General
Wired remote (RM-X81RF)
System Compact disc digital audio system
Laser Diode Properties
Material GaAlAs
Wavelength 780 nm
mission Duration Continuous
Laser output power Less than 44.6 µW*
* This output is the value measured at a distance of 200 mm from the objective lens surface on the Optical Pick-up Block.
Transmitting frequency 88.3 MHz/88.5 MHz/
88.7 MHz/88.9 MHz/
89.1 MHz/89.3 MHz/
89.5 MHz/89.7 MHz/
89.9 MHz/(switchable)
Input/output terminals Wired remote control (8 pin)
RF signal (FM) output
Power input (3 pin)
Current drain 800 mA (at playback)
800 mA (at disc loading/ejecting)
Operating temperature 10°C to +55°C (14°F to 131°F)
Dimensions Approx. 262 × 90 × 185 mm
(10 3/8 × 3 5/8 × 7 3/8 in.) (w/h/d)
Mass Approx. 2.1 kg (4 lb. 10 oz.)
2002 SONY MOBILE
PRODUCT GUIDE
Input/output Antenna input terminal
Antenna output cord
CD Changer input cord
Dimensions Approx. 40 × 40 × 27 mm
(1 5/8 × 1 5/8 × 1 1/8 in.) (w/h/d)
Mass Approx. 140 g (5 oz.)
Dimensions Approx. 52 × 8.5 × 90 mm
(2 1/16 × 3/8 × 3 9/16 in.) (w/h/d)
Mass Approx. 30 g (1 oz.) not incl. battery
Battery Lithium battery (CR2025)
Wireless remote (RM-X81RF)
CDX-555RF
Compact Disc Changer System
Relay Box
Dimensions Approx. 122 × 36.5 × 15.5 mm
(4 3/8 × 1 7/16 × 5/8 in.) (w/h/d)
Mass Approx. 255 g (9 oz.)
 CD-R Playback
 110-CD Custom File memory
 Built-in RF Modulator
 9 selectable RF frequencies
 5 selectable output levels
 Super Suspension Shock Isolation
 XA-250 10-disc Magazine
 Supplied Low-profile Wired Commander
(RM-X80RF)
 Supplied Wireless Remote (RM-X81RF)
 Indicates step-up
 CD T XT®
 8X Oversampling
 1-Bit D/A Converter
 D-Bass
Supplied accessories Disc magazine (1)
Parts for installation and connections (1 set)
CD Changer
Plug shown with wires facing viewer.
Pin Number Wire Color Description
1 Black Ground
2 Yellow Battery
3 Red Accessory
Harness Plug Configuration
321
Design and Specifications subject to change without notice.

185 mm (7 3/8)
2002 SONY MOBILE
PRODUCT GUIDE
CDX-555RF
Compact Disc Changer System
90 mm (3 5/8)
Wired Remote Connector
Relay Box Connector
Power
Design and Specifications subject to change without notice.
