 SHORT 0
J994 1-216-295-00 SHORT 0
J995 1-216-295-00 SHORT 0
< COIL >
L901 1-411-180-11 INDUCTOR 0uH
< PHOTO INTERRUPTER >
PH901 8-749-017-47 IC KPC117GR
< PILOT LAMP >
PL901 1-518-540-11 LAMP, PILOT
< TRANSISTOR >
Q301 8-729-052-02 TRANSISTOR KTD1304
Q302 8-729-232-66 TRANSISTOR 2SA1618-YGRTE85L
Q303 8-729-014-86 TRANSISTOR 2SC4207-YGRTE85L
Q304 8-729-037-03 TRANSISTOR KTA1266GR-AT
Q305 8-729-036-90 TRANSISTOR KTC3198BL-AT
Q306 8-729-900-97 TRANSISTOR 2SC1740
Q307 8-729-034-50 TRANSISTOR KTA1504
Q308 8-729-052-04 TRANSISTOR KTD600K
Q309 8-729-052-03 TRANSISTOR KTB631K
Q310 8-729-052-06 TRANSISTOR KTD718
Q311 8-729-052-05 TRANSISTOR KTB688
Q312 8-729-034-51 TRANSISTOR KTC3875
Q401 8-729-052-02 TRANSISTOR KTD1304
Q402 8-729-232-66 TRANSISTOR 2SA1618-YGRTE85L
Q403 8-729-014-86 TRANSISTOR 2SC4207-YGRTE85L
Q404 8-729-037-03 TRANSISTOR KTA1266GR-AT
Q405 8-729-036-90 TRANSISTOR KTC3198BL-AT
Q406 8-729-900-97 TRANSISTOR 2SC1740
Q407 8-729-034-50 TRANSISTOR KTA1504
Q408 8-729-052-04 TRANSISTOR KTD600K
Q409 8-729-052-03 TRANSISTOR KTB631K
Q410 8-729-052-06 TRANSISTOR KTD718
Q411 8-729-052-05 TRANSISTOR KTB688
Q412 8-729-034-51 TRANSISTOR KTC3875
Q901 8-729-052-01 TRANSISTOR KTA1023
Q902 8-729-034-50 TRANSISTOR KTA1504
Q903 8-729-034-51 TRANSISTOR KTC3875
Q904 8-729-034-50 TRANSISTOR KTA1504
Q905 8-729-034-51 TRANSISTOR KTC3875
Q906 8-729-034-50 TRANSISTOR KTA1504
Q907 8-729-034-51 TRANSISTOR KTC3875
MAIN

12
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
Q908 8-729-034-51 TRANSISTOR KTC3875
Q941 8-729-034-50 TRANSISTOR KTA1504
Q942 8-729-034-51 TRANSISTOR KTC3875
Q943 8-729-037-03 TRANSISTOR KTA1266GR-AT
Q944 8-729-036-90 TRANSISTOR KTC3198BL-AT
Q946 8-729-034-51 TRANSISTOR KTC3875
Q947 8-729-051-99 TRANSISTOR STP55NE06FP
Q948 8-729-051-99 TRANSISTOR STP55NE06FP
Q949 8-729-034-51 TRANSISTOR KTC3875
Q963 8-729-034-51 TRANSISTOR KTC3875
Q964 8-729-034-50 TRANSISTOR KTA1504
Q965 8-729-034-51 TRANSISTOR KTC3875
< RESISTOR >
R101 1-216-081-00 METAL CHIP 22K 5% 1/10W
R102 1-216-081-00 METAL CHIP 22K 5% 1/10W
R103 1-216-089-00 RES-CHIP 47K 5% 1/10W
R104 1-216-089-00 RES-CHIP 47K 5% 1/10W
R105 1-208-291-11 RES-CHIP 4.7M 5% 1/10W
R106 1-216-089-00 RES-CHIP 47K 5% 1/10W
R107 1-216-089-00 RES-CHIP 47K 5% 1/10W
R110 1-216-089-00 RES-CHIP 47K 5% 1/10W
R111 1-259-428-11 CARBON 1K 5% 1/6W
R112 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R113 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R115 1-216-097-00 RES-CHIP 100K 5% 1/10W
R116 1-216-097-00 RES-CHIP 100K 5% 1/10W
R117 1-216-035-00 METAL CHIP 270 5% 1/10W
R139 1-216-471-11 METAL OXIDE 27 5% 3W
