SERVICE MANUAL
US Model
Canadian Model
AEP Model
UK Model
E Model
XM-404EQX/604EQX
STEREO POWER AMPLIFIER
Other Specifications
Circuit system OTL (output transformerless) circuit
Pulse power supply
Inputs RCA pin jacks
High level input connector
Outputs Speaker terminals
Speaker impedance 2 – 8 Ω(stereo)
4 – 8 Ω(when used as a bridging
amplifier)
Maximum outputs XM-404EQX:
Four speakers:
80 watts ×4 (at 4 Ω)
Three speakers:
80 watts ×2 + 200 watts ×1 (at 4 Ω)
Two speakers:
200 watts ×2 (at 4 Ω)
XM-604EQX:
Four speakers:
120 watts ×4 (at 4 Ω)
Three speakers:
120 watts ×2 + 300 watts ×1 (at 4 Ω)
Two speakers:
300 watts ×2 (at 4 Ω)
Rated outputs (supply voltage at 14.4V)
XM-404EQX:
Four speakers:
40 watts ×4 (20 Hz – 20 kHz, 0.04%
THD, at 4 Ω)
50 watts ×4 (20 Hz – 20 kHz, 0.1%
THD, at 2 Ω)
Two speakers:
100 watts ×2 (20 Hz – 20 kHz, 0.1%
THD, at 4 Ω)
XM-604EQX:
Four speakers:
60 watts ×4 (20 Hz – 20 kHz, 0.04%
THD, at 4 Ω)
75 watts ×4 (20 Hz – 20 kHz, 0.1%
THD, at 2 Ω)
Two speakers:
150 watts ×2 (20 Hz – 20 kHz, 0.1%
THD, at 4 Ω)
Frequency response 5 Hz – 100 kHz ( dB)
Harmonic distortion 0.005% or less (at 1 kHz, 4 Ω)
Input level adjustment range
0.2 – 4.0 V (RCA pin jacks)
0.4 – 8.0 V (High level input)
High-pass filter 50 – 200 Hz, –12 dB/oct
Low-pass filter 50 – 200 Hz, –12 dB/oct
Equalizer 50 Hz, 200 Hz, 800 Hz, 3.2 kHz,
12.8 kHz
±12 dB
Power requirements 12 V DC car battery
(negative ground)
Power supply voltage 10.5 – 16 V
Current drain At rated output: 23 A
Remote input: 1.5 mA
Dimensions Approx. 260 ×55 ×320 mm
(w/h/d) (10 1/4 ×2 1/4 ×12 5/8 in.) not
incl. projecting parts and controls
Mass XM-404EQX:
Approx. 3.2 kg (7 lb. 1 oz.) not incl.
accessories
XM-604EQX:
Approx. 3.3 kg (7 lb. 4 oz.) not incl.
accessories
Supplied accessories Mounting screws (4), Terminal cap (1)
Design and specifications are subject to change without
notice.
SPECIFICATIONS
AUDIO POWER SPECIFICATIONS (US, Canadian model)
POWER OUTPUTAND TOTAL HARMONIC DISTORTION
40 (404EQX), 60 (604EQX) watts per channel minimum continuous
average power into 4 ohms, four channels driven from 20 Hz to 20 kHz
with no more than 0.04% total harmonic distortion per Car AudioAd Hoc
Committee standards.
+0
–3
Photo : XM-604EQX
MICROFILM

– 2 –
TABLE OF CONTENTS
1. GENERAL
Location and Function of Controls.......................................... 3
Connections ............................................................................. 4
2. DISASSEMBLY
2-1. Bottom Plate........................................................................ 6
2-2. Panel (A) ............................................................................. 6
2-3. Panel (B).............................................................................. 7
2-4. AMP Board ......................................................................... 7
2-5. Control Panel Block ............................................................ 8
3. DIAGRAMS
3-1. Block Diagram .................................................................... 9
3-2. Printed Wiring Board –AMP Section–.............................. 13
3-3. Schematic Diagram –AMP Section– ................................ 15
3-4. Schematic Diagram –EQ Section–.................................... 17
3-5. Printed Wiring Board –EQ Section– .................................17
3-6. Schematic Diagram –IND Section– .................................. 19
3-7. Printed Wiring Board –IND Section– ............................... 20
3-8. Schematic Diagram –LED Section– ................................. 21
3-9. Printed Wiring Board –LED Section–............................... 21
4. EXPLODED VIEWS
4-1. Heat Sink Section .............................................................. 22
4-2. Control Panel Section........................................................ 23
5. ELECTRICAL PARTS LIST ........................................ 24
Notes on Chip Component Replacement
•Never reuse a disconnected chip component.
•Notice that the minus side of a tantalum capacitor may be dam-
aged by heat.

