Sony XR-1100 User manual

2000 Sony Corporation
Operating Instructions
FM/AM
Cassette Car
Stereo
XR-1100
For installation and connections, see the supplied installation/connections
manual.
GB
3-868-315-51 (1)

2
GB
Features
General
•Built-in power amplifier (max. output:
45 W ×4 ch) enables you to enjoy a
4-speaker system.
•Digital 12-hour clock provided (page 6).
•D-BASS function enables you to enjoy clear
and powerful bass sounds (page 9).
Cassette player section
ATA (Automatic Tuner Activation) for
automatically turning on the tuner while fast-
forwarding or rewinding a tape (page 7).
Tuner section
•Up to 18 stations can be preset: 12 stations on
FM and 6 stations on AM.
•Automatic memory function stores a total
of 18 stations in memory quickly and easily
(page 8).
Welcome!
Thank you for purchasing the Sony Cassette
Car Stereo. This unit lets you enjoy a variety of
features.

3
GB
Precautions
•If your car was parked in direct sunlight
resulting in a considerable rise in
temperature inside the car, allow the unit to
cool off before operating it.
•If no power is being supplied to the unit,
check the connections first. If everything is in
order, check the fuse.
•If no sound comes from the speakers of a
2-speaker system, set the fader control to the
center position.
•If your car is equipped with a power
antenna, note that it will be automatically
extended while the unit is operating.
If you have any questions or problems
concerning your unit that are not covered in
this manual, please consult your nearest Sony
dealer.
To maintain high quality sound
If you have drink holders near your audio
equipment, be careful not to splash juice or
other soft drinks onto the car audio. Sugary
residues on this unit or cassette tapes may
contaminate the playback heads, reduce the
sound quality, or prevent sound reproduction
altogether.
Cassette cleaning kits cannot remove sugar
from the tape heads.
Notes on cassettes
Cassette care
•Do not touch the tape surface of a cassette, as
any dirt or dust will contaminate the heads.
•Keep cassettes away from equipment with
built-in magnets such as speakers and
amplifiers, as erasure or distortion on the
recorded tape could occur.
•Do not expose cassettes to direct sunlight,
extremely cold temperatures or moisture.
•When the tape is played back for a long
period, the cassette may become warm
because of the built-in power amplifier. This
is not a sign of a malfunction.
•Slack in the tape may cause the tape to be
caught in the machine. Before you insert the
tape, use a pencil or similar object to turn the
reel and take up any slack.
•Distorted cassettes and loose labels can cause
problems when inserting or ejecting tapes.
Remove or replace loose labels.
Notes on cassette deck tape heads
•Long use of cassette tapes contaminates the
tape head causing poor sound quality or
complete sound dropout. Therefore, we
recommend cleaning the tape head once a
month or so with the separately available
Sony Cassette Cleaning Set. If the sound does
not improve after using a cleaning cassette,
please consult your nearest Sony dealer.
•In case of old or inferior cassette tapes, the
tape head gets contaminated much more
quickly. Depending on the tape, one or two
playbacks may cause poor sound.
Slack

4
GB
Cassettes longer than 90 minutes
The use of cassettes longer than 90 minutes is
not recommended except for long continuous
play. The tapes used for these cassettes are
very thin and tend to be stretched easily.
Frequent playing and stopping of these tapes
may cause them to be pulled into the cassette
deck mechanism.
Table of Contents
Location of controls ................................................. 5
Getting Started
Setting the clock .................................................. 6
Cassette Player
Listening to a tape ............................................... 7
Ejecting the cassette ............................................ 7
Fast-winding the tape ......................................... 7
Radio reception during fast-forwarding or
rewinding of a tape
— ATA (Automatic Tuner Activation)
function ........................................................... 7
Radio
Searching for stations automatically
— Automatic tuning ...................................... 8
Tuning in by adjusting the frequency
— Manual tuning ........................................... 8
Memorising stations automatically
— Automatic memory function ................... 8
Memorising only the desired stations .............. 9
Receiving the memorised stations .................... 9
Other Functions
Adjusting the sound characteristics ................. 9
Boosting the bass sound
— D-Bass ......................................................... 9
Attenuating the beep tone ............................... 10
Additional Information
Maintenance ....................................................... 10
Dismounting the unit ....................................... 11
Specifications ..................................................... 12
Troubleshooting guide ..................................... 13

