Specification Sheet
Model MHS-FS3 MHS-FS2 MHS-FS1K
Lens
Lens Type Sony Lens
Optical Zoom
Magnification No
Lens
Construction 4 elements in 4 groups
F-number
(Maximum
Aperture) F2.8
Focal Length
(f = ) 4.1mm
35mm film equivalent
(Still Image16:9) 47mm
35mm film equivalent
(Still Image4:3) 41mm
35mm film
equivalent(Movie16:9) 47mm
35mm film
equivalent(Movie4:3) No
Focus
Range(from the
front of the
lens)
Auto 10cm (4") to infinity
Close Focus Enabled No
Iris Diaphragm No
Filter Diameter No
Lens Cover No
NightShot No
NightShot plus No
Image Sensor
Type Exmor CMOS sensor
ClearVid CMOS
Sensor No
Exmor R No
Exmor Yes
Size 4.5mm (1/4 type)
Number of
gross pixels Approx.5.15 Megapixcels
Scan System Progressive scan
Color Filter R,G,B primary color mosaic filters
Camera
Number of
effective pixels Approx.5.03 Megapixcels
Imaging
Processor DSP
Digtal Zoom Yes
Total Zoom
Magnification Digital Zoom Off(only Optical Zoom) No

Smart Zoom(with
Optical Zoom) No
Precision Digital Zoom(with Optical
Zoom) No
Optical Zoom
during movie
recording No
Noise
Reduction Clear RAW NR No
NR Slow Shutter No
NR Level setting No
AF Mode No
Macro Auto Macro Yes(Auto)
Close Focus Enabled No
Focus Mode Multi Point AF No
Center Weighted AF Yes
Spot AF No
Flexible Spot AF No
Semi Manual No
Manual No
Tracking Focus No
AF Illuminator No
Light Metering
Mode Multi Pattern No
Center Weighted Yes
Spot No
Aperture No
Shutter Speed Auto(1/30-1/4000)
ISO
Sensitivity(REI) Setting Auto
Auto Controll Range ISO80-800
Minimum Illumination N.A.
LOW LUX -
NightShot (plus) No
Exposure
Compensation Function No
EV Bar Display No
SteadyShot System Name Stedayshot
System (Still image) blur reduction
System (Movie) EIS(with GYRO)
Mode No
Active Mode No
Steadyshot ON/OFF No
White Balance
Mode Auto Yes
Candle Yes

Shooting Mode
( Movie ) Auto Adjustment Yes(2D Only) Yes
Face Detection Mode Auto
Face Selection No
Maximum number of
detectable faces 8 faces(2D Only) 8 faces
Exposure Control Yes
Color Control No
Focus Control Yes(2D Only) Yes
Recommended distance (in "MOVIE"
position) -
Self-Timer Off / 2sec. / 10sec.
Grid Line No
Auto
Orientation Yes Yes Yes
Auto Review Yes Yes Yes
Monitor, Viewfinder
LCD Monitor Type TFT LCD TFT LCD TFT LCD
Size 6.0cm(2.4type) 6.7cm(2.7type) 6.7cm(2.7type)
Aspect Ratio 4:3 16:9(WIDE) 16:9(WIDE)
Number of dots 230,400dots 230,400dots 230,400dots
Field of view 100% Yes Yes Yes
View angle (Horizontal
/ vertical) 40/40/15/40 60/60/65/60 60/60/65/60
LCD Name standard standard standard
Angle Adjustment No
Minimum Surface Luminance 210cd 400cd 400cd
Clear Photo LCD
/Clear Photo LCD plus
/ Xtra Fine LCD No
Compliant to x.v.Color No
Wide View Angle No
Tru black No
Hybrid LCD Monitor No
Sub LCD
Monitor
sub Monitor No Yes No
Type - TFT LCD -
Size - 5.0cm(2.0type) -
Aspect Ratio - 4:3 -
Number of dots - 153600 dots -
Field of view 100% - Yes -
View angle
（Horizontal /
vertical）- 40/40/20/50 -
LCD Name - Standard -
Angle Adjustment - No -
Minimum Surface
Luminance - 250cd -

Clear Photo LCD
/Clear Photo LCD plus
/ Xtra Fine LCD - No -
Compliant to x.v.Color - No -
Wide View Angle - No -
Tru black - No -
Hybrid LCD Monitor - No -
Recording
Media
Internal
Memory Built-in Flash memory Yes Yes Yes
Recoding Capacity Approx.8GB Approx.4GB Approx.4GB
Maximum Storage
Capacity(using PMB)*3 N.A. N.A. N.A.
Still Image
(
3D
)
3D still mode Yes No No
Still Image
Default
Recording
Media No - -
Selectable
Recording
Media No - -
Image Quality
Mode selection No - -
Image File
Format(Still
Image)
DCF(Design rule for
Camera File
System)Ver.2.0 Yes - -
DPOF(Digital Print
Order Format)Ver.1.1 No - -
ExifVer.2.3 Yes - -
MPF Baseline Yes - -
MPF Extended
(Disparity Image) No - -
MPF MV対応 No - -
Still Image
Number of
recorded pixels
(Image Size)
2M x2 (1920 x 1080 x
2) - - -
Image File
Format(Still
Image)
DCF(Design rule for
Camera File
System)Ver.2.0 Yes Yes Yes
ExifVer.2.3 Yes Yes Yes
MPF Baseline Yes Yes Yes
Still Image
Recording
Mode Normal (JPEG) Yes Yes Yes
Still Image
Number of
recorded pixels
(Image Size)
5M (2,592 x 1,944) Yes
16:9 mode 3.1M (2356 x 1324) /
0.4M(854x480) 3.1M (2356 x 1324) / 0.4M(854x480) 3.1M (2356 x 1324) / 0.4M(854x480)
Date / Time Yes/Yes Yes/Yes Yes/Yes