– 3 –
SECTION 1
GENERAL This section is extracted from
XM-604EQX’s instruction manual.

– 4 –

– 5 –

– 6 –
1 BTP 3x5
2 BTP 3x4
3 BTP 3x
4
4 bottom plate
SECTION 2
DISASSEMBLY
Note : Follow the disassembly procedure in the numerical order given.
2-1. BOTTOM PLATE
2-2. PANEL (A)
1 BTP 3x8
2 BTP 3x8
3 panel (A
)

1 BTP 3x12
2 BTP 3x12
4 BVTP 3x12
5 screw (3x8) (CNZ-N)
3 fuse
(30A): XM-404EQX
(40A): XM-604EQX
6 AMP board
2-3. PANEL (B)
2-4. AMP BOARD
– 7 –
2 BTP 3x8
1 BTP 3x8
3 panel (B
)
4 CNP804

1 claw
2 claw
3 CNP806
4 CNP807
5 CNJ807
6 CNJ808
7 control panel block
2-5. CONTROL PANEL BLOCK
– 8 –

XM-404EQX/604EQX
3-1. BLOCK DIAGRAM
– 9 – – 10 –
SECTION 3
DIAGRAMS
ON/OFF
DRIVE
DRIVER
Q907
ON/OFF
DRIVE
Q909
ON/OFF
DRIVE
Q908
+6V
REG
Q904
Q905, 906
T901
DC-DC CONVERTER
TRANSFORMER D912
+6V
+15V
REG
Q911, 913
–15V
REG
Q912, 914
B+(AMP)
+15V
–15V
B–(AMP)
B+(PRE)
B–(PRE)
D901
D902
D903
D904
R-CH
Signal path
: AUDIO
CN803
CN805
–4
–3
CNJ801
(REAR)
(FRONT)
+
+
CNJ801-2
CNJ801-1
+
+
+
CN802
L
CN801
+12V
REMOTE
LINE AMP
IC101
R-CH
R-CH
LPF
IC103 (2/2)
76
LPF
IC103 (1/2)
12
VR101-1
LPF
OFF
HPF
S101
FILTER
(FRONT)
EQ AMP
VR101
FILTER
(FRONT)
S102
DIRECT
(FRONT)
OFF
ON
BUFFER
IC110
LINE
SWITCH
Q112
13
LINE
CONTROL
B– (AMP) B+(AMP)
Q813, 814
POWER
ON/OFF
Q901
B+
SWITCH
Q902 , 903
LED
DRIVE
SWITCH
Q807
F901
3
16 10 9
ON/OFF
CONTROL OSC
12
DC-DC CONVERTER
CONTROL
IC901
TH802 TH801
PROTECT
LATCH
Q809, 812
(CURRENT CHECK)
PROTECT
LATCH
Q808, 811
(CURRENT CHECK)
DRIVER
Q101 – 106
POWER
AMP
Q107 – 110
OVER LOAD
DET
Q111
VOLTAGE
CHECK
Q815-816
SIGNAL METER AMP
IC801
76 1
12 – 15 16 – 21
LED
DRIVE
Q801 – 804 LD801 – 824
LED CONTROL
(FRONT)
IC802
L
R
MONOL+R
L
R
MONO
L+R
CN804
R-CH
VR107
LEVEL
HIGH
LEVEL
INPUT
L
(MONO)
L
(MONO)
INPUT
FRONT
VCC
LEVEL
METER
POWER/PROTECTOR
THERMAL
+
–
21
3+
–
57
6
EQ
IC102
VR101-2
+
–
21
3
IC104-108
VR102 50Hz
VR103 200Hz
VR104 800Hz
VR105 3.2kHz
VR106 12.8kHz
EQUALIZER
EQ BUFFER
IC109
DC DET
IC902
42
31
B+
AC1 IN
D4–D1 O6–O1
Q810
B+
LED
DRIVE
SWITCH
Q806
OFFSET
B+
LD826
LED
DRIVE
SWITCH
Q805
OVER
CURRENT
B+
LD825
B+
D801
R
L
HIGH
LEVEL
INPUT R
SPEAKER OUT
FRONT
SPEAKER OUT
REAR
(FRONT)
(FRONT)
ON/OFF
DRIVE
Q910 604EQX
604EQX
1
R
R
INPUT
REAR
LD827
04