5
GB
Location of controls
Refer to the pages for further details.
1SOUND (control mode select) button
6, 9, 10
2TUNER/A MEM (radio on •band select/
automatic memory) button 6, 8, 9
3(volume/bass/treble/balance/
fader control) buttons 6, 9
4Z(eject) button 7
5Display window
6m/M(fast winding)/DIR (tape
transport direction change) buttons 7
D-BASS
DSPL
234561
LOCAL
SOUND
OFF
ATA
A MEM
TUNER
SEEK
MANU
XR-1100
DIR
7D-BASS button 9
8OFF button
9During radio reception:
Preset number buttons 9
During tape playback:
1
ATA
(Automatic Tuner Activation)
button 7
q; SEEK/MANU button 8
qa LOCAL (local seek) button 8
qs DSPL (display mode change/time set)
button 6

6
GB
The clock activates.
6Press the
DSPL
button momentarily.
Note
The clock cannot be set unless the power is turned
on. Set the clock after you turn on the radio, or
during tape playback.
Getting Started
Setting the clock
The clock has a 12-hour digital indication.
For example, setting it to 10:08
1Turn the ignition switch of your car on.
2Press the
TUNER
button, or insert a cassette
to turn the unit on.
3Display the time.
(Press the
DSPL
button during unit
operation.)
4Press the
DSPL
button for more than two
seconds.
Set the hour digits.
5Press the
SOUND
button momentarily.
Set the minute digits.
to go forward
to go back
to go forward
to go back
The hour digit blinks.
The minute digits blink.

7
GB
Direction
indicator*
N
n
To advance To rewind
To resume playback, press the other fast-
winding button partially until the locked
button is released.
*The nor Nindicator will flash while fast-
winding the tape.
Radio reception during
fast-forwarding or
rewinding of a tape
— ATA (Automatic Tuner Activation) function
Press the
1
ATA
button during playback.
t“ATA” appears on the display.
When fast-forwarding or rewinding with the
mor Mbutton, the tuner will turn on
automatically.
Fast-winding the tape
Cassette Player
Listening to a tape
After inserting the cassette, playback
will start automatically.
To change the tape direction,
press both the mand the Mbuttons at the
same time.
Indication of tape transport direction
The side facing up is being played.
The side facing down is being played.
At the end of the tape, the playing direction
will change automatically.
Note
Before turning off the unit, eject the tape to avoid
tape damage.
Ejecting the cassette
Press the button to stop playback and eject
the cassette.
DIR
Getting Started/Cassette Player

8
GB
Tuning in by adjusting the
frequency —Manual tuning
1Select the desired band.
2Press and hold either side of the SEEK/
MANU button.
Release the button when the desired station
is received.
PREVENT ACCIDENTS!
While driving, use the automatic tuning and
the memory preset tuning instead of the
manual tuning.
Memorising stations
automatically
—Automatic memory function
Stations with the clearest reception are
automatically searched and memorised on
each band (FM1, FM2 and AM). Up to 6
stations on each band can be stored on the
preset number buttons 1 to 6 in the order of
band frequency.
1Select the desired band.
2Press the TUNER/A MEM button for more
than two seconds.
The unit will start scanning the selected
band and automatically memorise the
tuned stations on the preset number button
1 through 6.
FM1 tFM2 tAM tFM1
FM1 tFM2 tAM tFM1
Radio
Searching for stations
automatically
—Automatic tuning
1Select the desired band.
2Press either side of the SEEK/MANU
button momentarily to search for the
next station (automatic tuning).
The scanning stops when a station is received.
Press either side of the button repeatedly until
the desired station is received.
When an FM stereo programme with a sufficient
signal strength is tuned in,
To avoid the automatic tuning from stopping on
stations too frequently, press the LOCAL button
momentarily to get the “LCL” indication (local
seek mode).
Only the stations with relatively strong signals will
be tuned in. The local seek mode functions only
when the automatic tuning is in operation.
the “STEREO” indication will appear.
FM1 tFM2 tAM tFM1
For lower
frequencies
For higher
frequencies
A MEM
TUNER
SEEK
MANU
A MEM
TUNER
For lower
frequencies
For higher
frequencies
SEEK
MANU
A MEM
TUNER
A MEM
TUNER

