Sony BRC-X1000 User manual

Color Video Camera
Operating Instructions
Software Version 1.0
Before operating the unit, please read this manual thoroughly
and retain it for future reference.
BRC-X1000/H800
C-455-100-11(1)
© 2016 Sony Corporation

2
Table of Contents
Overview
Using This Manual ................................................ 4
Precautions for Preventing Access to the
Camera by an Unintended Third Party .............. 5
Features .................................................................. 6
Location and Function of Parts ........................... 7
Camera ............................................................ 7
Remote commander (supplied) ..................... 10
System Configuration ......................................... 13
Operating the camera using the supplied
remote commander ....................................... 13
Operating the camera using the remote
controller (not supplied) ............................... 13
Connecting multiple cameras to the remote
controller (not supplied) ............................... 14
Installation and Connection
Installing the Camera ......................................... 15
Installing the camera on a desk ..................... 15
Installing the camera at a high spot .............. 16
Connecting the Camera ...................................... 23
Connecting an AC power supply .................. 23
Connecting the camera to a PoE+ (Power over
Ethernet Plus) power supply device .............. 24
Connecting a single camera to a switcher,
recorder and monitor .................................... 25
Connecting a single camera to a single
remote controller (not supplied) ................... 26
Connecting a single camera to a single
remote controller (not supplied) ................... 26
Connecting multiple cameras to a single
remote controller (not supplied) ................... 27
Connecting a commercially available video
switcher ......................................................... 28
Externally synchronizing a single camera .... 29
Adjusting and Configuring through
On-Screen Menus
About On-Screen Menus .....................................30
Main menu ....................................................30
Setting menu .................................................30
How to Use Menus ...............................................31
Using the supplied remote commander .........31
EXPOSURE Menu ..............................................32
COLOR Menu .....................................................34
DETAIL Menu .....................................................35
KNEE Menu .........................................................36
GAMMA/VISIBILITY ENHANCER Menu ....36
GAMMA .......................................................36
VISIBILITY ENHANCER ...........................37
FOCUS Menu ......................................................37
PICTURE/OPTICAL FILTER Menu ...............38
PAN TILT/ZOOM Menu ....................................39
VIDEO OUT Menu .............................................39
SYSTEM Menu ....................................................40
NETWORK Menu ...............................................41
Operations Using the Supplied
Remote Commander
Before Starting Operations .................................42
Turning on the Power ..........................................42
Pan/Tilt and Zoom Operations ...........................42
Panning and Tilting .......................................42
Zooming ........................................................43
Operating multiple cameras with the remote
commander ....................................................44
Adjusting the Camera .........................................44
Focusing on a subject ....................................44
Shooting with back lighting ..........................44
Storing the Camera Settings in Memory
– Presetting Feature .............................................45
Upgrading the firmware
Before starting the operation ..............................46
Setting-up the PC ..........................................46
Accessing the camera using the Web
browser ..........................................................46
Operation .............................................................47
Firmware update tab ......................................47
Password tab ..................................................47

3
Appendix
Message List ........................................................ 48
Troubleshooting ................................................... 49
Menu Configuration ........................................... 50
Preset Items ......................................................... 53
Specifications ....................................................... 55
Dimensions ................................................... 57
SYSTEM SELECT switch settings .............. 58
Pin array of the VISCA RS-422 terminal and
how to use it .................................................. 58