22 21 20 19 18 17 16 15 14 13 12
1 2 3 4 5 6 7 8 9 10 11
D4 D3 D2 D1 O6 O5 O4 O3 O2 O1 VCC
GND GND
OSC
H.C
MUTE
AC/DC
DC IN
CR2
AC2 IN
CR1
AC1 IN
PEAK HOLD LOGIC
COMPARATOR
SWITCHER
DRIVER
VREF. I/N
OSC
AMP AMP INPUT
INTERFACE
CLOCK
16 15 14 13 12 11 10 9
1 2 3 4 5 6 7 8
OSC
REF. REG.
ERROR
ERROR
0.1V
– 11 –
• IC Block Diagrams
IC901 µPC494GS
IC802 BA6820F

– 12 –
Ref. No. Location
D101 D-3
D102 D-1
D201 D-5
D202 D-3
D301 D-7
D302 D-6
D401 D-9
D402 D-8
D801 G-8
D802 H-13
D803 F-2
D804 F-2
D805 F-3
D806 F-4
D807 F-2
D901 D-13
D902 D-13
D903 B-12
D904 B-11
D905 F-12
D906 E-11
D907 F-13
D908 H-14
D909 H-14
D912 E-14
D913 G-13
D914 G-12
• Semiconductor Location
(AMP Board)
THIS NOTE IS COMMON FOR PRINTED WIRING
BOARDS
AND SCHEMATIC DIAGRAMS.
(In addition to this, the necessary note is
printed in each block.)
for schematic diagrams
• All capacitors are in µF unless otherwise noted. pF: µµF
50WVorlessare not indicated exceptforelectrolyticsand
tantalums.
• All resistors are in Ωand 1/4W or less unless otherwise
specified.
• % : indicates tolerance.
•2: nonflammable resistor.
•C: panel designation.
•U: B+ Line.
• Powervoltageisdc14.4V and fed withregulateddcpower
supply from +12V and REMOTE terminals.
• Voltage is dc with respect to ground under no-signal
condition.
• Voltages are taken with a VOM (Input impedance 10 MΩ).
Voltage variations may be noted due to normal production
tolerances.
• Signal path.
F: AUDIO
for printed wiring boards
•X: parts extracted from the component side.
•r: Through hole.
•b: Pattern from the side which enables seeing.
(The other layer’s patterns are not indicated.)
Caution:
Pattern face side: Parts onthepatternfaceside seenfrom the
(Side B) pattern face are indicated.
Parts face side: Parts on the parts face side seen from the
(Side A) parts face are indicated.
Ref. No. Location
IC101 G-4
IC301 G-3
IC801 E-3
IC901 E-14
IC902 G-2
Q101 D-2
Q102 D-2
Q103 C-3
Q104 C-1
Q105 A-2
Q106 A-2
Q107 C-2
Q108 C-2
Q109 A-3
Q110 B-2
Q111 A-2
Q112 D-2
Q201 C-4
Q202 C-4
Q203 C-5
Q204 C-4
Q205 A-4
Q206 A-4
Q207 C-4
Q208 C-4
Q209 A-5
Q210 B-4
Q211 A-4
Q212 D-4
Q301 D-7
Q302 D-6
Q303 C-7
Q304 C-6
Q305 A-7
Q306 A-7
Q307 C-7
Q308 C-6
Q309 A-7
Q310 A-6
Q311 A-6
Q312 D-6
Q401 D-9
Q402 D-8
Q403 C-9
Q404 C-8
Q405 A-9
Q406 A-9
Q407 C-9
Q408 C-8
Q409 A-9
Q410 A-9
Q411 A-8
Q412 E-8
Q808 G-7
Q809 G-8
Q810 F-7
Q811 F-7
Q812 F-8
Q813 E-2
Q814 E-2
Q815 F-3
Q816 F-3
Q817 F-2
Q818 F-2
Q819 F-1
Q901 I-14
Q902 G-14
Q903 G-14
Q904 H-13
Q905 D-14
Q906 D-14
Q907 A-15
Q908 A-13
Q909 A-16
Q910 A-14
Q911 G-13

