Sony DSX-S100 User manual

DSX-S100
DSX - S100 Digital Media Receiver
FLIP - DOWN FACE WITH FRONT AUX IN
The 2 - line fluorescent LCD display makes it easy to read song information
and the front auxiliary input lets you connect almost any portable audio
device to your car's sound system.
INTEGRATED TUNE TRAY
Tune Tray compartment lets you easily connect your iPod , Walkman
player or other USB device via USB 1 - Wire . Your iPod and connector are
secured inside the receiver, and the reminder alert ensures you don’t
leave your device behind.
QUICK - BROWZER WITH JUMP MODE FEATURE
Search and select songs by category, including artist, album, genre, or
playlist. Jump Mode allows you to fast forward through a music category in
10 percent increments.
ZAPPIN ™FUNCTION
Use ZAPPIN function to play 6, 9, or 30 - second music clips until you find the
song you want.
MP3/WMA PLAYBACK WITH DM+
Hear the music on your recorded files in their original vibrancy with DM+
(Digital Music Plus), an original Sony codec enhancer that reproduces
detailed and high - frequency sound from compressed audio.
SATELLITE RADIO / HD RADIO ™ READY
The DSX - S100 integrates seamlessly with Satellite Radio and HD Radio
Sony Bus adaptors so you can receive digital satellite radio or HD Radio
broadcasts.
EQ3, DSO AND 52 WATTS X 4 HIGH POWER
The DSX - S100 delivers 52 watts of peak power to all four speakers while DSO
and EQ3 stage 2 lets you adjust the mix for a dynamic sound experience.
The Sony DSX - S100 stereo receiver features a Tune Tray that eliminates
visible wires in your car, allowing you to connect and store your iPod
behind the sleek flip - down faceplate. To make the most of your drive
time the latest Sony audio technologies, including DM+ Advanced,
ZAPPIN™and Quick - BrowZer features are also included.
®2
®
5
®
1
®
3
4
3
4
®
®
®2
®

Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1.800.222.7669 • www.sony.com
Last Updated: 04/08/2011
DSX-S100
DSX - S100 Digital Media Receiver
Specifications
Convenience Features
On - Screen Clock: 12H
DimmerAdjust: Selectable Auto adjust or
manual on/off
KeyIllumination: Blue
General
Color: Dark Titanium
Audio
PreoutImpedance: 220 ohms
PreoutVoltage: 2 volt
S/NRatio: Audio Power: CEA2006 S/N 80
dBA
StationPreset(s): 18 FM / 12 AM
Digital - to - AnalogConverter: 24bit
Tuner Frequency Range: FM:Tuner
Frequency Range(MHz): 87.5 - 107.9
AM:Tuner Frequency Range(kHz): 530 -
1710
TunerType: SSIR - EXA with RDS
VolumeControl: Tel/Nav Attenuation
Band: AM / FM
Format(s)Supported: MP3/WMA/AAC
files
Equalizer: EQ3: 3 band EQ
+/ - 10 dB at 60 Hz
+/ - 10 dB at 1 kHz
+/ - 10dB at 10 kHz
Convenience
TiltRange: 0 - 45 ° mounting angle
Display
Technology: LCD
DisplayColor: Black color / Negative
TextDisplayed: Source, artist, track,
playback time, menu and clock
TextLines: 2 lines of information
Amplifier Section
SpeakerImpedance: 4 - 8 Ohms
Max power output: 52 watts x 4 at 4 ohms
Tuner
FM Usable Sensitivity: 10 dBf
Selectivity: 75 dB at 400 kHz
S/NRatio: 70 dB (mono)
FrequencyResponse: FM: 20 - 15,000 Hz
StereoSeparation: 40 dB at 1 KHz
Power
OutputPower: 52W x4 Watts Max Power -
CEA2006 Standard Power Output: 17
Watts RMS per channel into 4 Ohms, 4
channels driven from 20 Hz to 20 kHz with
less than 1% THD+N.
CurrentDrain: 3 - 5 amps
InputVoltage: 12 V DC car battery
(negative ground)
1
Inputs and Outputs
RCA Audio Output(s): Front and Rear/Sub
selectable RCA pre - amp outputs
Digital Audio Input(s): Ability to use all
forms of USB devices may vary as not all
devices are compatible.
This unit can be connected to the
following iPods. Update your iPod to the
latest software before you use it.
iPod Nano 1st generation*
iPod Nano 2nd generation (aluminum)
iPod Nano 3rd generation (video)
iPod 5th generation (video)*
iPod Classic
iPod Touch
This unit is compliant with MSC (Mass
Storage Class) and MTP (Media Transfer
Protocol) type USB devices compliant
with the USB standard.
This unit cannot recognize USB devices
via a USB hub.
If you have any questions or problems
concerning your unit that are not
covered in the owners manual, consult
your nearest Sony dealer.
USBPort(s): USB - Full Speed
AntennaTerminal(s): AM/FM Antenna
Input Terminal
12V Trigger Output(s): Power antenna
Amplifier turn on
RemoteJack: Optional wired remote
terminal
AudioIn: Front Aux with variable level: - 8dB
∼
+18dB
USB input
Sony Bus terminals
InfraredPort: Wireless remote input
Dimensions
Weight: 1.3 kg (2 lb. 14 oz.)
Measurements: 178 x 50 x 179mm
Supplied Accessories
Parts for installation and connections (1
set)
RM - X151 wireless remote
XA - 50IP USB connector for iPod
Optional Accessories
Replacement remote: RM - X151
CD changer (6 discs): CDX - T69
Source selector: XA - C40
Aux - in selector: XA - 300
HD Radio ® tuner: XT - 100HD
Walkman player USB adapter: XA - 50WM
®
Color: Dark Titanium
UPC Code: 027242787438
1.NotallMP3,WMA,AACfilesmayplaybackduetofilevariations.
CopyrightprotectedACC - LCfiles cannot be played back.
2.Abilityto use all generations ofiPodproducts may vary as notall
productsare compatible. Compatiblewith iPod ® touch,iPodNano
3rdgeneration, iPod classic, iPodNano2nd generation, iPod 5th
generation,iPod Nano 1stgeneration, iPod 4thgeneration, iPod mini.
3.Satelliteradioservice requires a satellite radio tuner andservice
subscription,soldseparately.
4. HD Radio ™ capability requires an optional HD Radio tuner (XT -
100HD).
5.Abilityto use all forms of USBdevicesmay vary as not all devicesare
compatible.
©2010SonyElectronicsInc.Allrightsreserved.Reproductioninwholeor
inpart without written permissionis prohibited. Sony, Quick - Browzer,
Walkman,Xpl
ō d, ZAPPIN, and the Sony and Xpl ō dlogosaretrademarksof
Sony.iPodisatrademarkofAppleInc.Allothertrademarksare
trademarksoftheir respective owners. Features and specificationsare
subjectto change withoutnotice. Non - metricweightsandmeasuresare
approximateand may vary.