4
Overview
Safety Regulations (Supplied)
Describes the important points for safe use of the
camera.
Be sure to read it.
Operating Instructions (This document/
Web)
These operating instructions describe the names of the
various parts of camera and installation, connection, and
operation methods.
Using This Manual
The Operating Instructions is designed to be read on a
computer display.
The content you need to know in order to use the camera
is described here.
Read it before you operate the camera.
Jumping to a related page
When you read the instructions on a computer display
and click on the related part of the relevant page that is
being displayed, you jump to the related page. Relevant
pages can be searched easily.
Software display examples
The software displays described in this manual are
explanatory examples. Note that some displays may be
different from the ones that actually appear.
The illustrations of the camera and menu display in the
instructions show the BRC-X1000 as an example.
Printing the Operating Instructions
Depending on your system, certain displays or
illustrations in the Operating Instructions, when printed
out, may differ from those that appear on your screen.
NOTICE TO USERS
© 2016 Sony Corporation. All rights reserved. This
manual or the software described herein, in whole or
in part, may not be reproduced, translated or reduced
to any machine readable form without prior written
approval from Sony Corporation.
SONY CORPORATION PROVIDES NO
WARRANTY WITH REGARD TO THIS
MANUAL, THE SOFTWARE OR OTHER
INFORMATION CONTAINED HEREIN AND
HEREBY EXPRESSLY DISCLAIMS ANY
IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR ANY
PARTICULAR PURPOSE WITH REGARD TO
THIS MANUAL, THE SOFTWARE OR SUCH
OTHER INFORMATION. IN NO EVENT SHALL
SONY CORPORATION BE LIABLE FOR ANY
INCIDENTAL, CONSEQUENTIAL OR SPECIAL
DAMAGES, WHETHER BASED ON TORT,
CONTRACT, OR OTHERWISE, ARISING OUT
OF OR IN CONNECTION WITH THIS MANUAL,
THE SOFTWARE OR OTHER INFORMATION
CONTAINED HEREIN OR THE USE THEREOF.
Sony Corporation reserves the right to make any
modification to this manual or the information
contained herein at any time without notice.
The software described herein may also be governed
by the terms of a separate user license agreement.
• is trademark of Sony Corporation.
• “Exmor R” and are trademarks of
Sony Corporation.
• HDMI, HDMI High-Definition Multimedia
Interface, and HDMI logo is a trademark of HDMI
Licensing LLC and is registered trademark in
United States and/or other countries.
• Microsoft, Windows, and Internet Explorer are
registered trademarks of United States Microsoft
Corporation in the United States and/or other
countries.
• Java Script is a trademark of Sun Microsystems,
Inc.
• Adobe, Adobe Reader and Adobe Flash are
trademarks of Adobe Systems Incorporated.
Other system names, product names appearing in this
document are trademarks or registered trademarks of
their respective manufacturers. However, ®, TM marks
in this document are not explicit.

5
Precautions for
Preventing Access to
the Camera by an
Unintended Third Party
The camera settings may be changed by an unintended
third party on the network, depending on the usage
environment.
The camera can be fraudulently accessed in a network
environment where a device is connected or connectable
to the network without the administrator's permission, or
where a PC or other network device connected to the
network can be used without any permission.
Connect to these environments at your own risk.
After configuring the camera, immediately change the
password you use for upgrading the firmware on the
camera with a Web browser on your PC. For how to
change password, refer to “Password tab” (page 47) in
“Updating the System”.

6
Features
Pan/Tilt/Zoom CMOS video camera
equipped with a small built-in pan-tilt
head
• The camera unit is equipped with a 1.0-type Exmor R®CMOS
sensor and an optical 12×zoom lens with pan/tilt/zoom
features integrated into a small built-in pan-tilt head. This
versatile camera can be used for various applications.
• The pan-tilt head can pan to the right or left by ±170 degrees
and tilt upward to 90 degrees and downward to 30 degrees,
which allows the camera to remotely shoot wide areas.
• The camera pans and tilts smoothly, even at low movement
speed.
• The camera pans and tilts quietly, even at its maximum speed of
60 degrees per second.
High sensitivity and high resolution from
built-in 1.0-type CMOS image sensor
With the built-in highly photosensitive 1.0-type Exmor
R®CMOS sensor, high resolution shooting with less
noise can be achieved. Highly sensitive shooting unique
to the large sensor can be achieved. In addition, the
camera is equipped with a ZEISS Vario-Sonnar T* built-
in lens.
Supports multi-format
3840 ×2160/29.97p (2SI)*1
1920 ×1080/59.94p, 1920 ×1080/59.94i, 1280 ×720/
59.94p
3840 ×2160/25p (2SI)*1
1920 ×1080/50p, 1920 ×1080/50i, 1280 ×720/50p
Switching possible with the SYSTEM SELECT switch
*1Compatible only with the BRC-X1000
Equipped with 3G-SDI and HDMI output
The camera can deliver 4K output for both Dual Link
3G-SDI ×2 (2SI) and HDMI.
Various installation environments are available in order
to establish a connection with HDMI, in addition to the
coaxial cable.
Equipped with PoE+ (Power Over
Ethernet Plus)
The camera is compatible with PoE+ (Power Over
Ethernet Plus), so a single LAN cable can be used for
power provision and control.
Adopting VISCA Camera Protocol
• The camera is equipped with a RS-422 communication
interface. The camera supports the industry-standard VISCA
camera protocol. Hence, a maximum of seven cameras can be
connected and remotely operated with high communication
speed (38,400 bps).
• Remote controller (not supplied) allows easy camera
operations.
Compatible with VISCA over IP protocol
An IP connection can be established between the camera
and the remote controller.
Equipped with External Video Sync Function
The camera is equipped with an external video sync
function to synchronize the camera images on multiple
cameras.
Equipped with Tally Lamp Function
The camera is equipped with a Tally lamp that quickly
distinguishes when the camera is in use.
The front Tally lamp is a large Tally lamp used for
improving visibility. The camera is also equipped with a
Tally lamp behind the camera block, in order to improve
visibility from the rear side.