R201 1-216-081-00 METAL CHIP 22K 5% 1/10W
R202 1-216-081-00 METAL CHIP 22K 5% 1/10W
R203 1-216-089-00 RES-CHIP 47K 5% 1/10W
R204 1-216-089-00 RES-CHIP 47K 5% 1/10W
R205 1-216-089-00 RES-CHIP 47K 5% 1/10W
R206 1-216-089-00 RES-CHIP 47K 5% 1/10W
R210 1-216-089-00 RES-CHIP 47K 5% 1/10W
R211 1-259-428-11 CARBON 1K 5% 1/6W
R212 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R213 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R215 1-216-097-00 RES-CHIP 100K 5% 1/10W
R216 1-216-097-00 RES-CHIP 100K 5% 1/10W
R217 1-216-035-00 METAL CHIP 270 5% 1/10W
R239 1-216-471-11 METAL OXIDE 27 5% 3W
R301 1-216-073-00 METAL CHIP 10K 5% 1/10W
R302 1-216-234-00 RES-CHIP 33K 5% 1/8W
R303 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R304 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R305 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R306 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R307 1-216-085-00 METAL CHIP 33K 5% 1/10W
R308 1-259-430-11 CARBON 1.2K 5% 1/6W
R309 1-259-436-11 CARBON 2.2K 5% 1/6W
R310 1-216-025-00 RES-CHIP 100 5% 1/10W
R311 1-216-097-00 RES-CHIP 100K 5% 1/10W
R312 1-216-097-00 RES-CHIP 100K 5% 1/10W
R313 1-216-025-00 RES-CHIP 100 5% 1/10W
R314 1-216-047-00 RES-CHIP 820 5% 1/10W
R315 1-216-035-00 METAL CHIP 270 5% 1/10W
R316 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R317 1-249-907-11 CARBON 220 5% 1/4W
R318 1-216-308-00 METAL CHIP 4.7 5% 1/10W
R319 1-216-308-00 METAL CHIP 4.7 5% 1/10W
R320 1-205-991-11 METAL 0.1 10%
R321 1-216-049-00 RES-CHIP 1K 5% 1/10W
R322 1-216-049-00 RES-CHIP 1K 5% 1/10W
R323 1-216-113-00 METAL CHIP 470K 5% 1/10W
R324 1-216-073-00 METAL CHIP 10K 5% 1/10W
R325 1-249-883-11 CARBON 22 5% 1/4W
R326 1-249-883-11 CARBON 22 5% 1/4W
R401 1-216-073-00 METAL CHIP 10K 5% 1/10W
R402 1-216-234-00 RES-CHIP 33K 5% 1/8W
R403 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R404 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R405 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R406 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R407 1-216-085-00 METAL CHIP 33K 5% 1/10W
R408 1-259-430-11 CARBON 1.2K 5% 1/6W
R409 1-259-436-11 CARBON 2.2K 5% 1/6W
R410 1-216-025-00 RES-CHIP 100 5% 1/10W
R411 1-216-097-00 RES-CHIP 100K 5% 1/10W
R412 1-216-097-00 RES-CHIP 100K 5% 1/10W
R413 1-216-025-00 RES-CHIP 100 5% 1/10W
R414 1-216-047-00 RES-CHIP 820 5% 1/10W
R415 1-216-035-00 METAL CHIP 270 5% 1/10W
R416 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R417 1-249-536-11 CARBON 220 5% 1/4W
R418 1-216-308-00 METAL CHIP 4.7 5% 1/10W
R419 1-216-308-00 METAL CHIP 4.7 5% 1/10W
R420 1-205-991-11 METAL 0.1 10%