Continuous file
number REC Yes Yes Yes
Image Delete Yes (Internal Memory
One/Select) Yes (Internal Memory One/Select) Yes (Internal Memory One/Select)
Image Protect Yes (Internal Memory
One/Select) Yes (Internal Memory One/Select) Yes (Internal Memory One/Select)
Playback Zoom Yes (x2,x4,x8)(FunctionKe
y)
Yes
(x2,x4,x8)(FunctionKe
y)
Yes
(x2,x4,x8)(FunctionK
ey)
Movie
Movie
Recording
Format File Format MP4 MP4 MP4
Video Compression MPEG-4 AVC/H.264 MPEG-4 AVC/H.264 MPEG-4 AVC/H.264
Audio Recording
Format MPEG4-AAC MPEG4-AAC MPEG4-AAC
Movie
Recording
Mode(MP4)
1920 x 1080(29.97fps,
Progressive) Approx.12Mbps(Aver age bit-rate) Approx.12Mbps(Aver age bit-rate) Approx.12Mbps(Aver age bit-rate)
1280 x 720(59.94fps,
Progressive) Approx.6Mbps(Avera ge bit-rate) Approx.6Mbps(Avera ge bit-rate) Approx.6Mbps(Avera ge bit-rate)
1280 x 720(29.97fps,
Progressive) Approx.4Mbps(Avera ge bit-rate) Approx.4Mbps(Avera ge bit-rate) Approx.4Mbps(Avera ge bit-rate)
480 x 270, (29.97fps,
Progressive) Approx.0.8Mbps(Aver age bit-rate) Approx.0.8Mbps(Aver age bit-rate) Approx.0.8Mbps(Ave rage bit-rate)
Effective pixels
of moving
pictures(MP4)
1920 x 1080(29.97fps,
Progressive) 2356 x 1324 2356 x 1324 2356 x 1324
1280 x 720(59.94fps,
Progressive) 1178 x 662 1178 x 662 1178 x 662
1280 x 720(29.97fps,
Progressive) 2356 x 1324 2356 x 1324 2356 x 1324
480 x 270, (29.97fps,
Progressive) 2356 x 1324 2356 x 1324 2356 x 1324
Dual Rec Yes Yes Yes
Number of pixels (in
"MOVIE" Rec
position)(1920x1080
16:9)
1920x1080 1920x1080 1920x1080
Number of pixels (in
"MOVIE" Rec
position)(1280x720
16:9)
1280x720 1280x720 1280x720
Number of pixels (in
"MOVIE" Rec
position)(480 x 270
16:9)
480 x 270 480 x 270 480 x 270
3D Movie
3D Movie recording Yes No No
Movie
Recording
Format File Format MP4 - -
Video Compression MPEG-4 AVC/H.264 - -
Audio Recording
Format MPEG4-AAC - -
Movie
Recording
Mode(MP4)
1920 x 1080(29.97fps,
Progressive) Yes - -
1280 x 720(59.94fps,
Progressive) No - -
1280 x 720(29.97fps, No - -

Progressive)
VGA(640 x 480,
29.97fps, Progressive) No - -
Effective pixels
of moving
pictures(MP4)
1920 x 1080(29.97fps,
Progressive) 2356 x 1324 x 2 - -
1280 x 720(59.94fps,
Progressive) - - -
1280 x 720(29.97fps,
Progressive) - - -
WVGA(480 x 270,
29.97fps, Progressive) - - -
Dual Rec
Number of pixels (in
"MOVIE" Rec
position)(1920x1080
16:9)
2356 x 1324 x 2 - -
Vertical
Shootin
g
Recording Yes(2D Only) Yes Yes
Micropho
ne /
Built-in
Microphone Stereo Mono
Speaker Mono
Volume Setting 16 steps
Audio
Audio recording
system MPEG4 AAC
Built-in
Microphone Yes (ElectricCondencer)
Speaker Yes(10mm)
Speaker Volume
Control Yes (+)(-)(FunctionKey)
Playback
Maximum
Playback Size Still Image Under 5M (2,592 x 1,944)
Movie Under 2.07M (1920 x 1080)
Single Image Cue, Review(Movie) Yes
Image Index Index 20 images
View Mode Date view Yes
3D Viewing
Mode Yes(without glasses) No
Zoom
Magnification of
Playback Mode 8x
Automatic
Image Rotation Yes(2D Only) Yes
Delete Yes
Protect Yes
Next Yes
Previous Yes
OSD On/Off Yes(Auto)
OSD Output No
TV
Type(16:9/4:3)
Select No