7
Location and Function
of Parts
Camera
Front (BRC-X1000)
ALens
This is a 12×magnification optical zoom lens.
When CLEAR IMAGE ZOOM in the PAN TILT
ZOOM menu is turned on, the camera can zoom up
to 18×for 4K and 24×for HD.
Do not touch the part around the lens or the ring
outside the lens when energized. It may cause a
malfunction.
BTally lamp
Lights up in red when a VISCA Tally command is
received or the camera is selected by the remote
controller (not supplied) (depending on the setting
mode). Brightness can be selected from HIGH,
LOW, and OFF (the lights are turned off) in TALLY
MODE in the SYSTEM menu.
CRemote commander sensors
These are sensors for the supplied remote
commander.
DBack Tally lamp
Lights up in red when a VISCA Tally command is
received or the camera is selected by the remote
controller (not supplied) (depending on the setting
mode). The back Tally lamp does not light up when
TALLY MODE in the SYSTEM menu (page 41) is
set to OFF.
If a fault inside the camera is detected, the lamp
flashes at approximately 0.7 second intervals
irrespective of the on/off status of the back Tally
lamp. When a fault is detected, its content will be
displayed in the menu (see page 48). If, however,
“CAMERA FAULT” is shown, the back Tally lamp
may not flash.
ESONY nameplate, 4K or HD nameplate
Pull them out to turn them over and attach upside
down if required.
4K: BRC-X1000
HD: BRC-H800
FPOWER lamp
Flashes in green when the camera is connected to an
outlet using an AC adapter and power cord (not
supplied), or when power is being supplied by
connecting the camera and PoE+ Hub using a LAN
cable. The green lamp stops flashing and lights up
when start-up is complete.
The green lamp flashes when the camera receives an
operation command from the supplied remote
commander.
The orange lamp comes on when the POWER
button on the supplied remote commander is
pressed.
The yellow lamp flashes while upgrading the
firmware.
The yellow lamp flashes during a user version
upgrade.
The orange lamp flashes when there are defects in
the camera (for instance, when rotations of fan
motor slow down or stop etc.).
GNetwork lamp
Lamp flashes during initialization when it is
connected to a PoE+ Hub using a LAN cable and
power is being supplied from the PoE+ Hub. The
lamp lights up when it is connected to the network
once start-up is complete.
Lights up after start-up is complete if network is
connected, when power is supplied to the camera
from outlet using AC adapter and power cord. The
lamp is unlit when not connected to the network.
The lamp turns off while upgrading the firmware.
The lamp flashes when there are defects in the
camera (for example, when the fan motor stops).
Note
1
67
42
5
3