9
GB
0dB
D-BASS 3
D-BASS 2
D-BASS 1 D-BASS 3
D-BASS 2
D-BASS 1
Memorising only the
desired stations
1Select the desired band.
2Tune in the station which you wish to
store on the preset number button.
3Press and hold the desired preset
number button (
1
ATA
to 6) for about
two seconds until you hear a beep tone.
The number of the pressed preset number
button appears in the display window.
Up to 6 stations on each band (FM1, FM2 and AM)
can be stored on the preset number buttons in the
order of your choice. Therefore, 12 stations can be
memorised on FM.
If you try to store another station on the same
preset number button, the previously stored
station will be erased.
Receiving the memorised
stations
1Select the desired band.
2Press momentarily the preset number
button on which the desired station is
stored.
Note
If you press the preset number button for more
than two seconds, the currently received station
will be memorised. To receive the previously
memorised station, make sure that the preset
number button is pressed only momentarily.
FM1 tFM2 tAM tFM1
FM1 tFM2 tAM tFM1
A MEM
TUNER
A MEM
TUNER
Other Functions
Adjusting the sound
characteristics
1Select the item you want to adjust by
pressing the
SOUND
button repeatedly.
BAS (bass) tTRE (treble) tBAL
(balance) tFAD (fader) tVOL (volume)
tBAS (bass)
2Adjust the selected item by pressing
either the or button.
Adjust within three seconds after selecting.
(After three seconds the button will again
serve as volume control button.)
Boosting the bass sound
—D-Bass
You can enjoy clear and powerful bass sounds.
The D-bass function boosts the low frequency
and high frequency signal with a sharper
curve than conventional bass boost.
You can hear the bass line more clearly even if
the vocal sound is the same volume. You can
emphasize and adjust the bass sound easily.
Press the
D-BASS
button repeatedly to
select the desired bass curve.
As the D-BASS number increases so does the
effect.
D-BASS 1 tD-BASS 2 tD-BASS 3 t
no display (cancel)
Note
The bass sound may distort at same volume. If the
bass sound distorts, select less effective bass curve.
Radio/Other Functions
Level
Frequency (Hz)

10
GB Fuse (10 A)
Attenuating the beep
tone
Press the
5
button while pressing
the
SOUND
button.
To reactivate the beep tone, press these buttons
once more.
Additional
Information
Maintenance
Fuse replacement
When replacing the fuse, be sure to use one
matching the amperage rating stated on the
fuse. If the fuse blows, check the power
connection and replace the fuse. If the fuse
blows again after replacement, there may be an
internal malfunction. In such a case, consult
your nearest Sony dealer.
Warning
Never use a fuse with an amperage rating
exceeding the one supplied with the unit as
this could damage the unit.

11
GB
Dismounting the unit
1Insert the supplied tool between the unit
and the frame, and rotate 90° to release
the hidden mounting spring. Repeat on
the opposite side and remove the frame.
2Insert a flathead screwdriver between
the bracket and mounting spring. Gently
pry the spring toward the unit while
pulling the unit out a little. Repeat on
the opposite side and remove the unit.
Other Functions/Additional Information
4 mm
10 mm
90°

12
GB
Cassette player section
Tape track 4-track 2-channel stereo
Wow and flutter 0.13 % (WRMS)
Frequency response 30 –15,000 Hz
Signal-to- noise ratio 55 dB
Tuner section
FM
Tuning range 87.5 –108.0 MHz
Antenna terminal External aerial connector
Intermediate frequency 10.7 MHz
Usable sensitivity 9 dBf
Selectivity 75 dB at 400 kHz
Signal-to-noise ratio 65 dB (stereo),
68 dB (mono)
Harmonic distortion at 1 kHz
0.7% (stereo),
0.4% (mono)
Separation 35 dB at 1 kHz
Frequency response 30 –15,000 Hz
AM
Tuning range 531 –1,602 kHz
Antenna terminal External aerial connector
Intermediate frequency 10.71 MHz/450 kHz
Sensitivity 30 µV
Power amplifier section
Outputs Speaker outputs
(sure seal connectors)
Speaker impedance 4 –8 ohms
Maximum power output 45 W ×4 (at 4 ohms)
General
Output lead Power aerial relay control
lead
Tone controls Bass ±8 dB at 100 Hz
Treble ±8 dB at 10 kHz
Power requirements 12 V DC car battery
(negative ground)
Dimensions Approx. 188 ×58 ×177 mm
(w/h/d) not incl.
projecting parts and
controls
Mounting dimension Approx. 182 ×53 ×163 mm
(w/h/d) not incl.
projecting parts and
controls
Mass Approx. 1.2 kg
Supplied accessories Parts for installation and
connections (1 set)
Design and specifications are subject to change
without notice.
Specifications