HDMI Output
Resolution
Select No
HDMI 60p/50p
Output No
HDMI
60Hz/50Hz
Output Yes
Original Edit Yes
Delete Yes
Protect Yes
Playback Zoom Yes (x2 , x4 , x8)(FunctionKey)
("Photo" Position Only)
360Video
playback yes
PC Link
Bloggie
software Win/MAC OS Yes/Yes
Share-it-Later Win/MAC OS Yes/Yes
WEB camera
mode Win/MAC OS Yes/No
Dedicated buttons
Power Button Yes
Lens Cover No
Shutter Button Yes
Zoom
Lever(Switch) No
Mode Switch No
Playback
Button Yes
Mode Dial No
Movie Start /
Stop Button Yes
Menu Button Yes
Control Button Yes
Image Size &
Delete Buttons Yes(Control Button)
Zoom(Lever/bu
tton on
LCD/Control
Button）
Yes(No/No/Yes)
Menu, Indicator
On-Screen
Indicators Yes(Control Button)
Battery
Remaining
Indicator(Icon) Yes
Recording
Media
Remaining
Indicator
Yes
Beep On / Off
Manage
Memor
y
Internal
Memory Tool Format Yes

Other Functions
Area Setting Auto only
Clock setting Yes
DST or Summer time Yes
Flicker
reduction on/off Yes
Initialize Yes
Demo Mode Off/On
Video Out
HDMI 2D Yes
3D Yes -
Video Out
Mode 60Hz / 50Hz
USB
Hi-Speed
USB(USB2.0) Yes
USB Connect Auto(MultiConfiguratio
n) No
Mass Storage Yes
PictBridge No
PTP/MTP No
PTP No
USB Streaming Yes
LUN
Settings(Multi/S
ingle) Yes
Interface
HDMI Yes
USB No
Built-in USB
arm Yes
DC IN Terminal No
External Mic.
Input No
Phone Jack No
Remote No
360 Video
360 Video Yes
360 Video Lens
supply Yes/VCL-BPP3
Movie recording 1920x1080 30P
Still image recording 2M
Angle (vertical) +41 deg. -10 deg.
Auto Focus fixed
Zoom No
Face Detection/ Face
recognization No
Self-Timer Yes
O
p
t
Conversion
Lens Type No

Filter Diameter No
Mode No
Tripod
Receptacle Yes
Power, Others
Power Source Battery NP-SP70 3.6V
AC adaptor No
USB power adaptor 5.0V
Supplied
Battery Maximum Voltage 4.2V
Nominal Voltage 3.6V
Capacity for Shooting typical: 3.6Wh(1000mAh), minimum: 3.4Wh(925mAh)
USB charge 500mA Yes
100mA Yes
Charge on
main unit Yes
Menu Button Yes(Control Button)
PlayButton Yes(Control Button)
One Touch
Disc Burn
Button No No No
Auto Shut Off Yes Yes Yes
LED Light
on/off button Yes No
sub display
on/off button No Yes No
3D button Yes No
GPS On/Off
Switch No
Remote Sensor
/ Remote
On/Off No
Beep Sound /
On/Off Yes (Menu)
Power
consumption(C
amera mode) LCD On Approx.2.2W Approx.1.6W Approx.1.6W
Viewfinder(LCD Off) No
Power Consumption (Recoeding
mode/Recording media : Default Setting) Approx.2.4W Approx.1.7W Approx.1.7W
Dimensions(Wx
HxD)CIPA
55.0mm x 108.0mm x
17.3mm
( 2 1/4" x 4 3/8" x
11/16")
55.0mm x 108.0mm x
18.4mm
( 2 1/4" x 4 3/8" x
3/4")
55.0mm x 108.0mm
x 15.8mm
( 2 1/4" x 4 3/8" x
5/8")
Special
Mention on
Dimension - - -
Carton
Dimension TBD
Weight Battery and Memory Stick DUO are
included Approx. 120g (4.2oz.) Approx. 139g (4.9oz.) Approx. 110g
(3.9oz.)
Body only Approx. 120g (4.2oz.) Approx. 139g (4.9oz.) Approx. 110g
(3.9oz.)
360 Video Lens are 135g 144g 125

included
Body Material ABS
Operating
Temperature 0 degrees C. - +40 degrees C.
Storage
Temperature -20 degrees C. - +60 degrees C.
Operating Speed*1
Start-up Time approx. 2.5s
Shooting Time
Lag approx. 1.2s
Shutter
Release Time
Lag approx. 0.1s
Shooting
Interval Maximum number of recoded pixels approx. 4.3s
Burst
Speed(maximu
m)
Burst(Maximum
number of recoded
pixels) -
Extra High-speed Burst -
Burst
Interval(minimu
m)
Burst(Maximum
number of recoded
pixels) -
Extra High-speed Burst -
Supplied
Accessorie
USB connection support cable, Wrist Strap, 360 Video Lens, 360 Video Lens Case