8
Back
HSYSTEM SELECT switch
Used for selecting the video format of the signal to
be output from the HDMI OUT, MONITOR OUT,
and LINE OUT terminals.
For details, see “SYSTEM SELECT switch
settings” (page 58).
IAC adapter cord clamper
Fix the cord of an AC adapter with the cord clamper
so that it does not come out.
Do not use any AC adapter other than the specified
optional one. Otherwise, a fire or malfunction may
occur.
JIR SELECT switch
Select the camera number when you operate
multiple cameras with the same remote commander.
KRemote commander sensors
This is sensor for the supplied remote commander.
LNetwork reset switch
This switch is for initializing network settings such
as the IP address.
Press the switch for 5 seconds or longer with a pen
point, etc., to initialize the network settings.
The camera will reboot, and the network settings
will return to the factory default.
Factory settings for network
IP address: 192.168.0.100
Subnet mask: 255.255.255.0
Default gateway: 0.0.0.0
Name: CAM1
Password: Admin_1234
MCAMERA SETUP switches
SDI format/level settings
The baud rate settings and camera address settings
of RS-422 are set for VISCA communication.
CAMERA SETUP switch settings
1SDI format/level settings
* Turn the power off or to standby, then turn the power
on to reflect the changes after setting
Note
EXT SYNC IN
TERMI-
NATION
ON OFF
ON
ON
OFF
LINE OUT
SDI 1
OSD
LAN
SDI 2
23456781
MONITOR OUTHDMI OUT
SDI 1 SDI 2
IN
SYSTEM
SELECT
IR SELECT CAMERA SETUP
123
VISCA RS- 422 OUT 12V
qd qf
qg qh qj w; wa ws wd wfqlqk
98 0 qa qs
EXT SYNC IN
TERMI-
NATION
ON OFF
ON
ON
OFF
OSD
LAN
23456781
HDMI OUT
IN
SYSTEM
SELECT
IR SELECT CAMERA SETUP
123
VISCA RS- 422 OUT 12V
MONITOR
OUT LINE OUT
qd qf
q
g
q
h
q
j
w
;
w
a
w
s
w
d
w
f
q
l
q
k
98 0 qa qs
BRC-X1000
BRC-H800
Switch No. Setting items
1Setting up 3G-SDI level
2System reserve
3
4Baud Rate settings of RS-422 for VISCA
communication
5VISCA Address settings for VISCA
communication
6
7
8System reserve
Switch state SDI format/level
ON Level-B
OFF Level-A
1456 7

9
4Baud Rate settings of RS-422 for VISCA
communication
* Turn the power off and on to reflect the changes
after setting
567 Camera address settings
Sets camera address.
It is normally set to “Auto”. When “Auto” is
selected, an address is automatically assigned to the
camera.
To set the address manually, set a value between “1”
to “7” for this switch as indicated below.
* Turn the power off and on to reflect the changes
after setting
NU(earth) terminal
OHDMI OUT terminal
Supplies the images as an HDMI video signal.
* The contents of the menu screen, such as text, can
be displayed in the output signal when the OSD
switch is turned ON.
• When either 0 or 8 is selected for SYSTEM
SELECT, 2K output from the HDMI output
terminal results in lower quality images.
• When 7 is selected for SYSTEM SELECT, VGA
output from the HDMI output terminal results in
lower quality images.
PVISCA RS-422 IN terminal
Connect with an remote controller (not supplied).
When you connect multiple cameras, connect it to
the VISCA RS-422 OUT terminal of the previous
camera in the daisy chain connection.
QVISCA RS-422 OUT terminal
When you connect multiple cameras, connect it to
the VISCA RS-422 IN terminal of the next camera
in the daisy chain connection.
RMONITOR OUT
Outputs the image from the camera as a 4K or HD
signal.
4K output:
Connect the SDI 1 (3G-SDI) output to the SDI 1
input and the SDI 2 (3G-SDI) output to the SDI 2
input respectively.
HD output:
Connect to SDI 1 (3G-SDI) or SDI 2 (3G-SDI).
* The contents of the menu screen, such as text, can
be displayed in the output signal when the OSD
switch is turned ON.
* For the BRC-H800, only HD output is available.
SOSD (On Screen Display) switch
The contents of the menu screen, such as text, can be
superimposed onto the video signal output to
MONITOR OUT & HDMI OUT when the switch is
turned ON.
TLINE OUT
Outputs the image from the camera as a 4K or HD
signal. OSD (screen display) is not superimposed,
irrespective of the OSD switch setting.
Equivalent signals are delivered to both SDI 1 and
SDI 2.
4K output:
Connect the SDI 1 (3G-SDI) output to the SDI 1
input and the SDI 2 (3G-SDI) output to the SDI 2
input respectively.
HD output:
Connect to SDI 1 (3G-SDI) or SDI 2 (3G-SDI).
* For the BRC-H800, only HD output is available.
ULAN (network) terminal (RJ-45)
Network communication and PoE+* power supply
are provided using the network cable (category 5e or
higher, shielded twist pair).
For more information on the connection, refer to the
instruction manual of the power supply system.
(*PoE+: an abbreviation of Power over Ethernet
Plus, which complies with IEEE802.3at)
The indicator lights up or flashes when the camera
is connected to the network.
The indicator is off when the camera is not
connected to the network.
VEXT SYNC IN
Accepts external video sync signals.
Switch state Baud Rate
ON 38,400 bps
OFF 9,600 bps
Switch No. Camera
address
56 7
OFF OFF OFF Auto
ON OFF OFF 1
OFF ON OFF 2
ON ON OFF 3
OFF OFF ON 4
ON OFF ON 5
OFF ON ON 6
ON ON ON 7
Notes