XM-404EQX/604EQX
– 13 – – 14 –
3-2. PRINTEDWIRING BOARD — AMP SECTION — • Refer to page 12 for Semiconductor Location.
(Page 20) (Page 21) (Page 17) (Page 17)
1-672-785-

– 15 – – 16 –
3-3. SCHEMATIC DIAGRAM — AMP SECTION — • Refer to page 11 for IC Block Diagrams.
XM-404EQX/604EQX
(Page 17)
(Page 17)
(Page 19)
(Page 18)
(Page 18)
(Page
21)

– 17 – – 18 –
3-5. PRINTED WIRING BOARD — EQ SECTION —
Ref. No. Location
IC102 A-3
IC103 A-4
IC104 B-6
IC105 A-7
IC106 A-7
IC107 A-8
IC108 A-9
IC109 A-5
IC110 A-1
IC203 A-5
• Semiconductor
Location
3-4. SCHEMATIC DIAGRAM — EQ SECTION —
XM-404EQX/604EQX
(Page 15) (Page 15)
(Page 14)

– 19 – – 20 –
3-7. PRINTED WIRING BOARD — IND SECTION —3-6. SCHEMATIC DIAGRAM — IND SECTION — • Refer to page 11 for IC Block Diagrams.
( ) : SIDE B
XM-404EQX/604EQX
Ref. No. Location
IC802 A-2
(LD801) B-4
(LD802) A-4
(LD803) B-3
(LD804) A-3
(LD805) B-3
(LD806) A-3
(LD807) B-3
(LD808) A-3
(LD809) B-3
(LD810) A-3
(LD811) B-2
(LD812) A-2
(LD813) B-2
(LD814) A-2
• Semiconductor Location
Ref. No. Location
(LD815) B-2
(LD816) A-2
(LD817) B-2
(LD818) A-2
(LD819) B-1
(LD820) A-1
(LD821) B-1
(LD822) A-1
(LD823) B-1
(LD824) A-1
Q801 A-3
Q802 A-1
Q803 A-3
Q804 A-1
(Page 15)
(Page 13)

– 21 –
Ref. No. Location
D880 B-2
D881 A-1
D882 A-1
(LD825) A-2
(LD826) A-1
(LD827) A-1
Q805 A-2
Q806 A-1
Q807 A-1
• Semiconductor
Location
3-9. PRINTED WIRING BOARD — LED SECTION —
3-8. SCHEMATIC DIAGRAM — LED SECTION —
( ) : SIDE B
XM-404EQX/
604EQX
(Page 15)
(Page 14)

