Sony XR-1800 User manual
MICROFILM
SERVICE MANUAL
AEP Model
UK Model
E Model
XR-1800
East European Model
XR-1803
Saudi Arabia Model
XR-1804
Model Name Using Similar Mechanism NEW
Tape Transport Mechanism Type MG-36SZ9-32
SPECIFICATIONS
XR-1800/1803/1804
Photo: XR-1804
– Continued on next page –
XR-1800: AEP, UK Model/XR-1803
FM/MW/LW CASSETTE CAR STEREO
XR-1800: E Model
FM/AM CASSETTE CAR STEREO
XR-1804
FM/MW/SW CASSETTE CAR STEREO