10
WTERMINATION switch
X12 V !(DC power input) terminal
Connect the AC adapter (not supplied).
Bottom
wg Ceiling bracket mounting screw holes
When you install the camera to the ceiling, on a
shelf, or in another high spot, secure the supplied
ceiling bracket to these holes using four of the
supplied screws.
The four feet are attached to the holes at the factory.
For installation, see “Installing the camera at a high
spot” (page 16).
wh Tripod screw holes (1/4-20UNC)
Used to fix the camera to the camera tripod or
something similar.
wj Rating label
This label shows the name of device and its electric
rating.
The product name and electric rating are located at
the bottom of the unit.
Remote commander (supplied)
ACAMERA SELECT buttons
Press the button corresponding to the camera you
want to operate with the remote commander. The
camera number can be set using the IR SELECT
switch on the rear of the camera.
If two or more cameras are adjacent and have the
same camera number, they are operated
simultaneously with the supplied remote
commander. When you install the cameras close to
each other, set different camera numbers.
For setting of camera No., see “Operating multiple
cameras with the remote commander” (page 44).
BFOCUS buttons
Used for focus adjustment.
Press the AUTO button to adjust the focus
automatically. To adjust the focus manually, press
the MANUAL button, and adjust it with the FAR
and NEAR buttons.
Important
whwg wg wj
Note
POWER
CAMERA SELECT
123
AUTO
POSITION
HOME
RESET
PRESET
STD REV
BACK LIGHT
MANUAL
FAR
FOCUS
NEAR
W
T
W
T
123
456
PAN - T I LT
SLOW FAST
ZOOM
L/R
DIRECTION SET
PAN - T I LT
RESET
DATA SCREEN
6
7
8
9
q;
1
2
3
4
5

11
Press the MANUAL button and adjust the focus
manually when shooting the following objects.
• White walls and other objects without contrast
• Objects behind glass
• Objects with horizontal stripes
• Objects on which bright lights are cast or reflected
• Nightscapes and other dark objects with blinking
lights
• Lit objects shot with darkened exposure
adjustment or exposure compensation settings
CDATA SCREEN button
Press this button to display the main menu PAGE.
Press it again to close the menu. If you press the
button when a lower-level menu is selected, the
display goes back to a higher-level menu.
• You cannot perform pan/tilt/zoom operations
while the menu is displayed.
• The menus are output through MONITOR OUT
and HDMI OUT.
When you want to display the menus, turn on the
OSD switch on the back of the camera.
DPAN-TILT button
Press the arrow buttons to pan or tilt the camera.
Press the HOME button to face the camera back to
the front.
When the menu is displayed, use Vor vto select the
menu items and Bor bto change the set values.
Display the menu of selected items with the HOME
button.
The selected setting menu is displayed by pressing
the HOME button when the main menu is displayed.
EL/R DIRECTION SET button
Hold down this button and press the REV button to
change the direction of the camera movement to be
opposite the direction of the arrows on the Band b
buttons. To reset the direction of the camera
movement, press the STD button while holding
down this button.
FPOWER button
Press this button to turn on power or to put the
camera in the standby mode.
GBACK LIGHT button
Press this button to enable backlight compensation.
Press it again to disable backlight compensation.
The BACK LIGHT button is enabled when MODE
in the EXPOSURE menu is FULL AUTO,
SHUTTER Pri, IRIS Pri, or GAIN Pri.
HPOSITION buttons
Hold down the PRESET button and press button 1 to
6 to store the current camera direction, zoom, focus
adjustment and backlight compensation in the
memory of the pressed number button.
To erase the memory contents, hold down the
RESET button and press button 1 to 6.
• These buttons do not function when the menu is
displayed.
• Some memory contents may not be erased even if
you use the RESET button.
For details on items that can be stored by the
PRESET button and erased by the RESET button,
see “Preset Items” (page 53).
IPAN-TILT RESET button
Press this button to reset the pan/tilt position.
JZOOM buttons
Use the SLOW button to zoom slowly, and the
FAST button to zoom quickly.
Press the T (telephoto) side of the button to zoom in,
and the W (wide angle) side to zoom out.
Notes
Notes
Note
Notes