Q908 (404EQX)
Q907, 909
(604EQX)
Q907 (404EQX)
Q908, 910
(604EQX)
D903
D904
Q409
Q410
Q309
Q310
Q209 Q210
Q109
Q11
0
TH802
Q911
Q912
#1
#1
#4 #4 #4 #4 #1
#2
#2
#3
#1
#8
#1
#1
#9
#9 #3
#3
#3
#9
#5
#5
#5
#5#6
#6
#6
#3
#1
F901
not supplied
not supplied
not
supplied
not
supplied
not
supplied
1
1
2
4
5
6
6
7
89
10
3
11
12
#13
#13
SECTION 4
EXPLODED VIEWS
NOTE:
• The mechanical parts with no reference
number in the exploded views are not supplied.
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Color Indication of Appearance Parts
Example :
KNOB, BALANCE (WHITE) ... (RED)
Parts Color Cabinet’s Color
Ref. No. Part No. Description Remark
4-1. HEAT SINK SECTION
N
N
Ref. No. Part No. Description Remark
• Accessories and packing materials and
hardware (# mark) list are given in
the last of this parts list.
– 22 –
1 3-013-266-01 SCREW, ORNAMENTAL
2 3-033-970-01 PLATE, ORNAMENTAL (404EQX)
2 3-033-970-11 PLATE, ORNAMENTAL (604EQX)
*3 3-032-786-01 HEAT SINK (404EQX)
*3 3-032-786-11 HEAT SINK (604EQX)
4 3-035-756-01 PANEL (A) (404EQX)
4 3-035-756-11 PANEL (A) (604EQX)
5 3-035-757-01 PANEL (B) (404EQX)
5 3-035-757-11 PANEL (B) (604EQX)
6 3-933-766-01 SCREW (3X8) (CZN-N)
*7 3-035-902-01 HEAT SINK, SUB
*8 A-3317-649-A AMP BOARD, COMPLETE (404EQX)
*8 A-3317-650-A AMP BOARD, COMPLETE (604EQX)
9 3-912-432-01 SCREW M4X8
*10 3-035-901-01 PLATE, BOTTOM
11 1-763-107-11 MOTOR, FAN (604EQX)
*12 3-023-795-01 BRACKET (FAN) (604EQX)
D903 8-719-023-35 DIODE FMG-32S
D904 8-719-023-34 DIODE FMG-32R
F901 1-532-947-11 FUSE (BLADE TYPE) (AUTO FUSE) 30A(404EQX)
F901 1-533-743-11 FUSE (BLADE TYPE) (AUTO FUSE) 40A(604EQX)
Q109 8-729-024-80 TRANSISTOR 2SC5100-Y
Q110 8-729-024-77 TRANSISTOR 2SA1908-Y
Q209 8-729-024-80 TRANSISTOR 2SC5100-Y
Q210 8-729-024-77 TRANSISTOR 2SA1908-Y
Q309 8-729-024-80 TRANSISTOR 2SC5100-Y
Q310 8-729-024-77 TRANSISTOR 2SA1908-Y
Q409 8-729-024-80 TRANSISTOR 2SC5100-Y
Q410 8-729-024-77 TRANSISTOR 2SA1908-Y
Q907 8-729-030-72 FET MTAJ50N05HD (404EQX)
Q907 8-729-030-73 FET MTAJ30N06HD (604EQX)
Q908 8-729-030-72 FET MTAJ50N05HD (404EQX)
Q908 8-729-030-73 FET MTAJ30N06HD (604EQX)
Q909 8-729-030-73 FET MTAJ30N06HD (604EQX)
Q910 8-729-030-73 FET MTAJ30N06HD (604EQX)
Q911 8-729-209-15 TRANSISTOR 2SD2012
Q912 8-729-141-83 TRANSISTOR 2SB1375
TH802 1-809-664-51 THERMISTOR, POSITIVE

– 23 –
4-2. CONTROL PANEL SECTION
Ref. No. Part No. Description RemarkRef. No. Part No. Description Remark
51
53 52
53
54 52
57
58
59
60 62
61
55
56
56
55
#11
#11
#7 #7
#7
#12
#10
#10
#10
#10
supplied with RV
supplied with RV
51 3-032-785-01 PLATE, ORNAMENTAL (404EQX)
51 3-032-785-11 PLATE, ORNAMENTAL (604EQX)
52 3-035-767-01 KNOB (VR)
53 3-035-768-01 KNOB (SW)
*54 3-035-904-01 BRACKET (CHASSIS)
*55 3-035-903-01 BRACKET (VR)
*56 1-672-786-11 EQ BOARD
57 3-035-765-01 LENS (A)
*58 1-672-784-11 LED BOARD
59 1-790-765-11 CABLE, PARALLEL (5P)
60 3-035-766-01 LENS (B)
*61 1-672-783-11 IND BOARD
62 1-790-764-11 CABLE, PARALLEL (4P)