R421 1-216-049-00 RES-CHIP 1K 5% 1/10W
R422 1-216-049-00 RES-CHIP 1K 5% 1/10W
R423 1-216-113-00 METAL CHIP 470K 5% 1/10W
R424 1-216-073-00 METAL CHIP 10K 5% 1/10W
R425 1-249-883-11 CARBON 22 5% 1/4W
R426 1-249-883-11 CARBON 22 5% 1/4W
R501 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R502 1-216-073-00 METAL CHIP 10K 5% 1/10W
R503 1-216-689-11 METAL CHIP 39K 0.5% 1/10W
R504 1-216-689-11 METAL CHIP 39K 0.5% 1/10W
R505 1-216-073-00 METAL CHIP 10K 5% 1/10W
R506 1-216-073-00 METAL CHIP 10K 5% 1/10W
R507 1-216-073-00 METAL CHIP 10K 5% 1/10W
R508 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R509 1-216-102-00 RES-CHIP 160K 5% 1/10W
R510 1-216-102-00 RES-CHIP 160K 5% 1/10W
R511 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R512 1-216-073-00 METAL CHIP 10K 5% 1/10W
R514 1-208-291-11 RES-CHIP 4.7M 5% 1/10W
R901 1-216-073-00 METAL CHIP 10K 5% 1/10W
R902 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R903 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R904 1-216-186-00 RES-CHIP 330 5% 1/8W
R905 1-216-202-00 RES-CHIP 1.5K 5% 1/8W
R906 1-216-202-00 RES-CHIP 1.5K 5% 1/8W
R907 1-216-103-00 METAL CHIP 180K 5% 1/10W
R909 1-216-079-00 METAL CHIP 18K 5% 1/10W
R910 1-216-081-00 METAL CHIP 22K 5% 1/10W
R911 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
MAIN

13
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
R912 1-216-073-00 METAL CHIP 10K 5% 1/10W
R913 1-216-121-00 RES-CHIP 1M 5% 1/10W
R914 1-216-073-00 METAL CHIP 10K 5% 1/10W
R915 1-216-093-00 RES-CHIP 68K 5% 1/10W
R916 1-216-032-00 METAL CHIP 200 5% 1/10W
R917 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R918 1-216-089-00 RES-CHIP 47K 5% 1/10W
R919 1-216-073-00 METAL CHIP 10K 5% 1/10W
R920 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R921 1-216-073-00 METAL CHIP 10K 5% 1/10W
R922 1-216-073-00 METAL CHIP 10K 5% 1/10W
R923 1-216-073-00 METAL CHIP 10K 5% 1/10W
R924 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R925 1-216-073-00 METAL CHIP 10K 5% 1/10W
R926 1-216-073-00 METAL CHIP 10K 5% 1/10W
R930 1-216-073-00 METAL CHIP 10K 5% 1/10W
R938 1-216-073-00 METAL CHIP 10K 5% 1/10W
R939 1-216-073-00 METAL CHIP 10K 5% 1/10W
R940 1-216-089-00 RES-CHIP 47K 5% 1/10W
R941 1-216-190-00 RES-CHIP 470 5% 1/8W
R943 1-216-017-00 RES-CHIP 47 5% 1/10W
R944 1-216-017-00 RES-CHIP 47 5% 1/10W
R945 1-216-150-00 RES-CHIP 10 5% 1/8W
R946 1-216-150-00 RES-CHIP 10 5% 1/8W
R947 1-216-049-00 RES-CHIP 1K 5% 1/10W
R948 1-216-049-00 RES-CHIP 1K 5% 1/10W
R949 1-216-190-00 RES-CHIP 470 5% 1/8W
R950 1-259-436-11 CARBON 2.2K 5% 1/6W
R951 1-259-436-11 CARBON 2.2K 5% 1/6W
R952 1-216-049-00 RES-CHIP 1K 5% 1/10W