12
Installing Batteries in the remote
commander
Installing batteries
Two R6 (size AA) batteries are required for the remote
commander. To avoid the risk of explosion, use R6 (size
AA) manganese or alkaline batteries.
Danger of explosion if the batteries are incorrectly
replaced. Replace only with the same or equivalent type
recommended by the manufacturer. When you dispose
of the batteries, you must obey the laws of your area or
country.
R6 (size AA) batteries are not supplied.
Note
Two R6 (size AA) batteries
(not supplied)

13
System Configuration
This camera can be arranged into various system configurations with other products (not supplied). This section
describes typical system examples, with the required components and the main usage of each system.
Operating the camera using the supplied remote commander
What you can do with this system
Operate the camera readily from a short distance.
System Configuration
Operating the camera using the remote controller (not supplied)
What you can do with this system
Perform pan/tilt and zoom operations using the joystick of the remote controller.
System Configuration
Remote commander (supplied)
Video monitor
Video signal
Signal flow
,
Remote controller
Video monitor
Video signal
Remote Control (VISCA) signal
Signal flow

14
Connecting multiple cameras to the remote controller (not supplied)
What you can do with this system
• Operate up to seven cameras remotely using a single remote controller.
• Perform pan/tilt and zoom operations using the joystick.
System Configuration
,
Remote controller
Video monitor
Video switcher
Video signal
Remote Control (VISCA) signal
Tally/contact signal
Signal flow

15
Installation and Connection
Installing the Camera
• Be sure to provide safety measures against falling
when you mount the camera.
• Do not grasp the camera head when carrying the
camera.
• Do not turn the camera head by hand. Doing so may
result in a camera malfunction.
Installing the camera on a desk
Installing the camera on a desk
Place the camera on a flat surface.
If you have to place the camera on an inclined surface,
make sure that the inclination is less than ±15 degrees to
guarantee pan/tilt performance, and take measures to
prevent it from falling.
Attaching the camera to a tripod
Screw the tripod screw into a tripod screw hole on the
bottom of the camera.
The tripod should be placed on a level surface, and
tighten the screw firmly by hand.
The tripod screw should be compliant with the following
standards.
4= 4.5 - 7 mm
4= 0.18 - 0.27 inches
Notes
Caution
Installation of the camera using the tripod screws and
screw holes should not be done for installation on a
ceiling, shelf, or other high spot.
1/4-20UNC

16
Installing the camera at a high spot
The camera can be mounted on a ceiling or on a shelf or
stand located at a high spot using the supplied ceiling
bracket.
The surface on which the camera will be mounted
should be level. If you have to mount the camera on a
tilted surface, make sure that the angle is less than 15
degrees to ensure the camera can pan/tilt properly.
Before installing the camera
Decide which way the camera will shoot, and drill holes
for the ceiling bracket (B) and the connecting cable in
the ceiling or the shelf. For the dimensions of the ceiling
bracket (B), refer to page 57.
• Connection cables cannot be routed through the
ceiling bracket (A). A hole to route wires through is
needed in the ceiling or the shelf at the back of the
camera.
• Do not mount anything other than the camera onto the
ceiling bracket.
• The ceiling bracket cannot be mounted on a junction
box.
Installing the camera on the ceiling
(example)
1 Turn on IMG FLIP in the SYSTEM menu.
2 Loosen the four screws at the bottom of the camera
to remove the four feet.
Caution
• When you want the camera to be mounted at a high
spot, such as on a ceiling, have a professional
contractor do the job.
• When you mount the camera at a high spot, make
sure the attachment materials to which the camera
will be mounted and the fittings (except for
accessories) are capable of supporting a weight of
60 kg or greater and that the installation is done
properly. If the installation is not strong enough, the
camera may fall, resulting in a serious injury.
• As a fall prevention measure, be sure to attach the
supplied wire rope to the camera securely.
• When you mount the camera at a high spot, inspect
the installation once a year for any loosened parts.
Depending on the operation conditions, inspect
more frequently.
Notes