– 24 –
SECTION 5
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
When indicating parts by reference
number, please include the board.
AMP
*A-3317-649-A AMP BOARD, COMPLETE (404EQX)
*A-3317-650-A AMP BOARD, COMPLETE (604EQX)
*********************
< CAPACITOR >
C101 1-126-047-11 ELECT 4.7uF 20% 50V
C102 1-126-047-11 ELECT 4.7uF 20% 50V
C103 1-163-081-00 CERAMIC CHIP 0.22uF 25V
C104 1-163-081-00 CERAMIC CHIP 0.22uF 25V
C105 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C106 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C107 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C108 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C109 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C110 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C130 1-124-994-11 ELECT 100uF 20% 10V
C131 1-102-518-11 CERAMIC 33PF 5% 50V
C132 1-102-947-00 CERAMIC 10PF 5% 50V
C133 1-126-025-11 ELECT 330uF 20% 25V
C134 1-130-495-11 MYLAR 0.1uF 5% 50V
C135 1-130-491-00 MYLAR 0.047uF 5% 50V
C138 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C141 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(604EQX)
C141 1-164-162-11 CERAMIC CHIP 100PF 5% 100V
(404EQX)
C142 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(604EQX)
C142 1-164-162-11 CERAMIC CHIP 100PF 5% 100V
(404EQX)
C143 1-130-483-00 MYLAR 0.01uF 5% 50V
C201 1-126-047-11 ELECT 4.7uF 20% 50V
C202 1-126-047-11 ELECT 4.7uF 20% 50V
C203 1-163-081-00 CERAMIC CHIP 0.22uF 25V
C204 1-163-081-00 CERAMIC CHIP 0.22uF 25V
C205 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C206 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C207 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C208 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C209 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C210 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C230 1-124-994-11 ELECT 100uF 20% 10V
C231 1-102-518-11 CERAMIC 33PF 5% 50V
C232 1-102-947-00 CERAMIC 10PF 5% 50V
C234 1-130-495-11 MYLAR 0.1uF 5% 50V
C235 1-130-491-00 MYLAR 0.047uF 5% 50V
C236 1-163-081-00 CERAMIC CHIP 0.22uF 25V
C238 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C241 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(604EQX)
C241 1-164-162-11 CERAMIC CHIP 100PF 5% 100V
(404EQX)
C242 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(604EQX)
C242 1-164-162-11 CERAMIC CHIP 100PF 5% 100V
(404EQX)
C243 1-130-483-00 MYLAR 0.01uF 5% 50V
C301 1-126-047-11 ELECT 4.7uF 20% 50V
C302 1-126-047-11 ELECT 4.7uF 20% 50V
C303 1-163-081-00 CERAMIC CHIP 0.22uF 25V
C304 1-163-081-00 CERAMIC CHIP 0.22uF 25V
C305 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C306 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C307 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C308 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C309 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C310 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C330 1-124-994-11 ELECT 100uF 20% 10V
C331 1-102-518-11 CERAMIC 33PF 5% 50V
C332 1-102-947-00 CERAMIC 10PF 5% 50V
C334 1-130-495-11 MYLAR 0.1uF 5% 50V
C335 1-130-491-00 MYLAR 0.047uF 5% 50V
C336 1-163-081-00 CERAMIC CHIP 0.22uF 25V
C338 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C341 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(604EQX)
C341 1-164-162-11 CERAMIC CHIP 100PF 5% 100V
(404EQX)
C342 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(604EQX)
C342 1-164-162-11 CERAMIC CHIP 100PF 5% 100V
(404EQX)
C343 1-130-483-00 MYLAR 0.01uF 5% 50V
C401 1-126-047-11 ELECT 4.7uF 20% 50V
C402 1-126-047-11 ELECT 4.7uF 20% 50V
C403 1-163-081-00 CERAMIC CHIP 0.22uF 25V
C404 1-163-081-00 CERAMIC CHIP 0.22uF 25V
C405 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C406 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C407 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C408 1-163-251-11 CERAMIC CHIP 100PF 5% 50V