13
GB
Troubleshooting guide
The following checklist will assist in the correction of most problems which you may encounter with
your unit.
Before going through the checklist below, refer to the connection and operating procedures.
General
Cause/Solution
•Adjust the volume with the button.
•Set the fader control to the centre position for 2-speaker
systems.
Problem
No sound
Tape playback
Problem
The sound is distorted.
Cause/Solution
Contamination of the tape head. tClean the head.
Radio reception
Problem
Preset tuning is not possible.
The stations cannot be
received.
The sound is hampered by
noises.
Automatic tuning is not possible.
Cause/Solution
•Memorise the correct frequency.
•The broadcast is too weak.
Connect an power aerial control lead (blue) or accessory power
supply lead (red) to the power supply lead of a car’s aerial
booster.
(When your car has built-in FM/AM aerial in the rear/side glass
only.)
The broadcast is too weak. tUse the manual tuning.
Additional Information

14
GB

±≥
AR
WOU{≈ UuKF
tö≈Ë qK)« Íd% qOœ
Æp¹b “UN'UÐ UN UBð b w²« öJA*« `O×Bð w h×H« WLzU bŽU²Ý
ÆqOGA²«Ë qOu²« «¡«dł≈ ŸułdUÐ r ¨ÁU½ √ h×H« WLzUIÐ dýU³ð Ê√ q³
WU
jdA« qOGA
uœ«d« ‰UI≈
q(«ØV«
• —e« WDÝ«uÐ uB« Èu² j³CÐ rÆ
•Æ5²ŽUL« ÂUEM nB²M*« l{Ë vKŽ XH<UÐ rJײ« ÕU²H l{uÐ r
WKJA*«
u ô
WKJA*«
ÁuA uB«
q(«ØV«
«—c j¹dA« ”√—Î ÆTÆ”√d« nOEM²Ð r
WKJA*«
WMJ2 dO jC« WI*« WH«u*«
UD;« ‰UI« sJ1 ô
¡U{uC uB« guA r
WMJ2 dO WOzUIK« WH«u*«
q(«ØV«
•Æ`O×B« d²« kH×Ð r
•«bł WHOF{ Y³« …—Uý≈ÎÆ
v« ©dLŠ«® wULJ« —UO²« «b« pKÝ Ë« ©‚—“«® wü« wz«uNUÐ rJײ« pKÝ qOu²Ð r
Æ…—UOK wz«uN« —“«R* —UO²« «b« pKÝ
N− pð—UOÝ X½U «–«®Ò wz«uNÐ …e
FM/AM©ÆjI w³½U'«ØwHK)« ÃUłe« w wKš«
«bł WHOF{ Y³« …—Uý≈Î Æ
TÆW¹ËbO« WH«u*« Âb²Ý≈