17
3 Attach the ceiling bracket (A) to the bottom of the
camera by using supplied four screws (3M3 ×8).
Align the amark of the bracket (A) with the front
of the camera as illustrated, with the screw holes of
the bracket aligned to the screw holes of the camera.
4 Attach the ceiling bracket (B) to the attachment
materials (not supplied) to mount the camera on the
ceiling.
Be sure to attach it so that the fhole of the ceiling
bracket (B) is placed where the front of the camera
will face.
5 Attach the wire rope for fall prevention to the
ceiling.
Using an M5 (3/16 inches) socket cap screw (not
supplied), attach it to the attachment materials
different from the one to which the ceiling bracket
(B) is attached.
Caution
Use the supplied screws. Otherwise, you may
break the internal parts of the camera.
Front of the
camera
Ceiling
bracket (A)
3M3×8(supplied)
amark
fhole
Ceiling
Ceiling bracket (B)
Attachment materials
Ceiling
Ceiling bracket (B)
Attachment
materials
M5 (3/16 inch) socket
cap bolt
Wire rope (supplied)

18
6 Attach the wire rope for fall prevention to the ceiling
bracket (A).
Put the wire rope through the fitting for wire rope of
the ceiling bracket (A) and securely attach it to the
bracket using the supplied stainless steel screw
(3M4 ×8).
7 Aligning the ahole in the front of the ceiling
bracket (A) to the hole of the ceiling bracket (B),
push in the camera unit, and turn the camera with the
ceiling bracket (A) clockwise to temporarily secure
the camera.
8 Secure the ceiling brackets (A) and (B) using
supplied three screws (3M3 ×8).
Caution
Use the supplied screw. Otherwise, the wire rope
may not function properly.
Ceiling
bracket (A)
Wire rope (supplied)
3M4 ×8(supplied)
Fitting for wire rope
1
2
Ceiling
bracket (B)
Ceiling
Align
Ceiling
bracket (A)
amark
mark
Ceiling
3M3×8
(supplied)

19
9-1 Connect the cables to the terminals at the back of
the camera.
• Make sure no load is applied to connectors of the
cables.
• For measures that prevent the cord of the AC
adapter (not supplied) from being pulled out,
refer to “Connecting the Camera” (page 23).
• For measures that prevent the HDMI cable from
being pulled out, proceed to “9-2” after
connecting the HDMI cable. Then, connect all
the other cables.
9-2 To help prevent the HDMI cable from being pulled
out, remove the HDMI cable locking screw
(M2.6 ×6, black), and use it to attach the supplied
HDMI cable fixing plate to the back of the camera.
Secure the HDMI cable with a commercially
available tie-wrap.
Do not leave the HDMI cable attached to the camera
if you do not use it.
10 Flip the SONY nameplate and 4K or HD nameplate
around as necessary.
How to remove the camera
1 Remove the three screws which secured the camera
in Step 8 of “Installing the camera on the ceiling
(example)”.
2 Turn the camera unit counter-clockwise to remove
it.
Notes
Ceiling
Note
HDMI cable locking screw (M2.6 ×6, black)
HDMI cable fixing plate (supplied)
Tie-wrap (commercially
available)

20
Installing the camera on a shelf located
at a high spot (example)
1 Loosen the four screws at the bottom of the camera
to remove the four feet.
2 Attach the ceiling bracket (A) to the bottom of the
camera by using supplied four screws (3M3 ×8).
Align the amark of the bracket (A) with the front
of the camera as illustrated, with the screw holes of
the bracket aligned with the screw holes of the
camera.
Use the supplied screws. Otherwise, you may break
the internal parts of the camera.
3 Attach the wire rope for fall prevention to the ceiling
bracket (A).
Put the wire rope through the fitting for wire rope of
the ceiling bracket (A) and securely attach it to the
bracket using the supplied stainless steel screw (3
M4 ×8).
Front of the
camera Ceiling
bracket (A)
3M3×8(supplied)
amark
Note
Caution
Use the supplied screw. Otherwise, the wire rope
may not function properly.
Ceiling
bracket (A)
Wire rope (supplied)
3M4 ×8(supplied)
Fitting for wire rope