– 25 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
AMP
C409 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C410 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C430 1-124-994-11 ELECT 100uF 20% 10V
C431 1-102-518-11 CERAMIC 33PF 5% 50V
C432 1-102-947-00 CERAMIC 10PF 5% 50V
C434 1-130-495-11 MYLAR 0.1uF 5% 50V
C435 1-130-491-00 MYLAR 0.047uF 5% 50V
C436 1-163-081-00 CERAMIC CHIP 0.22uF 25V
C438 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C441 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(604EQX)
C441 1-164-162-11 CERAMIC CHIP 100PF 5% 100V
(404EQX)
C442 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(604EQX)
C442 1-164-162-11 CERAMIC CHIP 100PF 5% 100V
(404EQX)
C443 1-130-483-00 MYLAR 0.01uF 5% 50V
C801 1-126-044-11 ELECT 1uF 20% 50V
C802 1-126-044-11 ELECT 1uF 20% 50V
C806 1-126-006-11 ELECT 22uF 20% 16V
C807 1-126-006-11 ELECT 22uF 20% 16V
C808 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C809 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C811 1-126-006-11 ELECT 22uF 20% 16V
C812 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C813 1-126-006-11 ELECT 22uF 20% 16V
C814 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C815 1-130-483-00 MYLAR 0.01uF 5% 50V
C817 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C818 1-126-006-11 ELECT 22uF 20% 16V
C901 1-136-899-11 MYLAR 0.47uF 5% 50V
C902 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C903 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C904 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C905 1-130-471-00 MYLAR 0.001uF 5% 50V
C906 1-126-006-11 ELECT 22uF 20% 16V
C907 1-124-994-11 ELECT 100uF 20% 10V
C908 1-126-023-11 ELECT 100uF 20% 16V
C909 1-130-495-11 MYLAR 0.1uF 5% 50V
C910 1-126-015-11 ELECT 3300uF 20% 16V
(404EQX)
C910 1-126-768-11 ELECT 2200uF 20% 16V
(604EQX)
C911 1-126-015-11 ELECT 3300uF 20% 16V
(404EQX)
C911 1-126-768-11 ELECT 2200uF 20% 16V
(604EQX)
C912 1-126-768-11 ELECT 2200uF 20% 16V
(604EQX)
C913 1-130-495-11 MYLAR 0.1uF 5% 50V
C914 1-130-495-11 MYLAR 0.1uF 5% 50V
C915 1-104-613-21 ELECT 4700uF 20% 35V
(404EQX)
C915 1-128-711-11 ELECT 5600uF 20% 35V
(604EQX)
C916 1-104-613-21 ELECT 4700uF 20% 35V
(404EQX)
C916 1-128-711-11 ELECT 5600uF 20% 35V
(604EQX)
C917 1-126-052-11 ELECT 100uF 20% 35V
C918 1-126-052-11 ELECT 100uF 20% 35V
C919 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C920 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C921 1-126-023-11 ELECT 100uF 20% 16V
C922 1-126-023-11 ELECT 100uF 20% 16V
C923 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C924 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C927 1-126-023-11 ELECT 100uF 20% 16V
C928 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C929 1-124-994-11 ELECT 100uF 20% 10V
C930 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
< TERMINAL TABLE >
CN801 1-694-511-11 TABLE, TERMINAL (3P) (REMOTE/+12V/GND)
CN804 1-694-512-11 TABLE, TERMINAL (4P) (SPEAKER OUT
(FRONT L/R))
CN805 1-694-512-11 TABLE, TERMINAL (4P) (SPEAKER OUT
(REAR L/R))
CNJ801 1-537-479-11 TERMINAL (INPUT FRONT L/R,
INPUT REAR L/R) (604EQX)
< CONNECTOR >
CN802 1-784-904-21 CONNECTOR 4P (INPUT FRONT
(HIGH LEVEL INPUT))
CN803 1-784-904-31 CONNECTOR 4P (INPUT REAR
(HIGH LEVEL INPUT))
CNJ807 1-793-098-11 CONNECTOR, FFC/FPC (ZIF) 4P
CNJ808 1-793-099-11 CONNECTOR, FFC/FPC (ZIF) 5P
CNP804 1-564-718-00 PIN, CONNECTOR (SMALL TYPE) 2P (604EQX)
CNP806 1-793-038-11 CONNECTOR, BOARD TO BOARD 10P
CNP807 1-793-038-11 CONNECTOR, BOARD TO BOARD 10P
< JACK >
CNJ801 1-779-078-41 JACK, PIN 4P (INPUT FRONT L/R,
INPUT REAR L/R) (404EQX)
< DIODE >
D101 8-719-800-76 DIODE 1SS133T-91
D102 8-719-800-76 DIODE 1SS133T-91
D201 8-719-800-76 DIODE 1SS133T-91
D202 8-719-800-76 DIODE 1SS133T-91
D301 8-719-800-76 DIODE 1SS133T-91
D302 8-719-800-76 DIODE 1SS133T-91
D401 8-719-800-76 DIODE 1SS133T-91
D402 8-719-800-76 DIODE 1SS133T-91
D801 8-719-801-78 DIODE 1SS184
D802 8-719-801-78 DIODE 1SS184