R953 1-216-073-00 METAL CHIP 10K 5% 1/10W
R954 1-216-085-00 METAL CHIP 33K 5% 1/10W
R955 1-216-096-00 RES-CHIP 91K 5% 1/10W
R956 1-216-121-00 RES-CHIP 1M 5% 1/10W
R957 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R958 1-216-049-00 RES-CHIP 1K 5% 1/10W
R959 1-216-210-00 RES-CHIP 3.3K 5% 1/8W
R960 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R961 1-216-073-00 METAL CHIP 10K 5% 1/10W
R962 1-216-121-00 RES-CHIP 1M 5% 1/10W
R963 1-216-073-00 METAL CHIP 10K 5% 1/10W
R964 1-216-073-00 METAL CHIP 10K 5% 1/10W
R965 1-216-073-00 METAL CHIP 10K 5% 1/10W
< SWITCH >
SW101 1-692-721-11 SWITCH, SLIDE (FILTER)
SW501 1-771-802-11 SWITCH (TEST TONE)
< TRANSFORMER >
T901 1-435-419-11 TRANSFORMER, DC-DC CONVERTER
< THERMISTOR >
TH901 1-810-506-21 THERMISTOR NTH5G39B223K01TE
TH902 1-809-664-51 THERMISTOR, POSITIVE
< VARIABLE RESISTOR >
VR101 1-225-647-11 RES, VAR 20K/20K/20K/20K
VR102 1-225-648-11 RES, VAR 5K/5K
< DIODE >
ZD901 8-719-025-50 DIODE 02CZ16-TE85L
ZD902 8-719-025-34 DIODE 02CZ6.8-TE85L
ZD910 8-719-025-49 DIODE 02CZ15-TE85L
ZD911 8-719-025-49 DIODE 02CZ15-TE85L
ZD913 8-719-025-34 DIODE 02CZ6.8-TE85L
***************************************************************
MISCELLANEOUS
*************
D905 8-719-079-03 DIODE LTL-30EFJ
D906 8-719-079-03 DIODE LTL-30EFJ
D907 8-719-079-03 DIODE LTL-30EFJ
D908 8-719-912-51 DIODE ESAC25-02C
D909 8-719-918-73 DIODE ESAC25-02N
F901 1-532-732-11 FUSE (BLADE TYPE) (AUTO FUSE)(20A)
Q310 8-729-052-06 TRANSISTOR KTD718
Q311 8-729-052-05 TRANSISTOR KTB688
Q410 8-729-052-06 TRANSISTOR KTD718
Q411 8-729-052-05 TRANSISTOR KTB688
Q947 8-729-051-99 TRANSISTOR STP55NE06FP
Q948 8-729-051-99 TRANSISTOR STP55NE06FP
TH901 1-810-506-21 THERMISTOR NTH5G39B223K01TE
**************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
3-045-623-01 COVER (for POWER TERMINAL)
3-045-651-11 MANUAL, INSTRUCTION
(ENGLISH,FRENCH)(255EX:CND,AEP/255NX:UK)
3-045-651-21 MANUAL, INSTRUCTION
(GERMAN,RUSSIAN)(255EX:G)
3-045-651-31 MANUAL, INSTRUCTION
(SPANISH,PORTUGUESE)(255EX:AEP)
3-045-651-41 MANUAL, INSTRUCTION
(DUTCH,SWEDISH)(255EX:AEP)
3-045-651-51 MANUAL, INSTRUCTION
(ITALIAN,GREEK)(255EX:AEP)
3-367-410-01 SCREW (DIA. 5X15), TAPPING
**************************************************************
**************
HARDWARE LIST
**************
#1 7-685-543-21 SCREW +BTP 3X4 TYPE 2
#2 7-685-545-11 SCREW +BTP 3X6 TYPE 2 N-S
#3 7-685-546-19 SCREW +BTP 3X8 TYPE 2 N-S
#4 7-682-949-01 SCREW +PSW 3X10

14
Sony Corporation
Mobile Electronics Division Company
9-870-069-11 2000A090267-1
Printed in Japan © 2000. 1
Published by General Engineering Dept.
XM-255EX/255NX
