SERVICE MANUAL
Sony Corporation
Published by Sony Techno Create Corporation
HVL-F60M
SPECIFICATIONS
FLASH
9-893-591-02
2012L33-1
© 2012.12
US Model
Canadian Model
AEP Model
UK Model
E Model
Chinese Model
Ver. 1.1 2012.12
Guide number
Normal flash (ISO100 in meters)
Manual flash/35mm-format
APS-C format
Power level BA* BA Flash coverage setting (mm)
15* 24 28 35 50 70 105
1/1 152017293136424860
1/2 10.614.112.020.521.925.529.733.942.4
1/4 7.5 10.0 8.5 14.515.518.021.024.030.0
1/8 5.3 7.1 6.0 10.3 11.0 12.7 14.8 17.0 21.2
1/16 3.8 5.0 4.3 7.3 7.8 9.0 10.5 12.0 15.0
1/32 2.7 3.5 3.0 5.1 5.5 6.4 7.4 8.5 10.6
1/64 1.9 2.5 2.1 3.6 3.9 4.5 5.3 6.0 7.5
1/128 1.3 1.8 1.5 2.6 2.7 3.2 3.7 4.2 5.3
1/256 0.9 1.3 1.1 1.8 1.9 2.3 2.6 3.0 3.8
BA: When bounce adaptor is attached
* When the wide panel is attached.
Power level BA* BA Flash coverage setting (mm)
15* 24 28 35 50 70 105
1/1 15 20 17 31 36 42 48 51 60
1/2 10.6 14.1 12.0 21.9 25.5 29.7 33.9 36.1 42.4
1/4 7.5 10.0 8.5 15.5 18.0 21.0 24.0 25.5 30.0
1/8 5.3 7.1 6.0 11.0 12.7 14.8 17.0 18.0 21.2
1/16 3.8 5.0 4.3 7.8 9.0 10.5 12.0 12.8 15.0
1/32 2.7 3.5 3.0 5.5 6.4 7.4 8.5 9.0 10.6
1/64 1.9 2.5 2.1 3.9 4.5 5.3 6.0 6.4 7.5
1/128 1.3 1.8 1.5 2.7 3.2 3.7 4.2 4.5 5.3
1/256 0.9 1.3 1.1 1.9 2.3 2.6 3.0 3.2 3.8
BA: When bounce adaptor is attached
* When the wide panel is attached.
HSS flat flash (ISO100 in meters)
Manual flash/35mm-format
APS-C format
Recycling time/Number of flashes
sThe number of flashes is the approximate number of times the
flash unit can fire before a new battery is completely dead.
Shutter speed BA* BA Flash coverage setting (mm)
15*2428355070105
1/250 5.4 7.7 6.4 11.8 12.9 14.8 17.3 19.5 22.4
1/500 3.8 5.4 4.6 8.4 9.1 10.5 12.2 13.8 15.9
1/1000 2.7 3.8 3.2 5.9 6.4 7.4 8.6 9.8 11.2
1/2000 1.9 2.7 2.3 4.2 4.6 5.2 6.1 6.9 7.9
1/4000 1.4 1.9 1.6 3.0 3.2 3.7 4.3 4.9 5.6
1/8000 1.0 1.4 1.1 2.1 2.3 2.6 3.1 3.5 4.0
1/12000 0.7 1.0 0.8 1.5 1.6 1.8 2.2 2.4 2.8
BA: When bounce adaptor is attached
* When the wide panel is attached.
Shutter speed BA* BA Flash coverage setting (mm)
15*2428355070105
1/250 5.4 7.7 6.4 12.9 14.8 17.3 19.5 19.9 22.4
1/500 3.8 5.4 4.6 9.1 10.5 12.2 13.8 14.0 15.9
1/1000 2.7 3.8 3.2 6.4 7.4 8.6 9.8 9.9 11.2
1/2000 1.9 2.7 2.3 4.6 5.2 6.1 6.9 7.0 7.9
1/4000 1.4 1.9 1.6 3.2 3.7 4.3 4.9 5.0 5.6
1/8000 1.0 1.4 1.1 2.3 2.6 3.1 3.5 3.5 4.0
1/12000 0.7 1.0 0.8 1.6 1.8 2.2 2.4 2.5 2.8
BA: When bounce adaptor is attached
* When the wide panel is attached.
Alkaline Nickel hydride
(2100 mAh)
Recycling time (sec) Approx. 0.1 - 3.5 Approx. 0.1 - 2.6
Number of flashes (times) Approx. 120 or more Approx. 200 or more
Continuous flash
performance
40 flashes at 10 flashes per second
(Normal flash, power level 1/32, nickel-metal hydride
battery)
AF illuminator Autoflash at low contrast and low brightness
Operating range (with a 50 mm lens attached to
SLT-A99V)
Central area (approx.): 0.5 m to 10 m (1 ft. 7 3/4 in. to 32
ft. 9 3/4 in.)
Peripheral areas (approx.): 0.5 m to 3 m (1 ft. 7 3/4 in. to 9
ft. 10 1/8 in.)
Flash control Flash control using pre-flash
LED light Center luminance
intensity: Approx. 1200 lux at 0.5m (1 feet
7 3/4 inches) or 300 lux at 1m (3
feet 3 3/8 inches) (without built-
in diffuser for LED light or color
temperature conversion filter)
Lighting distance: Approx. 2m (6 feet 6 3/4 inches)
(When recording movies, set to
ISO 3200 & F5.6, without built-in
diffuser for LED light or color
temperature conversion filter)
Focal length supported: 35mm (35mm format
angle of view, without
built-in diffuser for LED
light or color temperature
conversion filter)
Continuous lighting Approx. 1 hour (using AA
ta,seirettabenilakla:emit
center luminance
intensity)
Color temperature: Approx. 5500K (without built-in
diffuser for LED light or color
temperature conversion filter)
Approx. 3200K (without built-in
diffuser for LED light, using color
temperature conversion filter)
Functions in these operating instructions depend on testing conditions at our firm.
Design and specifications are subject to change without notice.
Trademark
“Multi Interface Shoe” is a trademark of Sony Corporation.
Dimension
(Approx.)
80 mm × 150 mm × 102 mm (W/H/D) (3 1/4 in. × 6 in. × 4
1/8 in.)
Mass (Approx.) Approx. 450 g (15.9 oz) (main body only)
Power requirements DC 6 V
Recommended
batteries
Four AA-size alkaline batteries
Four AA-size rechargeable nickel-metal hydride batteries
Included items Flash unit (1), Bounce adaptor (for flash)(1), Color
conversion filter (for LED light) (1), Connector protect
cap (1), Mini-stand (1), Shoe Adaptor (ADP-AMA) (1),
Carrying case (1), Mini-carrying case(1), Carrying
pouch(1), Set of printed documentation