±≤
AR
UH«u*«
XOUJ« qGA r
j¹dA« —Uu¹dO²Ý≈ ÊUðUM ≤ «—U ¥ nOb«Ë ËUH²« • ∞[±≥(WRMS)
d²« WÐU−²Ý≈eðd¼ ±µ∞∞∞ ≠ ≥∞ ZO−C« …—Uý≈ W³½q³O¹ µµ
n«u*« r
Â≈ ·√ WuFM WH«u*« ‚UD½eðd¼ UGO ±∞∏[∞ ≠ ∏∑[µ wz«uN« ·dÞwł—U)« wz«uN« qu jÝu²*« d²«eðd¼UGO ±∞[∑ … UH²*« WOÝU(«·« q³O¹ π WOzUI²½ù«eðd¼uKO ¥∞∞ bMŽ q³O¹ ∑µ ZO−C« …—Uý≈ W³½¨©u¹dO²Ý≈® q³O¹ ∂µ
©Í UŠ√® q³O¹ ∂∏
eðd¼uKO ± bMŽ WOI«u²« WLGM« n¹d%
¨©u¹dO²Ý≈® • ∞[∑
©Í UŠ√® • ∞[¥ ‰eF«eðd¼uKO ± bMŽ q³O¹ ≥µ d²« WÐU−²Ý√eðd¼ ±µ∞∞∞ ≠ ≥∞
Â≈ t√ WuAM WH«u*« ‚UD½eðd¼uKO ±∂∞≤ ≠µ≥± wz«uN« ·dÞwł—Uš wz«u¼ qu jÝu²*« d²«eðd¼uKO ¥µ∞Øeðd¼UGO ±∞[∑± WOÝU(«XuËdJ¹U ≥∞
…—bI« rC r
Ãd)«WŽUL« Ãdš
©XÐUŁ qH öu® WŽUL« WËUFÂË√ ∏ ≠ ¥ vB_« …—bI« Ãdš©ÂË√ ¥ bMŽ® ¥ ™ «Ë ¥µ
WU
Ãd)« qO…—bI« qLF¹ wz«u¼ qŠd rJ% qO WLGM« ULJ% dON'«±eðd¼ ±∞∞ bMŽ q³O¹ ∏
WOUF« WI³D«±eðd¼uKO ±∞ bMŽ ∏ …—bI« U³KD²…—UOÝ W¹—UDÐ dýU³ —UOð ju ±≤
©w³KÝ i¹—Qð® UFÐ_«3 ±∑∑ ™ µ∏ ™ ±∏∏ w«uŠ
dOž ©oLF«ØŸUHð—ù«Ø÷dF«®
rJײ«Ë ◊UIÝù« ¡«eł√ WMLC² VOd²« UFÐ√3 ±∂≥ ™ µ≥ ™ ±∏≤ w«uŠ
dOž ©oLF«ØŸUHð—ù«Ø÷dF«®
rJײ«Ë ◊UIÝù« ¡«eł√ WMLC² WK²J«r− ±[≤ w«uŠ WId*« UI×K*«©rIÞ ±® öOu²«Ë VOd²« ¡«eł√
Æ—UFý≈ ÊËbÐ dOOG²K W{dŽ UH«u*«Ë rOLB²«

±±
AR
“UN'« pOJH
±rË ¨—Uù«Ë “UN'« 5 WId*« …«œ_« ‰UœS r
VOd« wd« dd W—œ π∞ ÁdËb
Ÿe«Ë fUF*« VU'« vK —«dJU r wH<«
—Uù«
≤5 ”√d« `D w«d pH ‰UœS r
ÁU&U wd« ld r VOd« wdË ”uI«
r ×UK V ¡UM√ p–Ë nDK “UN'«
“UN'« Ÿe«Ë fUF*« VU'« vK —«dJ
WOU{≈ UuKFØÈd√ nzUËØuœ«—
3 ±∞
W—œ π∞
3 ¥

±∞
AR
tOM« u nOH
åVOò
—e« jG{≈
5
—e« jG{ ¡UM√
SOUND
…d —«—“_« Ác¼ jG{≈ ¨åVOÐò tO³M²« u jOAMð … UŽù
ÆÈdš√
WOU{≈ UuKF
WUOB«
©“uOH«® WOzUdNJ« WULB« ‰«b≈
«– …bŠ«Ë «b²Ý≈ s bQð ¨WOzUÐdNJ« WULB« ‰«b³²Ý≈ bMŽ
Xd²Š≈ «–≈ ÆWULBK nOMB²« … b×Ë WIÐUD² W¹dO³√
ÆW}zUÐdNJ« ÂULB« ‰b³²Ý≈Ë …—bI« qOuð h×HÐ r ¨WULB«
«cN ¨‰«b³²Ýù« bFÐ Èdš√ …d WOzUÐdNJ« WULB« Xd²Š≈ «–≈
öKš „UM¼ ÊuJ¹ b t½QÐ wMF¹ÎqBð≈ ¨WU(« Ác¼ q¦ w ÆwKš« Æp¹b w½uÝ qOË »dQÐ
dc%
«bÐ√ rIð ôÎsŽ bz«“ wDu —UOF «– W}zUÐdN WUL «b²ÝUÐ
Æ“UN'« nK²¹ ·u ô≈Ë “UN'« «c¼ l WId*« WULB«
W}zUdNJ« WULB«
©dO√ ±∞®

π
AR
jI Wud*« UD;« kH
±ÆWud*« Wu*« —UOU r
≤vK UNMe w Vd w« WD;« WH«u0 r
ÆjC« WI*« WOLd« —«—“_«
≥jGCU dL≈Ë jG{≈WOLd« —«—“_« vK
s® Wud*« jC« WI*«
1
ATA
v≈
6
©√ v≈ 5OU …b*ÆåVOò tOM« WLG lL Ê
Æ÷dF« …cUMÐ ◊uGC*« j³C« o³*« rd« —“ dNE¹
± Â ·√ Włu® Włu q s UD× ∂ W¹UG s¹eð sJ1 FM1 Włu ¨ ≤ Â ·√
FM2 Â t¹√ WłuË ¨ AM j³C« WI³*« WOLd« —«—“_« vKŽ ©
Włu vKŽ WD× ±≤ s¹eð sJ1 ¨tOKŽ Æ„—UO²š« VŠ VOðd²Ð FM Ær²O ¨j³C« o³*« rd« —“ vKŽ Èdš√ WD× s¹eð XËUŠ «–
UIÐUÝ W½e<« WD;« ‰«b³²ÝÎÆ…b¹b'« …—U²<« WD;UÐ
WuH;« UD;« ‰UI≈
±ÆWud*« Wu*« —UOU r
≤vK jC« o*« rd« —“ UOE( jG{«
ÆUNMe w Vd w« WD;«
WEö
kHŠ r²O ¨5²O½UŁ s d¦_ j³C« o³*« rd« —“ jGCÐ XL «–
UOUŠ WK³I²*« WD;«ÎjG{ s bQð ¨UIÐUÝ WþuH;« WD×ô ‰U³I²Ýô Æ
ÆUOE( j³C« o³*« rd« —“
FM1 TAM TFM2 TFM1
A MEM
TUNER
Èd√ nzUË
eO2 j{uB« « ±od s tDC Ábd Íc« bM« —UOU r
—e« jG{
SOUND
Æ—dJ qJA
BAS ©dON'«® T TRE©WI³D« wUŽ u®
T BAL ©uB« Ê“«u® T FAD©uB« XH®
T VOL ©uB« Èu²® T BAS©dON'«®
≤s Í√ jG{ od s —U<« bM« jC r
s—e« Ë√ Æ
w½«uŁ WŁöŁ bFЮ Æ—UO²šù« bFÐ w½«uŁ WŁöŁ ‰öš j³CUÐ r
©ÆuB« Èu²0 rJײ« v rd« bðdOÝ
eFdON'« u e
wLd« dON'« ≠
ÂuIð WOLd« dON'« WHOþË ÆW¹u dONł «uQÐ l²L²« pMJ1
d¦« vM×M0 WOUF« œœd²« «—Uý«Ë WCHM*« «œœd²« e¹eF²Ð
ÆÍbOKI²« dON'« e¹eFð sŽ …bŠ
u ÊU «–« v²Š UŠu{Ë d¦« dON'« jš ŸULÝ p½UJSÐ
Èu² fHMÐ »dD*«u j³{Ë e¹eFð p½UJSÐ ÆuB« ÆWuNÐ dON'«
—e« jG{«
D-BASS
dON'« vMM —UOô «—«dJ Æ»ud*«
wLd« dON'« r— œ«œe¹ YOŠD- BASSÆdOŁQ²« pc UC¹«Ë
D-BASS 1 T D-BASS 2 T D-BASS 3 T
©¡UG ® ÷dŽ błu¹ ô
WEö
u »dD{« «–« ÆuB« Èu² fHMÐ dON'« u »dDC¹ b
ÆdOŁQð q« dONł vM×M —UO²šUÐ r ¨dON'«
Èd√ nzUËØuœ«—
A MEM
TUNER
FM1 TAM TFM2 TFM1
0dB
D-BASS 3
D-BASS 2
D-BASS 1 D-BASS 3
D-BASS 2
D-BASS 1
Èu*«
©ed® œœd«
